D hiren m Engineers & Consultant Dm what you think.....we bring it..... INTRODUCTION We are introduce our selves as D for D hiren & M for M achineries. First time in our Indian Market, We have developed WOO D EN

SLIDE 1

Dm what you think.....we bring it.....

Dhirenm

Engineers & Consultant

SLIDE 2

INTRODUCTION We are introduce our selves as “D” for Dhiren & “M” for Machineries. First time in our Indian Market, We have developed “WOODEN HANDLE MACHINERY” Fully Automatic, PLC Controlled, Pneumatically Operated, High Production Capacity.

SLIDE 3

We are Machinery Manufacturer of :-

Wooden Handle Machineries,
Special Types of Wood Working

Machineries,

Special Purpose / Sp. Application -

SPM - Customized Machineries,

Machine Tools, Jigs & Fixtures,
Designing & Engineering

Consultancy,

Pharmaceutical Machineries,

SLIDE 4

WOODEN HANDLE Machine

SLIDE 5

PAINT BRUSH WOODEN HANDLE Machine

SLIDE 6

Applications :-

SLIDE 7

Applications :-

This Machine can be used for Manufacturing of Wooden Handles of Round / Oval Types of any sizes & any shapes of Wooden Handles for Construction Inds. Tools, Work Shop Hand Tools, Carpenter Tools, Paint Brushes, Kitchen Ware, Furniture Inds, Agriculture Inds, Horticulture / Gardening Industries, Playground Equipments & Toys Inds etc.

Carpenter Tools & Work Shop Hand Tools :-

Chisels, Screw Driver Handles, Hand Hacksaw Handle, Hammer Handles, Garage tools Handles,

Painting Brush Industries :- All Types & All Sizes of

Paint Brush Wooden Handles, Roller Paint Handles,

Kitchen Ware Industries :- Utensils Handles, Bucket

Handles, Tokar, Tavetha, Scoop, Pavadi wooden handle

SLIDE 8

Applications (cont.) :-

Furniture Industries :- Drawers Wooden Handle, Door

Wooden Handle, Cupboard Wooden Handle,

Round Types of Legs of Beds, Tables, Cupboard, &
ther House Furniture items, Wooden Temple articles,
Agriculture / Horticulture / Gardening Industries :-

Wooden Handles for Shovels, Sickle, Pawrah, Pickaxe, Axe, Grass Trimmers, Grass Cutter, Plant cutter, Flower cutter, Crowbars etc

Construction Industries (Real Estate) :- Brick cutter, All

Types of Trowel Handles,

Playground Equipments & Toys Likes Skipping /

Jumping Rope Handles, Cricket Bat Handles, Dumbbells, & other Exercise Equipments.

Broom Wooden Handles, Mop wooden Handles.

SLIDE 9

Video of the Machine

SLIDE 10

Video of the Paint Brush Wooden Handle Machine

SLIDE 11

Specifications :-

Capacity : 150* to 400*pcs/hrs.
Power Consumption : 2 / 3 HP*
Cutter Speed : 4000/6000 RPM*

*(as per Wood Property sizes & Shapes)

Video Link : (Round Type All Wooden Handle)

https://www.youtube.com/watch?v=ss9EsUBtyHA&featur e=youtu.be

Video Link : (Paint Brush Wooden Handle)

https://www.youtube.com/watch?v=EmgY5yWIENI

Delivery Terms : 6 to 10 Weeks.

SLIDE 12

Fully Automatic,
Pneumatically Operated,
PLC Controlled,
Auto Feeder for Wood pc (Job),
Auto Ejection for Finished Job,
All safety Interlocks & Safety Guards are

provided for full safety to avoid an accident & damages of machine & human.

No Wood Piece (Job) at Centre, Cutter will not

start.

Full Safety with required Proxy Switches &

Sensors,

Features & Competitive Advantages :-

SLIDE 13

Features & Competitive Advantages :-

High Production Capacity
Auto Drilling of Job at Single Side (Optional),
Auto Drilling of Job at Other Side (Optional),
Auto Polishing - Papering (Optional),
Easy to Operate, User Friendly,
Low Maintenance Cost,
High Durability,
Continuous Process (Less Men power Required)
Low Power Consumption,
User Friendly,

SLIDE 14

Utility Requirements :-

2 HP / 3 HP* Electric Power supply Three

Phase 415 V 50 Hz / Single Phase 230 V 50 Hz (*as per wood property, wooden Handle size & shape)

Compressed Air up to 6 bar (6 kg/sq.cm)

SLIDE 15

Other Machineries :-

WE ARE ALSO MANUFACTURING MACHINERIES

FOR LONG WOODEN HANDLES UP TO 48” FOR BROOMS, MOPS, SHOVELS, SICKLES, PAWRAH, PICKAXES, AXES etc.

WE ARE ALSO PROVIDING CUSTOMIZED

WOOD WORKING MACHINERIES AS PER CUSTOMER'S REQUIREMENT.

WE ARE ALSO MANUFACTURING ALL TYPES OF

CUSTOMIZED MACHINERIES & SPECIAL PURPOSE MACHINERIES.

SLIDE 16

Other Machineries :-

SLIDE 17

Other Machineries :-

(continuous)

SLIDE 18

Long Wooden Handles Images :-

SLIDE 19

Contact :- Dhirenm Engineers & Consultant

Address :- 142, Parishram Estate, Nr. Jantanagar, CTM-Ramol Road, Ramol, Ahmadabad – 38, Gujarat, INDIA. Address :- A/37, Sarathi Tenements, Nr. Geban-Shah Pir Mosque, B/H. Partheshwar Mahadev Temple, Isanpur, Ahmadabad – 382443, Gujarat, INDIA. Mobile :- +91-99137 96866 / +91-99097 10140 WhatsApp :- 98791 86866. Email :- dhiren9256@gmail.com; dhiren9256@yahoo.com; Website :- www.dhirenm.com; www.dhirenm.in;
