SLIDE 1
CSCI261
Lecture 27: Events, Interrupts & Event Handling Memory, Stack, Stack Frames, The Heap
Attribution: http://123rf.com
CSCI261 Lecture 27: Events, Interrupts & Event Handling Memory, - - PowerPoint PPT Presentation
CSCI261 Lecture 27: Events, Interrupts & Event Handling Memory, - - PowerPoint PPT Presentation
CSCI261 Lecture 27: Events, Interrupts & Event Handling Memory, Stack, Stack Frames, The Heap Attribution: http://123rf.com keypress Keyboard Interface (Serial USB) Bus CPU Operating System Application keypress Keyboard Interface
SLIDE 2
SLIDE 3
Keyboard Interface (Serial USB) Bus CPU Operating System Application
keypress
SLIDE 4
Keyboard Interface (Serial USB) Bus CPU Operating System Application
keypress electrical signal hardware “interrupt”
“oooh, a keypress event” event handler
SLIDE 5
Event Loop
Modern graphical programs wait in an infinite “event loop,” waiting for some events to happen. update(); draw(); update(); draw(); update(); draw();
SLIDE 6
Event Handling
When an event occurs, call a function. an “event handler”
SLIDE 7
OF Event Handlers
- keyPressed
- keyReleased
- mouseMoved
- mouseDragged
- mousePressed
- mouseReleased
- windowResized
SLIDE 8
SLIDE 9
Memory & Functions
- Stack
- Stack Frames
- The Heap
SLIDE 10
The Stack
LIFO
SLIDE 11
int main() { int x = 2; int y = 5; int z = sum(x, y); }
2 5
?
SLIDE 12
int main() { int x = 2; int y = 5; int z = sum(x, y); }
2 5
?
int sum(int x, int y) { return x + y; }
2 5
local variables
SLIDE 13
int main() { int x = 2; int y = 5; int z = sum(x, y); }
2 5
?
int sum(int x, int y) { return x + y; }
2 5 7
stack frame
SLIDE 14
int main() { int x = 2; int y = 5; int z = sum(x, y); }
2 5
int sum(int x, int y) { return x + y; }
5
SLIDE 15
Stack Frames
One aspect of where “scope” comes from. Contains parameter values, local variable values, and “bookkeeping” information. Function call? New stack frame. Function return? Pop the entire stack frame.
SLIDE 16
Problem
Things created within functions “go away” after the function returns... ... and sometimes, we want those “things” to stick around after the function returns.
SLIDE 17
Problem
Storing too much on the stack can cause “stack overflow” http://stackoverflow.com
SLIDE 18
Problem
In many cases, we do not know how much memory to allocate at compile time. We must allocate memory dynamically, during run-time.
SLIDE 19
Is there another place we can store stuff?
SLIDE 20
SLIDE 21
The Heap
A pool of unused memory, for your programs to use.
aka “the free store”
SLIDE 22
Stack vs. Heap
- rganized
efficient accessed “directly” storage of “things” known in advance and more... unorganized less efficient (but we don’t care) dynamic storage and more...
SLIDE 23
Heap
The exact location of things on the heap is not known in advance. How can your code access data whose locations are not known in advance?
SLIDE 24
How can your code access data whose locations are not known in advance?
Pointers
(to be continued)
SLIDE 25
Homework
Choose final project partners and send your instructor an email.
