Financing Sustainable Water: Effective Rate Modeling in an Uncertain World

AWE Sales Forecasting and Rate Model

Why a New Rate Model?

Typical water rate models assume that future sales are known with certainty, and do not respond to price, weather, the economy, or supply shortages—that is to say, not the world we live in.

 The AWE Sales Forecasting and Rate

Model addresses this deficiency:

• Customer Consumption Variability—weather,

drought/shortage, or external shock

• Demand Response—Predicting future block sales

(volume and revenue) with empirical price elasticity's

• Drought Pricing—Contingency planning for revenue

neutrality

• Probability Management—Risk theoretic simulation
• f revenue risks
• Fiscal Sustainability—Sales forecasting over a 5 Year

Time Horizon

• Affordability—Can customers afford water service?

WHERE MODEL FITS INTO RATE SETTING PROCESS

Rate Design Cost Allocation Cost of Service/Revenue Requirements Capital Planning

Model Useful Here Model Does Not Do These Things

Modular Design

 Rate Design Module  Revenue Simulation

Module

Model Setup

Model Setup

Rate Design Module

Questions the Rate Design Module Can Address

 What effect would increasing the rate in our top tier by 15%

have on water demand?

 Will shifting to seasonal rates cause overall water use to

increase or decrease?

 What block rate design could allow us to preserve our

current level of revenue while reducing overall demand?

 What proportion of customer bills will increase (or

decrease) under our proposed rates when compared to our current rates?

 How should we adjust our rates to support our water

demand management objectives during water shortages?

What Rate Designs Can Be Modeled?

 Rate Designs

• Uniform
• Seasonal
• Block
• Seasonal Block

 Up to 5 blocks  Can vary rates and blocks by customer class  Up to six customer classes

What Data is Needed to Use It?

 Bill Tabulations from Billing System Data

• By Class
• By Season (Off-Peak, Peak)

 Follows AWWA M1 Bill Tabulation

Methodology

 Allocating Bills to Seasons

• Easy when bills are rendered monthly
• Bit harder when bills are rendered bi-monthly or

quarterly

Bill Tabulation Screenshot

Rate Design Table

Block # Block Switch Point Rate for Block Block 1 10 $2.50 Block 2 20 $3.00 Block 3 $3.75 Block 4 $3.75 Block 5 $3.75

Rate for first 10 units Rate for next 10 units Rate for units in excess of 20

Copy rate in last block to unused blocks

Rate Design Screenshot

• 2. Specify rates for each Customer Class in the tables below.

Save/Load Rates button Use the tables below to specify the Current and Proposed rates for each Customer Class. You can specify uniform, block, seasonal, and seasonal block rates. Uniform and Uniform Seasonal Designs: Enter the same rate for all five blocks. If you want the uniform rate to vary by season, set a different uniform rate for each season. Block and Seasonal Block Designs: Enter the blocks and rates for each block level. You can specify up to 5 blocks. If you want fewer blocks than 5 -- say 3 -- then enter the same rate and block information for Block 4 and Block 5 that you did for Block 3. If you want seasonal block rates, you can specify different blocks and/or rates for each season. Mixed Designs: You can vary the rate design by Customer Class and season. For example, you can specify a block rate for the single family residential class and uniform rates for all

• ther classes. Or you can specify a uniform rate for one season and a block rate for the other.

Rate Performance by Customer Class Single Family Off Peak Season Peak Season Annual Sales Volume Current Rates Proposed Rates Current Rates Proposed Rates Current Proposed % Change Block Rate Block Rate Block Rate Block Rate CCF 9,069,061 8,913,705

• 1.7%

(CCF) ($/CCF) (CCF) ($/CCF) (CCF) ($/CCF) (CCF) ($/CCF) Block 1 5 $3.00 5 $2.50 5 $3.00 5 $3.75 Annual Revenue (Thou. $) Block 2 10 $3.00 10 $2.50 10 $3.00 10 $3.75 Current Proposed % Change Block 3 15 $3.00 15 $2.50 15 $3.00 15 $3.75 Service $12,263 $12,263 0.0% Block 4 15 $3.00 15 $2.50 15 $3.00 15 $3.75 Volume $27,207 $27,744 2.0% Block 5 15 $3.00 15 $2.50 15 $3.00 15 $3.75 Total $39,470 $40,007 1.4% Annual Sales Volume (% Change) Annual Service & Volume Revenue (% Change) Impact of Proposed Rates Relative to Current Rates

0.2 0.4 0.6 0.8 1 1.2

• 50%
• 30%
• 10%

10% 30% 50%

0.2 0.4 0.6 0.8 1 1.2

• 50%
• 30%
• 10%

10% 30% 50%

Save/Load Rates

Rate Design Tables Rate Performance Indicators

Bill Impacts Screenshot

• 3. Bill impacts of Proposed rates

Under your Proposed rates, the volume charge may go up for some customers and down or stay the same for others. The Bill Impacts Table shows the percentage of bills that will go down, stay the same, or go up -- and by how much. Charts showing the distribution of bill impacts for each customer class are provided on the Bill Impacts worksheet. Affordability Index % Change in Average and Median Annual Water Service Cost by Customer Class Current Proposed Average Annual Water Service Cost Median Annual Water Service Cost Affordability index equals Customer Class Current Proposed % Change Current Proposed % Change the median annual water Single Family $777 $804 3.4% $650 $672 3.3% cost for the primary Multi Family $4,254 $4,294 0.9% $1,930 $1,942 0.6% residential customer class CII $3,323 $3,382 1.8% $1,481 $1,504 1.5% divided by median Landscape $5,599 $6,007 7.3% $2,503 $2,720 8.7% household income. Not in use Not in use Bill Impacts Table % of bills decreasing by No More Than % of bills increasing by Customer Class more than 20% 15 to 20% 10 to 15% 5 to 10% +/- 5% 5 to 10% 10 to 15% 15 to 20% more than 20% Single Family 0% 0% 21% 38% 9% 4% 17% 11% 0% Multi Family 0% 1% 38% 25% 4% 4% 18% 12% 0% CII 0% 0% 25% 20% 28% 7% 9% 10% 0% Landscape 0% 0% 26% 12% 33% 2% 6% 20% 0% Not in use Not in use

0.0% 1.0% 2.0% 3.0% 4.0% 5.0% 0.0% 1.0% 2.0% 3.0% 4.0% 5.0% 0% 10% 20% 30% 40% 50% more than 20% 15 to 20% 10 to 15% 5 to 10% 5 to 10% 10 to 15% 15 to 20% more than 20% Percent of Bills

Single Family Customer Class Bill Impact Histogram

% Decrease in Bill % Increasein Bill

No More Than +/- 5%

Avg and median bill impacts Bill Impact Histograms Affordability Indicator

Drought Rates

 Evaluate rate performance under water use

curtailment

 Up to 4 drought stages can be specified  Curtailment levels can vary by customer class  User can design rates “by hand”, OR  Use built-in calculator to find revenue-neutral

rates by drought stage

Specifying Curtailment Levels

• 1. Specify Curtailment Levels for Drought/Shortage Stages
• 1. Enter the Customer Class curtailment levels for each stage. If you have fewer than 4 stages, enter the last curtailment level in the unused stages. Stage 0 is the default No

Shortage condition. Do not modify the settings for this stage.

• 2. For each stage, enter the expected compliance rate. The compliance rate can vary by stage. For example, stages with voluntary curtailment may have lower compliance than

stages where curtailment is mandatory and enforced. The expected curtailment level for a stage is the product of the stage's curtailment level and the expected compliance rate. Drought/Shortage Stage Customer Class Curtailment Levels Table Expected Curtailment Customer Class Stage 0 Stage 1 Stage 2 Stage 3 Stage 4 Stage 0 Stage 1 Stage 2 Stage 3 Stage 4 Single Family 0% 10% 15% 20% 25% 0% 8% 12% 17% 21% Multi Family 0% 10% 15% 20% 25% 0% 8% 12% 17% 21% CII 0% 0% 10% 20% 25% 0% 0% 8% 17% 21% Landscape 0% 0% 10% 20% 25% 0% 0% 8% 17% 21% Not in use 0% 0% 0% 0% 0% 0% Not in use 0% 0% 0% 0% 0% 0% Enter Expected Compliance % 100% 80% 80% 85% 85%

Requested curtailment level by stage Expected compliance rate Expected curtailment

Designing Drought Rates

• 2. Rate Performance by Drought/Shortage Stage

The tables in this section hold two sets of rates. Your proposed rates are carried over from Step 3. These cannot be modified on this worksheet. They provide the point of reference for calculating the revenue impacts of drought stages. The Stage rates are the rates that would apply for a given drought/shortage stage. To see how your Proposed rates would perform in a drought stage, click the Reset Drought Stage Rates to Proposed Rates. This will copy your Proposed rates into the tables for the Stage Rates. You can then use the Select Drought Stage drop-down list to cycle through the drought stages and see how your sales revenue would be impacted by each stage. Impacts to annual sales volume and revenue for each Customer Class Select Drought Stage are summarized to the right of the rate tables. You can adjust the Stage Rates to see how your annual sales volume and revenue would respond. You can adjust the size or number of blocks as well as the rates for each block. You can use trial and error to find rates appropriate to each drought/shortage stage, or you can use Excel's goal-seek or solver functionality to do this. Section 3 provides a calculator that can quickly identify rates for a given drought/shortage stage that are revenue neutral. Rate Performance by Customer Class Single Family Off Peak Season Peak Season Annual Sales Volume Proposed Rates Stage 2 Rates Proposed Rates Stage 2 Rates Proposed Stage 2 % Change Block Rate Block Rate Block Rate Block Rate CCF 8,913,705 7,844,060

• 12.0%

(CCF) ($/CCF) (CCF) ($/CCF) (CCF) ($/CCF) (CCF) ($/CCF) Block 1 5 $2.50 5 $2.50 5 $3.75 5 $3.75 Annual Sales Revenue (Thou. $) Block 2 10 $2.50 10 $2.50 10 $3.75 10 $3.75 Proposed Stage 2 % Change Block 3 15 $2.50 15 $2.50 15 $3.75 15 $3.75 Service $12,263 $12,263 0.0% Block 4 15 $2.50 15 $2.50 15 $3.75 15 $3.75 Volume $27,744 $24,415

• 12.0%

Block 5 15 $2.50 15 $2.50 15 $3.75 15 $3.75 Total $40,007 $36,678

• 8.3%

Annual Sales Volume (% Change) Annual Service & Volume Revenue (% Change) Impact of Drought Stage Rates Relative to Proposed Rates

0.2 0.4 0.6 0.8 1 1.2

• 50%
• 30%
• 10%

10% 30% 50%

0.2 0.4 0.6 0.8 1 1.2

• 50%
• 30%
• 10%

10% 30% 50%

Rate Design Tables Rate Performance Indicators Drought Stage Selector

Drought Rate Calculator

• 3. Calculate Revenue Neutral Rates by Drought Stage

The revenue neutral rates calculator will quickly find a set of rates for a given drought/shortage stage that will generate the same revenue as your Proposed rates under a no shortage

• condition. There are four steps to using the calculator:
• 1. Choose the drought/shortage stage you want to calculate rates for.
• 2. Choose the method for calculating the rates. There are two choices. The first choice is to adjust your Proposed rates so that each customer class generates the same revenue

it would have generated under your Proposed rates assuming no use curtailment. This may result in significant differences across classes in the amount by which rates are

• adjusted. The second choice is to adjust your Proposed rates so that all classes when grouped together are revenue neutral. Rates across classes will be adjusted by the same

proportionate amount. Revenue neutrality may not hold for individual classes, but overall revenue will be neutral to the Proposed rates assuming no use curtailment.

• 3. Complete the Leave or Adjust Rate in Block table below. Choose Leave if you want the rate in the block to be the same as it is for your Proposed rates. Choose Adjust if you

want the calculator to adjust this rate. For example, if you only want to adjust the upper block rates, choose Leave for lower blocks and Adjust for upper blocks. If you have fewer than 5 blocks, set the unused blocks to the same setting used for your last block.

• 4. Make desired adjustments to the block widths for the Stage Rates in the Stage Rates tables above.
• 5. Click the Find Revenue Neutral Rates button.

Note: The calculator will overwrite the rates that are in the Stage Rates tables above. If you want to preserve these rates, save them as a rate scenario by clicking the Save/Load Rates button before using the calculator. Choose Drought Stage to Evaluate: Choose Method for Calculating Revenue Neutral Rates: Leave or Adjust Rate in Block? Class Block 1 Block 2 Block 3 Block 4 Block 5 Single Family Leave Adjust Adjust Adjust Adjust Multi Family Leave Adjust Adjust Adjust Adjust CII Leave Adjust Adjust Adjust Adjust Landscape Leave Adjust Adjust Adjust Adjust Not in use Leave Leave Leave Leave Leave Not in use Leave Leave Leave Leave Leave Find Revenue Neutral Rates Reset Drought Stage Rates to Proposed Rates Save/Load Rates

Limitations of the Rate Design Module

 Results only as good as the bill tabulation

data

 Can only evaluate how rates will perform ON

AVERAGE

 Does not provide insight into VARIABILITY of

performance

 That’s where the Revenue Simulation Module

steps in

Plans based on average assumptions are wrong on average -- Sam Savage, The Flaw of Averages

Revenue Simulation Module

Questions the Simulation Module Can Address

 What is the likelihood we will meet our one-

year, three-year, five-year revenue targets under our current or proposed rates?

 What is the chance our revenues will turn out

more than 15% below our current projections?

 What level of confidence can we have that our

sales will exceed our minimum planning estimates?

Flaw of Averages

Fact 1 – Planning for the future is rife with

uncertainties.

Fact 2 - Most people are not happy with Fact

1 and prefer to think of the future in terms of average outcomes.

Fact 3 - The “flaw of averages” states that

plans based on average assumptions are, on average, wrong.

• adapted from Savage (2012) Flaw of Averages

www.probabilitymanagment.org

Average Outcome vs. Likely Outcomes

The cyclist is safe

• n the average

path On average, the cyclist is de

dead.

Monthly Precipitation Data 2000-2014 Mean vs. Actual

0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 8.00 9.00 10.00 Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec

Temperature Data 2000 – 2014 Mean vs. Actual

50 55 60 65 70 75 80 85 90 95 100 Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec

Planning for the Future

• r

How Does It Work?

 The model focuses on three variables that are key

to short-run revenue performance:

• Weather (historical or synthetic)
• Growth (projected)
• Supply disruption/use curtailment (correlated to

weather)

 Two rate designs are simultaneously evaluated:

• Current rate (reference condition)
• Proposed rate

 Monte Carlo Simulation

Simulation Process

• 2. Calculate

model

• 3. Save result

(trial)

• 1. Draw model

variables from their probability distributions

A cycle constitutes 1 trial. In the Revenue Simulation Module, User can simulate 10, 100, 500, or 1000 trials.

Why Simulate?

 Alternatives to simulation are:

• Ignore uncertainty (a common strategy)
• Construct scenarios (also common)
• Both are problematic

 Simulation offers:

• More complete enumeration of possible
• utcomes
• Likelihood of particular outcomes

Simulation of Sales Revenue Distribution

Additional Data Needed for Module

 Weather

• Monthly Precipitation and Temperature data for

Service Area

• Historical (up to 90 years), OR
• Synthetic (for example, to simulate impact of climate change)
• Easy to get historical weather data for service areas –

Guidebook recommends several sources for weather data

 Customer Class Account Growth

• User specifies Low, Medium, High Account Growth

Rates, by Class

Weather Data Screenshot

Step 6: Enter Weather Data to be Used by Revenue Simulation Module On this worksheet you enter historical monthly precipitation and temperature data for your service area. The model will use this data to simulate how your demands may vary in response to deviations from normal weather patterns. You can enter up to a maximum of 90 years of historical data -- 1924-2013. Your historical data must be contiguous -- there cannot be gaps between years. It also must be complete across months. The model will ignore years where these conditions are not met. It is not required that you provide data for all 90 years. For example, if you only have data for the period 1982-2012 you can enter that in the approprate rows of the tables. To get reliable results, however, it is strongly recommended you enter at least 15 years of data. Consult the user guide for information on weather data sources. Go back to Revenue Simulation Module Worksheet Go forward to Step 7: Setup Simulation Worksheet

• 1. Set most recent year in your weather data

Enter the most recent year for which you are providing weather data. Most recent year: 2012

• 2. Enter Monthly Precipitation Totals (in)
• 3. Enter Monthly Average Maximum Air Temperature (degrees F)

Enter total monthly precipitation in inches for each year of weather data you have for your service area. Enter the monthly average daily maximum air temperature in degrees Fahrenheit for each year of weather data you have for your service area. Be sure you are entering average daily maximum air temperature and not average daily air temperature. Year Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec Year Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec 2012 2.91 1.18 4.17 2.56 0.00 0.04 0.00 0.00 0.00 0.87 4.09 5.83 2012 61.0 63.0 63.0 70.6 78.6 82.9 85.9 87.3 83.4 75.7 65.8 56.9 2011 1.18 4.06 6.26 0.28 0.79 1.93 0.00 0.00 0.00 0.91 1.22 0.08 2011 56.2 60.5 62.7 69.0 72.4 79.2 84.3 84.5 86.4 76.5 62.8 60.0 2010 5.71 2.80 1.93 3.82 1.06 0.00 0.00 0.00 0.00 0.83 1.85 5.71 2010 55.1 60.8 65.3 66.1 72.5 82.6 84.1 83.3 85.2 74.9 64.7 57.2 2009 1.02 6.34 2.36 1.22 0.71 0.00 0.00 0.00 0.16 3.74 0.59 2.40 2009 60.4 59.1 65.4 70.6 78.6 80.4 86.6 87.1 88.0 73.3 65.7 54.6 2008 7.13 1.85 0.12 0.08 0.00 0.00 0.00 0.00 0.00 0.04 2.36 1.81 2008 53.7 60.8 66.5 71.6 77.7 85.3 86.7 88.5 85.1 78.1 66.9 54.7 2007 0.43 3.70 0.24 0.59 0.28 0.00 0.00 0.00 0.12 1.22 0.75 2.40 2007 58.2 60.8 70.5 72.2 77.7 83.9 86.1 87.0 80.8 72.9 67.4 55.9 2006 2.24 1.97 6.26 4.25 1.02 0.00 0.00 0.00 0.00 0.12 1.42 2.95 2006 58.5 63.2 59.3 66.0 77.8 84.9 91.8 83.9 83.0 74.0 64.2 57.9 2005 4.33 3.31 2.60 1.46 1.26 0.28 0.00 0.00 0.00 0.12 0.94 10.04 2005 52.7 61.3 67.0 68.8 74.9 78.7 89.7 87.2 80.1 75.6 67.8 58.8 2004 2.48 5.04 0.91 0.08 0.08 0.00 0.00 0.00 0.08 2.64 2.17 3.90 2004 55.1 59.7 74.0 75.0 77.9 83.2 85.9 87.0 86.7 73.1 62.2 56.8 2003 1.14 0.98 1.46 3.58 0.51 0.00 0.00 0.00 0.00 0.00 1.65 5.94 2003 59.2 61.5 67.6 64.9 76.6 83.3 91.1 86.3 86.6 81.5 61.7 56.6 2002 0.75 1.54 1.89 0.16 1.18 0.00 0.00 0.00 0.00 0.00 2.40 8.66 2002 55.0 63.0 64.6 69.5 76.1 84.0 87.5 86.1 86.1 76.2 66.9 58.1 2001 1.89 5.51 1.10 1.14 0.00 0.12 0.00 0.00 0.12 0.28 3.58 7.01 2001 57.0 59.2 69.1 67.9 85.9 87.2 84.0 86.4 82.1 78.7 65.9 55.7 2000 5.79 8.11 2.01 0.79 1.14 0.08 0.00 0.00 0.04 1.34 0.75 0.39 2000 58.8 60.0 66.5 72.9 76.9 84.5 82.5 86.1 84.3 73.1 61.0 59.3 1999 2.76 5.12 2.48 1.69 0.08 0.00 0.00 0.00 0.00 0.31 2.05 0.51 1999 55.3 58.5 60.8 69.1 73.0 80.7 83.2 83.3 82.8 79.3 66.4 61.2 1998 8.03 12.20 2.09 1.26 2.64 0.00 0.00 0.00 0.16 0.79 3.07 0.67 1998 56.3 57.6 64.9 67.5 67.3 76.5 85.4 88.9 82.6 73.8 62.3 55.3 1997 8.19 0.20 0.24 0.24 0.28 0.20 0.00 0.47 0.00 0.79 5.47 2.56 1997 56.0 63.4 69.9 73.1 82.6 83.0 86.5 84.6 86.1 75.2 65.5 56.5 1996 5.28 5.94 2.44 1.81 1.77 0.00 0.00 0.00 0.00 0.91 2.72 6.89 1996 57.9 62.1 67.1 72.9 77.5 84.3 89.5 88.9 82.1 75.5 65.1 59.0 1995 9.84 0.20 8.62 1.06 1.22 1.18 0.00 0.00 0.00 0.00 0.00 6.77 1995 57.1 61.3 62.2 68.3 71.7 79.9 86.2 87.7 83.8 79.2 71.2 59.9 1994 1.77 3.94 0.20 0.87 1.61 0.00 0.00 0.00 0.00 0.67 5.91 2.48 1994 58.2 58.4 68.4 70.9 74.1 83.4 84.4 87.0 82.4 75.3 58.0 53.0 1993 8.46 4.25 2.13 0.59 0.55 0.39 0.00 0.00 0.00 0.31 2.52 2.36 1993 54.8 58.7 67.2 69.9 75.8 84.6 85.7 86.6 84.1 76.8 65.3 55.0 1992 1.38 5.94 3.11 0.31 0.00 0.28 0.00 0.00 0.00 1.38 0.16 6.02 1992 52.8 63.7 65.7 74.8 81.9 80.8 85.7 88.8 84.9 79.1 66.6 54.2

Can enter up to 90 yrs. Need at least

• 15. More is better than less.

Can modify historical weather for future climate change if desired.

Calculation of Weather Effects

 Based on CUWCC GPCD Weather Normalization

Methodology and Empirical Model

 Accounts for

• Seasonal Shape of Demand
• Relative Importance of (weather sensitive) Outdoor Use

 Monthly effects formed into weighted-average

seasonal effect

 Weighting accounts for:

• Monthly contribution to total seasonal use
• Strength of monthly weather effect on total seasonal use

 Weather effect coefficients can be modified by user

Uncertain Account Growth

 Can simulate with or without growth uncertainty

• No Growth
• Certain Growth
• Uncertain Growth

 If Uncertain Growth, then Low, Medium, High

Growth Rates transformed into probability distribution

• Normal
• Triangular
• Uniform

 User specifies which distribution to use

Water Use Curtailments

 Three Choices

• Exclude from simulation
• Associate with historical weather (preferred

method)

• Specify likelihood

Associate Drought Stage with Historical Weather

• 3. Enter Monthly Average Maximum Air Temperature (degrees F)
• 4. Enter Drought Shortage Stage

Enter the monthly average daily maximum air temperature in degrees Fahrenheit for each year of weather data you have for your (Optional) For each hydrologic year you can select what drought/shortage stage service area. Be sure you are entering average daily maximum air temperature and not average daily air temperature. would have applied given your current system supplies and customer demands. You can then have the model use this information when it simulates water sales. This is explained further in Step 5 Setup Simulation. Year Jan Feb Mar Apr May Jun Jul Aug Sep Oct Nov Dec Stage Index 2012 61.0 63.0 63.0 70.6 78.6 82.9 85.9 87.3 83.4 75.7 65.8 56.9 Stage 0 2011 56.2 60.5 62.7 69.0 72.4 79.2 84.3 84.5 86.4 76.5 62.8 60.0 Stage 0 2010 55.1 60.8 65.3 66.1 72.5 82.6 84.1 83.3 85.2 74.9 64.7 57.2 Stage 0 2009 60.4 59.1 65.4 70.6 78.6 80.4 86.6 87.1 88.0 73.3 65.7 54.6 Stage 2 2 2008 53.7 60.8 66.5 71.6 77.7 85.3 86.7 88.5 85.1 78.1 66.9 54.7 Stage 0 2007 58.2 60.8 70.5 72.2 77.7 83.9 86.1 87.0 80.8 72.9 67.4 55.9 Stage 0 2006 58.5 63.2 59.3 66.0 77.8 84.9 91.8 83.9 83.0 74.0 64.2 57.9 Stage 0 2005 52.7 61.3 67.0 68.8 74.9 78.7 89.7 87.2 80.1 75.6 67.8 58.8 Stage 0 2004 55.1 59.7 74.0 75.0 77.9 83.2 85.9 87.0 86.7 73.1 62.2 56.8 Stage 0 2003 59.2 61.5 67.6 64.9 76.6 83.3 91.1 86.3 86.6 81.5 61.7 56.6 Stage 0 2002 55.0 63.0 64.6 69.5 76.1 84.0 87.5 86.1 86.1 76.2 66.9 58.1 Stage 0 2001 57.0 59.2 69.1 67.9 85.9 87.2 84.0 86.4 82.1 78.7 65.9 55.7 Stage 1 1 2000 58.8 60.0 66.5 72.9 76.9 84.5 82.5 86.1 84.3 73.1 61.0 59.3 Stage 0 1999 55.3 58.5 60.8 69.1 73.0 80.7 83.2 83.3 82.8 79.3 66.4 61.2 Stage 0 1998 56.3 57.6 64.9 67.5 67.3 76.5 85.4 88.9 82.6 73.8 62.3 55.3 Stage 0 1997 56.0 63.4 69.9 73.1 82.6 83.0 86.5 84.6 86.1 75.2 65.5 56.5 Stage 0 1996 57.9 62.1 67.1 72.9 77.5 84.3 89.5 88.9 82.1 75.5 65.1 59.0 Stage 0 1995 57.1 61.3 62.2 68.3 71.7 79.9 86.2 87.7 83.8 79.2 71.2 59.9 Stage 0 1994 58.2 58.4 68.4 70.9 74.1 83.4 84.4 87.0 82.4 75.3 58.0 53.0 Stage 0 1993 54.8 58.7 67.2 69.9 75.8 84.6 85.7 86.6 84.1 76.8 65.3 55.0 Stage 0 1992 52.8 63.7 65.7 74.8 81.9 80.8 85.7 88.8 84.9 79.1 66.6 54.2 Stage 0 1991 57.8 65.3 59.6 68.5 72.7 77.9 85.1 82.0 84.4 80.6 67.6 57.1 Stage 4 4 1990 57.0 57.8 65.4 73.3 74.6 81.8 85.8 84.7 83.3 79.2 65.9 53.9 Stage 3 3 1989 55.6 56.8 63.4 73.5 75.6 80.5 86.4 83.1 79.0 74.5 67.2 57.0 Stage 2 2 1988 56.2 66.0 70.1 70.9 74.6 81.3 89.2 84.5 83.1 75.7 62.6 57.1 Stage 1 1 1987 55.2 62.1 64.8 76.2 78.8 81.5 80.9 83.9 82.6 77.7 63.6 55.2 Stage 0

Drought Stage association table Preferred Method

Specify Drought Stage Likelihood

Choose Method for Simulating Impact of Droughts/Shortages on Sales Volumes and Revenues: Drought Stage Probabilities Table Table Instructions: For each stage, enter the likelihood of occurrence. Likelihood of Cumulative For example, if historically your system has had no water use Drought Stage Occurrence Probability curtailments in 90% of years, you would enter 90% for Stage 0. The Stage 0 90.00% 90.00% remaining 10% would then be distributed across the other stages Stage 1 5.00% 95.00% according to the likelihood of each stage's occurrence. The sum of the Stage 2 2.50% 97.50%

• ccurrence likelihoods must sum to 100%.

Stage 3 1.50% 99.00% Stage 4 1.00% 100.00% 100.00%

User specifies probability

• f occurrence

Secondary Method

Simulation Outputs

Summary Statistics

• 1. Simulation Summary Statistics

Summary statistics for the simulation are provided in the following tables. The average value shows the central tendency while the standard deviation indicates the degree of variability. The minimum and maximum values define the range of outcomes.

• ---- Results based on 1000 simulation trials -----

Under Current Rates Under Proposed Rates Sales Volume (CCF) Sales Volume (CCF) Year 1 Year 2 Year 3 Year 4 Year 5 Year 1 Year 2 Year 3 Year 4 Year 5 Avg 15,391,247 15,496,019 15,635,586 15,697,702 15,861,245 Avg 15,155,448 15,259,211 15,397,276 15,457,801 15,619,683 St Dev 841,193 894,240 880,139 935,512 900,860 St Dev 829,223 880,884 867,799 922,020 888,074 Min 12,254,361 12,309,867 12,375,362 12,440,635 12,474,137 Min 12,070,660 12,125,441 12,190,075 12,254,491 12,287,565 Max 16,200,382 16,344,414 16,520,316 16,657,595 16,843,932 Max 15,964,343 16,106,516 16,280,144 16,415,657 16,599,589 Sales Revenue (Thou. $) Sales Revenue (Thou. $) Year 1 Year 2 Year 3 Year 4 Year 5 Year 1 Year 2 Year 3 Year 4 Year 5 Avg $69,966 $70,430 $70,999 $71,338 $71,981 Avg $70,634 $71,096 $71,664 $72,016 $72,657 St Dev $2,524 $2,682 $2,645 $2,809 $2,706 St Dev $2,551 $2,719 $2,670 $2,842 $2,735 Min $60,555 $60,814 $61,121 $61,426 $61,581 Min $61,031 $61,292 $61,600 $61,908 $62,063 Max $72,393 $73,011 $73,767 $74,356 $75,157 Max $72,994 $73,573 $74,308 $75,010 $75,705

Simulation Distributions

• 2. Sales Volume and Revenue Distributions

The charts below show the frequency and cumulative distributions for simulated sales volume and revenue. The cumulative distributions (the dashed lines in the charts) show the likelihood of sales volume or revenue being above or below the corresponding value on the x-axis. The frequency distributions (the bars) show the likelihood that sales volume or revenue will fall between the value indicated on the x-axis and the value to its left. Use the drop-down to choose the forecast year to display: 5

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250

Cumulative % of Outcomes Frequency of Outcomes Water Sales (Thou. CCF)

Annual Sales Volume Simulation Distributions

Under Current Rates Under Proposed Rates 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 50 100 150 200 250

Cumulative % of Outcomes Frequency of Outcomes Sales Revenue (Thou. $)

Annual Service Charge and Sales Revenue Simulation Distributions

Under Current Rates Under Proposed Rates

User selects forecast year Water Sales Annual Revenue Used to Assess Revenue Risks

Confidence Intervals

• 3. Sales Volume and Revenue Confidence Intervals

A 95% confidence interval indicates the range of values such that 95% of all simulation outcomes fall within this interval. Similarly, for a 90% confidence interval, 90% of all simulation out- comes would fall within the interval. More generally, for an x% interval, x% of all simulation outcomes would fall within the interval. This means the probability that the outcome variable will take on a value in the indicated range is x%. The charts below show confidence intervals (by year) for sales volume and revenue under your Current and Proposed rates. You can use the drop-down list to select the desired confidence level for the intervals. As you select higher levels of confidence you will note the intervals widen to accommodate the broader range

• f potential outcomes.

Use drop-down to select confidence level for sales volume and revenue confidence intervals: 90%

12,000 12,500 13,000 13,500 14,000 14,500 15,000 15,500 16,000 16,500 17,000 Year 1 Year 2 Year 3 Year 4 Year 5 Water Sales Volume (Thou. CCF)

Current Rates Water Sales Volume: 90% Confidence Interval

12,000 12,500 13,000 13,500 14,000 14,500 15,000 15,500 16,000 16,500 17,000 Year 1 Year 2 Year 3 Year 4 Year 5 Water Sales Volume (Thou. CCF)

Proposed Rates Water Sales Volume: 90% Confidence Interval

$60,000 $62,000 $64,000 $66,000 $68,000 $70,000 $72,000 $74,000 $76,000 Year 1 Year 2 Year 3 Year 4 Year 5 Water Sales Revenue (Thou. $)

Current Rates Annual Revenue: 90% Confidence Interval

$60,000 $62,000 $64,000 $66,000 $68,000 $70,000 $72,000 $74,000 $76,000 Year 1 Year 2 Year 3 Year 4 Year 5 Water Sales Revenue (Thou. $)

Proposed Rates Annual Revenue: 90% Confidence Interval

User selects level of confidence for interval (50-95%)

Exceedence Probabilities

• 4. Determine Sales Revenue Exceedence Probability

The sales revenue exceedence probability gives the probability that sales revenue will equal or exceed a target revenue. Use the Target Cells below to see the likelihood of mee revenue target under your Current and Proposed rates. Under Current Rates Under Proposed Rates Target Amount (Thou. $) First Year Revenue $71,000 3-Year Cumulative Revenue $215,000 5-Year Cumulative Revenue $360,000

Year 1 Revenue

Target Exceedence Probability: 43%

Year 1 Revenue

Target Exceedence Probability: 66%

3-Yr Cum. Revenue

Target Exceedence Probability: 21%

3-Yr Cum. Revenue

Target Exceedence Probability: 52%

5-Yr Cum. Revenue

Target Exceedence Probability: 20%

5-Yr Cum. Revenue

Target Exceedence Probability: 61%

User sets revenue targets

Model calculates likelihood of meeting or exceeding target

Dynamic Step-Through Charts

• 5. Step Through the Simulation Trials

You can use the slider bar below the charts to step through each trial of the simulation. The charts display the simulated sales volume and revenue for each forecast year along with the averages across all the trials. The x-axis labels will show the weather year sequence used in the trial. Click the Animate Simulation button to cycle through all the simulations dynamically. If you want to see even more detail, you can access all the simulation output on the Simulation Output worksheet.

Simulation Trial #: 1

Click the Animate Simulation Button to cycle You can type a trial # in the box below through all the simulation trials dynamically to see the results for a specific trial Simulation Trial Number: 1

12,000 12,500 13,000 13,500 14,000 14,500 15,000 15,500 16,000 16,500 17,000 2000 2001 2002 2003 2004

• Thou. CCF

Weather Year Sequence

Annual Sales Volume

Current Rates Proposed Rates Avg Current Avg Proposed $60,000 $62,000 $64,000 $66,000 $68,000 $70,000 $72,000 $74,000 $76,000 2000 2001 2002 2003 2004

• Thou. Dollars

Weather Year Sequence

Annual Service Charge and Sales Revenue

Current Rates Proposed Rates Avg Current Avg Proposed

Animate Simulation

Dynamic charts let user step through each simulation trial

Demo

 Model includes built-in demonstration data

and exercises:

• Model setup
• Bill tabulation
• Setting service charges
• Designing volume rates
• Drought rate adjustments
• Simulation
