Earth's Energy Imbalance: Natural Variability and SST patterns Cristian Proistosescu JISAO, University of Washington The Earths Energy Imbalance and its implications Nov 15, 2018 Toulouse, France Collaborators: Yue Dong, Kyle Armour, Robb

slide-1
SLIDE 1

Earth's Energy Imbalance: Natural Variability and SST patterns

Cristian Proistosescu

JISAO, University of Washington The Earth’s Energy Imbalance and its implications Nov 15, 2018 Toulouse, France Collaborators: Yue Dong, Kyle Armour, Robb Wills, David Battisti - University of Washington Malte Stuecker - IBS, Pusan, South Korea

slide-2
SLIDE 2

λ = F − Q T ICS = F2×CO2 λ

Net feedback: Inferred Climate Sensitivity

Q

radiative forcing radiative response heat uptake

Energy Budget at TOA

Q = F + λT R(T) = λT F T

Energy budget and climate sensitivity

Gregory et al 2002

slide-3
SLIDE 3

λ = Fμ + Qμ Tμ Q = 0.71 W/m2

Central estimate based on historical anomalies since pre-industrial

F = 2.33 W/m2

  • 2005-2015 average

WCRP assessment; in prep

slide-4
SLIDE 4

λ = (Fμ+Fσ) − Qμ Tμ Q = 0.71 W/m2

Uncertainty in forcing leads to large uncertainty in inferred sensitivity

F = 2.33±0.5 W/m2

3.05 K (Forcing Only)

  • 2005-2015 average
slide-5
SLIDE 5

λ = (Fμ+Fσ) − (Qμ+Qσ) Tμ+Tσ

Additional uncertainty due to observation error is negligible (1/25)

Q = 0.71±0.1 W/m2 F = 2.33±0.5 W/m2

3.05 K (Forcing Only) 3.25 K (Forcing, EEI, Temp)

  • 2005-2015 average
  • Uncertainties add in quadrature
slide-6
SLIDE 6

λ = (Fμ+Fσ) + (Qμ−Qσ + Qvar) Tμ+Tσ + Tvar

3.05 K (Forcing Only) 3.25 K (Forcing, EEI, Temp)

Account for natural variability using decadal averages across CMIP5 piControl runs

3.28 K (Forcing, EEI, Temp +variability)

F = 2.33±0.5 W/m2 Q = 0.71±0.1±0.08 W/m2

  • 2005-2015 average
  • Uncertainties add in quadrature
slide-7
SLIDE 7
  • Uncertainty in forcing strongly dominates observational uncertainty

and natural variability (uncertainties add in quadrature)

  • Natural variability comes from models:
  • What is its structure?
  • Can we trust it?
slide-8
SLIDE 8

CMIP5 piControl variability

  • Variability in TOA associated with ENSO & PDO
  • On long time scales: very little additional

variability in TOA despite significant low frequency variability in TAS

TAS TOA

slide-9
SLIDE 9

CAM5 AMIP run with prescribed SST and Sea Ice (SIC)

  • Atmospheric concentrations (GHG, aerosols) fixed at 2000 level
  • Changes in EEI at TOA driven by changes in SST & SIC

Q = R = λT F = 0

(anomalous)

slide-10
SLIDE 10

CAM5 AMIP run SST [K]

Decompose TOA into mean response to global temperature changes + variability

Q = λ ⋅ T(t) + Qvar λ = < T > < Q > T(t)

slide-11
SLIDE 11

CAM5 AMIP run exhibits significant variability More outgoing radiation recently - more negative feedbacks

λ ⋅ T(t) Qvar T(t)

SST [K]

More Negative Feedback LOWER ICS

slide-12
SLIDE 12

Historical SSTs drive much higher interdecadal variability than the SSTs produced by coupled models

Qvar λ ⋅ T(t) Qvar

More Negative Feedback LOWER ICS

slide-13
SLIDE 13
  • Uncertainty in forcing strongly dominates observational uncertainty

and natural variability (uncertainties add in quadrature)

  • Natural variability comes from models:
  • What is its structure?
  • Can we trust it? - NO!
  • What causes decadal variability in EEI? (in AMIP runs at least?)
slide-14
SLIDE 14

137 fixedSST runs on CAM4

J = ∂R( ⃗ x 1) ∂SST( ⃗ x 2)

Green’s function approach: TOA radiative response to localized SST anomalies

(Dong, Proistosescu, Armour, Battisti, in prep) (Zhou, Zelinka, Klein 2017)

slide-15
SLIDE 15

Response to representative patches

  • S
  • Dong et al in prep
slide-16
SLIDE 16

Controlled by West Pacific Surface Temp Controlled by local warming

slide-17
SLIDE 17

Global radiative response to localized warming

∂R ∂T( ⃗ x )

(downward)

slide-18
SLIDE 18

Future warming pattern preferentially excites positive feedbacks

(downward)

  • Decreased outgoing radiation
  • More positive feedbacks
  • higher climate sensitivity
slide-19
SLIDE 19

Future warming pattern preferentially excites positive feedbacks

(downward) Feedback W/m2/K year Abrupt4xCO2

slide-20
SLIDE 20

Simulations

Probability

Historical

T2×CO2

Pattern effect explains why historical estimates of ECS are low with respect to long term GCM estimates

Feedback W/m2/K year Abrupt4xCO2

Proistosescu & Huybers 2017 Armour 2017 Andrews and Webb 2018

slide-21
SLIDE 21

Feedbacks increase with time in models, but decrease with time in AMIP runs

Feedback W/m2/K year Abrupt4xCO2

(with respect to pre-industrial level)

AMIP- Historical SSTs Feedback W/m2/K year

slide-22
SLIDE 22

Global radiative response to localized warming

∂R ∂T( ⃗ x )

(downward)

slide-23
SLIDE 23

Weight SST field by Green’s function, and take EOFs

Y = T( ⃗ x , t) ⋅ ∂R ∂T( ⃗ x )

slide-24
SLIDE 24

Two dominant EOFs: ENSO + extended warm pool warming

slide-25
SLIDE 25

Warm pool warming dominates decadal changes in TOA EEI

slide-26
SLIDE 26

Warm pool warming dominates decadal changes in TOA EEI EOF #1 Mean warming pattern

Constant feedback term Green’s function x EOF #1 Green’s function Reconstruction CAM5 output

slide-27
SLIDE 27

Coupled models do not generate sufficient decadal variability in warm pool temperatures

AMIP 1σ piControl 1σ

slide-28
SLIDE 28

Conclusions

  • Observational Uncertainty not a major contributor to ECS uncertainty
  • Do we trust uncertainty estimates?
  • Pattern effect: slowly evolving patterns of SST (multidecadal) are the major

source of uncertainty in linking EEI to ECS.

  • Feedbacks increase with time (higher ECS) in coupled models
  • Decrease with time in AMIP runs (historical ECS) due to relative Warm

Pool warming

  • Coupled models severely underestimate decadal scale variability in EEI
  • Associated with underestimation of West Pacific variability
  • Forced (aerosols?) /Unforced?
slide-29
SLIDE 29

SUPPLEMENTAL SLIDES

slide-30
SLIDE 30

Sanity Check: CAM5 (prescribed SST) reproduces CERES EBAF radiation over PDO switch: 2014:2017 - 2000:2014

CERES EBAF SW CERES EBAF LW CERES EBAF NET CESM1 AMIP LW CESM1 AMIP NET CESM1 AMIP SW W/m2

slide-31
SLIDE 31

T Q Background variability in atmospheric TAS and TOA

  • CAM5 AGCM control:
  • Simulations with climatological SSTs
  • White noise variability in TAS and TOA
slide-32
SLIDE 32

Background variability in atmospheric TAS and TOA + variability driven by changes in SSTs TAS TOA

  • CAM5 AGCM control:
  • Simulations with climatological SSTs
  • White noise variability in TAS and TOA
  • CESM1.2 control:
  • Additional variability in TOA associated with

ENSO & PDO type signals

  • On long time scales: very little additional

variability in TOA despite significant variability in TAS

slide-33
SLIDE 33

Background variability in atmospheric TAS and TOA + variability driven by changes in SSTs

  • CAM5 AGCM control:
  • Simulations with climatological SSTs
  • White noise variability in TAS and TOA
  • CESM1.2 control:
  • Additional variability in TOA associated with

ENSO & PDO type signals

  • On long time scales: very little additional

variability in TOA despite significant variability in TAS

  • CMIP5 piControl
  • Consistent picture

TAS TOA
