SLIDE 1

Designing Pop-Up Cards

Carleton Algorithms Seminar Zachary Abel, Erik D. Demaine, Martin L. Demaine, Sarah Eisenstat, Anna Lebiw, Andr´ e Schulz, Diane L. Souvaine, Giovanni Viglietta, Andrew Winslow Ottawa – November 29, 2013

(Figures and animations by Sarah Eisenstat and Andr´ e Schulz) Designing Pop-Up Cards

SLIDE 2

Pop-up cards

Pop-up cards (or books) are 3D paper models that fold flat with

ne degree of freedom.

(The Jungle Book: A Pop-Up Adventure, by Matthew Reinhart) Designing Pop-Up Cards

SLIDE 3

Pop-up cards

Pop-up cards (or books) are 3D paper models that fold flat with

ne degree of freedom.

Can every possible shape be modeled as a pop-up card, and how efficiently?

(The Jungle Book: A Pop-Up Adventure, by Matthew Reinhart) Designing Pop-Up Cards

SLIDE 4

Pop-up cards

Pop-up cards (or books) are 3D paper models that fold flat with

ne degree of freedom.

Can every possible shape be modeled as a pop-up card, and how efficiently? We are not concerned with practical realizability (e.g., paper thickness, feature size).

(The Jungle Book: A Pop-Up Adventure, by Matthew Reinhart) Designing Pop-Up Cards

SLIDE 5

Outline

2D orthogonal polygon pop-ups, O(n) links. 2D general polygon pop-ups, O(n2) links. 3D orthogonal polyhedron pop-ups, O(n3) links.

Designing Pop-Up Cards

SLIDE 6

2D model for pop-ups

Desired card Cross section 2D model

Designing Pop-Up Cards

SLIDE 7

Linkages

Linkages are formed by rigid bars and flexible joints. If bars intersect only at joints, the linkage configuration is called non-crossing. Three non-crossing configurations of a 7-bar linkage.

Designing Pop-Up Cards

SLIDE 8

More general joints

Common joint: • Flap: ◦ Sliceform: ×

Designing Pop-Up Cards

SLIDE 9

Everything is a joint

ε

Flap with joints Sliceform with flaps + joints

Designing Pop-Up Cards

SLIDE 10

Problem formulation

Input: 2D polygon P (unfolded shape),

ne distinguished vertex, n edges.

Designing Pop-Up Cards

SLIDE 11

Problem formulation

Input: 2D polygon P (unfolded shape),

ne distinguished vertex, n edges.

Output: linkage L with boundary P.

L folds to a line, L is non-crossing throughout, L has one degree of freedom.

(Pop-up designed using algorithm by Hara and Sugihara, 2009) Designing Pop-Up Cards

SLIDE 12

Problem formulation

Input: 2D polygon P (unfolded shape),

ne distinguished vertex, n edges.

Output: linkage L with boundary P.

L folds to a line, L is non-crossing throughout, L has one degree of freedom.

(Pop-up designed using algorithm by Hara and Sugihara, 2009) Designing Pop-Up Cards

SLIDE 13

Problem formulation

Input: 2D polygon P (unfolded shape),

ne distinguished vertex, n edges.

Output: linkage L with boundary P.

L folds to a line, L is non-crossing throughout, L has one degree of freedom.

(Pop-up designed using algorithm by Hara and Sugihara, 2009) Designing Pop-Up Cards

SLIDE 14

Orthogonal polygons

P orthogonal: every edge is either vertical or horizontal. Opening angle is 90◦ (angles 180◦, 270◦, and 360◦ are discussed later). Strategy: preserve parallelism throughout the motion (i.e., shearing motion).

Designing Pop-Up Cards

SLIDE 15

3-step construction

Subdivide P into horizontal stripes.

Designing Pop-Up Cards

SLIDE 16

3-step construction

Subdivide P into horizontal stripes. Model all degree-3 vertices as flaps.

Designing Pop-Up Cards

SLIDE 17

3-step construction

Subdivide P into horizontal stripes. Model all degree-3 vertices as flaps. Enforce a 1-dof motion by adding vertical bars connected by sliceforms.

Designing Pop-Up Cards

SLIDE 18

Larger opening angle

Strategy: combine the 90◦ shearing motions. Need to “reflect” the shear.

Designing Pop-Up Cards

SLIDE 19

Reflector gadget

The top part keeps vertical lines parallel. The two kites are similar and force the left and right halves to move symmetrically.

4 1 2 2 2 4 1

Designing Pop-Up Cards

SLIDE 20

Reflector gadget

The top part keeps vertical lines parallel. The two kites are similar and force the left and right halves to move symmetrically.

Designing Pop-Up Cards

SLIDE 21

Synchronizing shears

Cut P along the x and y axes. Reconnect the 90◦ solutions via reflector gadgets.

Designing Pop-Up Cards

SLIDE 22

Result

The resulting structure has complexity O(n).

Designing Pop-Up Cards

SLIDE 23

Result

The resulting structure has complexity O(n).

Designing Pop-Up Cards

SLIDE 24

General polygons: V-folds

Outward V-fold: sum of adjecent edges is the same.

4 3 2 1

Designing Pop-Up Cards

SLIDE 25

General polygons: V-folds

Outward V-fold: sum of adjecent edges is the same.

Designing Pop-Up Cards

SLIDE 26

General polygons: V-folds

Outward V-fold: sum of adjecent edges is the same. Inward V-fold: sum of

pposing edges is the same.

4 3 2 1

Designing Pop-Up Cards

SLIDE 27

General polygons: V-folds

Outward V-fold: sum of adjecent edges is the same. Inward V-fold: sum of

pposing edges is the same.

Designing Pop-Up Cards

SLIDE 28

Nested V-folds

Lemma The closing motion of nested outward (resp. inward) V-folds intersects only in the end configuration.

Designing Pop-Up Cards

SLIDE 29

Nested V-folds

Lemma The closing motion of nested outward (resp. inward) V-folds intersects only in the end configuration.

Designing Pop-Up Cards

SLIDE 30

Nested V-folds

Lemma The closing motion of nested outward (resp. inward) V-folds intersects only in the end configuration.

Designing Pop-Up Cards

SLIDE 31

Nested V-folds

Lemma The closing motion of nested outward (resp. inward) V-folds intersects only in the end configuration.

Designing Pop-Up Cards

SLIDE 32

Nested V-folds

Lemma The closing motion of nested outward (resp. inward) V-folds intersects only in the end configuration.

Designing Pop-Up Cards

SLIDE 33

Cell decomposition

Designing Pop-Up Cards

SLIDE 34

Cell decomposition

Draw a ray from the fold to every vertex in P.

Designing Pop-Up Cards

SLIDE 35

Cell decomposition

Draw a ray from the fold to every vertex in P. Make outward V-folds for all edges between rays.

Designing Pop-Up Cards

SLIDE 36

Cell decomposition

Draw a ray from the fold to every vertex in P. Make outward V-folds for all edges between rays.

Designing Pop-Up Cards

SLIDE 37

Cell decomposition

Draw a ray from the fold to every vertex in P. Make outward V-folds for all edges between rays. Every wedge can be folded flat, but there are too many dof!

Want: wall segments rotate around fold. Want: wedge motions be synchronized.

Designing Pop-Up Cards

SLIDE 38

Restricting to rotations

For each pair of wall segment in an internal cell:

Designing Pop-Up Cards

SLIDE 39

Restricting to rotations

For each pair of wall segment in an internal cell:

Add two parallel segments.

Designing Pop-Up Cards

SLIDE 40

Restricting to rotations

For each pair of wall segment in an internal cell:

Add two parallel segments. Add two parallelograms to get two outward V-folds.

Designing Pop-Up Cards

SLIDE 41

Restricting to rotations

For each pair of wall segment in an internal cell:

Add two parallel segments. Add two parallelograms to get two outward V-folds.

Result: wall segments rotate around the apex.

Designing Pop-Up Cards

SLIDE 42

Restricting to rotations

For each pair of wall segment in an internal cell:

Add two parallel segments. Add two parallelograms to get two outward V-folds.

Result: wall segments rotate around the apex.

Designing Pop-Up Cards

SLIDE 43

Restricting to rotations

For each pair of wall segment in an internal cell:

Add two parallel segments. Add two parallelograms to get two outward V-folds.

Result: wall segments rotate around the apex. (Leaf cells are handled separately.)

Designing Pop-Up Cards

SLIDE 44

Synchronizing wedges

Strategy: link neighboring cells with with a gadget that synchronizes the independent motions of the wedges.

Designing Pop-Up Cards

SLIDE 45

Synchronizing wedges

Strategy: link neighboring cells with with a gadget that synchronizes the independent motions of the wedges. Basic sync gadget: inward V-fold + outward V-fold.

Designing Pop-Up Cards

SLIDE 46

Synchronizing wedges

Strategy: link neighboring cells with with a gadget that synchronizes the independent motions of the wedges. Basic sync gadget: inward V-fold + outward V-fold. The basic sync gadget has a 1-dof motion that makes all the cells in the same wedge fold at the same speed.

Designing Pop-Up Cards

SLIDE 47

Fitting the sync gadget

Designing Pop-Up Cards

SLIDE 48

Folding leaf cells

For cells with only one wall, use two sync gadgets and no rotation gadget.

Designing Pop-Up Cards

SLIDE 49

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 50

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 51

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 52

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 53

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 54

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 55

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 56

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 57

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 58

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 59

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 60

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 61

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 62

Result

The resulting structure has complexity O(n2).

Designing Pop-Up Cards

SLIDE 63

3D (orthogonal) model for pop-ups

Input: orthogonal polyhedron P, one distinguished edge. Output: set of hinged rigid sheets of paper that folds from P to a flat state with a 1-dof motion.

Designing Pop-Up Cards

SLIDE 64

3D (orthogonal) model for pop-ups

Input: orthogonal polyhedron P, one distinguished edge. Output: set of hinged rigid sheets of paper that folds from P to a flat state with a 1-dof motion. Bellows theorem: every flexible polyhedron has the same volume in all configurations.

We must cut the boundary.

Designing Pop-Up Cards

SLIDE 65

Cutting into slices

Use the 3D grid induced by the vertices of P. Create slices perpendicular to the crease.

Each slice is a 2D linkage problem.

Designing Pop-Up Cards

SLIDE 66

Pinwheel construction

For each cross section, construct a pinwheel-pattern linkage, enforcing a 1-dof shearing motion.

Designing Pop-Up Cards

SLIDE 67

Pinwheel construction

For each cross section, construct a pinwheel-pattern linkage, enforcing a 1-dof shearing motion. Extrude each cross section to get a 3D model for a slice of P.

Designing Pop-Up Cards

SLIDE 68

Putting slices together

Fuse paper in adjacent slices.

But we still have holes on the sides...

Designing Pop-Up Cards

SLIDE 69

Closing holes

Add two hinged sheets of paper to close each hole. Just the left and bottom sides are hinged to the rest of the structure.

Designing Pop-Up Cards

SLIDE 70

Closing holes

Add two hinged sheets of paper to close each hole. Just the left and bottom sides are hinged to the rest of the structure.

Designing Pop-Up Cards

SLIDE 71

Closing holes

Add two hinged sheets of paper to close each hole. Just the left and bottom sides are hinged to the rest of the structure.

Designing Pop-Up Cards

SLIDE 72

Closing holes

Add two hinged sheets of paper to close each hole. Just the left and bottom sides are hinged to the rest of the structure.

Designing Pop-Up Cards

SLIDE 73

Closing holes

Add two hinged sheets of paper to close each hole. Just the left and bottom sides are hinged to the rest of the structure.

Designing Pop-Up Cards

SLIDE 74

Closing holes

Add two hinged sheets of paper to close each hole. Just the left and bottom sides are hinged to the rest of the structure.

Designing Pop-Up Cards

SLIDE 75

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 76

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 77

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 78

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 79

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 80

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 81

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 82

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 83

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 84

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 85

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 86

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 87

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 88

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 89

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 90

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 91

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 92

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 93

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 94

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 95

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 96

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 97

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 98

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 99

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 100

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 101

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 102

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 103

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 104

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 105

Result

The resulting structure has complexity O(n3).

Designing Pop-Up Cards

SLIDE 106

Summary

O(n) solution for orthogonal polygons. O(n2) solution for general polygons. O(n3) solution for orthogonal polyhedra. Open problems: Can every polyhedron be a pop-up? Are our solutions optimal? Practical concerns:

Paper thickness? Paper flexibility? Feature size?

Designing Pop-Up Cards

SLIDE 107

References

Z. Abel, E.D. Demaine, M.L. Demaine, S. Eisenstat, A. Lubiw,
A. Schulz, D.L. Souvaine, G. Viglietta, and A. Winslow

Algorithms for designing pop-up cards STACS 2013

T. Hara and K. Sugihara

Computer-aided design of pop-up books with two-dimensional v-fold structures JCCGG 2009

R. Uehara and S. Teramoto

The complexity of a pop-up book CCCG 2006

Designing Pop-Up Cards
