Effective Remediation of Gun Propellant Residues in Surface GROUPE DE SOUTIEN DE LA 5 e DIV CA Soils Using Commercially Available Asphalt Heaters 5 TH CDN DIV SUPPORT GROUP Presenter: Kelsey Keys Connell 5CDSG Environmental Coordinator Guy

slide-1
SLIDE 1

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Guy Ampleman, Sonia Thiboutot & Michel Kervarec

DRDC – Valcartier/Weapon Systems Sheldon Downe 5CDSG Chief of Environmental Services Branch

Effective Remediation of Gun Propellant Residues in Surface Soils Using Commercially Available Asphalt Heaters

Presenter: Kelsey Keys Connell 5CDSG Environmental Coordinator

UNCLASSIFIED

NOTICE (U) (U) This document has been reviewed and DOES NOT ¡CONTAIN ¡controlled ¡ goods.

slide-2
SLIDE 2

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Outline

Background Objective Trials and Technologies Results Next Steps Questions

2

The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.
slide-3
SLIDE 3

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.

5th CDSB Gagetown

slide-4
SLIDE 4

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

5CDSB Gagetown RTA

Training Area: 1,100 Sq Km2 Canada’s second largest military training area Centre of Excellence for Army Training

slide-5
SLIDE 5

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

slide-6
SLIDE 6

6

The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.

FIRING POSITIONS WELLINGTON RANGE

slide-7
SLIDE 7

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again. The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.

84mm

  • High deposition rate of Nitrocellulose(NC) /

Nitroglycerin(NG) based propellant

  • High NG concentrations behind firing positions
  • NC is highly insoluble and resilient
  • After 25 years of inactivity, still over 4000 ppm in surface soils

Anti-Tank Firing Background

M72

slide-8
SLIDE 8

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Health and Safety Risk

  • Surface soil ignition causing fire upon discharge
  • f weapons
  • Fire could trigger detonation of stockpiled

munitions

  • Inhalation of NG leads to strong headaches

8

slide-9
SLIDE 9

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Objective

  • The objective of this trial was to establish

if NG concentrations in soil at firing points could be reduced using high heat technology

9

slide-10
SLIDE 10

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Option analysis for remediation

  • NC matrix highly water insoluble, prevents the use of

bioremediation

  • NC resistance prevents the use of chemical reduction,

hydrolysis or oxidation

  • Ex-situ treatment using soil stabilization (STABLEX) limited by

the high concentrations of energetic materials (limit of 5000 mg/kg)

  • Contamination concentrated at surface, in the first 10-15 cm
  • Incineration was selected as the preferred option as NG

destruction temperature is around 200oC

slide-11
SLIDE 11

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Burning Technologies

  • In-situ technology using solvent
  • Trials ran from 2009-2011 by Isabelle Poulin from DRDC
  • Two drawbacks:

– Too expensive for large scale deployment – Temperature not high enough to burn NG in subsurface

11

The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.
slide-12
SLIDE 12

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Direct Flame Burning

  • Hand-held propane burner delivering heat as a direct flame
  • Trial conducted at Carpiquet, Quebec the summer of 2013
  • Drawbacks

– Time consuming, not user friendly – Difficult to manage for large scale deployment – Temperatures not sufficient to burn NG completely at the surface – Insufficient heat penetration did not allow burning of NG in sub-surface

slide-13
SLIDE 13

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Asphalt Heating Technology

  • Portable infrared heater uses a radiant blue flame
  • Tested in two trials conducted in 2013 and 2014
  • First trial performed with a IR-Proheater single at two locations

at Wellington Range firing positions

slide-14
SLIDE 14

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

2013 Trial Results

  • After 15 minutes exposure: NG surface soil concentrations

decreased from 1960 to 1650 mg/kg for 17% reduction

  • After 30 minutes exposure: NG surface soil concentrations

decreased from 310 to 260 mg/kg for 14% reduction

  • Average of 15% reduction was achieved for both trials
slide-15
SLIDE 15

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

2014 Trial

  • Performed in September 2014 using a larger heater (Asphalt Reheat

System – Manta Ray EXT)

  • Probes were used to measure the temperature at different depths down

to 25 cms

The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file
  • again. If the red x still appears, you may have to delete the image and then insert it again.
The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again. The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file
  • again. If the red x still appears, you may have to delete the image and then insert it again.
The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.
slide-16
SLIDE 16

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Manta Ray EXT Trailer by ARS

The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again. The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been
  • corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then
insert it again.
slide-17
SLIDE 17

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Sample locations

  • Location A:

– Sampled prior to heating – Heating period of 30 minutes – resampled – Re-heating for another 30 minutes and re-sampled

  • Location B:

– Sampled prior to heating – Heating period of 60 minutes – resampled – Re-heating for 60 minutes, re-sampled including sub-surface

  • Location C:

– Sampled prior to heating – Heating period of 240 minutes – Resampled the surface

17

slide-18
SLIDE 18

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Results – 30+30 Minutes

  • After 30 minutes of heating, temperatures reach 340oC
  • After a cooling period plus an additional heating time
  • f 30 minutes, temperatures reach 425oC
The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. If the red x still appears, you may have to delete the image and then insert it again.
slide-19
SLIDE 19

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Results 60+60 Minutes Heating

slide-20
SLIDE 20

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

After Heating

slide-21
SLIDE 21

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Following 4 hours of Heating

  • Visual observation of soil drying down to a depth of

15 cm

slide-22
SLIDE 22

2014 Results

NG Concentrations

Location A Location B Location C Before 9,300 mg/kg 2,500 mg/kg 13,000 mg/kg Heating Time 30 minutes 30 + 30 minutes 60 minutes 60 + 60 minutes 240 minutes After 1,000 mg/kg ND ND ND ND After sub- surface 0-15 cm ___ ___ ___ ND ___ After sub- surface 15-30 cm ___ ___ ___ 75 mg/kg ___

ND=Non Detect

slide-23
SLIDE 23

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Conclusions

  • Portable infrared heating technology successfully reduced NG

concentrations in surface soils.

  • Maximum surface soil temperatures achieved: 470 C°
  • Complete degradation of NG in surface soils after one hour.
  • Technology easy to deploy, very efficient at heating soils down

to 15 cm, cost effective.

  • This technology has potential to be used as a remedial tool for

anti-tank range firing points, but also at sites containing single, double or triple base propellants (Demo Sites).

  • Not appropriated for gun propellants (2,4-DNT based).
slide-24
SLIDE 24

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Way Ahead

  • Additional trials will be conducted to establish specific

heating times, including subsurface sampling for each trial (before and after)

  • Trials will be conducted in other soil types
  • Further investigation into this technology will be undertaken

this coming summer for other sites

slide-25
SLIDE 25

5TH CDN DIV SUPPORT GROUP GROUPE DE SOUTIEN DE LA 5e DIV CA

Questions?

25
