SLIDE 1
- THE FIRST
DEVELOPED BY SFS STRUCTURES LTD.WITH COLLABORATION OF SCHEMATIC - - PowerPoint PPT Presentation
DEVELOPED BY SFS STRUCTURES LTD.WITH COLLABORATION OF SCHEMATIC - - PowerPoint PPT Presentation
SFS SYSTEM CONSTRUCTION NEW SHORING FOUNDATION SYSTEM DEVELOPED BY SFS STRUCTURES LTD.WITH COLLABORATION OF SCHEMATIC PRESENTATION SFS SYSTEM THE FIRST STEP IS TO DRILL ALL HOLES FOR COLUMNS / PILING SFS SYSTEM AFTER
SLIDE 2
SLIDE 3
- AFTER
DRILLING HOLES COLUMNN / PILES ARE CENTERED, ALIGNED AND PLACED IN POSITION.
SFS SYSTEM
SLIDE 4
- THIS HOLE
DRILLING AND COLUMN / PILING
PLACING
TAKES PLACE PRIOR TO MASS EXCAVATI ON.
SFS SYSTEM
SLIDE 5
- PERIMETER
COLUMNS /
PILES ARE PLACED ON SITE AND CENTRAL COLUMNS / PILES ARE PLACE D AT THE SAME TIME.
SFS SYSTEM
SLIDE 6
- DETAIL OF A
CENTRAL PILE AFTER INSTALLATION.
SFS SYSTEM
SLIDE 7
- EXCAVATION
DOES NOT COMMENCE
UNTIL AFTER
ALL COLUMNS / PILES ARE INSTALLED INTO THEIR EXACT LOCATION.
SFS SYSTEM
SLIDE 8
- CONCRETE WALL
PANELS ARE INSTALLED AS EXCAVATION PROCEEDS
SFS SYSTEM
SLIDE 9
- VIEW OF
FIRST ROW OF CONCRETE PANELS IN
- PLACE. AT
THIS POINT EXCAVATION TO THE DEPTH OF 1.5 METRES IS COMPLETED.
SFS SYSTEM
SLIDE 10
- AT THIS TIME
THE BEAM SYSTEM INSTALLATION IS PERFORMED, CONECTING PERIMETER COLUMNS WITH CENTRAL COLUMNS (FOR EACH LEVEL OF PARKADE).
SFS SYSTEM
SLIDE 11
- GENERAL
VIEW OF CONDITION
PREVIOUS TO
INSTALLATIO N OF SECOND ROW OF
CONCRETE
WALL PANELS.
SFS SYSTEM
SLIDE 12
- GENERAL VIEW
OF CONDITION WHEN SECOND CONCRETE PANEL ROW IS COMPLETED . EXCAVATION IS NOW 3.0 METRES IN DEPTH AT THIS POINT.
SFS SYSTEM
SLIDE 13
- INTERIOR
VIEWPOINT AFTER SECOND ROW OF CONCRETE PANELS IS COMPLETED. ALSO SHOWS COLUMN AND BEAM SYSTEM.
SFS SYSTEM
SLIDE 14
- EXTERIOR
VIEWPOINT ( FROM STREET
LEVEL)
WITH FIRST LEVEL OF PARKADE COMPLETED.
SFS SYSTEM
SLIDE 15
- GENERAL
VIEW OF THE ENTIRE SYSTEM INCLUDING CONCRETE AT THE BASE OF EACH COLUMN / PILE. SUPERSTRUCT URE COLUMNS AND BEAMS ALSO SHOWN INSTALLED.
SFS SYSTEM
SLIDE 16
- PERSPECTIVE
VIEW FOR THE ENTIRE SYSTEM.
SFS SYSTEM
SLIDE 17
- PANORAMIC
VIEW FROM
STREET
LEVEL.
SFS SYSTEM
SLIDE 18
- INTERIOR
