Dedicated Cloud Access

Customer Presentation June 2018

Start presentation

State Of Cloud Adoption

93%

Organizations currently using Cloud Services

15 Months

For cloud spending to account for 80% of IT budgets

3X

Hybrid cloud adoption grew 3X in the 2017, increasing from 19% to 57%.

73%

• f companies

planning to move to a fully software-defined data center within 2 years.

Source Forbes: 2017-04 State Of Cloud Adoption And Security

Enterprises need a secure and reliable cloud connectivity experience

Cloud Connectivity Requirements

Customers want a more secure and reliable cloud networking experience – the public internet does not always provide this 1

SECURITY

2

LATENCY

With Enterprises shifting their core infrastructure and services to Cloud, security has become number one priority for Cloud connectivity Deterministic latency is important for mission critical services that Enterprises are moving to Cloud

any other connected CSP

85% 70%

3

THROUGHPUT

High throughput is another key requirement that helps Customers get the best out of their Cloud platform

65%

4

RELIABLE

Reliability of private connectivity services makes it an obvious choice for most customers looking to get the best out of their Cloud platform

60% Source IDC: Cloud Computing

Colt’s Dedicated Cloud Access (DCA)

4

DCA connects customers to the major public cloud providers in Europe, Asia and to USA in near future DCA is NOT a cloud resell service

DCA to Cloud – What services are supported?

Ethernet IP-VPN (MPLS) Ethernet + Managed router

Standard for all CSP’s

Standard for AWS & Azure, on request for all other CSP’s Standard for AWS & Azure, on request for all other CSP’s

Overview – Cloud Provider Network Access Cities

DCA Commercial Structure

Presentation title

Enterprise customer has 2 independent SLA / Bill / Helpdesk

Internet (before dedicated connectivity) Using Colt DCA Cloud Provider (AWS, Azure etc.) CSP service charges (e.g. AWS EC2) Internet traffic (e.g. €0.09 / GB) No port fee Content charges (e.g. AWS EC2) Traffic (e.g .~€0.02 / GB) Private network port (e.g. ~€211 MRC for 1Gbps) Carrier Customer may have 3rd party internet service DCA service

3 No change Much lower New 1 2

Dedicated Cloud Access

Dedicated Cloud Access contract Colt invoices for…

3

CSP private network/port traffic charges Content charges

2 1

Cloud Service Providers invoices for … And other CSP’s

Why Colt DCA?

• With 250+ DCA customers in

Europe & Asia

• Multiple direct NNI with Cloud

providers

• Connect to the nearest Cloud

PoP or through our extensive network connecting 25K+ buildings in 28 countries Expertise and Coverage

• Guaranteed service quality with

industry-leading SLAs covering Delivery, Fault Handling, Availability, Frame loss, Latency and Jitter

• Fully protected network

backbone offering unmatched resiliency and maximum up-time

• DCA services are deployed on

same network infrastructure that trusted by the financial industry for their mission-critical data

• Colt operates one of the best

low latency networks, allowing data to move over the optimum latency paths Security and low latency Scalability and flexibility Resilient network

• Bandwidth upgrades are

seamless, with no interface changes or work required

• With Dedicated Cloud Access

On-Demand, you get a leading ‘real-time’ and ‘pay per use’ cloud connectivity service that matches the benefits of the IT Cloud providing the first all-in-

• ne cloud experience end to end

DCA for Amazon Web Services (AWS)

AWS regions & network access PoPs

EU Ireland

A A A A A A A A A

EU Frankfurt

A A

Asia Pacific (Singapore)

A A

Asia Pacific (Tokyo)

Europe Asia Pacific Customers can now also access other Amazon regions, through the AWS Gateway Equinix LD5 & DRT London support both access to the EU Ireland EU London regions

Eircom Dublin Interxion Dublin Equinix LD5 Equinix FR5 Interxion FRA6 Interxion Madrid Interxion Stockholm Equinix AMS3 Direct Connect PoP – Colt connected

Asia Pacific (Seoul)

A A

Direct Connect PoP - Colt not yet connected Equinix SG2

A

Global Switch Equinix OS1 Equinix TY2 Amazon cloud region

EU London Asia Pacific (Hong Kong)

A

London DRT Telehouse Paris

EU Paris

A

AWS Cloud PoP locations

Note: Colt is also able to offer connectivity to a number of US locations for AWS Direct Connect: Dedicated port. Please contact your account manager for more information.

Network Access (carrier) PoP Network Access PoP Address AWS Region

Eircom Clonshaugh (Dublin) Clonshaugh Industrial Estate DUB 17 EU Ireland Dublin Interxion Unit 24, Park West Business Park Hume Avenue, Dublin 12 EU Ireland London Digital Realty (Sovereign House) Sovereign House, 227 Marsh Wall London E14 9SD EU Ireland & EU London London Equinix LD5 8 Buckingham Avenue, Slough SL1 4AX EU Ireland & EU London Frankfurt Equinix FR5 Equinix FR5, Kleyerstraße 90, Frankfurt 60326 EU Frankfurt Frankfurt Interxion FRA06 Interxion FRA06, 300 Hanauer Landstrasse, Frankfurt 60314 EU Frankfurt Amsterdam Equinix AM3 Science Park 610, 1098 XH Amsterdam EU Frankfurt Paris Telehouse Voltaire Paris, Ile-de-France, 75011, France EU Paris Madrid Interxion Interxion MAD02, 71-73 Calle Albasanz, Madrid 28037 EU Frankfurt Stockholm Interxion 11 Esbogaten, Stockholm 16474 EU Frankfurt Singapore Equinix SG2 Pioneer Walk Singapore 62775315 Asia Pacific (Singapore) Singapore Global Switch 2 Tai Seng Avenue, Singapore 534408 Asia Pacific (Singapore) Tokyo Equinix TY2 3-8-21 Higashi Shinagawa, Shinagawa-ku, Tokyo 140-0002 Asia Pacific (Tokyo) Osaka Equinix OS1 Nishi Shinsaibashi Building, 1-26-1 Shinmachi Nishi-ku, Osaka City, Osaka 550-0013, Japan Asia Pacific (Tokyo) Eircom Clonshaugh (Dublin) Clonshaugh Industrial Estate DUB 17 EU Ireland Dublin Interxion Unit 24, Park West Business Park Hume Avenue, Dublin 12 EU Ireland

AWS Direct Connect

• AWS Direct Connect program was launched by Amazon to help their customers reduce their network costs, increase

bandwidth throughput, and provide a more consistent and secure network experience than Internet-based connections.

• Under Direct Connect, customers can establish private connectivity between AWS and their datacenter, office, or colocation

environment. Hosted Dedicated

• Bandwidth between 50M & 500M
• Single BGP session / VLAN, multiple VPCs on the same

port (some regions offer single BGP/VLAN/VPC, being upgraded)

• Ideal for cost optimization
• Leased line connection at minimal cost
• On DCA-NNI
• Dedicated 1G/10G port with AWS (Colt bandwidth 50M-

10G)

• Multiple BGP sessions, VLANs, multiple VPCs on the

same port

• Ideal for sharing across multiple departments
• Built to handle large volume data
• Colt offers cross-connect to dedicated port (also in US)

Anything beyond the AWS Direct Dedicated Port is handled by Amazon Web Services.

AWS Direct Connect dedicated port

N x VPC VLAN VLAN VLAN

Colt Network

Covered by Colt SLA CPE Router N x VPC N x VPC Anything beyond the AWS Direct Connect hosted Port is handled by Amazon Web Services.

AWS Direct connect: DCA-NNI port

VLAN

Colt Network

Covered by Colt SLA CPE Router N x VPC

Two Direct Connect options:

AWS Bandwidth Options and Charges

Colt Bandwidth Connection into AWS Physical cross connect required? Ethernet IP VPN 10/50/100/200/300/400/500Mbps Hosted connection (50/100/200/300/400/500Mbps) No Yes Yes 1 or 10 Gbps Dedicated 1G or 10G port Yes Yes No 10/50/100/200/300/400/500Mbps Dedicated 1G or 10G port Yes Yes No

Fee structure: AWS fees are based on connection ports and data volume. Charges depend on the number of physical ports used and data volume over the network.

Pricing as of June 2017. For the latest pricing details see here

Port Speed Port-Hour Rate (All Regions except Japan) Port-Hour Rate in Japan 50M $0.03/hour $0.029/hour 100M $0.06/hour $0.057/hour 200M $0.12/hour $0.114/hour 300M $0.18/hour $0.171/hour 400M $0.24/hour $0.228/hour 500M $0.30/hour $0.285/hour 1G $0.30/hour $0.285/hour 10G $2.25/hour $2.142/hour

Port charges Pricing is per port-hour for all AWS Direct Connect locations. Data Transfer

• In is $0.00 per GB in all locations.
• Out is as below

Location (few examples) Data Transfer OUT Eircom, Dublin $0.02 per GB Equinix, LD4-6, London $0.02 per GB for London, $0.03 per GB for London Equinix, FR4-5, Frankfurt $0.02 per GB Global Switch, Singapore $0.045 per GB

AWS Customer Use Case

7/12/2018

AWS POPs Customer DC locations

UK1 DUB LON UK2 FRA NL1 AMS TKY HK SIN SG1

• Customer runs internationally renowned search engine
• Website is 100% based on Amazon cloud
• High volume of traffic meant that Direct Connect was only viable option
• Colt provided multiple links into cloud regions in Europe and Asia

Colt DCA – AWS Competency

Colt moved from Advance partner towards Networking Competency partner

AWS Partner Competency Program: Colt has been recognized as an AWS Direct Connect Integrated Partner and an AWS Direct Connect Infrastructure partner, which is testament to the wide range of capabilities that we can offer to AWS customers in both Europe and in Asia. AWS Direct Connect Integrated Partners: Provide direct connectivity to AWS with hosted/port-based connections + some SDN features. AWS Direct Connect Infrastructure Partners: Provide network connectivity and infrastructure.

Colt is part of the AWS Networking Competency — the global APN Partner program that helps customers find the most qualified organizations with deep expertise and proven customer success. The AWS Networking Competency has been launched with 18 APN partners globally.

DCA for Microsoft Azure

Microsoft regions & network access PoPs

Europe Asia Pacific

North Europe

Microsoft regions are interconnected - i.e. customers can access all regions from a single PoP

(Germany regions are the exception – the two Germany regions are interconnected to each other but are isolated from the rest the Azure)

M M M

UK South UK West

M M M M

Germany central Germany Northeast ExpressRoute PoP – Colt connected ExpressRoute PoP – Colt not connected Microsoft Azure cloud region

M M

Japan East Japan West

M

East Asia

M

South East Asia Dublin London Berlin Singapore Paris Tokyo Osaka Frankfurt Newport

M

Amsterdam West Europe Hong Kong

M

Azure - Cloud PoP Locations

Network Access (carrier) PoP Network Access PoP Address Main Azure Region

London Equinix LD5 Microsoft Corporation (MC3), c/o Equinix LD5, 8 Buckingham Avenue, Slough Trading Estate, Slough Berkshire SL14AX Europe North, UK South Dublin Equinix DB3 Unit 2, Northwest Business Park, Dublin 15 Europe North Amsterdam Equinix AM5 Amsterdam AMS 5, Schepenbergweg 42, 1105 AT Amsterdam Zuidoost Europe West Frankfurt Interxion FRA08 Interxion FRA08, 36 Weismeullerstrasse, Frankfurt 60314 Germany East Paris Interxion PAR05 Interxion PAR05, 11-13 Avernue des Arts et Metirers, Paris, 93200 Europe West Tokyo Equinix TY4 North Tower, Otemachi Financial City, Otemachi 1-9-5 Chiyoda Ku, Tokyo 100- 004 Japan East

Microsoft ExpressRoute Overview

• Resilience – always made up of two parallel circuit paths
• Handover – handed over on dual NNIs between Colt and Azure

Key features Microsoft offers two commercial ExpressRoute options METERED ports Low fixed monthly commitment + PAYG traffic charges UNMETERED ports High fixed monthly commitment + no traffic charges

In either case, the Colt DCA service is based on a flat monthly fee Colt does not add traffic charges

Microsoft port size Colt service bandwidth L2: Ethernet point to point and Hub & spoke L3: Managed router & IP VPN 50Mbps 10/50 Mbps

Standard available Standard available

100Mbps 100 Mbps 200Mbps 200 Mbps 500Mbps 500 Mbps 1Gbps 1 Gbps 2Gbps 2 Gbps 5Gbps 5 Gbps 10Gbps 10 Gbps

Colt ExpressRoute Connectivity Features

• Resilience: ExpressRoute services are always made up of two parallel circuits. Handover
• ver dual NNIs between Colt and Azure.
• Routing domains: Customer can choose to enable one or two of the routing domains as part
• f their ExpressRoute circuit.

Key features

• Managed router – In addition to the standard Ethernet/layer 2 service, Colt can offer

a managed router at the customer site. This means that Colt manages the complexity

• f the ExpressRoute configuration
• IP address packages : Two different IP address packages

Optional features

Colt supports all 2 ExpressRoute routing (peering) domains

Public peering & Microsoft peering Private peering

Microsoft peering

• For access to Microsoft online services (such

as Office 365 services/CRM) will be through the Microsoft peering.

• Connect to Microsoft cloud services over public

IP addresses that are owned by customer or Customer’s connectivity provider

Public peering

• For access to services such as Azure Storage,

SQL databases and Azure Websites are

• ffered on public IP addresses.
• Privately connect to services hosted on public

IP addresses, through without having to connect through the internet.

Private peering

• For access to Azure compute services, namely

virtual machines (IaaS) and cloud services (PaaS), that are deployed within a virtual network can be connected through the private peering domain.

• The private peering domain is considered to be

a trusted extension of your core network into Microsoft Azure

Colt

Customer’s premises

DMZ/Extranet Internet edge Core network Firewall Microsoft recommends to have private peering connected directly to the customers’ core network, and the public and Microsoft peering links connected to their extranet

Through one network connectivity, Colt supports all the peering domains, without any additional charge Only Private Peering available in Asia.

Office 365 via ExpressRoute Overview

• Office 365 is available through all of the existing ExpressRoute PoPs
• All O365 opportunities require customers to engage with Microsoft:
• Each opportunity is subject to Microsoft deal approval
• Customers need to complete a network assessment
• Implemented via a 2nd routing domain within an ExpressRoute service –

does NOT require an additional order

• Based on Microsoft’s “Premium” ExpressRoute pricing option
• Colt can provide public IP address pack for O365 peering on request

ExpressRoute bandwidth: monthly charge by Microsoft

Port speed

Metered data plan Unlimited data plan

MRC Outbound data transfer rates MRC Outbound data transfer rate

50 Mbps €46.39 €0.0211 per GB €316.24 None 100 Mbps €92.77 €484.90 200 Mbps €122.28 €969.80 500 Mbps €244.56 €2,319.08 1 Gbps €367.68 €4,806.81 2 Gbps €735.36 €9,613.62 5 Gbps €1,838.40 €21,630.65 10 Gbps €4,216.50 €43,261.29

Metered Data plan

All inbound data transfer is free of charge, and all outbound data transfer is charged based on a pre-determined rate

Unlimited data plan

All inbound and outbound data transfer is free of charge. Users are charged a single fixed monthly port fee.

Inbound data transfer ( to Azure DC ) in both cases is Unlimited and is free Pricing as of June 2017. For the latest pricing details see here

Microsoft customer user case Based in Berlin, Munich, Hamburg, Frankfurt, Bremen and Braunschweig, the customer is a leading German engineering firm. Employing roughly 140 people, they develop fire protection systems for national and international construction projects ranging from office buildings to airports to football arenas. The Customer The customer wanted to replace their existing any-any it with a more efficient network that would meet its high security and performance requirements The customer asked Colt to implement a DCA solution to ensure secure, fast access to Microsoft Azure The Challenge The customer chose an Ethernet Hub & Spoke solution with managed layer 3 CPE :

• The main location was equipped with an existing hub with

redundant building feeds.

• In December 2014, two 200M Colt DCA spokes were added to

provide a connection to Microsoft Azure in Amsterdam

• Office 365 was added at a later stage

Solution The solution provides the customer with private, secure connectivity from their on-premises network to a flexible cloud service from Microsoft Azure. The solution allows the customer to scale up and down additional workloads in the Azure environment in line with their business demands, under a true hybrid model. Benefits

Hamburg Frankfurt Munich Berlin Amsterdam

DCA for Google

Google Cloud Interconnect (GCI) regions & network access PoPs

Europe Asia Pacific

I I

London Paris Frankfurt

I

Amsterdam

I I I I

Tokyo Hong Kong Singapore

Google worldwide regions are interconnected – Access to a Google location is not restricted E.g. customer in Frankfurt, will logically connect through Google Frankfurt PoP where they allocated cloud resources due to latency reasons. Asia Pacific locations will become available in Q4-’18

GCI PoP – Colt planned connectivity

I

Google region

Google Cloud Interconnect Partner - Cloud PoP locations

Name PoP’s Address Zones Region

Equinix FR4 Lärchenstraße 110, 65933 Frankfurt am Main, Germany Zone 1-2 Europe Global Switch 2 3 Nutmeg Ln, Poplar, London E14 2AX, UK Zone 2 Europe Equinix LD5 Slough Trading Estate, 8 Buckingham Ave, Slough SL1 4AX, UK Zone 1 Europe Equinix AM3 Science Park 610, 1098 XH Amsterdam, Netherlands Zone 2 Europe Equinix AM5 Schepenbergweg 42, 1105 AT Amsterdam-Zuidoost, Netherlands Zone 1 Europe Paris Interxion PA7 Rue Rateau 3, 93120, La Courneuve, Paris, France Zone 1 Europe Paris Global Switch 7-9 Rue Petit, 92582 Clichy, France Zone 2 Europe Available Q4: Mega iAdvantage, Hong Kong 399 Chai Wan Rd, Chai Wan, Hong Kong Zone 1 Asia Available Q4: Equinix HK1, Hong Kong 17/F, Global Gateway (Hong Kong), 168 Yeung Uk Road, Tsuen Wan, Hong Kong Zone 2 Asia Available Q4: Equinix TY2, Tokyo 3 Chome-8-21 Higashi Shinagawa, Shinagawa, Tokyo 140-0002 Zone 2 Asia Available Q4: ComSpace I, Tokyo 1 Chome-5-3 Nihonbashi Horidomecho, Chūō, Tokyo 103-0012 Zone 1 Asia Available Q4: Equinix SG3, Singapore 26A Ayer Rajah Crescent, Singapore 139963 Zone 1 Asia Available Q4: Global Switch, Singapore 2 Tai Seng Ave, Singapore 534408 Zone 2 Asia

Google Cloud Interconnect Partner

Provides connectivity between a customer on-premise network and the Google Cloud network edge, allowing the customer to extend their private network into their cloud network - the physical connectivity between Colt and Google Cloud is already in place and hosted to customers. Please note that Google Cloud Interconnect Partner is currently in Beta, and General Availability of the Google service is expected in June. Currently Google Cloud Interconnect Partner services are provided without Google SLA. Please check with your Google account manager for further information.

Customer Interconnection location

Anything beyond the Cloud shared Port is handled by the CSP.

DCA-NNI port

VLAN

Colt Network

Covered by Colt SLA CPE Router

1 x VPC

• Based on Single BGP peering / VLAN
• Ideal for cost optimization
• Leased line connection at minimal cost
• On shared DCA-NNI

Google Cloud Interconnect Partner services and options

Google Cloud Interconnect Colt Service Bandwidth CSP Bandwidth 10Mbps 50Mbps 50Mbps 50Mbps 100Mbps 100Mbps 200Mbps 200Mbps 300Mbps 300Mbps 400Mbps 400Mbps 500Mbps 500Mbps 1Gbps 1Gbps 2Gbps 2Gbps 5Gbps 5Gbps 10Gbps 10Gbps

• Colt has connected most Google Cloud PoP’s in Europe. Cloud PoP interconnections available in: Frankfurt, London,

Amsterdam and Paris. Asia follows in Q4-’18.

• Colt can provide Cloud PoP diversity in each city – Interconnects are established in two different metro locations in:

Amsterdam, London and Paris. In Frankfurt 2x interconnects within the same Cloud PoP location.

• Only the private domain can be reached (no public IP’s required/no internet access required) supporting the following

Google services

• Cloud Spanner, Google Cloud BigQuery, Google Cloud Bigtable, Google Cloud Dataproc, Google Cloud Datastore,

Google Cloud Pub/Sub, Google Cloud Storage

• Available topologies Layer 2:
• Point to point
• Hub and spoke
• Overview of Colt and

CSP bandwidth options

Google Cloud Interconnect - Dedicated option

Google Cloud Interconnect - Dedicated (a Dedicated Interconnect) provides direct physical connections between your on-premises network and Google’s network

Dedicated

• Dedicated 10G port only with Google
• Colt bandwidth 1-2-5-10Gbps
• Multiple BGP session, VLANs, multiple VPCs on the

same port

• Ideal for sharing across multiple departments
• Built to handle large volume data
• Colt offers cross-connect to dedicated port

Name PoP’s Address Zone(s) Region GCI partner GCI dedicated

Equinix AM5 Schepenbergweg 42 1105AT Amsterdam Netherlands 1 Europe x x Equinix AM3 Science Park 610 1098 XH Amsterdam Netherlands 2 Europe x x Interxion Hanauer Landstraße 298 60314 Frankfurt Germany 1 Europe x e-shelter Frankfurt 1 Eschborner Landstraße 100 60489 Frankfurt Germany 1-2 Europe x Equinix FR4 Lärchenstraße 110 65933 Frankfurt Germany 1 Europe x x Global Switch London 2 Nutmeg Lane 3 E14 2AX London United Kingdom 2 Europe x x Equinix LD5 Slough Trading Estate, 8 Buckingham Ave, 8 SL1 4AX Slough United Kingdom 1 Europe x x Interxion MRS1 Avenue Roger Salengro 40 13003 Marseille France 1 Europe x Interxion PAR7 Rue Rateau 3 93120 La Courneuve France 1 Europe x x Global Switch Rue Petit 7-9 92110 Clichy France 2 Europe x x Equinix MU1 Seidlstrasse 3 80335 Munich Germany 1-2 Europe x Interxion STO1 Esbogatan 11 164 74 Kista Sweden 1 Europe x Equinix SK1 Mariehällsvägen 36 16865 Bromma Sweden 2 Europe x ComSpace I ComSpace Bldg.

• Tokyo

Japan 1 Asia X (Q4-’18) x Equinix TY2 Higashi-Shinagawa Shinagawa-ku 3-8-21 140-0002 Tokyo Japan 2 Asia X (Q4-’18) x Global Switch Singapore TAI SENG AVENUE 2

• Singapore

Singapore 1 Asia X (Q4-’18) x Equinix SG3 Ayer Rajah Crescent 26A 139963 Singapore Singapore 2 Asia X (Q4-’18) x MEGA-i Chai Wan Road Chai Wan 399

• Hong Kong

Hong Kong 1 Asia X (Q4-’18) x Equinix HK2 Shing Yiu Street 3

• Hong Kong

Hong Kong 2 Asia X (Q4-’18) x

Google Cloud Interconnect (GCI) - Commercial Structure

Dedicated Cloud Access

Colt invoices for…

CSP private network charges per port / data rate plan

Cloud Service Providers invoices for …

• Google has four continental regions (Europe, North America, Asia and Australia), where

within the region lower egress cost applies

• For interconnecting to other regions, Google applies higher egress costs:

https://cloud.google.com/interconnect/pricing

• Google SLA will be available in June ‘18 (GA of Google Cloud Interconnect)

Google Cloud Interconnect (GCI) - resilience & diversity options

Google standard service (1 DCA connection) Google NNI diversity in same Cloud PoP (2 DCA connections) Google PoP diversity (2 DCA connections)

Different PoPs in same city (e.g. AMS, LND, PAR) Same PoP in same city (e.g. FF)

Both protected and unprotected resilience is supported, Gold and Platinum access resilience is not supported, 2 physical circuits need to be ordered):

Customer building Google Cloud PoP Google Cloud PoP A – Zone 1 Google Cloud PoP B – Zone 2 Google Cloud PoP A (Zone 1) Google Cloud PoP A (Zone 2) Customer building Customer building

DCA for IBM

IBM Direct Link regions & network access PoPs

Europe Asia Pacific

I I

London Paris Frankfurt

I

Amsterdam

I I I I

Tokyo Hong Kong Singapore

IBM regions are interconnected – i.e. customers can access all regions from a single PoP with Global routing option. Asia Pacific locations will become available in Q3-’18

DirectLink PoP – Colt planned connectivity

I

IBM Cloud region

IBM Direct Link Connect - PoP locations

Network Address POPs Address Region

InterXion FRA6 Hanauer Landstrasse 300a, Frankfurt, Germany D-60314 Paris/Frankfurt/Milan Equinix LD8 6/7 Harbour Exchange Square London E14 9GE London Equinix AM1/AM2 Luttenbergweg 4 1101 EB Amsterdam The Netherlands Amsterdam/Canada Equinix PA2 114 rue Ambroise Croizat 93200 Saint Denis France Paris/Frankfurt/Milan Available Q3: Mega-I Advantage 12F, 399 Chai Wan Road Chai Wan, Hong Kong Asia Available Q3: Equinix SG1 20 Ayer Rajan Crescent Industrial Park Ayer Rajan, Singapore 139964 Asia Available Q3: Equinix TY2 3-8-21 Higashi-Shinagawa Shinagawa-ku, Tokyo 104-0002 Asia

IBM Direct Link Connect offer

Customers can receive consistent, high-throughput connectivity between a remote network and an IBM Cloud customer with secure connectivity that never touches the public Internet. The physical connectivity between Colt and IBM Cloud is already in place and hosted to customers.

Customer Interconnection location

IBM Cloud Direct Link Connect

Anything beyond the Cloud shared Port is handled by the CSP.

DCA-NNI port

VLAN

Colt Network

Covered by Colt SLA CPE Router

VLAN

• Based on Single BGP peering / VLAN
• Ideal for cost optimization
• Leased line connection at minimal cost
• On shared DCA-NNI

IBM Direct Link Connect options

IBM Cloud (Direct Link Connect) Colt Service Bandwith CSP Bandwidth 10Mbps 50Mbps 50Mbps 50Mbps 100Mbps 100Mbps 200Mbps 200Mbps 500Mbps 500Mbps 1Gbps 1Gbps 2Gbps 2Gbps 5Gbps 5Gbps

• Colt has direct relationship with IBM Cloud - no third party in between
• Colt has connected most IBM Cloud PoP’s in Europe
• Cloud PoP interconnections available in Frankfurt, London, Amsterdam and Paris. Asia follows in Q3
• Colt can provide Cloud PoP diversity in each city – based on two separate interconnects in each location
• Available topologies Layer 2:
• Point to point
• Hub and spoke
• Overview of Colt and

CSP bandwidth options

IBM Direct Link Dedicated option

Dedicated

• When customer need 10Gbps port/bandwidth
• Other options: Dedicated 1-2-5-10G port with IBM
• Colt bandwidth 500Mbps,1-2-5-10Gbps
• One BGP session / VLAN
• Ideal for sharing across multiple departments
• Built to handle large volume data
• Colt offers cross-connect to dedicated port

Customers can receive consistent, high-throughput connectivity between a remote network and an IBM Cloud customer with secure and dedicated connectivity that never touches the public Internet.

Name PoP’s Address Region Direct Link Connect Direct Link Dedicated

Equinix AM1/AM2 Luttenbergweg 4-8 1101EC Amsterdam Netherlands Amsterdam/Canada x x KPN Rondebeltweg 62 1329 BG Almere Netherlands Amsterdam/Canada x Interxion FRA06 Hanauer Landstraße 300a 60314 Frankfurt Germany Paris/Frankfurt/Milan x x Equinix LD8 Harbour Exchange Square 6-7 E14 9GE London United Kingdom London x x DRT Chessington Cox Lane KT9 1SJ Chessington United Kingdom London x Equinix LD5 Buckingham Avenue 8 SL1 4AX Slough United Kingdom London x ARK datacenters Old Ively Road Unit 102 Cody Park GU14 0LH Farnborough United Kingdom London x NFRACOM PAL D Via Caldera 21/D 20153 Milan Italy Paris/Frankfurt/Milan x @byget Hans Møller Gasmanns Vei 9 598 Oslo Norway Norway x Equinix PA2 Rue Ambroise Croizat 114 93200 Saint Denis France Paris/Frankfurt/Milan x x Interxion STO1 Esbogatan 11 164 74 Kista Sweden Europe x Equinix TY2 Higashi-Shinagawa Shinagawa-ku 3-8-21 140-0002 Tokyo Japan APAC X (Q3-’18) x @Tokyo CC2

• Tokyo

Japan APAC x Equinix SG1 Ayer Rajah Crescent 20 139964 Singapore Singapore APAC X (Q3-’18) x Digital Realty

• Singapore

Singapore APAC x MEGA-i Chai Wan Road Chai Wan 399

• Hong Kong

Hong Kong APAC X (Q3-’18) x

IBM Direct Link - Commercial Structure

Dedicated Cloud Access

Colt invoices for…

A monthly port fee dependent on the Port speed selected

Cloud Service Providers invoices for …

• IBM has defined the following regions:
• With IBM Cloud Direct Link, customers have access to Local Routing, or POPs within the same city as a

target data center

• Inbound and outbound bandwidth is free
• Optionally, customers can choose Global Routing to access POPs and data centers anywhere in the world
• Inbound bandwidth is free
• Outbound bandwidth in same region as POP is free
• Please find charges of IBM Direct link: https://www-01.ibm.com/common/ssi/cgi-bin/ssialias?htmlfid=GML12366USEN&

IBM Direct Link - resilience & diversity options

IBM standard service (1 DCA connection) IBM NNI diversity in same Cloud PoP region (2 DCA connections)

Same PoP region: Frankfurt & Paris Customer building IIBM Cloud PoP IBM Cloud PoP (primary NNI) IBM Cloud PoP (secondary NNI) Customer building

IBM NNI diversity in same Cloud PoP location (2 DCA connections)

2x DCA NNI per location IBM Cloud PoP A IBM Cloud PoP A Customer building

Both protected and unprotected resilience is supported, Gold and Platinum access resilience is not supported, 2 physical circuits need to be ordered):

Colt Longtail CSP’s Offering

Regions & network access PoPs

Europe Asia Pacific

E E

London Frankfurt

E

Amsterdam

E E E

Tokyo Hong Kong Singapore ECX platform – Colt planned connectivity

E

ECX platform – connected

E E

Paris

PoP locations

Network Address POPs Address Equinix LD5 Buckingham Avenue 8, SL1 4AX Slough, London, United Kingdom Equinix FR4 Lärchenstraße 110, 65933 Frankfurt, Germany Equinix AM3 Science Park 610, 1098 XH Amsterdam, Netherlands Equinix TY2 Shinshu Meitetsu Shinagawa Bldg. (TY2), Higashishinagawa 3-8-21, Shinagawa- ku 140-0002 Tokyo (Kanto Region), Japan Equinix SG3 15 Pioneer Walk, 627753, Singapore

ECX Overview

The Equinix Cloud Exchange acts as a cloud aggregation platform, allowing Colt to interface with multiple cloud service providers at the ECX locations. It is effectively a “virtual cross connect” between the Colt network and the CSP. Available topologies Layer 2:

• Point to point
• Hub and spoke

Colt provides handover on Layer 2 with a single VLAN, the customer is responsible for BGP peering (layer 3)

Notes: a) Available in London, Frankfurt and Amsterdam, Tokyo and Singapore a) Hong Kong would be ready Q3 2018 b) AliCloud available in Asia

Colt Bandwidth & CSP Bandwidth - Europe

Colt service bandwidth CSP Bandwidth

VMWare Horizon Oracle Classic

• FastConnect

SAP Cloud - Hana Enterprise Other Oracle OCI - FastConnect Salesforce Express Connect SAP Cloud - SaaS

10Mbps

1Gbps 200 100 all values between 10Mbps and 10Gbps similar to Colt service bandwidth

50Mbps

1Gbps 200 100

100Mbps

1Gbps 200 100

200Mbps

1Gbps 200 200

300Mbps

1Gbps 500 300

400Mbps

1Gbps 500 400

500Mbps

1Gbps 500 500

1Gbps

1Gbps 1Gbps 1Gbps

2Gbps

10Gbps NA NA

5Gbps

10Gbps NA NA

10Gbps

10Gbps NA NA

• Colt and CSP Bandwidth vary per

longtail CSP (please see next slide)

• 10Gbps is non-standard

ECX locations of the Longtail CSP - Europe

CSP Name Product naming Source Metro Oracle Oracle Cloud Infrastructure Classic - FastConnect Amsterdam, London Oracle Cloud Infrastructure (OCI) FastConnect Frankfurt SalesForce Salesforce Express Connect Frankurt VMware VMware Horizon London SAP SAP Cloud - Hana Enterprise Amsterdam, Franfurt SAP Cloud - SaaS Amsterdam, Frankfurt

• Colt is connected to London and Amsterdam and Frankfurt on the ECX platform.
• Longtail CSP providers and their products are present in certain locations

Cloud Service Providers and Bandwidths - Asia

ECX City Cloud Service Providers Available bandwidths Tokyo

Alibaba Cloud ExpressConnect 10 Mb 20 Mb 50 Mb 100 Mb 200 Mb 500 Mb Google Cloud Interconnect AS24114(Layer 3) 1Gb SAP Cloud Peering for SaaS TBC IBM Cloud Direct Link 50 Mb 100 Mb 200 Mb 500 Mb 1 Gb VMWare Horizon 100 Mb 200 Mb 500 Mb 1 Gb 10 Gb

Singapore

Alibaba Cloud ExpressConnect 10 Mb 20 Mb 50 Mb 100 Mb 200 Mb 500 Mb Azure Express Route 50 Mb 100 Mb 200 Mb 500 Mb 1 Gb Google Cloud Interconnect AS24114(Layer 3) 1Gb SAP Cloud Peering for SaaS TBC IBM Cloud Direct Link 50 Mb 100 Mb 200 Mb 500 Mb 1 Gb VMWare Horizon 100 Mb 200 Mb 500 Mb 1 Gb 10 Gb

Thank you
