Data Caching, Garbage Collection, and the Java Memory Model

Wolfgang Puffitsch wpuffits@mail.tuwien.ac.at JTRES ’09, September 23-25, 2009

1 / 24

Motivation I

◮ Sequential consistency is expensive ◮ Multi-processors often implement

relaxed memory models

◮ JMM is a logical choice for a Java

processor

2 / 24

Motivation II

◮ JMM specifies memory model for

application

◮ JMM is agnostic of run-time system ◮ Minimal communication between

application and GC

◮ Asymmetric synchronization 3 / 24

The Java Memory Model

◮ Happens-before relation ◮ Similar to lazy release consistency ◮ Allows various optimizations ◮ Rules out a number of odd behaviors

◮ Causality must be obeyed 4 / 24

Surprising Behavior

int x = 0; Thread T1 Thread T2 int r1 = x; int r2 = x; x = 1; x = 2; Java memory model allows r1==2, r2==1

5 / 24

Data Cache Implementation I

◮ Implemented for JopCMP ◮ Predictable, low HW cost ◮ Follows idea of lazy release consistency ◮ Invalidate cache on monitorenter and

volatile reads

◮ Write-through cache

6 / 24

Data Cache Implementation II

◮ No global store order ◮ Accesses cannot bypass each other

locally

◮ Relatively simple memory model

◮ Good predictability

◮ Consistency actions are always local 7 / 24

Moving Objects

◮ Only minimal communication between

application and GC

◮ Avoid synchronization overhead for

reads

◮ How to force application to see moved

• bjects?

◮ Invalidate cache for each moved object ◮ Stronger memory model ◮ Avoid movement of objects 8 / 24

GC Algorithms – GC Cycle

void runGC () { // i n i t i a t e new GC c y c l e s t a r t C y c l e ( ) ; // r e t r i e v e root s gatherRoots ( ) ; // t r a c e the

• b j e ct

graph traceObjectGraph ( ) ; // c l e a r

• b j e c t s

that are s t i l l white sweepUnusedObjects ( ) ; //

• p t i o n a l memory defragmentation

defragment ( ) ; }

9 / 24

Tricolor Abstraction

◮ White objects have not been visited ◮ Gray objects need to be visited ◮ Black objects have been visited ◮ After tracing, reachable objects are

black and white objects are garbage

10 / 24

GC Algorithms – Tracing

void traceObjectGraph () { // while there are s t i l l gray

• b j e c t s

while ( ! grayObjects . isEmpty ( ) ) { // get a gray

• b je c t

Object

• bj = grayObjects . removeFirst ( ) ;

// i t e r a t e

• ver

a l l r e f e r e n c e f i e l d s for ( F i e l d f in g e t R e f F i e l d s ( obj )) { Object f i e l d V a l = g e t F i e l d ( obj , f ) ; // mark r e f e r e n c e d

• b j e c t s

i f ( c o l o r ( f i e l d V a l ) == white ) { markGray ( f i e l d V a l ) ; } } markBlack ( obj ) ; }}

11 / 24

GC Algorithms – Write Barrier

void putFieldRef ( Object

• bj ,

F i e l d f , Object newVal ) { // snapshot−at−beginning b a r r i e r Object

• ldVal = g e t F i e l d ( obj ,

f ) ; i f ( c o l o r ( oldVal ) == white ) { markGray ( oldVal ) ; } // w r i t e new value to f i e l d p u t F i e l d ( obj , f , newVal ) ; }

12 / 24

Tracing Requirements

The object graph can be traced correctly if

◮ a snapshot-at-beginning write barrier is

used, and

◮ new objects are allocated non-white, and ◮ a consensus is established at the

beginning of tracing

13 / 24

Tracing – Justification

◮ Objects must either be reachable from

snapshot or newly allocated

◮ Differences in object graph views must

stem from updates ⇒ write barrier

◮ Concurrent updates must see snapshot

◮ Works for our cache implementation ◮ Not guaranteed in JMM! 14 / 24

Tracing – JMM Counterexample

x.f == A; Thread T1 Thread T2 Obj o1 = x.f; Obj o2 = x.f; ... ... x.f = B; x.f = C; Java memory model allows o1==C, o2==B!

15 / 24

Sliding Consensus

◮ Consensus is established by invalidating

all caches

◮ How to make this non-atomically?

◮ Sliding view root scanning ◮ Invalidate cache at root scanning

◮ Assuming double-barrier

◮ Both old and new value are shaded 16 / 24

Start of GC Cycle – Requirements

◮ Field updates from earlier GC cycles

must be visible to write barriers of new GC cycle

◮ Field updates from earlier GC cycles

must be visible to root scanning

◮ Field updates from earlier GC cycles

must be perceived consistently

17 / 24

Start of GC Cycle – Consequences

◮ Clear separation of GC cycles ◮ Threads that are preempted while

executing a write barrier delay start of a GC cycle

18 / 24

Start of GC Cycle – Future work

◮ Costs of implementation choices to be

evaluated

◮ Avoid overlap of old and new barriers

◮ Handshake or mutual exclusion

◮ Enforce consistent perception in

write-barrier

◮ Bypass cache or cache invalidation 19 / 24

Object Initalization

◮ Threads must see default values ◮ Avoid synchronization between

allocation and potential uses

◮ Memory must not have been in use

since last GC cycle

◮ Cache invalidation at GC cycle start ⇒

Cache cannot contain stale values

◮ Analogue consideration for final values

20 / 24

Internal Data Structures

◮ Inter-thread communication of GC

algorithm

◮ Internal data structures can follow own

memory model

◮ E.g., bypass cache ◮ Avoids merging application and run-time

synchronization

◮ Depends on capabilities of platform 21 / 24

Conclusion I

◮ Cache that is consistent with JMM ◮ Moving of objects needs consistency

enforcement

◮ Tracing works if JMM surprising

behavior is avoided

◮ Start of GC cycle requires careful design

22 / 24

Conclusion II

◮ Object creation simple in some cases ◮ Run-time system synchronization can be

separated from application synchronization

23 / 24

Thank you for your attention!

24 / 24
