DTC AT A GLANCE



Total Regions : Four (East, West, South & North)



Total Depots : 40 Depots (33 Low Floor & 7 Standard Floor Depots)



Total No. of Routes in Operation (a) City Routes : 555 (b) NCR Routes : 11 (c) Ladies Spl. Trips : 28 (d) Night Service : 85



Fleet : 4226



• Sch. No. of Buses outshedded daily

: 3876



• Avg. Daily Traffic Earning

: Rs. 2.50 Cr



Kilometers Operated Daily : 7.00 Lakhs



• Avg. Traffic Earning per Kilometer

: Rs. 26.00 Paisa



Daily Ridership (excldg. Pass holders) : 18.00 Lakhs (Figures are indicative)

2

AUTOMATED FARE COLLECTION SYSTEM

• Global tender for

“Design, Develop, Build, Install, Maintain and Transfer of Automated Fare Collection System (AFCS) using Electronic Ticketing Machines (ETMs), Validators, DMRC Smart Cards in DTC buses on Build-Own-Operate-Transfer (BOOT) basis was floated and Work Order was issued to M/s Trimax IT Infrastructure & Services Ltd., Mumbai.

TENDERING PROCESS

MAIN FEATURES

• Transparency in bus ticketing operations in DTC

buses

• Better control over revenue and online monitoring.
• Increased efficiency and decreased operational costs.
• Cashless travelling using Smart Cards of Delhi Metro.
• Conductor less operation using validators.

PHASES OF AFCS

Phase-I Deployment

• f

Handheld Electronic Ticketing Machines for issuing thermal paper tickets by all the Conductors: ETMs in all depots have been supplied and commissioned by the Implementing Agency i.e. M/s Trimax IT Infrastructure & Services Pvt. Ltd., Mumbai.

• Phase-II Integration of Smart Cards of DMRC (Common Mobility

Card) using ETMs has been done for charging fare: Prototype has been finalized and transactions using Smart Cards of Delhi Metro have been tested successfully. Roll out is also expected shortly after necessary approval of RBI to be obtained by the Delhi Metro Rail Corporation.

• Phase-III Using Validators for conductor-less tickets issuing
• perations using Smart Card by the commuters: This also depends
• n DMRC due to pending approvals at their end.

STATUS ON COMMON MOBILITY CARD

 Integration of Contactless Smart Cards of Delhi Metro

with AFCS of DTC and with ETMs of Cluster buses is a part of the tender contract.

 Testing of Read & Write the Test Cards of DMRC with

ETMs has been already done successfully.

 Coding for reading real cards has been also done.  Roll out of Common Mobility Card is expected shortly,

waiting approval from RBI.

PAYMENT MODEL

• No upfront cost involved.
• Payments are purely on per transaction

basis.

STATUS ON OTHER ASPECTS OF AFCS

• The IA has supplied ETMs in all the depots.

Ticketing using ETMs in all depots is being done.

• Many conductors are carrying out 100%
• perations using

ETMs. Remaining are making efforts to achieve 100% operation.

• Overall

90% bus ticketing has been achieved.

CCTV IN 200 BUSES

Background

After the Nirbhaya incidence in Delhi, directives were received from Delhi Govt. on 31st July 2013 to install CCTV Camera system in 200 buses as a pilot. Accordingly, 200 buses AC & Non-AC i.e. all the 100 buses of Sarojini Nagar Depot and 100 buses of Rajghat Depot have been fitted with CCTV Camera system. The Work order was placed on M/s Matrix Securities and Surveillance Pvt. Ltd., Hyderabad on 07.07.2014 through open tendering process. The work of installation of CCTV camera system in buses and storage server in respective depots was completed in Nov. 2014.

 The scope of work for this project includes “Design,

Develop, Build, Install, Maintain and Transfer - Closed Circuit Television System for the buses of Delhi Transport Corporation” operating in Delhi and satellite towns of the NCR region on BOOT (Build Own Operate Transfer) PPP Model.

• 3 Nos. CCTV cameras in each bus have been fitted in 200

LF buses.

• MDVR with 320 GB Hard disc
• Server Control & Storage Rooms with 1 TB capacity in

each depot.

12

Scope of Work

The system captures motion pictures and stores in rugged MDVR with suitable enclosure to protect against fire incidences in the bus. The MDVRs have storage capacity of 7 days with a provision of 24*7 recording. The Cameras installed are capable to capture:

 Face of each and every passenger entering and exiting the

bus.

 The entire view of the bus (inside) without any blind spots.  The driver’s cabin covering all activities by driver and other

elements.

 All activities around conductor of the bus.  Front outside Driver’s view of the road enabling DTC to

analyze lane driving, proper parking and accidents.

13

The system is equipped with:

 Driver’s Alert to trigger alarm in case of emergency.

The videos recorded before one hour of alert and after

• ne hour of alert raised by driver are not deleted/over

written by the system.

 Instant Tamper Alerts through SMS and emails

against:

 Disconnection or vandalism  Putting any hindrance in front of cameras or covering

by cloth etc.

 At the time of restoring the cameras

14

Instant Alerts

• THE SYSTEM GENERATES ALERTS FOR:
• Panic button near driver’s seat.
• Camera disconnection.
• Camera blind
• Developing of Fault in Hard Disc
• Capturing both gates, face of each commuter, Conductor

area, Driver area and front road view for accident analysis.

• 24x7 recording by all cameras
• Night vision recording.

Main Features of Installed CCTV System

15

16

Panic Button near driver’s seat

17

View from Camera 1

18

Camera 1 (behind driver’s seat)

19

View from Camera 2

20

View from Camera 3

21

Locations Camera 2 & 3

 Camera recordings are stored in MDVRs fitted in each

bus and transferred to Storage Servers in each depot so as to maintain minimum 15 days recordings.

 Live Streaming is not taken due to (i) unlimited high

data transfer costs and (ii) not so good availability of connectivity in 2014.

 However, system is equipped for live streaming in

• rder to take care of Govt. decision to have live

streaming at a later date. But it will involve costs of data transfer.

22

Other Details

 Works as a deterrent to crime in buses  Help in solving crime cases in buses including eve-

teasing, theft, rioting, damaging of buses

 Sense of security in commuters increased  Improves driving habits, since being monitored  Helps in Accident Analysis  Helps DTC to monitor conductor’s performance on

duty

23

Advantages of CCTV in buses

 Cost per bus for 5 years is = Rs. 1.87 Lac  Cost per bus for 1 year is = Rs. 37,542/-  The estimated cost of CCTV in 6655 buses per year would be

= 25 Crore

 The estimated cost of CCTV in 6655 buses for 5 years work

• ut to = Rs. 125 Crore

 After addition of TV screen in each bus the cost of CCTV in

6655 buses for 5 years work out to = Rs. 140 Crore

24

Estimate of Costs

• The Payment terms are:
• After Installation & Commissioning : 40%
• Remaining 60% in equal Monthly Installments
• ver the period of contract of 5 years.
• Payment model purely based on uptime of

CCTV system based on SLA.

• Software for calculating uptime is a part of the

project.

25

Payment Model
