DiCeS: Detecting Communities in Network Streams Over the Cloud Panagiotis Liakos - Katia Papakonstantinopoulou Alexandros Ntoulas - Alex Delis University of Athens Athens University of Economics and Business 12 th IEEE
Panagiotis Liakos† - Katia Papakonstantinopoulou‡ Alexandros Ntoulas† - Alex Delis†
†University of Athens ‡Athens University of Economics and Business
12th IEEE International Conference on Cloud Computing, Milan, Italy
July 8th–13th, 2019
Fast unfolding of community hierarchies in large networks: Blondel et al. UoA Panagiotis Liakos DiCeS-• Motivation 2/24
Fast unfolding of community hierarchies in large networks: Blondel et al.
two large clusters
UoA Panagiotis Liakos DiCeS-• Motivation 2/24
Fast unfolding of community hierarchies in large networks: Blondel et al.
two large clusters
l i m i t e d i n t e r a c t i
b e t w e e n c l u s t e r s !
UoA Panagiotis Liakos DiCeS-• Motivation 2/24
Fast unfolding of community hierarchies in large networks: Blondel et al.
two large clusters
l i m i t e d i n t e r a c t i
b e t w e e n c l u s t e r s ! Brussels acts as a bridge!
UoA Panagiotis Liakos DiCeS-• Motivation 2/24
carbonbrief.org
UoA Panagiotis Liakos DiCeS-• Motivation 3/24
carbonbrief.org real-world networks are massive!
UoA Panagiotis Liakos DiCeS-• Motivation 3/24
carbonbrief.org real-world networks are massive! c h a n g e r a p i d l y !
UoA Panagiotis Liakos DiCeS-• Motivation 3/24
carbonbrief.org real-world networks are massive! c h a n g e r a p i d l y ! exhibit community structure!
UoA Panagiotis Liakos DiCeS-• Motivation 3/24
We want to extract the community structure of nodes in a network that changes rapidly.
Many useful applications:
we can launch accurate & successful advertising campaigns we can provide more informative & engaging social network feeds we can gain insights on the evolution of large real-world networks
Size of graph data appears to be ever-increasing:
Facebook has more than 2 billion registered users Google indexes more than 1 trillion unique URLs
UoA Panagiotis Liakos DiCeS-• Motivation 4/24
A novel community detection algorithm that operates on a graph stream, using space sublinear to the number of edges. Additionally: A PageRank-like A Novel Clustering Technique Edge Quality Variation for Community Size Determination
UoA Panagiotis Liakos DiCeS-• Our Approach 5/24
UoA Panagiotis Liakos DiCeS-• Our Approach 6/24
centralized by design
UoA Panagiotis Liakos DiCeS-• Our Approach 6/24
Worker node Worker node Worker node Worker node
8 9 2 3 7 5 6 3 8 1 4 7 5 2
9 9 3 2 7 5
UoA Panagiotis Liakos DiCeS-• Our Approach 7/24
We propose DiCeS, a novel distributed community detection algorithm for network streams. We implement DiCeS as a cloud application that handles streams of real-world networks at impressive rates. Using just 8 workers we can handle 50 million edges per hour. We achieve horizontal scalability that is close to linear. We offer significant improvements with regard to accuracy.
UoA Panagiotis Liakos DiCeS-• Our Approach 8/24
Apache Storm: Stream processing framework with broad use in production environments. Tuple: fundamental data unit Spout: source of tuples Bolt: responsible for transforming streams into the desired result Grouping: determines how the tuples are exchanged
UoA Panagiotis Liakos DiCeS-• Technologies Involved 9/24
Redis: In-memory key-value data store. Ultra-fast read/write operations Complex data types:
Strings Sets Sorted Sets
Redis-cluster
UoA Panagiotis Liakos DiCeS-• Technologies Involved 10/24
Scalability
Isolate the processing for every edge Distributed key-value store
Fault Tolerance
All edges must be processed Failing nodes must be restored
Interactivity
Updating the target communities Obtaining results on demand
UoA Panagiotis Liakos DiCeS-• Technologies Involved 11/24
UoA Panagiotis Liakos DiCeS-• Cloud Components 12/24
UoA Panagiotis Liakos DiCeS-• Cloud Components 13/24
Distributed key-value store (Redis Cluster) Network stream Spout Processing Bolt Processing Bolt Processing Bolt Processing Bolt
Pruning Bolt Community seed-sets
UoA Panagiotis Liakos DiCeS-• Cloud Components 14/24
Distributed key-value store (Redis Cluster) Network stream Spout Processing Bolt Processing Bolt Processing Bolt Processing Bolt
Pruning Bolt Community seed-sets
$ storm rebalance topology-name [-n new-num-workers] [-e component=parallelism]*
UoA Panagiotis Liakos DiCeS-• Cloud Components 14/24
Algorithm 1: DiCeS
input : A tuple emitted from the spout. begin if tuple.length == 1 then // renewed set of communities communities ← tuple[0]; else // handling of an edge u ← tuple[0]; v ← tuple[1]; degrees[u]+ = 1; degrees[v]+ = 1; foreach C ∈ {nc[u] ∪ nc[v]} do if u ∈ C then cDegrees[C][v]+ = cDegrees[C][u] degrees[u] ; if v ∈ C then cDegrees[C][u]+ = cDegrees[C][v] degrees[v] ; if u ∈ C then communities[C].put(v, cDegrees[C][v] degrees[v] ); nc[v].add(C); if v ∈ C then communities[C].put(u, cDegrees[C][u] degrees[u] ); nc[u].add(C); emit(1);
UoA Panagiotis Liakos DiCeS-• Cloud Components 15/24
Graphs Type Nodes Edges
DBLP Co-authorship 317, 080 1, 049, 866 3.31 22.45 Amazon Co-purchasing 334, 863 925, 872 2.76 13.49 Youtube Social 1, 134, 890 2, 987, 624 2.63 14.59 LiveJournal Social 3, 997, 962 34, 681, 189 8.67 27.80 Orkut Social 3, 072, 441 117, 185, 083 38.14 215.72 Friendster Social 65, 608, 366 1, 806, 067, 135 27.53 46.81
Networks exceeding 1.8 billion links Accompanying ground-truth communities allow for the evaluation of accuracy
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 16/24
100 200 300 400 500 600 A m a z
D B L P Y
t u b e L i v e J
r n a l O r k u t F r i e n d s t e r Average Processing Time per Edge Network 2 bolts 4 bolts 8 bolts
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 17/24
100 200 300 400 500 600 A m a z
D B L P Y
t u b e L i v e J
r n a l O r k u t F r i e n d s t e r Average Processing Time per Edge Network 2 bolts 4 bolts 8 bolts
we can reduce our processing time by adding bolts
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 17/24
Worker nodes 2 4 8 Pending tuples (in thousands) 5 10 15 20 Execution time (in s) 100 200 300 400 500 600 UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 18/24
Worker nodes 2 4 8 Pending tuples (in thousands) 5 10 15 20 Execution time (in s) 100 200 300 400 500 600
maximum al- lowed pending tuples impacts the performance
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 18/24
Worker nodes 2 4 8 Pending tuples (in thousands) 5 10 15 20 Execution time (in s) 100 200 300 400 500 600
DiCeS offers near-linear scaling!
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 18/24
2 4 6 8 10 200 400 600 800 1000 Processing time (in sec) Total edges processed (in thousands) UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 19/24
2 4 6 8 10 200 400 600 800 1000 Processing time (in sec) Total edges processed (in thousands)
DiCeS recovers its speed almost immediately
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 19/24
100 200 300 400 500 600 700 Degree:10, Comm:2K Degree:10, Comm:4K Degree:20, Comm:2K Degree:20, Comm:4K Average Processing Time Per Edge
CoEuS DiCeS (8 bolts)
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 20/24
100 200 300 400 500 600 700 Degree:10, Comm:2K Degree:10, Comm:4K Degree:20, Comm:2K Degree:20, Comm:4K Average Processing Time Per Edge
CoEuS DiCeS (8 bolts)
less impact for DiCeS
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 20/24
0.2 0.4 0.6 0.8 1 A m a z
D B L P Y
t u b e L i v e J
r n a l O r k u t F r i e n d s t e r F1-score Network
CoEuS DiCeS LEMON
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 21/24
0.2 0.4 0.6 0.8 1 A m a z
D B L P Y
t u b e L i v e J
r n a l O r k u t F r i e n d s t e r F1-score Network
CoEuS DiCeS LEMON
DiCeS outper- forms CoEuS
UoA Panagiotis Liakos DiCeS-• Experimental Evaluation 21/24
DiCeS is a streaming community detection virtual infrastructure for large-scale networks that evolve rapidly. DiCeS distributes load to worker nodes in the cloud. We can process almost 50 million edges per hour using only 8 worker nodes. DiCeS is shown to scale almost linearly.
UoA Panagiotis Liakos DiCeS-• Conclusion 22/24
[LND17] Panagiotis Liakos, Alexandros Ntoulas, and Alex Delis. COEUS: community detection via seed-set expansion on graph streams. In 2017 IEEE International Conference on Big Data, BigData 2017, Boston, MA, USA, December 11-14, 2017, pages 676–685, 2017. UoA Panagiotis Liakos DiCeS-• References 23/24
https://github.com/panagiotisl/DiCeS for further details email me at: p.liakos@di.uoa.gr
hive.di.uoa.gr/network-analysis/ www.madgik.di.uoa.gr/
UoA Panagiotis Liakos DiCeS-• Contact 24/24
