SLIDE 1

Day of the Master

Dr. Vadim Zaytsev

aka @grammarware

SLIDE 2

Introduction

Universiteit van Amsterdam (2013–2014) Centrum Wiskunde & Informatica (2010–2013) Universität Koblenz-Landau (2008–2010) Vrije Universiteit Amsterdam (2004–2008) Universiteit Twente (2002–2004) Rostov State Transport University (1999–2008) Rostov State University (1998–2003)

Vadim Zaytsev

SLIDE 3

One year Master of Science programme at UvA Drifted away from computer science We teach software construction, evolution, testing, architecture, process, requirements engineering, etc Programmer in, software engineer out

http://www.software-engineering-amsterdam.nl

SLIDE 4

From code-monkey…

Ogrons in Day of the Daleks http://anewviewonolddoctorwho.files.wordpress.com/2013/01/ogrons.png

SLIDE 5

…to the Master

Roger Delgado as The Master in The Claws of Axos http://www.eyeo!orus.org.uk/images/photo/03pertwee/clawsaxos/master-delgado.jpg

SLIDE 6

Engineering?

Science solves problems Engineering solves problems

SLIDE 7 Gürbüz Doğan Ekşioğlu, http://www.gurbuz-de.com/merdivenler-e.html

SLIDE 8 Gürbüz Doğan Ekşioğlu, http://www.gurbuz-de.com/merdivenler-e.html

SLIDE 9 Gürbüz Doğan Ekşioğlu, http://markovart.wordpress.com/2014/01/03/surrealism-by-gurbuz-dogan-eksioglu/

SLIDE 10

What is important in

! !

?

SLIDE 11

What’s important?

Domain analysis Educated choices Tradeoff awareness Human factors Communicating with management

(collected during the workshop)

SLIDE 12

–Kent Beck

“I’m not a great programmer, I’m just a good programmer with great habits”

Martin Fowler, Kent Beck, John Brant, Refactoring: Improving the Design of Existing Code, 2012. P . 97.

SLIDE 13

One year Master of Science programme at UvA Drifted away from computer science We teach software construction, evolution, testing, architecture, process, requirements engineering, etc Programmer in, software engineer out

http://www.software-engineering-amsterdam.nl

SLIDE 14

Coding Dojo

SLIDE 15 Zurfa, Hacker Dojo - Main Classroom, CC-BY-SA, 2013.

SLIDE 16 Wang Ming, Noma Dojo, 2006, CC-BY-SA, 2007.

SLIDE 17 The Doctor fencing with The Master, The Sea Devils, s09e03.

SLIDE 18 The Doctor fencing with The Master, The Sea Devils, s09e03.

SLIDE 19

Warm-up!

SLIDE 20

Henry Ernest Dudeney

Recipe (1924): take a numerical calculation (2*2=4) replace digits by letters (A*A=B) Results in: cryptarithm

http://www.cut-the-knot.org/cryptarithms/st_crypto.shtml http://en.wikipedia.org/wiki/File:Henry_Dudeney.jpg

SLIDE 21

James Hunter, 1955

Cryptarithm with numbers as meaningful words equations as meaningful phrases Results in alphametic

http://www.cut-the-knot.org/cryptarithms/st_crypto.shtml http://www.amazon.com/Mathematical-Brain-Teasers-James-H-Hunter/dp/0486233472

SLIDE 22

Send Mode Money!

SEND MORE MONEY

+

9567 1085 10652

+

SLIDE 23

No Gun No Hunt!

NO GUN NO HUNT

+

87 908 87 1082

+

SLIDE 24

Will Obey Dalek!

WILL OBEY DALEK

+

6099 7825 13924

+

SLIDE 25

E X T E R M I N A T E !

EXTERMINATE MONEYMAKING CRYPTARITHM

+

E X T E R M I N A T E !

SLIDE 26

Tasks

Find a solution of an alphametic cryptarithm puzzle Given a puzzle, find a solution Given a puzzle and a solution, check compatibility Find a puzzle with only one solution Given a desired word, find valid puzzles

Tomchen1989, Cburnett et al, Poker current event.svg, 2011. CC-BY-SA.

SLIDE 27

No

do you know the difference between loop and recursion?

Yes

SLIDE 28

ds = {*[0..9]}; for (str solution <- {" <N> <O> ' <G> <U> <N> ' <N> <O> ‘------------------------ ' <H> <U> <N> <T>" | int G <- ds, int H <- ds - {G}, int N <- ds - {G,H}, int O <- ds - {G,H,N}, int T <- ds - {G,H,N,O}, int U <- ds - {G,H,N,O,T}, G != 0, H != 0, N != 0, (O + 10 * N) + (N + 10 * U + 100 * G) + (O + 10 * N) == (T + 10 * N + 100 * U + 1000 * H)}) println(solution);

SLIDE 29 str gen(list[str] xs) { keys = sort({x | /str s <- xs, int x <- chars(s)}); int width = 4*max([size(s) | /str s := xs])+3; f = "module Solver 'import IO; 'void solveit(){ 'ds = {*[0..9]}; 'for (str solution \<- {\"" + intercalate(" ' \'", [right(intercalate(" ",["\<<stringChar(c)>\>" | int c <- chars(s)]),width) | s <- sx[..-1]])+ " ' \'"+ right("",width,"-")+" ' \'"+ right(intercalate(" ",["\<<stringChar(c)>\>" | int c <- chars(xs[-1])]),width)+”\” | \n"; visited = []; for (k <- keys) { f += " int <stringChar(k)> \<- ds - {<intercalate(",",visited)>},\n"; visited += stringChar(k); } notzeros = sort({chars(s)[0] | /str s <- xs}); f += "\t"+intercalate(", ",["<stringChar(c)> != 0" | c <- notzeros]) + ", ' <intercalate(" +\n",["(<factorise(s)>)" | s <- xs[..-1]])> == ' (<factorise(last(xs))>)}) ' println(solution); '} 'public void main(list[str] args) {solveit();}"; println(f); return f; }

SLIDE 30

Helping observations

Leftmost letters cannot be 0 The result cannot be too long or too short If the result is longer, its left digit is 1 No puzzle can contain more than 10 different letters Brute force solution can be optimised exclude obviously wrong hypotheses

SLIDE 31

Lessons leant

Recursion of known max depth  can be rewritten as nested loops Harder tasks can be made simple by solving subtasks Easier tasks can be inefficiently solved by reuse Small differences in requirements matter

(collected during the workshop)

SLIDE 32

SLOC

SLIDE 33

Lines of Code?

Count the number of lines of source code in a file Disregarding indentation and whitespace empty lines comments

SLIDE 34

Solution

Looping over lines Trimming/stripping Regular expressions for comments trouble with combinations of //, /* */ and “”

SLIDE 35

Regular languages

below context free in the Chomsky hierarchy!

Duncan Rawlinson, Chomsky.jpg, 2004, CC-BY.
J. Finkelstein, Chomsky-hierarchy.jpg, 2010, CC-BY-SA.

SLIDE 36

Regular expressions

Stephen Kleene invented regexps in 195x Ken Thompson added them to ed & grep POSIX standard since 1993 PCRE by Philip Hazel  (stable release Dec. 2013)

Konrad Jacobs, S. C. Kleene, 1978, MFO.  Archetypal hackers ken (left) and dmr (right).

SLIDE 37

Regular expressions

Stephen Kleene invented regexps in 195x Ken Thompson added them to ed & grep POSIX standard since 1993 PCRE by Philip Hazel  (stable release Dec. 2013)

Konrad Jacobs, S. C. Kleene, 1978, MFO.  Archetypal hackers ken (left) and dmr (right).

SLIDE 38

Lessons leant

Perfect solutions are sometimes provably impossible “Close enough” solutions are useful Science: definitive proofs  Engineering: constant incremental advancements Ultimate reuse: find a suitable tool Metrics should not be abused (careful reporting)

(collected during the workshop)

SLIDE 39

Grammars

SLIDE 40

Parsing: text in, tree out

V. Zaytsev, A. H. Bagge. A Bidirectional Megamodel of Parsing, under review at ECMFA 2014,

http://grammarware.net/writes/#Parsing2014

SLIDE 41

Compiler construction

Dragon Book everything you wanted to know about compilers but were afraid to ask not needed  in practice

SLIDE 42

Language workbenches

Rascal http://www.rascal-mpl.org/ Spoofax http://strategoxt.org/Spoofax/ ANTLR http://www.antlr.org/ MetaEdit+ http://www.metacase.com/ MetaProgramming System http://www.jetbrains.com/mps/ Xtext http://www.eclipse.org/Xtext/

r any old-fashioned parser generator of your choice

SLIDE 43

SLIDE 44

A ::= B C;

!

B ::= “hello”;

!

C ::= “world”;

Grammar as parsing spec

Terminals: expected text Nonterminals: classes or categories Can be combined in a sequence or with choice

(other workshop-specific fluff)

SLIDE 45

2 + 2

!

2 - (2 + 2)*2/2-2

!

2 - 2 - 2 - 2

!

2

Expression language

Need to process an expression language Don’t write a parser Write a spec Concrete syntax def Let’s start with numbers

SLIDE 46

Expressions: numbers

Grammar is a spec, tests are for the parser Numbers do not start with zeros There is whitespace around them

SLIDE 47

Expressions: binary ops

We have numbers Next step:

perators

let’s focus on the binary ones +, -, /, *

SLIDE 48

Expressions: priorities

expression: conditional-or-expression conditional-or-expression: conditional-and-expression conditional-or-expression "||" conditional-and-expression conditional-and-expression: inclusive-or-expression conditional-and-expression "&&" inclusive-or-expression inclusive-or-expression: exclusive-or-expression inclusive-or-expression "|" exclusive-or-expression exclusive-or-expression: and-expression exclusive-or-expression "^" and-expression and-expression: equality-expression and-expression "&" equality-expression

Microsoft, C# Language Specification 4.0, 2010, http://slps.github.io/zoo/cs/csharp-msft-ls-4.0.html Pelf Nyok, Stacked-up river terrapins, 2006, PD.

SLIDE 49

Expressions: priorities

equality_expression: shift_expression equality_expression EQ_OP relational_expression equality_expression NE_OP relational_expression shift_expression: additive_expression shift_expression LEFT_OP additive_expression shift_expression RIGHT_OP additive_expression additive_expression: multiplicative_expression additive_expression '+' multiplicative_expression additive_expression '-' multiplicative_expression multiplicative_expression: cast_expression multiplicative_expression '*' cast_expression multiplicative_expression '/' cast_expression multiplicative_expression '%' cast_expression

Jeff Lee, jutta@pobox.com et al, ANSI C Yacc grammar, http://www.quut.com/c/ANSI-C-grammar-y.html Unknown source (PD?), http://imgur.com/09C5G

SLIDE 50

Expressions: priorities

Doug South, Tom Copeland, C grammar defintion for use with JavaCC, 1997, https://java.net/downloads/javacc/contrib/grammars/C.jj Murata Seimin, Five Turtles, 1761 and 1837, http://art.thewalters.org/detail/37228 void LogicalORExpression() : {} { LogicalANDExpression() [ "||" LogicalORExpression() ] }

!

void LogicalANDExpression() : {} { InclusiveORExpression() [ "&&" LogicalANDExpression() ] }

!

void InclusiveORExpression() : {} { ExclusiveORExpression() [ "|" InclusiveORExpression() ] }

!

void ExclusiveORExpression() : {} { ANDExpression() [ "^" ExclusiveORExpression() ] }

!

void ANDExpression() : {} { EqualityExpression() [ "&" ANDExpression() ] }

!

void EqualityExpression() : {} { RelationalExpression() [ ( "==" | "!=" ) EqualityExpression() ] }

!

void RelationalExpression() : {} { ShiftExpression() [ ( "<" | ">" | "<=" | ">=" ) RelationalExpression() ] }

SLIDE 51

Side story: parsing techniques

Top-down recursive descent parsers: LL(k) etc right recursion is ok, left recursion is deadly Bottom-up parsers: CYK, LR(k), LALR, etc right recursion is suboptimal, left recursion is ok Top-down parsing, bottom-up lookahead: Earley etc right recursion is ok, left recursion is faster

SLIDE 52

Expressions: priorities

Expression: Expression1 (AssignmentOperator Expression1)? Expression1: Expression2 Expression1Rest? Expression1Rest: ("?" Expression ":" Expression1)? Expression2: Expression3 Expression2Rest? Expression2Rest: (Infixop Expression3)* | "instanceof" Type Expression3: PrefixOp Expression3 Expression3: "(" (Expression | Type) ")" Expression3 Expression3: Primary Selector* PostfixOp*

J. Gosling, B. Joy, G. Steele, G. Bracha, Java Language Specification, 1998, §18: Syntax, pages 449–456,

http://slps.github.io/zoo/java/java-2-jls-impl.html

SLIDE 53

Expressions: priorities

Expression: Expression1 (AssignmentOperator Expression1)? Expression1: Expression2 Expression1Rest? Expression1Rest: ("?" Expression ":" Expression1)? Expression2: Expression3 Expression2Rest? Expression2Rest: (Infixop Expression3)* | "instanceof" Type Expression3: PrefixOp Expression3 Expression3: "(" (Expression | Type) ")" Expression3 Expression3: Primary Selector* PostfixOp*

J. Gosling, B. Joy, G. Steele, G. Bracha, Java Language Specification, 1998, §18: Syntax, pages 449–456,

http://slps.github.io/zoo/java/java-2-jls-impl.html

SLIDE 54

Expressions: priorities

exp: 'nil' | 'false' | 'true' | number | string | '...' | functiondef | prefixexp | tableconstructor | exp binop exp | unop exp; binop : '+' | '-' | '*' | '/' | '^' | '%' | '..' | '<' | '<=' | '>' | '>=' | '==' | '~=' | 'and' | 'or'; unop : '-' | 'not' | '#';

Kazunori Sakamoto, Lua 5.2 grammar in ANTLR4, https://github.com/antlr/grammars-v4/blob/master/lua/Lua.g4?

SLIDE 55

Expressions: interpreter

Recogniser tells us which program is correct Parser builds a parse tree Some want a semi-auto-derived abstract syntax tree We need smth to walk that tree and execute it e.g., perform calculation e.g., check for correctness

SLIDE 56

Expressions: variables?

how to introduce variables into a software language? many different ways each one has implications very hard to do  w/o background

(λ x . 2 + x) 2

!

2 + x where x=2

!

{x=2;return 2 +x}

SLIDE 57

Lessons leant

Full TDD: start with failing tests, adapt, repeat [1-9][0-9]*|[0] is uglier than [0-9]+ Comments should not show up explicitly in the grammar Separate tree validation function is useful Parsing can be ambiguous Several ways to specify/encode priorities

(collected during the workshop)

SLIDE 58

Summary

Software engineering vs computer science Alphametic cryptarithms Calculating lines of code in a software system Software language engineering Mining software repositories (no time)

http://grammarware.net/talks/#DayOfTheMaster2014

SLIDE 59

Coding Dojo Feedback

What went well? What did not? What did we learn?

KendoSnowman, Jon Takagi dojo 1970, CC-BY-SA, 2014

SLIDE 60

Feedback

Hacking is fun. Moar hacking! Brief SLE intro appreciated Background info feels CS, not SE

(collected during the workshop)

SLIDE 61

One year Master of Science programme at UvA

! ! ! !

http://www.software-engineering-amsterdam.nl

vadim@grammarware.net

Skills covered: programming critical thinking solving unsolvable Skills uncovered: reading scientific papers collaborating in bigger projects

SLIDE 62

Designosaur by Archy Studio Heuristica by Andrej Panov

Matt Smith Doctor Who by thejamjar

GNU Typewriter by Lukasz Komsta Dalek by K-Type

Doctor Who screenshots by BBC logo by Vadim Zaytsev logo by Tobias Baanders Everything used strictly for educational purposes Yours, @grammarware
