Current and future satellite based broadband technologies ATU - - PowerPoint PPT Presentation

SES Proprietary and Confidential SES Proprietary and Confidential

Presented by Patrick van Niftrik VP Spectrum Development EMEA Presented on 28 April 2016

Current and future satellite based broadband technologies

ATU Capacity building workshop – Cotonou, Benin

SES Proprietary and Confidential ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

2 Addis Ababa Ethiopia Johannesburg South Africa Accra Ghana

Global satellite operator providing capacity for reliable and secure satellite services and solutions 10 satellites at 7 orbital positions. With C- and Ku-band over the entire continent SES satellites and teleports are supporting communications networks across Africa Committed to growing the African continent with local teams & regional

• ffices in Johannesburg, Accra and

Addis Ababa Caravan and Elevate programmes

Caravan Elevate

► SES invested heavily in satellites system covering the region

including platforms and ground segment facilities

SES investments and presence in Africa

SES Proprietary and Confidential

Supporting Africa growth with satellites Undersea cables only serve the coasts

3

 300 million people are over 50 km from fibre or cable broadband connection

The greater the distance the worse the connection quality.

 400 million people have no internet access at all

10% more broadband connectivity equals 1.38% increase in GDP for developing nations.

 Broadband cables are expensive to install

Fibre bridges the digital divide between the Western World and Africa, but does not bridge the digital divide within Africa between urban and non- urban areas.

 Satellite provides efficient way of connecting the majority of the 700 million unconnected people

Satellite also has the advantage of reach, providing an efficient way of connecting the majority of the poorly connected people. Snapshot of African undersea cables

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

4

► SES satellites covering Africa support the growing demand for modern

telecommunications and bridge the digital divide in the continent: e-Health, e-Education, Digitalization, Ground equipment, …

e-Health e-Education e-Government Broadcasting Broadband WiFi hotspot

Bridging the digital divide into the continent

SES Proprietary and Confidential

5

22°W 5°E 28.2°E

Francophone West & Central Africa 1 satellite SES-4 East & Southern Africa 2 satellites ASTRA-A4 & SES-5 Anglophone West Africa 2 satellites ASTRA-2F & ASTRA-2G

► SES’ 3 prime video orbital positions at 22W, 5°E and 28.2W currently

carry 7 DTH platforms, reaching 7M TV homes with over 500 channels

1.5 M TV HH 0.5 M TV HH 5 M TV HH

Television landscape Sub-Sahara African DTH platforms on SES’ satellites

SES Proprietary and Confidential

6 Addis Ababa Ethiopia Johannesburg South Africa Accra Ghana

Elevate

SES Elevate programme

 SES Quality Assurance and Accreditation training programme for Satellite dish installers across the African continent  Train, motivate and engage with installers network to support DTH  Conceived in 2012  Trainings conducted in 12 African countries  Theoretical and practical aspects  The SES ELEVATE team has so far trained over 5,000 installers !!

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

7 Addis Ababa Ethiopia Johannesburg South Africa Accra Ghana

Elevate

SES Elevate programme

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

A shared satellite antenna & WiFi or other wireless in the last mile SolarKiosk (Ethiopia) Wifi Mini Hotspot

8

► Satellite delivers internet connectivity to rural communities which can enable e- commerce, e-school, e-health and e-government initiatives

Process Applications

Households Mobile/ Roaming users SME

SES Broadband for Kiosks and Wifi Hotspots

SES Proprietary and Confidential

What is SATMED

9

• Secure data storage and content

management capacities

• Satellite connectivity for areas in which mobile or

terrestrial internet is lacking

• E-Health tools (covers full spectrum of e-health

including e-learning, e-care and e-surveillance)

SATMED is a cloud-computing based e-health platform that operates on a global scale.

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

Connectivity Support for elections in Burkina Faso

10

 The project was about interconnecting the 368 election sites across Burkina Faso to support the presidential and legislative elections  Each site had to be equipped with a VSAT station to allow for a rapid transmission of the results from the local offices to the headquarters of the ‘Commission Electorale Nationale Indépendante’ (CENI), where the results were consolidated before they got published.  CENI had committed to a publication of the election results 24 hours after closure

• f the polling stations to demonstrate the commitment to a transparent and fair

election process.  Fast deployment : the implementation of a satellite communications system for electoral data transmission within eight weeks from contract signature

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

11

11

► O3b constellation is already connecting customers in

South Sudan, D.R. Congo and Somalia Fiber capacity & low latency via O3b

 Circular equatorial orbit at 8062 km altitude (MEO)  O3b’s operates in Ka-band  Fiber-like latency and capacity

SES Proprietary and Confidential

Communication ecosystem is evolving

12

Traditional ecosystem mainly connected linear broadcast customers

Teleport GEO Direct-to-Home Television

Infrastructure Connected nodes Device/ application

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

Communication ecosystem is evolving

13

Modern ecosystem also includes deeper networks/applications with a multitude of connectivity options

Remote Enterprise Enterprise Teleport Computing Data Centres Big Data Machine-to- Machine GEO MEO Cellular Direct-to-Home WiFi Television Personal Computing E-Commerce Mobile Devices Maritime Aeronautical Public WiFi Fiber Optics

Infrastructure Connected nodes Device/ application

Fixed Microwave ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

SES’s new satellite mantra

14

solution Issue / opportunity

~50% of total payload mass is traditionally propellant; of which ~⅔ burnt in a few days

Light in weight

1

Electric propulsion

Communication ecosystem is evolving with additional need for more efficient, affordable data connectivity solutions

Efficient in beams

2

HTS capacity Digital processing

Currently takes ~3 years to design, build and launch a GEO satellite

Fast to market

3

New launch vehicles Exploring other possibilities

(e.g. modular construction, reusable rockets)

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

Delivering greater flexibility of market coverage

15

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

For illustrative purposes only

SES Proprietary and Confidential

Building SES’s future technology infrastructure

16

Next Gen: Now Next Next Gen: 2019 Future: Blue Sky

 Electric propulsion allows for larger satellites to be launched on smaller vehicles  Selective payload processing builds in flexibility to market demand  Qualifying new launch vehicles (Falcon 9) which diversify access to space  Hybrid network offerings interconnecting SES’s GEO coverage with low latency/low cost per bit of O3b  Massively processed payloads optimising spectrum allocation  Full digitisation means simpler, smaller, lighter payload manufacturing  Fully reusable launch vehicles (Falcon 9-R) which amortises rocket costs over multiple missions  Satellite at heart of universal global transparent network  Upgradeable payloads leverage digital technology evolution rates  Advanced launch strategies (e.g. ‘space tugs’) maximising efficiency to orbit  Allocation-specific programmable transponders allow payloads to be reconfigured in software on orbit

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

Patrick van Niftrik VP Spectrum Management and Development, EMEA patrick.vanniftrik@ses.com T +31 70 306 4226 M +971 52 612 0319

STAY IN TOUCH

www.ses.com

Thank you!

Questions?

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

18

Appendix

SES Fleet coverage over Africa

SES Proprietary and Confidential

SES C-band capacity over Africa

19 19

SES-5 5°E NSS-12 57°E SES-4 22°W NSS-10 37.5°W NSS-7 20°W

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016

SES Proprietary and Confidential

SES Ku-band capacity over Africa

20 20

SES-4 22°W ASTRA 4A + SES-5 5°E ASTRA 2F/2G 28.2°E NSS-12 57°E

East Africa: West & Central Africa: Southern Africa:

ATU Capacity building workshop – Cotonou, Benin – 25-28 April2016
