DCatch: Automatically Detecting Distributed Concurrency Bugs in Cloud Systems

Haopeng Liu, Guangpu Li, Jeffrey Lukman, Jiaxin Li, Shan Lu, Haryadi Gunawi, and Chen Tian*

*

2

Cloud systems

3

Cloud systems

4

Distributed concurrency bugs (DCbugs)

5

Distributed concurrency bugs (DCbugs)

• Unexpected timing among distributed operations

6

Distributed concurrency bugs (DCbugs)

• Unexpected timing among distributed operations
• Example

B A C MapReduce-3274

7

Distributed concurrency bugs (DCbugs)

• Unexpected timing among distributed operations
• Example

B A C B A C MapReduce-3274

hang

8

DCbugs need to be tackled

• Common in distributed systems [1, 2, 3]

– 26% failures caused by non-deterministic [1] – 6% software bugs in clouds system [2]

[1] Yuan. Simple Testing Can Prevent Most Critical Failures. In OSDI’14 [2] Gunawi. What Bugs Live in the Cloud?. In SoCC’14 [3] Leesatapornwongsa. TaxDC. In ASPLOS’16

9

DCbugs need to be tackled

• Common in distributed systems [1, 2, 3]
• Difficult to avoid, expose and diagnose

[1] Yuan. Simple Testing Can Prevent Most Critical Failures. In OSDI’14 [2] Gunawi. What Bugs Live in the Cloud?. In SoCC’14 [3] Leesatapornwongsa. TaxDC. In ASPLOS’16

10

DCbugs need to be tackled

• Common in distributed systems [1, 2, 3]
• Difficult to avoid, expose and diagnose

“That is one monster of a race!” Hadoop Map/Reduce / MAPREDUCE-3274 [1] Yuan. Simple Testing Can Prevent Most Critical Failures. In OSDI’14 [2] Gunawi. What Bugs Live in the Cloud?. In SoCC’14 [3] Leesatapornwongsa. TaxDC. In ASPLOS’16

11

DCbugs need to be tackled

• Common in distributed systems [1, 2, 3]
• Difficult to avoid, expose and diagnose

“That is one monster of a race!” Hadoop Map/Reduce / MAPREDUCE-3274 “There isn’t a week going by without new bugs about races.” HBase / HBASE-4397 [1] Yuan. Simple Testing Can Prevent Most Critical Failures. In OSDI’14 [2] Gunawi. What Bugs Live in the Cloud?. In SoCC’14 [3] Leesatapornwongsa. TaxDC. In ASPLOS’16

12

DCbugs need to be tackled

• Common in distributed systems [1, 2, 3]
• Difficult to avoid, expose and diagnose

“That is one monster of a race!” Hadoop Map/Reduce / MAPREDUCE-3274 “There isn’t a week going by without new bugs about races.” HBase / HBASE-4397 “We have already fix many cases, however it seems exist many other [racing] cases.” HBase / HBASE-6147 [1] Yuan. Simple Testing Can Prevent Most Critical Failures. In OSDI’14 [2] Gunawi. What Bugs Live in the Cloud?. In SoCC’14 [3] Leesatapornwongsa. TaxDC. In ASPLOS’16

13

DCbugs need to be tackled

• Common in distributed systems [1, 2, 3]
• Difficult to avoid, expose and diagnose

“That is one monster of a race!” Hadoop Map/Reduce / MAPREDUCE-3274 “There isn’t a week going by without new bugs about races.” HBase / HBASE-4397 “We have already found and fix many cases, however it seems exist many other cases.” HBase / HBASE-6147 “This has become quite messy, sigh.” Hadoop Map/Reduce / MAPREDUCE-4819 [1] Yuan. Simple Testing Can Prevent Most Critical Failures. In OSDI’14 [2] Gunawi. What Bugs Live in the Cloud?. In SoCC’14 [3] Leesatapornwongsa. TaxDC. In ASPLOS’16

14

DCbugs need to be tackled

• Common in distributed systems [1, 2, 3]
• Difficult to avoid, expose and diagnose

“That is one monster of a race!” Hadoop Map/Reduce / MAPREDUCE-3274 “There isn’t a week going by without new bugs about races.” HBase / HBASE-4397 “We have already found and fix many cases, however it seems exist many other cases.” HBase / HBASE-6147 “This has become quite messy, sigh.” Hadoop Map/Reduce / MAPREDUCE-4819 “Great catch, Sid! Apologies for missing the race condition.” Hadoop Map/Reduce / MAPREDUCE-4099 [1] Yuan. Simple Testing Can Prevent Most Critical Failures. In OSDI’14 [2] Gunawi. What Bugs Live in the Cloud?. In SoCC’14 [3] Leesatapornwongsa. TaxDC. In ASPLOS’16

15

[1] Yuan. Simple Testing Can Prevent Most Critical Failures. In OSDI’14 [2] Gunawi. What Bugs Live in the Cloud?. In SoCC’14 [3] Leesatapornwongsa. TaxDC. In ASPLOS’16

DCbugs need to be tackled

• Common in distributed systems [1, 2, 3]
• Difficult to avoid, expose and diagnose

“That is one monster of a race!” Hadoop Map/Reduce / MAPREDUCE-3274 “There isn’t a week going by without new bugs about races.” HBase / HBASE-4397 “We have already found and fix many cases, however it seems exist many other cases.” HBase / HBASE-6147 “This has become quite messy, sigh.” Hadoop Map/Reduce / MAPREDUCE-4819 “Great catch, Sid! Apologies for missing the race condition.” Hadoop Map/Reduce / MAPREDUCE-4099 “We [prefer] debug crashes instead of hanging jobs.” Hadoop Map/Reduce / MAPREDUCE-3634

16

[1] Yuan. Simple Testing Can Prevent Most Critical Failures. In OSDI’14 [2] Gunawi. What Bugs Live in the Cloud?. In SoCC’14 [3] Leesatapornwongsa. TaxDC. In ASPLOS’16

DCbugs need to be tackled

• Common in distributed systems [1, 2, 3]
• Difficult to avoid, expose and diagnose

“That is one monster of a race!” Hadoop Map/Reduce / MAPREDUCE-3274 “There isn’t a week going by without new bugs about races.” HBase / HBASE-4397 “We have already found and fix many cases, however it seems exist many other cases.” HBase / HBASE-6147 “This has become quite messy, sigh.” Hadoop Map/Reduce / MAPREDUCE-4819 “Great catch, Sid! Apologies for missing the race condition.” Hadoop Map/Reduce / MAPREDUCE-4099 “We [prefer] debug crashes instead of hanging jobs.” Hadoop Map/Reduce / MAPREDUCE-3634

Can we detect DCbugs before they manifest?

17

Previous work

• Model checking

– Work on abstracted models – Face state-space explosion issue

18

Our idea

• Follow the philosophy of traditional

concurrency bug detection

19

Our idea

• Follow the philosophy of traditional

concurrency bug detection

Machine 2 Machine 1 Machine 3 Machine 4

20

Our idea

• Follow the philosophy of traditional

concurrency bug detection

Machine 2 Machine 1 Machine 3 Machine 4

21

Our idea

• Follow the philosophy of traditional

concurrency bug detection

Machine 2 Machine 1 Machine 3 Machine 4

22

Example

B A C

23

Example

B A C B

//UnReg thread void unReg(jID){

jMap.remove(jID);

.... } //RPC thread Task getTask(jID){ ... return jMap.get(jID); }

24

Local concurrency bug detection

25

Local concurrency bug detection

26

Local concurrency bug detection

Is the problem solved?

27

Local concurrency bug detection

 

Trace

T1 T2 T3

28

Local concurrency bug detection

 

Trace

T1 T2 T3

C 1

C1: How to handle the huge amount of mem accesses? Challenges

29

Local concurrency bug detection

. . .

 

Trace HB

T1 T2 T3

C 1

C1: How to handle the huge amount of mem accesses? Challenges

30

Local concurrency bug detection

. . .

 

Trace HB

T1 T2 T3

C 1

C1: How to handle the huge amount of mem accesses? Challenges r w

31

Local concurrency bug detection

. . .

 

Trace HB

T1 T2 T3

C 1 C 2

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? Challenges r w

32

Local concurrency bug detection

. . .

 

Trace Triage HB

T1 T2 T3

. . .

C 1 C 2

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? Challenges

assert(r)

r w r w

33

Local concurrency bug detection

. . .

 

Trace Triage HB

T1 T2 T3

. . .

C 1 C 2 C 3

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? Challenges

assert(r)

r w r w

34

Local concurrency bug detection

. . .

T1 T2 T3

. . . . . .

 

Trace Triage Trigger HB

C 1 C 2 C 3

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? Challenges

+sleep

r w r w

assert(r)

35

Local concurrency bug detection

. . .

 

Trace Triage Trigger HB

T1 T2 T3

. . . . . .

C 1 C 2 C 3 C 4

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

+sleep

r w

assert(r)

r w

36

Contribution

• A comprehensive HB Model for distributed systems

37

Contribution

 

Trace Triage Trigger HB

C 1 C 2 C 3 C 4

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Solved by

DCatch

• A comprehensive HB Model for distributed systems
• DCatch tool detects DCbugs from correct runs

38

Contribution

• A comprehensive HB Model for distributed systems
• DCatch tool detects DCbugs from correct runs
• Evaluate on 4 systems
• Report 32 DCbugs, with 20 of them being truly

harmful

39

Outline

• Motivation
• DCatch Happens-before Model
• DCatch tool
• Evaluation
• Conclusion

40

DCatch Happens-before Model

HMaster Thd

w

41

DCatch Happens-before Model

Thd HMaster Thd

w

42

DCatch Happens-before Model

Thd Thd HMaster HRegionServer Thd

w

43

DCatch Happens-before Model

Thd Event thread Thd HMaster

e

HRegionServer Thd

w

44

DCatch Happens-before Model

Thd Event thread Thd HMaster

e

HRegionServer Thd ZK Coordinator

w

45

DCatch Happens-before Model

Thd Thd Event thread Thd HMaster

e

HRegionServer Thd ZK Coordinator

w

46

DCatch Happens-before Model

Thd Thd Event thread Thd HMaster

e

HRegionServer Thd ZK Coordinator

w r

47

DCatch Happens-before Model

Thd Thd Event thread Thd HMaster

e

HRegionServer Thd ZK Coordinator

w r

Where is HB model for distributed systems?

48

DCatch Happens-before Model

Thd Thd Eve thd Thd HMaster HRegionServer Thd ZK Coordinator

w r

49

DCatch Happens-before Model

Dist. Loc.

Thd Thd Eve thd Thd HMaster HRegionServer Thd ZK Coordinator

w r Dist.

50

DCatch Happens-before Model

Dist. Loc. Async. Sync.

Thd Thd Eve thd Thd HMaster HRegionServer Thd ZK Coordinator

w r Dist. Async.

51

DCatch Happens-before Model

Stand. Dist. Loc. Cust. Async. Sync.

Thd Thd Eve thd Thd HMaster HRegionServer Thd ZK Coordinator

w r Dist. Async. Cust.

52

Distributed rules

Distributed Local Standard Custom Async. Sync.

53

Distributed rule #1

• Logical time clock (Leslie Lamport, 1978)

Send Recv Machine1 Machine2 Standard Asynch. Customize Synch. Socket

54

Distributed rule #1

• Logical time clock (Leslie Lamport, 1978)

Send Recv Machine1 Machine2 Standard Asynch. Customize Synch. Socket

55

Distributed rule #2

RPC-call RPC-begin Machine1 Machine2 RPC-rt RPC-end Standard Asynch. Customize Synch. RPC

Socket

56

Distributed rule #2

RPC-call RPC-begin Machine1 Machine2 RPC-rt RPC-end Standard Asynch. Customize Synch. RPC

Socket

waiting

57

Distributed rule #2

RPC-call RPC-begin Machine1 Machine2 RPC-rt RPC-end Standard Asynch. Customize Synch. RPC

Socket

waiting

58

Distributed rule #3

//Thread1 flag = True; //Thread while(!flag){ } ...

In multi-threaded systems:

Standard Asynch. Customize Synch.

Socket RPC

• Dist. while-loop

59

Distributed rule #3

//Thread1 flag = True; //Thread while(!flag){ } ...

In multi-threaded systems:

Standard Asynch. Customize Synch.

Socket RPC

• Dist. while-loop

60

Distributed rule #3

//Thread1 flag = True; //Thread while(!flag){ } ...

In multi-threaded systems:

Standard Asynch. Customize Synch.

Socket RPC

• Dist. while-loop

In distributed systems:

61

Distributed rule #3

//Thread1 flag = True; //Thread while(!getFlag()){ } ... //Thread2 bool getFlag(){ return flag; }

Machine B Machine A

In distributed systems:

Standard Asynch. Customize Synch.

Socket RPC

• Dist. while-loop

62

Distributed rule #3

//Thread1 flag = True; //Thread while(!getFlag()){ } ... //Thread2 bool getFlag(){ return flag; }

Machine B Machine A

In distributed systems:

Standard Asynch. Customize Synch.

Socket RPC

• Dist. while-loop

63

Distributed rule #4

Thd Thd Eve thd Thd Thd ZK Coordinator

w r

Standard Asynch. Customize Synch.

Socket RPC

ZooKeeper Service

64

Distributed rule #4

Standard Asynch. Customize Synch. ZooKeeper Service

Socket RPC

Thd Thd Eve thd Thd Thd ZK Coordinator

w r

65

Distributed rules

Standard Customized Asynchronous Synchronous RPC

• Dist. While-loop

Socket Zookeeper Service

66

Local rules

Distributed Local

67

Local rules

Standard Customized Asynchronous Synchronous Event-related n/a

68

Local rules

Standard Customized Asynchronous Synchronous Event-related Thread fork/join While-loop n/a

69

Local rules

Standard Customized Asynchronous Synchronous Thread fork/join While-loop Event-related n/a

70

Outline

• Motivation
• DCatch Happens-before Model
• DCatch tool
• Evaluation
• Conclusion

71

Triage Trigger Trace HB

72

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Selective tracing: only mem accesses in Event/message handlers and their callee.

73

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Local Distributed

[1] Raychev. Effective Race Detection for Event-Driven Programs. In OOPSLA’13

74

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Machine B

//RPC thread Task getTask(jID){ ... return jMap.get(jID); } //UnReg thread void unReg(jID){

jMap.remove(jID);

.... }

75

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Machine B Machine A

//RPC thread Task getTask(jID){ ... return jMap.get(jID); } //UnReg thread void unReg(jID){

jMap.remove(jID);

.... }

while(!getTask(jID)){

}

76

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Machine B Machine A

//RPC thread Task getTask(jID){ ... return jMap.get(jID); } //UnReg thread void unReg(jID){

jMap.remove(jID);

.... }

while(!getTask(jID)){

}

77

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Machine B Machine A

//RPC thread Task getTask(jID){ ... return jMap.get(jID); } //UnReg thread void unReg(jID){

jMap.remove(jID);

.... }

while(!getTask(jID)){

}

hang

78

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Thd Thd Event thread

e2 e1

w r

79

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Thd Thd Event thread

e2 e1

w r +sleep

80

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Thd Thd Event thread

e2 e1

w r +sleep

81

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Thd Machine A Thd Machine C Thd Thd Event thread

e2 e1

w r

Machine B

82

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Thd Machine A Thd Machine C Thd Thd Event thread

e2 e1

w r

Machine B

+sleep +sleep

83

C1: How to handle the huge amount of mem accesses? C2: What’s the happens-before model? C3: How to estimate the distributed impact of a race? C4: How to trigger with distributed time manipulation? Challenges

Triage Trigger Trace HB

Thd Machine A Thd Machine C Thd Thd Event thread

e2 e1

w r

Machine B

+sleep +sleep +sleep +sleep

84

Outline

• Motivation
• DCatch Happens-before Model
• DCatch tool
• Evaluation
• Conclusion

85

• Benchmarks:

– 7 real-world DCbugs from TaxDC[1] – 4 distributed systems

Methodology

[1] Leesatapornwongsa. TaxDC. In ASPLOS’16

86

Overall results

BugID Detected? #. Bugs #. Benign #. false-pos CA-1011 ✔ 3 HB-4539 ✔ 3 1 HB-4729 ✔ 4 1 MR- 3274 ✔ 2 4 MR- 4637 ✔ 1 2 4 ZK-1144 ✔ 5 1 1 ZK-1270 ✔ 6 2 Total 20 5 7

87

Overall results

BugID Detected? #. Bugs #. Benign #. false-pos CA-1011 ✔ 3 HB-4539 ✔ 3 1 HB-4729 ✔ 4 1 MR- 3274 ✔ 2 4 MR- 4637 ✔ 1 2 4 ZK-1144 ✔ 5 1 1 ZK-1270 ✔ 6 2 Total 20 5 7

88

Overall results

BugID Detected? #. Bugs #. Benign #. false-pos CA-1011 ✔ 3 HB-4539 ✔ 3 1 HB-4729 ✔ 4 1 MR- 3274 ✔ 2 4 MR- 4637 ✔ 1 2 4 ZK-1144 ✔ 5 1 1 ZK-1270 ✔ 6 2 Total 20 5 7 = 12 + 8

89

Overall results

BugID Detected? #. Bugs #. Benign #. false-pos CA-1011 ✔ 3 HB-4539 ✔ 3 1 HB-4729 ✔ 4 1 MR- 3274 ✔ 2 4 MR- 4637 ✔ 1 2 4 ZK-1144 ✔ 5 1 1 ZK-1270 ✔ 6 2 Total 20 5 7

90

Other results in our paper

• Performance overhead
• Trace compositions
• HB model impact

– False-positive – False-negatives

• …

91

Outline

• Motivation
• DCatch Happens-before Model
• DCatch tool
• Evaluation
• Conclusion

92

Conclusion

• A HB Model for distributed systems
• DCatch detects DCbugs from correct runs with

low false positive rates.

 

Trace Triage Trigger HB

C 1 C 2 C 3 C 4

Local Distributed

93

Thank you! Q&A
