Adapted from Computer Organization and Design, Patterson & Hennessy, UCB

ECE232: Hardware Organization and Design

Lecture 23: Associative Caches

ECE232: Associative Caches 2

Overview

• Last time: Direct mapped cache
• Pretty simple to understand
• Every memory block goes in only one place in the cache
• Somewhat limiting
• May cause a lot of the cache to be unused
• Idea!
• Why not be more flexible: data can go into more than one place
• Associative caches

ECE232: Associative Caches 3

Cache addressing

• How do you know if

something is in the cache? (Q1)

• If it is in the cache,

how to find it? (Q2)

• Traditional Memory
• Given an address, provide

the data (has address decoder)

• Associative Memory
• AKA “Content Addressable

Memory”

• Each line contain the

address (or part of it) and the data

Full/MSBs of Address Data

Tag Memory Cache To Processor From Processor Block X Block Y Block X

CPU

ECE232: Associative Caches 4

Cache Organization

• Fully-associative: any memory

location can be stored anywhere in the cache

• Cache location and memory

address are unrelated

• Direct-mapped: each memory

location maps onto exactly one cache entry

• Some of the memory address

bit are used to index the cache

• N-way set-associative: each

memory location can go into

• ne of N sets

MSBs of Address Data LSBs of Address

Tag

ECE232: Associative Caches 5

Direct mapped cache (assume 1 byte/Block)

• Cache Block 0 can be
• ccupied by data from
• Memory blocks

0, 4, 8, 12

• Cache Block 1 can be
• ccupied by data from
• Memory blocks

1, 5, 9, 13

• Cache Block 2 can be
• ccupied by data from
• Memory blocks

2, 6, 10, 14

• Cache Block 3 can be
• ccupied by data from
• Memory blocks

3, 7, 11, 15

4-Block Direct Mapped Cache

Memory

Cache Index

00002 01002 10002 11002

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 1 2 3

Block Index

ECE232: Associative Caches 6

Fully Associative Cache

00 10 00 01 10 00 10 10 00 11 10 00 tag Memory

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

Block Index

Memory block address

1 word

tag

• ffset

0110 0010 1110 1010

ECE232: Associative Caches 7

CPU Main Memory

Tag Data

data address

Fully Associative Cache: Block=1 Byte

ECE232: Associative Caches 8

Two-way Set Associative Cache

• Two direct-mapped caches operate in parallel
• Cache Index selects a “set” from the cache (set includes 2

blocks)

• The two tags in the set are compared in parallel
• Data is selected based on the tag result

Cache Data Cache Block 0 Cache Tag Valid

: : :

Cache Data Cache Block 0 Cache Tag Valid

: : :

Cache Index

Mux

1 Sel1 Sel0

Cache Block Compare

Tag

Compare OR

Hit Tag Set

ECE232: Associative Caches 9

4-way Set Associative Cache

• Allow block anywhere in a set
• Advantages:
• Better hit rate
• Disadvantage:
• More tag bits
• More hardware
• Higher access time

A Four-Way Set-Associative Cache, Block size = 4 bytes

Address 22 8 V Tag Index 1 2 253 254 255 Data V Tag Data V Tag Data V Tag Data 32 22 4-to-1 multiplexor Hit Data 1 2 3 8 9 10 11 12 30 31

ECE232: Associative Caches 10

Set Associative Cache - addressing

TAG INDEX/Set # OFFSET

Tag to check if have correct block anywhere in set Index to select a set in cache Byte offset

ECE232: Associative Caches 11

Associative Caches

• Fully associative
• Allow a given block to go in any cache entry
• Requires all entries to be searched at once
• Comparator per entry (expensive)
• n-way set associative
• Each set contains n entries
• Block number determines which set
• (Block number) modulo (#Sets in cache)
• Search all entries in a given set at once
• n comparators (less expensive)

ECE232: Associative Caches 12

Spectrum of Associativity

• For a cache with 8 entries

ECE232: Associative Caches 13

How Much Associativity

• Increased associativity decreases miss rate
• But with diminishing returns
• Simulation of a system with 64KB

D-cache, 16-word blocks, SPEC2000

• 1-way: 10.3%
• 2-way: 8.6%
• 4-way: 8.3%
• 8-way: 8.1%

ECE232: Associative Caches 14

Set Associative Cache Organization

ECE232: Associative Caches 15

Types of Cache Misses (for 3 organizations)

• Compulsory (cold start): location has never been accessed -

first access to a block not in the cache

• Capacity: since the cache cannot contain all the blocks of a

program, some blocks will be replaced and later retrieved

• Conflict: when too many blocks try to load into the same set,

some blocks will be replaced and later retrieved

ECE232: Associative Caches 16

Cache Design Decisions

• For a given cache size
• Block (Line) size
• Number of Blocks (Lines)
• How is the cache organized
• Write policy
• Replacement Strategy
• Increase cache size
• More Blocks (Lines)
• More lines == Higher hit rate
• Slower Memory
• As many as practical

ECE232: Associative Caches 17

Summary

• Today: Associative caches
• Provide more choices for block storage
• More expensive in terms of hardware
• Require comparators for tags
• Many caches are set associative
• Remember:
• Direct mapped = 1 way set associative
• Full associative = N way set associate (N is total blocks in cache)
