EchoPanel EchoPanel Acoustics 101 NRC = Noise Reduction Coefficient Noisy office/restaurant NRC measures how much sound is absorbed High-NRC Materials reduce the sound echoing within a room STC = Sound Transmission Coefficient Loud

SLIDE 1

SLIDE 2

EchoPanel

SLIDE 3

Acoustics 101

EchoPanel

NRC = Noise Reduction Coefficient Noisy office/restaurant NRC measures how much sound is absorbed High-NRC Materials reduce the sound echoing within a room STC = Sound Transmission Coefficient Loud Neighbors STC measures how much sound is blocked High-STC materials reduce sound transmitted from room to room

SLIDE 4

Acoustic Testing

EchoPanel

The Noise Reduction Coefficient (commonly abbreviated NRC) is a scalar representation of the amount

f sound energy absorbed

upon striking a particular surface. ASTM C423-90A

SLIDE 5

Acoustic Testing

EchoPanel

Octave Band Chart Octave Band Graph EchoPanel helps out in the human voice range, making it great for offices and restaurants

SLIDE 6

Custom Ceiling Kirei EchoPanel #500 Queensland Museum Australia

Acoustic Control, Beautifully

SLIDE 7

Start with this…

SLIDE 8

Dune Tile Wave Tile

Kirei EchoPanel Dune and Wave Tiles EchoPanel 7mm/12mm panels Kirei EchoPanel Geometry Tiles

Create these…

SLIDE 9

Retail Clothing Display Kirei Board

EchoPanel: Dramatic design possibilities plus effective sound control

SLIDE 10

EchoPanel Print “Hex” #444 EchoPanel Print “Ripple” #258

SLIDE 11

Printed

Tackable!

Custom

CNC Cut

SLIDE 12

Residential Cabinetry Doors Kirei Board Retail Display Cabinetry Kirei Board

Custom Furniture ( (Hidden sound control)

SLIDE 13

EchoPanel Ceilings

SLIDE 14

EchoPanel Geometry Tiles

SLIDE 15

Residential Feature Wall Kirei Board

Kirei EchoPanel Wave & Dune Tiles

SLIDE 16

SLIDE 17

EchoPanel Dune Tile EchoPanel Wave Tile EchoPanel Wave Tile

SLIDE 18

Dune/Wave Tile Installation:

4 way clip 2-way clip Edge clip

1. Establish a level line
2. Measure tiles to set clip position
3. Screw clips to wall
4. Pop in tiles!

SLIDE 19

Restaurant Fixture Curved Kirei Board Panels

108 151 273 908 579 500 444 442 362 258 542 551 295

EchoPanel Colorways

Frequency Ceremony Hex Ripple Puzzle

EchoPanel Prints

Colorways & Prints

SLIDE 20

Product Specifications

Geometry Tiles Nominal Size: .47” x 8.66” x .87” Weight: .49 lbs/SF Fire Rating: E84 Class C (Class A treatment available) Tiles come Qty. 10/box – each box covers 3.44 SF Budget pricing: $18/SF Dune Tiles

Tile Size: 1.97” x 19.68” x 19.68” Weight: .79 lbs/tile Material Thickness: .16” Fire Rating: E84 Class A Sound Absorption: ASTM C423-90A-NRC .60 Tiles come 9/box Budget pricing: $23/SF

Wave Tiles

Tile Size: 2.36” x 19.68” x 19.68” Weight: .79 lbs/tile Material Thickness: .16” Fire Rating: E84 Class A Sound Absorption: ASTM C423-90A-NRC .55 Tiles come 9/box Budget pricing: $23/SF

EchoPanel Nominal Size: ½” or ¼” x 48” x 96” Fire Rating: E84 Class C (Class A treatment available) Sound Absorption: ASTM C423-90A NRC .35-.75 depending on installation Budget pricing: $10-12/SF (12mm), $7-12/SF (7mm)
