Designing Overhead Transmission Systems for Grid Resiliency Gary B Huffman Jr CLIENTS WE SERVE 1 1 14 18 Tran ansmissi smission on Power er Top op P Prog ogram am Top op 500 500 & & Distri Distribu bution tion
SLIDE 2
SLIDE 3
Tran ansmissi smission
- n
& & Distri Distribu bution tion Power er Top
- p P
Prog
- gram
am Mana Manage gemen ment Fir irms ms Top
- p 500
500 Design Design Fir Firms ms
I N D U S T R Y R A N K I N G S
14 18 1 1
Engineering News-Record
PS PSMJ MJ Pr Premier mier Aw Awar ard d for
- r Cli
Clien ent t Sa Satisf tisfac action tion Fortu tune Ma Magazine zine Best Best Comp Compan anies ies to to W Wor
- rk
k For
- r
C O M P A N Y A W A R D S
16
SLIDE 4
D e s i g n i n g O ve r h e a d Tr a n s m i s s i o n S y s t e m s f o r G r i d Re s i l i e n c y
► Why
hy Resilienc esiliency? y?
► Def
Defining ining Resilienc esiliency
► Regula
gulator tory y Polic
- licy
y Guida uidance nce
► Design
Design Str Strate tegies gies to to Consider Consider
► Q&A
&A
SLIDE 5
D e s i g n i n g O ve r h e a d Tr a n s m i s s i o n S y s t e m s f o r G r i d Re s i l i e n c y
Why Resiliency
►
Weather Events
►
Hurricanes
►
Fires
►
Floods & Storm Surge
►
Operational Events
►
Cascading Faults
►
Redundancy limitations
►
Less Rigorous Design Criteria
►
Security Events
►
Physical
►
Cyber
►
Economic Stimulus
SLIDE 6
Re g u l at o r y Po l i cy G u i d a n c e
The Commission places a priority on resilience, and today issued an order initiating a new proceeding (Docket No. AD18-7-000) to holistically examine the resilience of the bulk power system. The Commission recognizes that it must remain vigilant with respect to resilience challenges, because affordable and reliable electricity is vital to the country’s economic and national security.
SLIDE 7
D e s i g n i n g O ve r h e a d Tr a n s m i s s i o n S y s t e m s f o r G r i d Re s i l i e n c y
Wha hat t is is Resilienc esiliency? y?
FERC has proposed that resilience means the “ability to withstand and reduce the magnitude and/or duration of disruptive events, which includes the capability to anticipate, absorb, adapt to, and/or rapidly recover from such an event.”
Credit: Utility Dive Feb 2, 2018 by Kate Konschnik and Brian Murray
- Prevent Impacts
- Survivability
- Recovery
SLIDE 8
D e s i g n i n g O ve r h e a d Tr a n s m i s s i o n S y s t e m s f o r G r i d Re s i l i e n c y
High Level Resiliency Program Considerations
- Event Prevention:
- Upgrade Design standards
- Improve Construction guidelines
- Prioritize & Improve Maintenance routines and Inspection procedures
- Event Survivability: - Ability to maintain some basic level of electrical system functionality
- Identify key system components
- Communications with Customers / Agencies / IC Team
- Critical Infrastructures - traffic signals, prisons, hospitals, and cell phones
- Design to Survive diverse events
- Distributed Generation considerations – Microgrids
- Design Rigor
- Scenario Planning
- Event Recovery:
- Rapid Damage Assessment
- Prompt crew deployment / Crew & Equipment Staging
- Material Readiness
- Crew Routing
- Mutual Assistance agreements – Incident Command System
SLIDE 9
D e s i g n i n g O ve r h e a d Tr a n s m i s s i o n S y s t e m s f o r G r i d Re s i l i e n c y
High Level Resiliency Program Considerations
“Prevention”
- Upgrade Design standards
- Windloading Requirements
- 165 mph extreme event loading
- Foundation strategies
- Materials Upgrades – Concrete vs Wood
- 100 Year Flood Criteria
- Elevating equipment
- Undergrounding
- Flood monitoring
- OPGW – dedicated protection & communications
- Data Collection – Sensors
- Automation
- Improve Construction guidelines
- Prioritize & Improve Maintenance routines and Inspection procedures
SLIDE 10
D e s i g n i n g O ve r h e a d Tr a n s m i s s i o n S y s t e m s f o r G r i d Re s i l i e n c y
High Level Resiliency Program Considerations
“Survivability”
- Ability to maintain some basic level of electrical system functionality
►
Communications with Customers / Agencies / IC Team
►
Identification of Critical Community Infrastructure - traffic signals, prisons, hospitals, and cell phones
►
Identification of Critical Utility Infrastructure - Data & Controls
- Distributed Generation Integration
►
Renewable Sources
►
Storage
►
Traditional Solutions? Back-up Generation – Diesel?
►
Distribution Grid Modernization
►
Sectionalizing & Self Healing Automation – FLISR
►
Smart Inverter Standards – IEEE 1547
►
Adaptive Relaying
SLIDE 11
D e s i g n i n g O ve r h e a d Tr a n s m i s s i o n S y s t e m s f o r G r i d Re s i l i e n c y
High Level Resiliency Program Considerations
“Recovery”
- Rapid Damage Assessment
- Helicopter technology
- Drone program
- SCADA & Sensor – Data Analytics
- Prompt crew deployment / Crew & Equipment Staging
- Standard Work Order preparation
- ERP Work Order / Material Management processes
- Material Readiness
- ERP Work Order / Material Management processes
- Partnerships with Material Vendors
- Crew Routing
- Mutual Assistance agreements – Incident Command System
SLIDE 12
D e s i g n i n g O ve r h e a d Tr a n s m i s s i o n S y s t e m s f o r G r i d Re s i l i e n c y
Case Study: FP&L Data Capabilities
