SLIDE 1
Data Storage and Interaction using Magnetized Fabric
Justin Chan Shyam Gollakota
1
PROJECT JACQUARD LILYPAD ARDUINO
Existing approaches Requires batteries
2
Data Storage and Interaction using Magnetized Fabric Justin Chan - - PowerPoint PPT Presentation
Data Storage and Interaction using Magnetized Fabric Justin Chan - - PowerPoint PPT Presentation
Data Storage and Interaction using Magnetized Fabric Justin Chan Shyam Gollakota 1 Existing approaches PROJECT JACQUARD LILYPAD ARDUINO Requires batteries 2 Can we create a smart fabric design without any onboard electronics or
SLIDE 2
SLIDE 3
Can we create a smart fabric design without any onboard electronics or batteries?
3
SLIDE 4
WATERPROOF BATTERY-FREE
Smart fabrics without electronics
4
SLIDE 5
CODES IMAGES Clothes with memory
5
SLIDE 6
Interact with a smartphone in your pocket
6
SLIDE 7
What are conductive threads used for?
7
SLIDE 8
Key Observation
Leverage magnetic properties of conductive thread
8
SLIDE 9
Smartphones have magnetometers
9
SLIDE 10
Our Contributions
- First to harness the magnetic properties
- f conductive fabric for interaction
- Provide a detailed characterization of
magnetized fabric
- Build electronic-free data storage and
gesture recognition applications on fabric
10
SLIDE 11
Characterization of magnetized fabric
11
SLIDE 12
What do we care about?
- Embroidery style
- Decay over distance
- Decay over time
12
SLIDE 13
20 40 60 80 100 1 2 3 4 5 6 7 8 Magnetic field strength (T) Noise Floor
Magnetic field strength (µT)
20 40 60 80 100
How does embroidery style afgect fjeld strength?
Denser styles have higher fjeld strength
13
2.5cm
SLIDE 14
How does fjeld strength decay over distance?
Works up to distances of 1 cm
10 20 30 40 50 60 5 10 15 20 Magnetic field strength (T) Distance from phone (mm) 2.5cm2 2.0cm2 1.5cm2
10 20 30 40 60 50 Magnetic field strength (µT) Distance from magnetometer (mm)
5 10 15 20
14
SLIDE 15
10 20 30 40 50 60 1 2 3 4 5 6 Magnetic field strength (T) Days 2.5cm2 2.0cm2 1.5cm2
1 2 3 4 5 6 10 20 30 40 50 60
Magnetic field strength (µT)
Days
2.5cm2 2.0cm2 1.5cm2
How does fjeld strength decay over time?
28-36% decrease over a week
15
Remagnetized
SLIDE 16
GESTURE RECOGNITION EMBEDDING INVISIBLE IMAGES DATA STORAGE
16
SLIDE 17
Unreadable on smartphones How do we tag clothing?
17
> $500-$2000
SLIDE 18
Reading and writing codes
Magnetometer
18
5mm Guard band 2cm 1cm < $0.17
SLIDE 19
Reading the tag on a smartphone
19
SLIDE 20
Change in fjeld strength Hand wash 11% Machine wash 5% Drying 9% Ironing (160°C) 1%
How durable are our tags?
20
SLIDE 21
21
Are our tags reprogrammable?
No degradation in fjeld strength
21
5 10 15 20 25 30 35 40 45 1 2 3 4 5 6 7 8 9 10 Magnetic field strength (T) Tag ID Number
Magnetic field strength (µT)
1 2 3 4 5 6 7 8 9 10
Number of new magnetic codes
10 20 30 40
SLIDE 22
Fashion accessories with memory
22
SLIDE 23
EMBEDDING INVISIBLE IMAGES
23
SLIDE 24
ENCODING DECODING
Drawing and reading images
24
SLIDE 25
Magnetic fjeld strength (µT) 60 40 20
- 20
- 40
- 60
1.8cm 9cm
How small can each pixel be?
Smallest pixel size: 1.8 cm2
25
SLIDE 26
9cm 9cm
Expressivity of images
225 ≈ 33 million possible images
26
SLIDE 27
27
SLIDE 28
GESTURE RECOGNITION
28
SLIDE 29
Smartphones in pockets
29
Low-power IoT devices Power: 72µW Magnetometer Cost: $0.80
SLIDE 30
Recognizing gestures
30
SLIDE 31
X Y Z X Y Z X Y Z X Y Z X Y Z
X Y Z
UP LEFT CLICK BACK CLICK DOWN RIGHT
31
SLIDE 32
Real time classifjer
32
SLIDE 33
Actual Gesture Performed Gesture Classified 0.06 0.02 0.04 0.86 0.03 0.01 0.01 0.01 0.92 0.02 0.02 0.04 0.94 0.02 0.01 0.03 0.87 0.06 0.02 0.01 0.9 0.02 0.03 0.03 0.01 0.91 0.01 0.01 0.04 0.03 Back Click Click Right Left Down Up Up Down Left Right Click Back Click Not seen
Classifjer accuracy
7 users 20 repetitions 90.1% accuracy
33
SLIDE 34
34
SLIDE 35
Custom designed textiles + a precise magnetic reader and writer
- Generate stronger fjelds
- Increase bit density
- Longer bit lifespan
How do we improve this?
35
SLIDE 36
Conclusions
- Harness the magnetic properties of
conductive fabric for interaction
- Provide a detailed characterization of
magnetized fabric
- Build electronic-free data storage and
gesture recognition applications on fabric
36
