DC-Link Input Exploration

Harry Johnson

Motivation:

General Specs:

• SiC low-side FET
• SiC high-side diode
• 1Mhz Switching Frequency
• Output cap appropriately sized.
• Average input current control loop.

Low-Side FET: Cree C2M0280120D

• 280mR RDSon

High-Side Diode: Cree C4D05120A

• Output current is actually rather low
• Optimize Qrr

MATLAB:

• Simple and quick to run sanity check
• Only models cycle-by-cycle, not control

inside cycle

• Results used earlier

LTSpice Overview:

• Models circuit behavior within cycle
• Runs for a single 120Hz cycle
• Exported setpoints from MATLAB to CSV, imported as

PWL files for current sources.

• Rest of Littlebox (main buck, DC-link output buck)

modeled as current sources where necessary.

• SiC devices: manufacturer-supplied models

LTSpice Schematic:

Main Buck Emulator DC-Link Input Current Setpoint DC-Link Capacitor Discharge Current

Package Inductance

Total Current setpoint: 5A w/ soft start 450V + 10R

Per-120Hz cycle plots.

Turn-On

Turn-Off

Calculated Results:

• Averaged over the entire charge cycle
• Power In: 1.3195KW
• Power Out (into cap): 1.2888 KW
• Switching Power Loss: 30.7 Watts
• Eff: 97.6% (only including switching loss)

Areas for Future Work

• Model capacitor ESR appropriately for

mega-cap array (not modelled at all for purposes of this simulation)

• Inductor losses: DCR relatively easy to

model but I suspect primary losses will be in core.

• Actually build the darn thing!

Bonus: Megaderp moment

Late-night calculations:

• Automatic power calculation in LTspice (alt-click) on

Cree NMOS model.

• 500W !?
• Worked for a long time trying to optimize package, gate

drive, etc.

• Turns out I’m being autotrolled by the thermal

modelling, which is represented by voltage and current sources.
