Detecting Unknown Network Attacks using Language Models Konrad Rieck and Pavel Laskov DIMVA 2006, July 13/14 Berlin, Germany The zero-day problem How to distinguish normal from unknown ? GET /dimva06/john/martin.html Accept: */*

slide-1
SLIDE 1

Detecting Unknown Network Attacks using Language Models

Konrad Rieck and Pavel Laskov DIMVA 2006, July 13/14 Berlin, Germany

slide-2
SLIDE 2

The zero-day problem

  • How to distinguish normal from unknown?

GET /scripts/..%%35c../..%%35c../..%%35c../..%%35c %%35c../winnt/system32/cmd.exe?/c+dir+c:\ HTTP/1.0 Host: www Connection: close

  • Cast intrusion detection into linguistic problem
  • Utilization of machine learning instruments

GET /dimva06/john/martin.html Accept: */* Accept-Language: en Host: www Connection: keep-alive

slide-3
SLIDE 3

N-gram models

ge et t▯

▯/

in nd

⋯

/i

2-grams

get▯/index.html

Connection payload

g e t

▯

i n

⋯

/

Bytes

get et▯ t▯/

▯/i

ind nde

⋯

/in

3-grams ⋯ n-grams

slide-4
SLIDE 4

N-grams in attacks

!0.02 !0.01 0.01 0.02 0.03 0.04 0.05 4!grams frequency difference Nimda IIS attack and HTTP traffic comparison

GET /scripts/..%%35c../..%%35c../..%%35c../..%%35c %%35c../winnt/system32/cmd.exe?/c+dir+c:\ HTTP/1.0

Frequency differences to 4-grams in normal HTTP

%%35

  • 35c. 5c..

c../ Acce cept

slide-5
SLIDE 5

Geometric representation

  • A simple example

0.005 0.01 0.05 0.005 0.01 0.015

Acce GET▯

GET▯ Acce %%35

0.005 0.01 0.05 0.005 0.01 0.015

%%35

HTTP pipelining Similarity of connections

  • Huge feature space
  • 256n dimensions
  • Geometric representation of connections
slide-6
SLIDE 6

Similarity measures

  • Distances, kernel functions, ... e.g.

k

  • w∈L |φw(x) − φw(y)|k
  • Minkowski
  • w∈L |φw(x) − φw(y)|
  • Manhattan
  • Efficient computation not trivial
  • Sparse representation of n-gram frequencies
  • Linear-time algorithms (cf. DIMVA 2006 paper)

x, y ∈ {0, . . . , 255}∗, L = {0, . . . , 255}n

φw(x) =

frequency of w in sequence x

slide-7
SLIDE 7

Anomaly detection

  • Detection of outliers in feature space
  • Exploration of geometry between connections
  • No training phase - no labels required
  • Anomaly detection (AD) methods
  • e.g. Spherical AD, Cluster AD, Neighborhood AD

0.2 0.4 0.6 0.8 1 0.2 0.4 0.6 0.8 1 Toy data 0.2 0.4 0.6 0.8 1 0.2 0.4 0.6 0.8 1 Toy data 0.2 0.4 0.6 0.8 1 0.2 0.4 0.6 0.8 1 Toy data 0.2 0.4 0.6 0.8 1 0.2 0.4 0.6 0.8 1 Spherical anomaly detection 0.2 0.4 0.6 0.8 1 0.2 0.4 0.6 0.8 1 Cluster anomaly detection 0.2 0.4 0.6 0.8 1 0.2 0.4 0.6 0.8 1 Neighborhood anomaly detection

slide-8
SLIDE 8

Experiments

  • Open questions
  • Do n-gram models capture semantics sufficient

for detection of unknown attacks?

  • Can anomaly detection reliably operate at low

false-positive rates?

  • How does this approach compare to classical

signature-based intrusion detection?

slide-9
SLIDE 9

Evaluation data

  • PESIM 2005 data set
  • Real network traffic to servers at our laboratory
  • HTTP

Reverse proxies of web sites

  • FTP

Local file sharing, e.g. photos, media

  • SMTP

Retransmission flavored with spam

  • Attacks injected by pentest expert (e.g. metasploit)
  • DARPA 1999 data set as reference
  • Statistical preprocessing
  • Extraction of 30 independent samples comprising

1000 incoming connection payloads per protocol

slide-10
SLIDE 10

Method comparison

  • Comparison of anomaly detection methods
  • Criteria: AUC0.01 - Area under ROC within [0, 0.01]
  • Results averaged over n-gram lengths [1,7]

Protocol Best method AUC0.01 HTTP Spherical (qsSVM) 0.781 FTP Neighborhood (Zeta) 0.746 SMTP Cluster (Single-linkage) 0.756 Bottom line: Different protocols require different anomaly detection methods

slide-11
SLIDE 11

N-gram lengths

  • How does one choose the optimal n-gram length?

0% 10% 20% 30% 40% 1 2 3 4 5 6 7 HTTP FTP SMTP

Optimal n-gram length per attack

  • No single n fits all: variable-length models required
slide-12
SLIDE 12

Variable-length models

index get html

Words

get▯/index.html

Connection payload

CR LF TAB ▯

, . : / &

Combined n-grams

g e t

▯

i n

⋯

/ ge et t▯

▯/

in nd

⋯

/i get et▯ t▯/

▯/i

ind nde

⋯

/in n = {1,2,3,...}

slide-13
SLIDE 13

Comparison with Snort

  • Language models vs. Snort
  • Combined n-gram (1-7) and word models
  • Snort: Version 2.4.2 with default rules

0.002 0.004 0.006 0.008 0.01 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 false positive rate true positive rate HTTP traffic Best combined Words Snort 0.002 0.004 0.006 0.008 0.01 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 false positive rate true positive rate FTP traffic Best combined Words Snort 0.002 0.004 0.006 0.008 0.01 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 false positive rate true positive rate SMTP traffic Best combined Words Snort

slide-14
SLIDE 14

Conclusions and outlook

  • Language models for intrusion detection
  • Characteristic patterns in normal traffic and attacks
  • Unsupervised nomaly detection with high accuracy
  • Detection of ~80% unknown network attacks
  • Future perspective
  • From in vitro to in vivo: real-time application
  • Language models as prototypes for signatures?
slide-15
SLIDE 15

Outwit language models

  • Approaches
  • Red herring

Denial-of-service with random traffic patterns

  • Creeping poisoning

Careful subversion of normal traffic model

  • Mimicry attacks

Adaption of attacks to mimicry normal traffic

  • Conclusions
  • (1) Worse for signature-based intrusion detection
  • (2,3) Requires profound insider knowlegde
slide-16
SLIDE 16

Questions?
