DNS Performance and the Effectiveness of Caching

Jaeyeon Jung, Emil Sit, Hari Balakrishnan, Robert Morris Presenter: Gigis Petros

Introduction

• Two factors contribute to the scalability of DNS
• hierarchical design around delegated name

spaces

• aggressive use of caching
• Reduce the load on the root servers
• Successful caching hopes to limit client-perceived

delays and wide-area bandwidth usage

Motivation

• What performance, in terms of latency and failures,

do DNS clients perceive?

• How does varying the TTL and degree of cache

sharing impact caching effectiveness?

DNS overview

• Mapping human-readable host names to IP addresses
• Reverse mapping & mail-routing information
• Mapping in the DNS name space are called resource records
• A record: name’ s IP address
• NS record: name of DNS server
• Caching in DNS
• Time To Live: expiration time by the originator of a neem
• Negative caching
• Caches work well because DNS changes slowly

Terminology

• A lookup refers to the entire process of translating a

domain name

• A query refers to a DNS request packet sent to a DNS

server

• A response refers to a packet sent by DNS server in

reply to a query packet

• An answer is a response from a DNS server that

terminates the lookup (successfully or unsuccessfully)

DNS Lookup Sequence

Questions

• What is the ratio of TCP connections to DNS A record

lookups?

• What is the number of DNS queries per lookup?
• DNS errors
• What percentage of lookups do never get an answer?
• Performance of retransmission protocol
• What is the effect of varying TTLs and degrees of caching

sharing on cache hit rate?

Key Findings

• TCP / DNS lookup ratio suggests that the hit rate of DNS caches inside MIT is between 70%

and 80%

• DNS queries per lookup
• Unanswered produces 10 query packets
• Answered 1.3 query packets
• 23% of all client lookups in the most recent MIT trace fail to elicit any answer
• 13% of lookups result in an answer that indicates a failure. Most of these failures indicate

NXDOMAIN

• % of TCP connections made to names with low TTL values increased from 12% to 25% in

2000

• Setting all A-record TTL’s to a value as small as 10 minutes is not likely to degrade the

scalability of DNS

MIT Dataset

• MIT’s laboratory for Computer

science (LCS) and Artificial Intelligence laboratory (AI) to the rest internet

• 24 internal subnetworks

sharing the border router

• Data collected in January and

December 2000

• 500 users, 1200 hosts

KAIST Dataset

• Korea Advanced Institute of

Science and Technology (KAIST) to the rest internet

• Collected May 2001
• 1000 users, 5000 hosts
• Only International TCP traffic

Methodology

• Collection Methodology
• Wide-area DNS query/response
• Outgoing TCP connections: SYN/FIN/RST
• Anonymized internal addresses
• Analysis of Methodology
• Sliding window of 60 seconds
• A referral occurs when a server does not know the answer to a query, but does know where the

answer can be found

Data Summary

• Categorize lookups
• 1. Negative answer: lookup gets a response with non-

zero response code

• 2. Zero answer: is authoritative and indicates no error,

but has no ANSWER, AUTHORITY or ADDITIONAL records

• 3. Answered with success: terminates with a response

that has a NOERROR code and one or more ANSWER

• All other lookups are considered unanswered

Data Summary

Latency

Latency distribution vs. number of referrals for the mit-dec00 trace

• Latency is affected by the number of referrals

Latency

• Cached NS records reduce the load on root

servers

Distribution of latencies for lookups that do and do not involve querying root servers.

Retransmissions

• A querying name server retransmits a query if it does not get a response from destination

within a timeout period

• Unanswered lookups categories
• Zero referrals (nothing received)
• Non-zero referrals (not lead to answer)
• Loops (misconfigured information)

Retransmissions

Cumulative distribution of number of retransmissions for answered (top most curved) and unanswered lookups

• 99.9% of answered lookups have <= 2 retransmissions

Retransmissions

• Each lookup that elicited zero referrals generated

about five times as many wide-area query packets

• We conclude that many DNS name servers are too

persistent in their retry strategies

• Results show that it is better for them to give up after

2 or 3 retransmissions and let client program decide

• Loops generated on average about 10 query

packets

Retransmissions

• Query packets generated by lookups that obtained no

answer

• - 59% (mit-jan00)
• 63% (mit-dec00)
• Names servers are using inappropriate setting for the

number of retries or excessive timeout value

• Nore transmissions within 60 seconds:
• 12% (mit-jan00), 19% (mit-dec00)

Failures

• Negative answers are mostly errors of NXDOMAIN or SERVFALL
• NXDOMAIN: request name doesn’t exist
• SERVFALL: supposed to be authoritative but does not have a valid copy or is
• ut of memory
• The largest cause of these error responses are inverse lookups for IP addresses
• Non-existent top-level domains: loopback, index.htm
• Large number of distinct names makes negative caching ineffective

Interactions with Root Servers

• 15 - 27% of the lookups sent to root name servers

resulted in negative responses

• Most of these appear to be mistyped names

The percentages are of the total number of lookups in the trace

Effectiveness of DNS Caching

• How useful is it to share DNS caches among many client

machines?

• Locality of references among clients
• What is the likely impact of choice of TTL on caching effectiveness?
• Locality of references in time
• Quantify two important statistics
• 1. Distribution of name popularity
• 2. The distribution of TTL values

Name Popularity

• The top 10% account for more than 68% of total

lookups

• A long tail : 9.0% are unique names

TTL Distribution

• The fraction of accesses to short TTLs has doubled
• Increased deployment of DNS-based server

selection

Trace-driven Simulation

• Two databases:
• “name database” maps every IP in A answer to the domain name
• “TTL database” maps each domain name to the highest TTL A record

for that domain

• Algorithm
• Randomly divide TCP clients into groups of size s
• For each new TCP connection, determine the group g and look for a

name n in the cache of group g

• If n exists and the cached TTL has not expired, record a hit. Otherwise

record a miss

Effect of Sharing on Hit rates

• Most of the benefit of sharing is obtained with as

few as 10 or 20 clients per cache

Impact of TTL on Hit rates

• Most of the benefit of caching is achieved with TTLs less than about 1000 seconds.
• 5-min TTLs would increase DNS traffic by factor of 1.5
• NS record caching is critical

Conclusions

• 1. About a quarter of all DNS lookups never get an answer, which

corresponds over 50% of DNS packets in the wide-area Internet

• 2. The DNS retransmission protocol appears to be overly

persistent, but in 10%-12% of cases, no retransmissions occur

• 3. Setting all A-record TTL’s to a value as small as 10 minutes is not

likely to degrade the scalability of DNS in any noticeable way

• 4. The cache ability of NS records enhances scalability by

reducing load on the root and top-level name servers

• 5. Little benefit is obtained from sharing a forwarding DNS cache

among than 10 - 20 clients
