Stay Connected & Secure On-the-go

June 2008 Updated

• V. 062008

Dual-WAN 3G / ADSL2+ Router Series

Usage Suggestion

This presentation document containing competition information is ideally created for the purpose of pre-sell training to the audience of Billion’s sales representatives, authorized sales agents, authorized distributors, or multiple tiered re-sellers when pre-selling education is needed. The disclosure of this entire documentation to SOHO/SMB end- users is not encouraged.

Agenda

• What is 3G?
• Unique Selling Points
• Key Features
• Target Users and Channels
• User Benefits
• Hardware Specifications
• Application Diagrams & Network Connections
• Compatible 3G Data Cards / 3G USB Modems
• Quick Start & GUI Demonstration Sites
• Reviews and Honors

3G is the common name for third-generation digital mobile technology. It offers consistent services delivered via 3G/HSDPA, EDGE, or UMTS mobile telephony protocols. Compared to 1G (analog wireless technology) and 2G (digital radio wireless technology such as GPRS), 3G offers faster data transfer rates up to 14.4Mbps.

What is 3G?

Unique Selling Points

3G/ADSL for true always-on connectivity Mobility assured by 3G support Automatically switch between ADSL and 3G as needed Car power cable for ultimate portability (BiPAC 7300GX) VPN security (BiPAC 7402(G)X series)

Mobility, Security and Always Online Create Your Own Portable Hotspot!

Key Features Comparison

Model BiPAC 7300GX BiPAC 7402X BiPAC 7402GX V

• PC card slot for 3G data card

V

• V

V V

• V

V

• V

V V V V V V V V V Quality of Service V V V Supports IPTV application V V V Optional

• V

V Optional BiPAC 7402GXL ADSL2+ V USB port for 3G USB modem V VPN security

• Firewall security

V 12V car power cable Optional Wireless 802.11g V WPA-PSK/WPA2-PSK V Wi-Fi Protected Setup V

Home users Office users Event or meeting organizers Public transport operators: e.g. long-distance bus operators

Ideal users

Telco/ISP: e.g. Vodafone in UK Transit operator

Place & Target Channels

Target Users and Channels

Communication Flexibility via 3G/HSDPA

User Benefits I

• Enjoy the broadband Internet connection by inserting a 3G/HSDPA

PC card into its built-in PC Card (BiPAC 7300GX)

• The router allows you to connect a 3G USB modem to its built-in USB

port, enabling you to use a 3G/HSDPA, UMTS, EDGE, GPRS, or GSM Internet connection, makes downstream rates of up to 14.4Mbps* possible. (BiPAC 7402X series)

• With the increasing popularity of the 3G standard, communication via

the 3G/ADSL2+ router series are becoming more convenient and widely available Watching movies or downloading music on the road Accessing e-mail no matter where you are Sharing your Internet connection with others, no matter if you're in a meeting, or speeding across the country on a train

Note: * The 3G/HSDPA data rate is dependent on your local service provider and your 3G/HSDPA modem.

Always Online

User Benefits II

• Using ADSL2/2+ technology, you'll be able to enjoy high-speed

ADSL and broadband multimedia applications such as interactive gaming, video streaming and real-time audio.

• The integrated Annex M standard supports ADSL2/2+ for higher

upload speeds by doubling the upload data rate.

• Planned support for auto fail-over means that you'll be assured of a

constant Internet connection – in case your ADSL line fails, the router will connect via 3G to deliver uninterrupted connectivity.

• An integrated 802.11g Wireless Access Point offers quick yet easy

access with data encryption for added security. Wireless Protected Access (WPA-PSK/WPA2-PSK) and Wireless Encryption Protocol (WEP) support ensures high-level data protection and WLAN access

• control. (BiPAC 7402GX(L)/BiPAC 7300GX)
• The built-in Wireless Distribution System (WDS) repeater function

allows you to expand the wireless network without the need for using any wires.

• Rich firewall security features such as SPI, DoS attack prevention and

URL content filtering are integrated to provide unparalleled protection for Internet access.

User Benefits III

Double-layer Protection

Secure VPN connection

User Benefits IV

BiPAC 7402(G)X

• The router supports embedded IPSec VPN (Virtual Private

Network) protocols, allowing users to establish encrypted private connections of up to 16 simultaneous tunnels over the Internet.

• With a built-in DES/3DES VPN accelerator, the router enhances

IPSec VPN performance significantly and ensures that data is transmitted securely between two or more sites.

Physical Interface

• DSL: ADSL Port
• Ethernet: 4-port 10/100 Mbps auto MDI/MDI-X Switch
• WLAN: one 2 dBi detachable antenna (BiPAC 7402GX(L)/BiPAC 7300GX)
• 3G/HSDPA PC Card Slot: for a mobile broadband data card (BiPAC 7300GX)
• USB 2.0 supports 3G/HSDPA modem backup (BiPAC 7402X series)
• Console: the Ethernet port # 4 can be also connected to console
• WPS button: for WPS push button configuration (BiPAC 7402GX(L)/BiPAC 7300GX)
• Factory default reset button
• Power jack
• Power switch

Physical Specifications

• Dimensions: 8.27" x 5.83" x 1.42" (BiPAC 7300GX)

7.28" x 4.86" x 1.42" (BiPAC 7402X series) Power Requirements

• Input:12V DC, 1 A (BiPAC 7300GX)

12V DC, 1.2 A (BiPAC 7402X series)

Hardware Specifications

Application Diagram

BiPAC 7402X Series

Application Diagram

BiPAC 7300GX

Application Diagram

Dual-WAN 3G/ADSL for true always-on connection

Notebook

3G Network

Billion’s 3G Router When the ADSL connection is not in service

Internet

Auto-failover to 3G connection for backup solution Service Provider

3G USB Modem ADSL Line

IGMP Technology

IGMP (Internet Group Management Protocol) is used to manage hosts from multicast group. It allows the video stream forwarding correctly.

VLAN Bridge Technology

VLAN (Virtual LAN) Bridge allows users to create VLAN group and specify the member.

Quality of Service Technology

The Quality of Service feature ensures a smooth voice and video transmission for inbound and

• utbound data with minimum traffic congestion.

Video Data Voice

Product Guide Menu

Advanced Router Applications

Triple-play for Digital Home (for BiPAC 7402X Series)

Note: This application is only for BiPAC 7402X series.

Billion’s 3G Router

IPTV Services

Internet

SIP-based Soft Phone

Internet Access VoIP IPTV

Advanced Router Applications

Triple-play for Digital Home (for BiPAC 7402X Series)

Note: This application is only for BiPAC 7402X series.

Network Connections

BiPAC 7402X Series BiPAC 7300GX

Application over 3G/ADSL networks

Connect anywhere, anytime!

Enjoy all the benefits of high- speed ADSL connection right at your desk with the router,

• ffering a secure computing

experience, with an integrated SPI firewall, DoS prevention and other robust security features.

Application over 3G/ADSL2+ networks

At the desk

The router's auto-failover feature ensures maximum connectivity and minimum interruption by quickly and smoothly connecting to a 3G network in the event that the landline fails. The router will then automatically return to the ADSL connection when it's restored - reducing connection

• costs. These features are

perfect for office situation where a constant connection is paramount.

Application over 3G/ADSL2+ networks

Anytime connection

The included 12V car power cable* allows you to connect to the Internet whilst in your car- so you can keep the children entertained on a long road trip, or refer to

• nline mapping sites

when you need to be somewhere you're not familiar with.

Application over 3G/ADSL2+ networks

In a car

Note: * Optional for BiPAC 7402X series

By installing the router, public transport operators can update passengers with real-time weather and event information, updated regularly via a 3G Internet connection, or

• ffer business travelers

Internet access that can be can be billed to create greater income potential.

Application over 3G/ADSL2+ networks

On public transports

The router innovative browser-based configuration allows you to quickly and easily set up a WLAN, so when you're at a meeting or training, your guests or participants can quickly and securely access the Internet via a 3G network to retrieve emails, share meeting minutes or training materials with their colleagues.

Application over 3G/ADSL2+ networks

In the meeting

The BiPAC 7402X series supports embedded IPSec VPN (Virtual Private Network) protocols, allowing users to establish encrypted private connections of up to 16 simultaneous tunnels over the Internet. With a built-in DES/3DES VPN accelerator, the router enhances IPSec VPN performance significantly and ensures that data is transmitted securely between two or more sites.

Application over 3G/ADSL2+ networks

In a car (for BiPAC 7402(G)X)

When you're chilling out at a party or concert, the light-weight, portable router frees you to instantly share your pictures or video clips of the event with friends and family -- so those close to you can share your enjoyment.

Application over 3G/ADSL2+ networks

At an event

Compatible 3G Data Cards

For BiPAC 7300GX

3G Operator Product Name Manufacturer & Model Name

T-Mobile web`n`walk card compact Option GlobeTrotter GT Max E T-Mobile web`n`walk card compact II Option GX0201 N/A N/A Novatel Merlin XU870 N/A N/A Bandrich C100 (EXPRESS to PCMCIA converter required.) N/A N/A Globtrotter GT MAx 7.2 card N/A N/A Option iCON 225 N/A N/A Option GlobeTrotter EXPRESS 7.2 GE0201 (EXPRESS to PCMCIA converter required.) N/A N/A ONDA N501HS T-Mobile web`n`walk card wlan Option GT Fusion+EMEA T-Mobile Mobile DSL 1800 Option GlobeTrotter HSPDA Vodafone Mobile Connect Huawei E630, Huawei E620, Option GT 3G+EMEA, Novatel Merlin U740

Note: * Please refer to http://www.billion.com/compatible-3G.html for the updates of compatible 3G data cards.

Compatible 3G USB Modems

For BiPAC 7402X series

Brand Model

Huawei E220 E270 BandRich Bandluxe C100 Huawei E272 MF622 Huawei ZTE

Note: * Please refer to http://www.billion.com/compatible-3G.html for the updates of compatible 3G data cards.

Quick Start & Demo Sites

Connect anywhere, anytime!

Quick Start

Hardware Connection

Step 2: Power Connection Step 1: 3G Data Card / USB Modem Connection Step 4: LAN Connection Step 3: ADSL Connection

Quick Start

Configures the router for Internet access in two ways:

Option 1: Easy Sign-On (EZSO) Option 2: Web Configuration Just open your browser and Easy Sign-On configuration wizard will be popped up to guide you to complete the basic network configuration. (for BiPAC 7300GX only) Log in to your router via your web browser and start to set it up according to your requirements.

GUI Demonstration Sites

www.billion.com/edu/3g/Demo-wireless-7402GX/ www.billion.com/edu/3g/Demo-7402X/

BiPAC 7402X

www.billion.com/product/wireless/Demo-3G-Router/

BiPAC 7300GX BiPAC 7402GX

Reviews and Honors

• n BiPAC 7300GX

Connect anywhere, anytime!

Reviews and Honors on BiPAC 7300GX

Overall Rating: 9/10 “…if you need a constant network connection or portable Internet access, it’s worth every penny.” “3G Internet backup and “good wireless range” Computer Shopper, UK, Nov. 2007 “Recommended” Award Overall Rating: 9/10 (English Translation) “Billion BiPAC 7300GX highlights the large number of possibilities that offer to the user when wants to select the technology of connection: wired, wireless, 802.11 or 3G.” TCN Magazine, Spain, Dec. 2007 “Best Buy” Award

Reviews and Honors on BiPAC 7300GX

“Losing your broadband connection can be a real pain, but with Billion's BiPAC 7300GX ADSL router you never have to worry again, as it's got 3G backup. “ “Alternatively, if you're doing a demonstration or exhibiting at a show this is a cheap way of providing a network connection on the move.” Computer Shopper, UK, Aug. 2007 "Produced excellent results in our speed tests, can distribute an Internet connection from a 3G PC Card, has good filtering and security options" "A PC Card slot allows this ADSL modem / router to double as a 3G modem/router. It performed very well in our tests and ships with a car kit, which, in effect, can turn your car into a mobile hotspot." PC World, Australia, January 2008 Overall Rating:

“A great choice for anyone who needs a backup to their broadband connection”

PC Pro magazine, UK, Oct. 2007

Reviews and Honors on BiPAC 7300GX

PC Authority, Australia, Nov. 2007

Reviews and Honors on BiPAC 7300GX

“Billion’s BiPAC 7300GX is an integrated all-in-one router. “

by iThome weekly, Taiwan, 308 & 309 Issue, Aug. 2007
