Terzo workshop italiano su PRIvacy e SEcurity – “PRISE" – Roma 20 0ttobre 2008

Effective features for detecting Effective features for detecting IRC botnets IRC botnets

Claudio Mazzariello, Claudio Mazzariello, Carlo Sansone Carlo Sansone Dipartimento di Informatica e Sistemistica Dipartimento di Informatica e Sistemistica University of Napoli Federico II University of Napoli Federico II via Claudio 21, 80125 Napoli (Italy) via Claudio 21, 80125 Napoli (Italy) {claudio.mazzariello, carlo.sansone}@unina.it {claudio.mazzariello, carlo.sansone}@unina.it

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

2

Problem Statement Problem Statement

• Botnet

 A network of infected hosts, named bots, under the control

• f an operator named botmaster

 Control performed by using a Command & Control channel

• Centralized (e.g. IRC, HTTP, ...)
• Distributed (e.g. P2P...)

 Commands out of a quite large and flexible set can be issued by the botmaster to each bot

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

3

Motivation of this work Motivation of this work

• Botnets keep spreading
• Botnets are able to perform many malicious actions

 Spam  ID theft  Clickfraud (e.g. Google AdSense abuse)  Cracking  Malware spreading  DDoS  Traffic Sniffing  Keylogging  Polls/statistics manipulation  …

• Botnets involve economic interests

 More dangerous than older attack types

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

4

Contribution Contribution

• Definition of a model of normal and botnet-related IRC

channel usage

• Definition of an architecture exploiting such a model for

botnet detection

• IRC user behavior classification aimed at botnet detection

by means of pattern recognition techniques

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

5

Presentation outline Presentation outline

• An introduction to botnets
• Details on IRC botnets
• The proposed detection approach

 IRC user behavior model  Detection system reference architecture

• Experimental evaluation

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

6

Centralized botnet's lifecycle Centralized botnet's lifecycle

• bot-herder configures initial bot parameters

and C&C details

• register IP at DNS for rendezvous
• bot-herder launches or seeds new bot(s) -

bots spreading, botnet growing

 Vulnerability discovery and exploitation  Malicious code download  DNS lookup for rendezvous  Join the C&C  Receive commands from the

Botmaster

• losing bots (stasis), botnet not growing
• abandon botnet and sever traces
• unregister DDNS

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

7

Botnet Statistics Botnet Statistics

• 60% are IRC bots

 70% of all the bots connect to a single IRC server

• 57,000 Active Bots per day for the first 6 months of

2006 ( Symantec )

• 4.7 million distinct computers being actively used in

Botnets

• Most Botnets are managed by a single server ( up to

15,000 bots )

• Mocbot seized control of more than 7,700 machines

within 24 hours

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

8

Why IRC? Why IRC?

• Oldest and most popular IM

 Bots were commonly user by channel operator for management and monitoring purposes

• Not owned by anyone – public
• Defined in RFC 1459
• Text based
• Designed for both point-to-point and point-to-multipoint

communication

 one-to-one, or one-to-group chat

• flexible, open-source protocol
• Potentially able to manage a high number of clients
• Grants anonymity for the botmaster

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

9

Centralized C&C Centralized C&C

• Easier to manage and use
• Easier to disrupt
• How do the bots know where the C&C is?

Hardcoded IP based rendezvous

• easily uncovered
• C&C needs replacement after disruption
• All Bots need replacement

Domain names used for rendezvous

• DNS RR can be updated to current C&C IP
• Bots can dynamically point to the correct C&C IP

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

10

Reference framework Reference framework

• Port based application protocol detection
• RFC based IRC decoder
• Model = representative features



Each IRC channel is represented by a feature vector, representing its status



Feature vectors are updated at each event occurring in the corresponding IRC channel

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

11

Intuitions about IRC based botnets Intuitions about IRC based botnets

• Bursty channel activity

 After command is issued, bots may respond at once, then be quiet

• Limited vocabulary
• Sentence structure

 May resemble a shell command  The same recurring structure may be found in many sentences

• Disproportion between user and control activity in a channel
• “strange” words used for communication

 Disproportion of consonants and vowels in words used for chatting

• Language dependent
• Changes and structure of chat room topic
• Unusual nicknames

 Completely random OR  Unexpextedly regular

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

12

IRC channel features IRC channel features

• Users Number:

 total number of users in the channel

• Average words number:

 average number of unique words in a sentence

• Average/Variance of Channel Dictionary

Cardinality:

 Mean and variance of the vocabulary’s cardinality

• Unusual Nicknames*
• Equal Answers:

 number of sentences with a common

• rdered subset of words
• Control Commands Number:

 count of channel control commands issued

• Join Number:

 JOIN rate in the channel

• SetMode Number:

 SetMode rate in the channel

• Nickname Changes:

 count of nickname changes in a channel

• Ping Number:

 PING rate in the channel

• IRC Commands Number:

 overall IRC command rate

• Active Users Number:

 number of users active in the channel

*J. Goebel and T. Holz. Rishi: identify bot contaminated hosts by irc nickname evaluation. In HotBots’07: Proceedings of the first conference on First Workshop on Hot Topics in Understanding Botnets, pages 8–8, Berkeley, CA, USA, 2007. USENIX Association.

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

13

Experimental Setup Experimental Setup

• Data collection

 Botnet related traffic from the Georgia Institute of Technology network  Normal IRC chats logged from the University of Napoli network

• Three datasets

 50,000 samples (25,000 normal + 25,000 botnet-related)

• Small, evenly split

 149,999 samples (75,010 normal + 74,989 botnet-related)

• Large, evenly split

 165,000 samples (150,000 normal + 15,000 botnet-related)

• Large, more realistic distribution of t-uples
• Selected algorithms

 SVM (Support Vector Machine) – very “popular”  J48 (Decision Tree) – very “quick”

• Performance evaluation

 10-fold cross validation

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

14

Classification algorithms Classification algorithms

• SVM – Kernel based method

 Search for hyperplanes effectively separating data points  Support vectors for providing better prediction performance  Non-linearly separable data can be trasformed by means of a kernel function in a space more suitable for linear separability  Separation hyperplane search is performed in transformed space

r ρ x x′

φ(.)

φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( ) φ( )φ( ) Feature space Input space

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

15

Classification algorithms Classification algorithms

• J48 – Decision tree

 Each attribute of the data can be used to make a decision which splits the data-set into smaller subsets  The normalized information gain is measured  The attribute generating the highest normalized information gain is chosen  The algorithm is recursively applied to the subsets

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

16

Experimental results Experimental results

Algorithm SVM J48 Samples 50000 149999 165000 50000 149999 165000 False alarm Rate < 0.001 Missed detection rate

• Most representative features



Limited vocabulary cardinality



Limited sentence variability

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

17

Conclusions Conclusions

• Promising model for botnet activity detection
• Tested on “real” data

 Results hopefully valid in a general scenario

• Model works with both a very reliable and a very quick

classifier

• Effective classification performed on a per-tuple basis

 Botnet detection accuracy within strict performance boundaries

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

18

Future work Future work

• Feature selection for faster training and detection
• Exploitation of “pure” anomaly detection techniques

 Malicious traffic no longer necessary for training

• Further model refinement
• Further testing

 More data available on eterogeneous IRC servers

• Exploitation of state-of-the-art application layer protocol recognition

techniques  Blind protocol identification overcomes the limitations of port-based methods

• Perform classification on a per-channel basis

 Try to reduce the number of errors

• Start thinking about complementary solutions for encrypted IRC

sessions

Claudio Mazzariello, Carlo Sansone – Effective features for detecting IRC botnets

19

Thank you for your attention Thank you for your attention

Any questions?
