W I S S E N T E C H N I K L E I D E N S C H A F T 1 Determination of the Sb(111)-phonon dispersion relation using inelastic HAS measurements Florian Apolloner , Patrick Kraus, Christian

slide-1
SLIDE 1

1 W I S S E N  T E C H N I K  L E I D E N S C H A F T  www.tugraz.at

Determination of the Sb(111)-phonon dispersion relation using inelastic HAS measurements

Florian Apolloner, Patrick Kraus, Christian Gösweiner, Giorgio Benedek, Wolfgang E. Ernst

slide-2
SLIDE 2

2 Florian Apolloner, Institute of Experimental Physics 28.08.15

Overview

  • Experimental setup
  • Time of flight measurements
  • Sb(111) phonon dispersion
  • Conclusions
slide-3
SLIDE 3

3 Florian Apolloner, Institute of Experimental Physics 28.08.15

H.Å.N.S.

Creation Interaction Detection

θSD = θi + θf = 91.5° Pressures: SC: 10-6 mbar MC: low 10-10 mbar D: 10-9 mbar Nozzle: 50 bar, 10μm

slide-4
SLIDE 4

4 Florian Apolloner, Institute of Experimental Physics 28.08.15

(Why) Antimony

  • semimetal in bulk

metal on the surface

  • topological insulators
  • nanofilms for topoelectronic

phase transistions

  • spintronics

Z=51, 5 th main group, 5 th period hexagonal structure

slide-5
SLIDE 5

5 Florian Apolloner, Institute of Experimental Physics 28.08.15

Beam generation

Supersonic adiabatic expansion Tnozzle = 65 – 299 K → Ekin= 14-43 meV → λ = 0.7-1.2 Å

 Nozzle: 50 bar through 10μm  further selection via a skimmer  ΔE/E roughly 1.5%

Ekin=1 2 mHe v He

2 =5

2 kbT nozzle

Why Helium

  • chemically, electrically, magnetically inert
  • completely nondestructive
  • strictly surface sensitive

strictly surface sensitive

  • high cross section for surface phonons
  • interaction with the electron charge density oscillations
slide-6
SLIDE 6

6 Florian Apolloner, Institute of Experimental Physics 28.08.15

Time of flight measurements

  • Continuous He beam chopped into packets
  • Interaction between He atom and quasiparticles leads to

engery change

  • Time-resolved intensity measurement to distinguish signals
  • Single-slit chopper replaced with pseudo-random

chopper for faster measurements

slide-7
SLIDE 7

7 Florian Apolloner, Institute of Experimental Physics 28.08.15

Phonons

slide-8
SLIDE 8

8 Florian Apolloner, Institute of Experimental Physics 28.08.15

Measuring sub-surface modes – Example Bi(111)

[1] A. Tamtögl et. al., 2013, Surface and subsurface phonons of Bi(111) measured with helium atom scattering, Phys. Rev. B87, 035410 [2] I. Yu. Sklyadneva et. al., 2011, Mode-Selected Electron-Phonon Coupling in Superconducting Pb Nanofilms Determined from He Atom Scattering,

  • Phys. Rev. Lett. 107, 095502
slide-9
SLIDE 9

9 Florian Apolloner, Institute of Experimental Physics 28.08.15

TOF Data

slide-10
SLIDE 10

10 10 Florian Apolloner, Institute of Experimental Physics 28.08.15

Dispersion relation

slide-11
SLIDE 11

11 11 Florian Apolloner, Institute of Experimental Physics

Experimental results

iHAS TOF measurements on Sb(111) (TS = 150 K) Ei = 15-18 meV

? Acoustic Plasmon ?

Background calculation from: [3] D. Campi et al., PRB 86, 075446 (2012)

iHAS TOF measurements on Sb(111) (TS = 150 K) Ei = 15-18 meV

? Acoustic Plasmon ?

28.08.15

slide-12
SLIDE 12

12 12 Florian Apolloner, Institute of Experimental Physics 28.08.15

Possible explanations

Accoustic surface plasmon:

  • Polarization could lead to multiple branches
  • Energy still way to low even for really low lying acoustic

plasmons (factor 1000?) E-h excitation:

  • Plausible energy range
  • Exact mechanism unclear
  • How to explain multiple branches
slide-13
SLIDE 13

13 13 Florian Apolloner, Institute of Experimental Physics 28.08.15

Summary and outlook

 Time-resolved inelastic helium atom scattering intensities  Complete picture of the acoustical and optical phonon modes

in both high-symmetry directions (Low-T optical still to be done)

 Appearence of unknown low-lying dispersed modes below the

Rayleigh curve

 Theoretical analysis of electron-excitation jump energies

(Dispersion) → Next step!

slide-14
SLIDE 14

14 14 Florian Apolloner, Institute of Experimental Physics 28.08.15

Thanks

Wolfgang E. Ernst Patrick Kraus Giorgio Benedek H.Å.N.S. Christian Gösweiner Financial Support: European Commission and Styrian Government within the ERDF program

slide-15
SLIDE 15

15 15 Florian Apolloner, Institute of Experimental Physics 28.08.15

Multiple branches 1/2

slide-16
SLIDE 16

16 16 Florian Apolloner, Institute of Experimental Physics 28.08.15

Multiple branches 2/2
