Detection of gravitational waves

Miquel Nofrarias Institut de Ciències de l’Espai (IEEC-CSIC)

slide-2
SLIDE 2

GW detection - M. Nofrarias ICE 02/07/18

Gravity gradient

  • Coupling of the suspended test mass with density fluctuations
  • Dominant source comes from seismic surface waves near the location of

the test mass

  • Solutions to these come from active isolation (using seismograph) to

underground facilities

2

slide-3
SLIDE 3

GW detection - M. Nofrarias ICE 02/07/18

Parametric instabilities

  • Energy can couple from the optical modes resonating in the cavity to the

acoustic modes in the test mass

  • Solution is design to avoid this instabilities.
  • Suppression can be achieved, for instance, by means of thermal

compensation

3

slide-4
SLIDE 4

GW detection - M. Nofrarias ICE 02/07/18

Parametric instabilities - thermal compensation

4

slide-5
SLIDE 5

GW detection - M. Nofrarias ICE 02/07/18

Active isolation

  • Test mass required to be located ~10-6 of

a wavelength

  • Residual motion is ~ microns
  • makes difficult to lock on mirror

because large forces need to be applied

  • Makes it impossible to act on the test

mass

  • noise limit on the actuator typically

10-9 of the max signal to be applied

  • 10-9 x 10-6 = 10-15 (large!)
  • Two options: either reduce residual

motion or attenuate test mass motion by means of control stages

5

slide-6
SLIDE 6

GW detection - M. Nofrarias ICE 02/07/18

Active isolation

  • The equation of motion for a suspended

pendulum

6

  • We use the error signal
  • Our transfer function is then
  • Suppression factor
slide-7
SLIDE 7

GW detection - M. Nofrarias ICE 02/07/18

Ultra low frequency pre-isolator

7

Equation of motion for inverted pendulum Equation of motion for folded pendulum

slide-8
SLIDE 8

GW detection - M. Nofrarias ICE 02/07/18

Inverted pendulum dynamics

8

slide-9
SLIDE 9

GW detection - M. Nofrarias ICE 02/07/18

VIRGO Superattentuator

9

slide-10
SLIDE 10

GW detection - M. Nofrarias ICE 02/07/18

External Injection Bench - Seismic Attenuation System

10

slide-11
SLIDE 11

GW detection - M. Nofrarias ICE 02/07/18

Suspended detection benches (Virgo)

11

slide-12
SLIDE 12

GW detection - M. Nofrarias ICE 02/07/18

Suspended detection benches (Virgo)

12

slide-13
SLIDE 13

GW detection - M. Nofrarias ICE 02/07/18

LIGO

13

slide-14
SLIDE 14

GW detection - M. Nofrarias ICE 02/07/18

Resonant mass/Acoustic detectors

14

slide-15
SLIDE 15

GW detection - M. Nofrarias ICE 02/07/18

Acoustic detectors

15

slide-16
SLIDE 16

GW detection - M. Nofrarias ICE 02/07/18

Weber pioneering work

16

  • Consider an harmonic oscillator driven by

gravitational waves

  • Derive equations of motion
  • Exploit piezoelectric effect: stress

in a piezoelectric will induce a signal that can be recorded, measure this and you can compute terms of the Riemann

  • As suggested by Dirac, what if

anomalies in Earth rotation would be due to gravitational wave radiation? 5 x 108 erg/cm2 :’The

Earth rotation is not a useful detector unless the anomaly can be reduced’

slide-17
SLIDE 17

GW detection - M. Nofrarias ICE 02/07/18

Resonant mass detectors network

17

slide-18
SLIDE 18

GW detection - M. Nofrarias ICE 02/07/18

Resonant bar

18

slide-19
SLIDE 19

GW detection - M. Nofrarias ICE 02/07/18

Resonant bar

19

slide-20
SLIDE 20

GW detection - M. Nofrarias ICE 02/07/18

Sensitivity to GW sources

20

  • Energy deposited in a resonant antenna
  • Total intrinsic noise of the antenna
  • Optimal result reaching the amplifier limit KBTN
  • Quantum limit
  • M = 1200kg, D = 3m, ωs =900Hz => TN = 0.04 uK , hmin = 10-21
slide-21
SLIDE 21

GW detection - M. Nofrarias ICE 02/07/18

Sensitivity to GW sources

21

slide-22
SLIDE 22

GW detection - M. Nofrarias ICE 02/07/18

Spherical GW detectors

22

slide-23
SLIDE 23

GW detection - M. Nofrarias ICE 02/07/18

Omnidirectional GW detectors

23

  • Various geometries proposed for omnidirectional GW detectors
  • Truncated Icosahedron (TIGA)
  • Pentagonal Hexacontahedron (PHC)
  • Some interesting properties derived from the geometry. In particular,

multimode analysis. PHC, for instance, shown to differentiate GR from BD theories from the monopole

slide-24
SLIDE 24

GW detection - M. Nofrarias ICE 02/07/18

Omnidirectional GW detectors

24

What can we learn about GW Physics with an elastic spherical antenna? J.A. Lobo PRD (1995)

slide-25
SLIDE 25

GW detection - M. Nofrarias ICE 02/07/18

DUAL wideband proposal

25

slide-26
SLIDE 26

GW detection - M. Nofrarias ICE 02/07/18

The gravitational wave spectra

26

slide-27
SLIDE 27

GW detection - M. Nofrarias ICE 02/07/18

Pulsar Timing Array

  • A pulsar timing network of ~100

pulsars each with better than 100 ns timing precision

  • Observing with weekly regular

cadence would enable nHz – μHz band

27

slide-28
SLIDE 28

GW detection - M. Nofrarias ICE 02/07/18

LISA recent chronology

  • 2011 Apr: “ESA has ended the partnership with NASA

because NASA is financially unable to participate when ESA's funding is available” R. Stebbins (NASA).

  • 2013 Nov: ESA selects ‘The Gravitational Universe’ as

scientific theme for L3 mission slot.

  • 2016 Feb: LIGO announcement (and LISA Pathfinder

successfully releases TMs in free-fall)

  • 2016 Nov: ESA call for mission proposals for the L3 slot

(1.000 ME, 2034)

  • 2017 Jan: LISA Consortium submits its proposal
  • 2017 Jun: ESA officially selects LISA as L3 mission of its

scientific programme

  • 2017 Jul-Dec: LISA phase 0 study. Output: Payload

Description Document (PDD)

  • 2018 June: LISA Phase A kick off (2 years).

28

slide-29
SLIDE 29

GW detection - M. Nofrarias ICE 02/07/18

It’s a long story…

NASA studies GWI (Gravity Wave Interferometer), an interferometer with a total launch mass of 16.4 t, which included four 1000kg test masses. The total cost of the project was estimated at that time to be $ 49.5 M

29

  • R. Weiss, P.L. Bender, C.W. Misner and R.V. Pound, in Report of the Sub-Panel on Relativity

and Gravitation, Management and Operations Working Group for Shuttle Astronomy, (NASA, Washington, DC, 1976).

slide-30
SLIDE 30

GW detection - M. Nofrarias ICE 02/07/18

LISA schedule

30

slide-31
SLIDE 31

GW detection - M. Nofrarias ICE 02/07/18

The LISA mission concept

31

LISA is the concept selected for ESA L3 mission slot (2034, 1000M€) LISA (Laser Interferometer Space Antenna)

Constellation of 3 satellites in heliocentric orbit Space-craft are drag-free, ie. it follows a test mass inside which is in nominal free fall Micro-newton thrusters steers the space-frat to be entered around the test mass Differential arm-length measured by laser interferometry

slide-32
SLIDE 32

GW detection - M. Nofrarias ICE 02/07/18

Black Hole Astronomy in the 2030s

32

Future EM

  • bs.

SKA,

Redshift, z

Future ground Current ground

Mass [log M/Mo]

slide-33
SLIDE 33

Thermo-elastic modelling workshop

LISA science case

33

L I S A P a t h fi n d e r

slide-34
SLIDE 34

Thermo-elastic modelling workshop

LISA measurement concept

34

slide-35
SLIDE 35

GW detection - M. Nofrarias ICE 02/07/18

LISA challenges — MOSA

35

Going to 20uHz requires 14h measurements. Many things move, so it requires:

very high pointing accuracy: 5 nrad/√Hz imaging systems and very good alignment between Optical Bench, Telescope and test mass (order of a few 10 μm)

The MOSA has to follow the constellation ‘breathing’, then

necessary a backlink fiber harness with 100+ cables must be continuously moved

One pm is 10-6 of a wavelength

stray light with an amplitude of 10-6 compared to the wanted light produces pm errors

slide-36
SLIDE 36

GW detection - M. Nofrarias ICE 02/07/18

LISA challenges — Gravitational Reference Sensor

  • Requirements on the test mass:
  • Allow TM to be a 3 fm/s2/Hz1/2 level

geodesic reference (relaxed 1/f2 from 20 mHz to 400 mHz)

  • Allow TM to be used as a mirror for < 10

pm/Hz1/2 IFO readout

  • Forces applied to the test mass dominate

noise budget at low frequency

  • Cold gas: initially 4 tanks 50kg each pulling
  • utwards on two TMs.
  • Cannot deplete fuel without unbalancing g
  • n two TMs
  • Costs ~ hundreds pm/s2 in differential

36

slide-37
SLIDE 37

GW detection - M. Nofrarias ICE 02/07/18

LISA challenges — interferometry

37

Beam expands to 15 km → only 1 nW received in telescope

Very accurate pointing (sub-μrad) required → complicated link acquisition

One-way light travel time is about 8 seconds, spacecraft are moving

phasemeter needs to take into account Doppler and implement tracking schemes

Difference between transmit and receive directions, changing over time

Need point-ahead mechanism in the

  • ptical path

Laser frequency noise couples into measurement with enormous amplification

Time-Delay Interferometry (TDI)

slide-38
SLIDE 38

GW detection - M. Nofrarias ICE 02/07/18

LISA challenges — Time Delay Interferometry (TDI)

38

TDI is essential to remove frequency noise in post-processing

Suppresses frequency noise by several orders of magnitude Fundamental step in post-processing LISA telemetry Based on pioneering work at JPL, Tinto et al. (1999) technique to ‘synthesize’ an equal arm interferometer, relying in accurate knowledge of satellite constellation

TDI impacts in mission design since it requires:

sub-m knowledge of absolute arm lengths ns-accurate time-stamping ranging function of phasemeter special requirements on spacecraft timing and clocks

slide-39
SLIDE 39

GW detection - M. Nofrarias ICE 02/07/18

LISA Pathfinder — paving the way for LISA

39

slide-40
SLIDE 40

GW detection - M. Nofrarias ICE 02/07/18

LPF - exploded view

40

slide-41
SLIDE 41

GW detection - M. Nofrarias ICE 02/07/18

Gravitational Reference Sensor

41

slide-42
SLIDE 42

GW detection - M. Nofrarias ICE 02/07/18

Gravitational Reference Sensor

42

slide-43
SLIDE 43

GW detection - M. Nofrarias ICE 02/07/18

LISA Pathfinder

43

Four interferometers in total

x1 x12 Reference Frequency

slide-44
SLIDE 44

GW detection - M. Nofrarias ICE 02/07/18

Optical Metrology - heterodyne interferometer

44

slide-45
SLIDE 45

GW detection - M. Nofrarias ICE 02/07/18

LPF - dynamics and control scheme

45

slide-46
SLIDE 46

GW detection - M. Nofrarias ICE 02/07/18

LPF - dynamics and control scheme

46

Armano et al. (LPF collaboration) Phys. Rev. D (accepted) Guidance signals applied to the system MCMC parameter estimation

46

slide-47
SLIDE 47

GW detection - M. Nofrarias ICE 02/07/18

LISA Pathfinder: tracking spacetime

47

slide-48
SLIDE 48

GW detection - M. Nofrarias ICE 02/07/18

LISA Pathfinder launch campaign

48

slide-49
SLIDE 49

GW detection - M. Nofrarias ICE 02/07/18

The Vega launcher

  • P80: Vega’s first stage is powered by a large single-piece solid rocket motor

containing 87,710 kg. of HTPB 1912 solid propellant. This solid rocket motor delivers maximum vacuum thrust of 3,015 kN and burns for 110 seconds prior to being jettisoned at an altitude of about 55 km.

49

  • ZEFIRO: Vega’s second and third stages use

Zefiro solid rocket motors. These two stages, each 1.9 meters in diameter, The Zefiro-Z23 stage is 8.39 meters long, and is loaded with 23,820 kg. of HTPB 1912 solid propellant, providing maximum vacuum thrust of 1,120 kN. It operates for 77 seconds in average.

  • AVUM (Attitude & Vernier Upper Module) has a

bipropellant propulsion system to provide orbital injection, and a monopropellant propulsion system for roll and attitude control. It is designed to inject different payloads into different orbits, and ensures the fine pointing of satellites prior to separation. The AVUM contains about 577 kg. of liquid propellant (UDMH/NTO), distributed in four tanks. It is powered by an engine derived from the re-ignitable RD-869, providing 2.45 kN of thrust. It also has two sets of three monopropellant thrusters to control roll and attitude.

slide-50
SLIDE 50

GW detection - M. Nofrarias ICE 02/07/18

Cruise phase to L1

50

slide-51
SLIDE 51

GW detection - M. Nofrarias ICE 02/07/18

LISA Pathfinder results: free fall

51

Armano et al. (LPF collaboration) Sub-femto-g free fall for space-based gravitational wave observatories: LISA pathfinder results. Phys. rev. lett. 116 (2016)

Brownian Interferometer noise Force on test mass and artifacts

LISA pathfinder appreciably constrains collapse models

  • Phys. Rev. D 95, 084054

Experimental bounds on collapse models from gravitational wave detectors

  • Phys. Rev. D 95, 084054
slide-52
SLIDE 52

Thermo-elastic modelling workshop 52

LISA Pathfinder results: free fall

SMBH merge (M = 5 x 106, z=2) f = 0.02 mHz: 35d before coalesce (SNR 50) f = 0.8 mHz: coalescence (SNR 1400) Armano et al. (LPF collaboration) Beyond required LISA free-fall performance: new LISA Pathfinder results down to 20 μHz Phys. Rev. Lett. 120 (2018)
