DataCamp Interactive Data Visualization with rbokeh INTERACTIVE DATA VISUALIZATION WITH RBOKEH Data Formats Omayma Said Data Scientist DataCamp Interactive Data Visualization with rbokeh hdi_cpi_2015 Data DataCamp Interactive Data

SLIDE 1

DataCamp Interactive Data Visualization with rbokeh

Data Formats

INTERACTIVE DATA VISUALIZATION WITH RBOKEH

Omayma Said

Data Scientist

SLIDE 2

DataCamp Interactive Data Visualization with rbokeh

hdi_cpi_2015 Data

SLIDE 3

DataCamp Interactive Data Visualization with rbokeh

Data Format (hdi_cpi_wide)

> str(hdi_cpi_wide) Classes ‘tbl_df’, ‘tbl’ and 'data.frame': 121 obs. of 8 variables: $ country : chr "Afghanistan" "Albania" "Algeria" "Angola" $ year : int 2015 2015 2015 2015 2015 2015 2015 2015 201 $ human_development_index : num 0.479 0.764 0.745 0.533 0.827 0.939 0.893 0 $ country_code : chr "AFG" "ALB" "DZA" "AGO" ... $ cpi_rank : int 166 88 88 163 106 13 16 50 139 15 ... $ region : chr "AP" "ECA" "MENA" "SSA" ... $ corruption_perception_index: int 11 36 36 15 32 79 76 51 25 77 ... $ continent

SLIDE 4

DataCamp Interactive Data Visualization with rbokeh

Data Format (hdi_cpi_long)

> str(hdi_cpi_long) Classes ‘tbl_df’, ‘tbl’ and 'data.frame': 242 obs. of 7 variables: $ country : chr "Afghanistan" "Afghanistan" "Albania" "Albania" ... $ country_code: chr "AFG" "AFG" "ALB" "ALB" ... $ cpi_rank : int 166 166 88 88 88 88 163 163 106 106 ... $ region : chr "AP" "AP" "ECA" "ECA" ... $ continent : chr "Asia" "Asia" "Europe" "Europe" ... $ index : chr "human_development_index" "corruption_perception_index" "h $ value : num 0.479 11 0.764 36 0.745 36 0.533 15 0.827 32 ...

SLIDE 5

DataCamp Interactive Data Visualization with rbokeh

gather() and spread()

SLIDE 6

DataCamp Interactive Data Visualization with rbokeh

Long to Wide

hdi_cpi_wide <- hdi_cpi_long %>% spread(key = index, value = value) str(hdi_cpi_wide) Classes ‘tbl_df’, ‘tbl’ and 'data.frame': 121 obs. of 8 variables: $ country : chr "Afghanistan" "Albania" "Algeria" "Angola" $ year : int 2015 2015 2015 2015 2015 2015 2015 2015 201 $ human_development_index : num 0.479 0.764 0.745 0.533 0.827 0.939 0.893 0 $ country_code : chr "AFG" "ALB" "DZA" "AGO" ... $ cpi_rank : int 166 88 88 163 106 13 16 50 139 15 ... $ region : chr "AP" "ECA" "MENA" "SSA" ... $ corruption_perception_index: int 11 36 36 15 32 79 76 51 25 77 ... $ continent : chr "Asia" "Europe" "Africa" "Africa" ...

SLIDE 7

DataCamp Interactive Data Visualization with rbokeh

Data Format (hdi_data_wide)

> hdi_data_wide # A tibble: 188 x 27 country `1990` `1991` `1992` `1993` `1994` `1995` `1996` `1997` `1998` <chr> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> <dbl> 1 Afghanistan 0.295 0.3 0.309 0.305 0.3 0.324 0.328 0.332 0.335 2 Albania 0.635 0.618 0.603 0.608 0.616 0.628 0.637 0.636 0.646 3 Algeria 0.577 0.581 0.587 0.591 0.595 0.6 0.609 0.617 0.627 4 Andorra NA NA NA NA NA NA NA NA NA 5 Angola NA NA NA NA NA NA NA NA NA 6 Antigua and ~ NA NA NA NA NA NA NA NA NA 7 Argentina 0.705 0.713 0.72 0.725 0.728 0.731 0.738 0.746 0.753 8 Armenia 0.634 0.628 0.595 0.593 0.597 0.603 0.609 0.618 0.632 9 Australia 0.866 0.867 0.871 0.874 0.876 0.885 0.888 0.891 0.894 10 Austria 0.794 0.798 0.804 0.806 0.812 0.816 0.819 0.823 0.833 # ... with 178 more rows, and 14 more variables: `2002` <dbl>, `2003` <dbl>, `20 # `2005` <dbl>, `2006` <dbl>, `2007` <dbl>, `2008` <dbl>, `2009` <dbl>, `2010` # `2011` <dbl>, `2012` <dbl>, `2013` <dbl>, `2014` <dbl>, `2015` <dbl>

SLIDE 8

DataCamp Interactive Data Visualization with rbokeh

Wide to Long

hdi_data_long <- hdi_data_wide %>% gather(key = year, value = human_development_index, - country) > hdi_data_long # A tibble: 4,888 x 3 country year human_development_index <chr> <int> <dbl> 1 Afghanistan 1990 0.295 2 Albania 1990 0.635 3 Algeria 1990 0.577 4 Andorra 1990 NA 5 Angola 1990 NA 6 Antigua and Barbuda 1990 NA 7 Argentina 1990 0.705 8 Armenia 1990 0.634 9 Australia 1990 0.866 10 Austria 1990 0.794 # ... with 4,878 more rows

SLIDE 9

DataCamp Interactive Data Visualization with rbokeh

Let's practice!

INTERACTIVE DATA VISUALIZATION WITH RBOKEH

SLIDE 10

DataCamp Interactive Data Visualization with rbokeh

More rbokeh Layers

INTERACTIVE DATA VISUALIZATION WITH RBOKEH

Omayma Said

Data Scientist

SLIDE 11

DataCamp Interactive Data Visualization with rbokeh

Scatter Plot + Regression Line

SLIDE 12

DataCamp Interactive Data Visualization with rbokeh

Scatter Plot + Regression Line

First: create scatter plot

## filter data dat_90_13 <- bechdel %>% filter(between(year, 1990, 2013)) ## create scatter plot p_scatter <- figure() %>% ly_points(x = log(budget_2013), y = log(intgross_2013), data = dat_90_13, size = 5, alpha = 0.4)

SLIDE 13

DataCamp Interactive Data Visualization with rbokeh

Scatter Plot + Regression Line

Second: fit linear regression model

## fit linear regression model lin_reg <- lm(log(intgross_2013) ~ log(budget_2013), data = dat_90_13) > summary(lin_reg) Call: lm(formula = log(intgross_2013) ~ log(budget_2013), data = dat_90_13) Residuals: Min 1Q Median 3Q Max

9.9518 -0.5414 0.1304 0.7083 4.8586

Coefficients: Estimate Std. Error t value Pr(>|t|) (Intercept) 2.43003 0.38987 6.233 5.84e-10 *** log(budget_2013) 0.90739 0.02253 40.269 < 2e-16 ***

Signif. codes: 0 ‘***’ 0.001 ‘**’ 0.01 ‘*’ 0.05 ‘.’ 0.1 ‘ ’ 1

Residual standard error: 1.258 on 1605 degrees of freedom (8 observations deleted due to missingness) Multiple R-squared: 0.5026, Adjusted R-squared: 0.5023 i i 1622 1 d 1605 l 2 2 16

SLIDE 14

DataCamp Interactive Data Visualization with rbokeh

Scatter Plot + Regression Line

## add regression line p_scatter %>% ly_abline(lin_reg)

SLIDE 15

DataCamp Interactive Data Visualization with rbokeh

Now it is your turn!

INTERACTIVE DATA VISUALIZATION WITH RBOKEH

SLIDE 16

DataCamp Interactive Data Visualization with rbokeh

Interaction Tools

INTERACTIVE DATA VISUALIZATION WITH RBOKEH

Omayma Said

Data Scientist

SLIDE 17

DataCamp Interactive Data Visualization with rbokeh

Interaction Tools

SLIDE 18

DataCamp Interactive Data Visualization with rbokeh

Interaction Tools

SLIDE 19

DataCamp Interactive Data Visualization with rbokeh

Interaction Tools (Default)

figure(tools = c("pan", "wheel_zoom", "box_zoom", "reset", "save", "help"), toolbar_location = "right")

SLIDE 20

DataCamp Interactive Data Visualization with rbokeh

Interaction Tools (All)

tools

"pan", "wheel_zoom", "box_zoom", "resize", "crosshair", "box_select", "lasso_select", "reset", "save", "help"

toolbar_location

'above', 'below', 'left', 'right', NULL

SLIDE 21

DataCamp Interactive Data Visualization with rbokeh

Interaction Tools (Custom)

figure(tools = c("pan", "wheel_zoom", "box_zoom"), toolbar_location = "above", legend_location = "bottom_right", ylim = c(0, 100)) %>% ly_points(x = gdpPercap, y = lifeExp, data = gapminder_2002, color = continent, size = 6, alpha = 0.7)

SLIDE 22

DataCamp Interactive Data Visualization with rbokeh

Interaction Tools (Custom)

SLIDE 23

DataCamp Interactive Data Visualization with rbokeh

Saving rbokeh Figures

png html

plot_scatter <- figure(title = "Life Expectancy Vs. GDP per Capita in 2002", legend_location = "bottom_right") %>% ly_points(x = gdpPercap, y = lifeExp, data = gapminder_2002) ## save figure as png widget2png(p = plot_scatter, file = "plot_scatter.png") ## save figure as html rbokeh2html(fig = plot_scatter, file = "plot_scatter_interactive.html") ## open saved html browseURL("plot_scatter_interactive.html")

SLIDE 24

DataCamp Interactive Data Visualization with rbokeh

Time to Practice

INTERACTIVE DATA VISUALIZATION WITH RBOKEH
