Dongguan Nistar Transmitting Technology Company Presentation

Nistar Facts and Figures

Established : Oct, 2000 in China Manufacturing space : 60,000 square meters Facilities : Dongguan, China Revenue : USD 7 billion in 2018 (Corporate), USD 58M in 2018 (Nistar) Employees : 550 Major products : High temperature cable, Electric Vehicle cable Industrial cable, Building Cable

Vice General Manager Marketing and Sales Customer Services PMC & Logistics HR & Administration Financial Center Purchasing Dept

Baosheng Group Chairman (Nistar) President (Nistar)

Vice General Manager Engineering Dept Quality Control Production Dept Vice General Manager

Company Structure

Milestones of Nistar

• 2000, Nistar was founded
• 2001, Certified UL and VDE Cable
• 2002, Quality system Certified to ISO9001:2008
• 2005, Environment system Certified to ISO14001:2000
• 2007, Quality system Certified to TS16949:2000
• 2008, Awarded “National Key Product Certificate”
• 2008, Recognized “National High Technology Enterprise”
• 2009, Recognized “Key Manufacturer Enterprise”
• 2009, Quality system Certified to ISO13485
• 2009, Certified UL,TUV cable for Solar Industry
• 2011, Certified UL Charge cable for Electric Vehicle
• 2015, Joined AVIC Baosheng with revenue of USD 3B

Revenue Breakdown by Geographic & Segment

Company Competency

Core Competency

Breadth of wire portfolios Turn-key integrated manufacturi ng solutions

Wide range

• f quality

certifications

Prompt customer service Competitive Price Advanced facility investment

Overall Capability Product Range: Standard and customized high temperature and high performance cable Temperature Range: From -100 degree Celsius to 450 degree Celsius Voltage Range: from 30V up to 50KV Minimum Wall Thickness：0.15mm Conductor Size Range: From 44AWG to 300mm2 Core wire: From single core to 120 core wires inside a jacket Conductor and Braiding Material

• 1. Bare Copper
• 2. Tin-plated Copper
• 3. Overcoat Copper - Tinned copper strands covered by tin coating
• 4. Top coated Copper - Bare copper strands covered by tin coating
• 5. Silver-plated Copper - Silver plated to copper strands
• 6. Nickel-plated Copper -Nickel plated to copper strands
• 7. hybrid conductor construction
• 8. Heating Alloy Copper
• 9. Carbon Fiber, glass fiber yarn
• 10. Other specialty conductors

Insulation Material

• 1. Teflon (PTFE,PFA,ETFE,FEP)
• 2. Silicone Rubber
• 3. PVC,XLPVC,SRPVC
• 4. PE,MPPE,FRPE,XLPE,TPE,TPU
• 5. Fiberglass yarn, Mica Tape
• 6. Other specialty compounds

Manufacturing Process Copper Stranding, Core Wire Extrusion, Paring Core Wire, Braiding, Wrapping, Cabling, Filtering, Jacket Extrusion

Capability Overview

Major Customers

ISO9001:2015 ISO14001:2015 ISO13485:2016 IATF 16949:2016

Quality Management System Certification

• ISO9001:2015
• ISO 14001:2015
• ISO 13485:2016
• IATF 16949:2016

Product Industry Certifications

UL Certified 786 Items CCC Certified 4 Items VDE Certified 27 Items RoHS Green Certified CE Europe Certified TUV Certified 5 items CSA Certified 4 group items

• Invention patent

21 items

• Practical patent

60 items

• Appearance patent

31 items

• Other patents

18 items

• Total 130 items

PATENTS

Patents Granted

Shanghai Electric Cable

Research Institute University of Science and Technology of China

Tsinghua University

UESTC Jiangsu University

Partnership with Universities & 3rd Party

Major Product Portfolios

High Temperature Cable

• Teflon cable (PTFE,

PFA, ETFE, FEP)

• Fiberglass cable

(silicone rubber)

• Cross-linked cable

(XLPE)

• EPDM cable

Electric Vehicle & Automotive Cable

• High-voltage

silicone cable

• High-voltage

XLPE cable

• TPE EV charge

cable

• PVC EV charger

cable

• Conventional

automotive cable

Electronics Cable

• PVC cable
• XLPE cable
• HF XLPE cable
• FRPE cable
• Building cable

Industrial & Medical Cable

• Medical cable
• TPU/TPE cable
• Heating cable
• Robotic cable
• Other specialty

cable

Industry Standard: UL, VDE Nistar Featured Wire: UL1911, UL10109, UL10086, UL3122, UL3071, UL1330, UL3398, UL3135 VDE H05S-K, VDE FG4G4, VDE 7023 and more Wire Type: Teflon, Silicone, XLPE

Oven Hot Fun Gas Range Microwave Water Heater Hob Coffee Machine Cooking Hoods

Cables for Appliance Industry

UL & VDE Wire

Industry Standard: UL or custom-designed Nistar Featured wire: Size from 10AWG to 200mm2 with UL10070, UL10198, UL3132,UL3212 etc Wire Feature: High Flexible, UV resistant, High Duration, Halogen Free (optional) Wire Type: PVC, Silicone, TPE, XLPE

Power Cabinet Power Inverter Solar Power Storage EV Battery Assy

UL Big Size Wire

Cable for Power Industry

Industry Standard: UL , VDE Featured Wire: UL1199, UL3266, UL3398, UL3271, UL3122 and more. Wire Type: Teflon, Silicone, XLPE

UL & VDE Wire

Cables for Motor Industry

High-temp Sensor Vibration Sensor Temperature Sensor NTC Sensor Level Sensor Fluid Sensor Position Sensor Pressure Sensor

Customiz ed wire

Cable for Sensor and Automation

Industry Standard: Custom-designed to customer spec Wires type: Single and multi-cores insulated PTFE, FEP, Silicone, TPU, XLPE,PVC

4/21/2020 page 18

Surgical Device Wire Harness ECG Cable SPO2 Cable Hemodialysis Device Ultrasonic Device X-Ray Device Patient Monitoring

Cable for Medical Device

Wire Type: SFP, Mini-SAS, SATA, LVDS, USB2.0, USB3.1, HDMI, DP, RF Cable

Cable for Datacom Industry

SFP Cable (developing)

Mini-SAS assembly SATA cable assembly MiniSAS Cable Display Port HDMI assembly USB cable assembly RF cable assembly

High Voltage Cable for Electric Vehicle

Single and double insulation (shielding): 2.5mm2, 4.0mm, 6.0mm2, 10mm2, 16mm2, 25mm2, 35mm2, 50mm2, 70mm2, 95mm2. 120mm2

Features:

 Versatile and specially selected insulation material (Silicone, TPE, XLPE)  High flexibility and bending radius  Good thermal property up to 200C operating temperature  Good mechanical property  Design with and without EMI shielding function  Bare copper or tinned copper conductor

Charger Cable for Electric Vehicle

• EVE 3X14AWG+2X16AWG EVJE 3X14AWG+1X16AWG
• EVE 3X6AWG+1X8AWG+2X16AWG EVE 3X10AWG+2X16AWG
• EV 2*120mm2+16mm2+2*4mm2+4*0.75mm2
• EV 2*70mm2+16mm2+2*4mm2+4*0.75mm2
• EV 35mm2+16mm2+24mm2+4*16mm2
• EV07E2Q-H, EV07EE-H, EV07EEC4E-H

Features:

 Broad wire offerings applied from household to public fast charging (AC & DC)  UL-62 certified cable (UL:E341742)  CQC & DERKA certified for Chinese market  Optional insulation (TPE, PVC, HF)  Conventional design and coiled design  Good mechanical, thermal, electrical property

IEC type-1 AC Charging Plug GB DC Charging Plug GB 63AAC Charging Plug GB AC Vehicle inlet GB AC Charging Socket-outlet GB DC Vehicle inlet GB Mode2 AC Charging Plug

GB DC Charging Plug with Socket GB AC Charging Plug with Socket

GB AC Charging Plug

EV Connector and Socket

GB AC Charging Plug

GB DC Charging Plug

GB DC Charging Socket

Production line Photos

Copper Stranding Fiberglass Yarn Braiding Teflon Insulation Extrusion Silicone Wire Insulation Extrusion

Production Line Photos

Paper Wrapping Silicone Wire Saturation Electronics Wire Insulation Extrusion Warehousing

AC Dielectric Tester

Testing Lab- Electrical Test

DC Resistance Bridge DC Dielectric Tester LCR Tester High Voltage Tester Insulation Tester

Vibration Tester Elongation tester Flexing Tester Bending Tester Tensile Strength Tester Section Projector Pull Tester Low Temperature Chamber

Testing Lab- Mechanical Test

Temperature/Humidity Chamber Temperature Rise Curve Tester Advanced REACH & RoHS Tester Aging Oven Chamber Flammability Tester Low Temperature Tester

Testing Lab- Environment Test

UV Resistance Tester Bending Cycle Tester

Why Nistar can be a good partner?

 Strong finance background  Trusted by world-class customers  Reliable materials are used  Experienced team in the industry  Customized design solution for customers

Thank you

North American and Europe representative: François Balthazar Cell: 514-983-1258 1-800-479-1309 ext.707 francois.b@voltage.ca

Innovateur de ressources • Resource innovator
