CSCI 350 Ch. 8 Address Translation Mark Redekopp Michael Shindler - - PowerPoint PPT Presentation

1

CSCI 350

• Ch. 8 – Address Translation

Mark Redekopp Michael Shindler & Ramesh Govindan

2

Abstracting Memory

• Thread = Abstraction of the processor
• What about abstracting memory?

– "All problems in computer science can be solved by another level of indirection"

• Address translation => Abstraction of memory

Processor Memory Output Devices Input Devices

Software Program Data

3

Benefits of Address Translation

• What is enabled through address translation?

– Illusion of more or less memory than physically present – Isolation – Controlled sharing of code or data – Efficient I/O (memory-mapped files) – Dynamic allocation (Heap / Stack growth) – Process migration

4

Virtual vs. Physical Addresses

• Translation between:

– Virtual address: Address used by the process (programmer) – Physical address: Physical memory location of the desired data

Translation Unit / MMU (Mem. Mgmt. Unit)

Proc. Core

Virtual Addr

Memory

Physical Addr Data 0x00000000 0x3fffffff

frame

• Pg. 1

Physical Memory and Address Space

• Pg. 0
• Pg. 3
• Pg. 2
• Pg. 0

frame I/O and un- used area

0xffffffff

• Pg. 0
• Pg. 1
• Pg. 2
• Pg. 3

unused

• Pg. 0
• Pg. 1
• Pg. 2
• Pg. 0
• Pg. 1
• Pg. 2
• Pg. 3

Secondary Storage

… unused … unused … unused

• Pg. 0
• Pg. 1
• Pg. 2
• Pg. 3
• Pg. 0
• Pg. 1
• Pg. 2
• Pg. 0
• Pg. 1
• Pg. 2
• Pg. 3

Fictitious Virtual Address Spaces

5

Translation Goals & Roadmap

• Functional Goals

– Isolation and transparency to programmer – Controlled sharing – Support for sparse address spaces and dynamic resizing

• Performance Goals

– Flexible physical placement – Fast translation – Low memory overhead (compact tables)

• We'll first focus on function and then discuss

efficiency

6

Evolution of Translation

• Base + bounds check
• Segmentation
• Paging

7

SEGMENTATION

8

Base and Bounds

• Each running process has a:

– Virtual address space from VA: 0 to N-1 – Physical address space from PA: BASE to BASE+N-1

• Program written (compiled) using VAs and determine

necessary BOUND (i.e. N)

• When loaded, OS assigns BASE (phys. addr. space) dynamically
• Hardware converts VAs to PAs and performs bounds check

CPU

esp

VA: 0x02000

ebx eip eax Translation Unit / MMU

0x14000

base

0x05000

bound

> + PA: 0x16000

Exception

Physical Addr Virtual Addr

unused

P1 Phys. Addr. Space Base: 0x14000 Base + Bound: 0x19000 0x16000 P2 Phys Addr. Space

• The "BASE" and "BOUNDS" registers

and checking hardware are termed the MMU (Mem. Mgmt. Unit) or Translation Unit

• Base and Bound are loaded/restored
• n process switches.

9

Base and Bounds Pros & Cons

• Pros:

– Simple – Provides isolation amongst processes

• Cons:

– No easy way to share data – Can't enforce access rights within the process (e.g. code = read only)

• Processes can "rewrite" their own address space

CPU

esp

VA: 0x02000

ebx eip eax Translation Unit / MMU

0x14000

base

0x05000

bound

> + PA: 0x16000

Exception

Physical Addr Virtual Addr

unused

P1 Phys. Addr. Space Base: 0x14000 Base + Bound: 0x19000 0x16000 P2 Phys Addr. Space

• The "BASE" and "BOUNDS" registers

and checking hardware are termed the MMU (Mem. Mgmt. Unit) or Translation Unit

• Base and Bound are loaded/restored
• n process switches.

10

Segmentation

• Allow a process to be broken into multiple base +

bounds "segments"

– Code, data, stack, heap

• Multiple base + bounds registers stored in a table

in the MMU

• Updating the table is a "privileged" (kernel-only)
• peration

CPU

esp

VA: 0x102000

ebx eip eax Translation Unit / MMU

> + PA: 0x16000

Exception

Physical Addr Virtual Addr

unused Stack Seg.

Base: 0x14000 Base + Bound: 0x19000 0x16000 0x2a000 0x03200 R/W Base Bound R/W 0x14000 0x05000 R/W 0x08000 0x0400 R 1 02000 seg.

• ffset

1 2 Descriptor Table 1:1:3

ss

13 bits=Seg. 1=LDT/0=GDT 0-3=RPL

• Seg. Reg.

Format:

Data Seg.

Base: 0x2a000

Code Seg.

Base + Bound: 0x2d200 Base: 0x08000 Base + Bound: 0x80400

http://ece-research.unm.edu/jimp/310/slides/micro_arch2.html

11

Segmentation Pros

• Enforce access rights to various segment using access bit

entries in the segment descriptor

• Detect out of bounds accesses (segmentation fault)
• Memory mapped files (segment = file on disk)
• Sharing code + data (see example in a few slides)

– Shared code / libraries and/or data – One code segment for multiple instances of a running program

• Key idea: What is behind a segment can be "anything"

– Translation gives us a chance to intervene

CPU

esp

VA: 0x102000

ebx eip eax Translation Unit / MMU

> + PA: 0x16000

Exception

Physical Addr Virtual Addr

unused Stack Seg.

Base: 0x14000 Base + Bound: 0x19000 0x16000 0x2a000 0x03200 R/W Base Bound R/W 0x14000 0x05000 R/W 0x08000 0x0400 R 1 02000 seg.

• ffset

1 2 Descriptor Table 1:1:3

ss Data Seg.

Base: 0x2a000

Code Seg.

Base + Bound: 0x2d200 Base: 0x08000 Base + Bound: 0x80400

12

Segmentation Cons

• External Fragmentation

– As a system runs and segments are created and deleted the physical address may have many small, unusable gaps and we effectively lose that memory for use

• Growing a segment may be hard since they must

be contiguous (other segments may be bracketing

• ur growth)

CPU

esp

VA: 0x102000

ebx eip eax Translation Unit / MMU

> + PA: 0x16000

Exception

Physical Addr Virtual Addr

unused Stack Seg.

Base: 0x14000 Base + Bound: 0x19000 0x16000 0x2a000 0x03200 R/W Base Bound R/W 0x14000 0x05000 R/W 0x08000 0x0400 R 1 02000 seg.

• ffset

1 2 Descriptor Table 1:1:3

ss

13 bits=Seg. 1=LDT/0=GDT 0-3=RPL

• Seg. Reg.

Format:

Data Seg.

Base: 0x2a000

Code Seg.

Base + Bound: 0x2d200 Base: 0x08000 Base + Bound: 0x80400

http://ece-research.unm.edu/jimp/310/slides/micro_arch2.html

13

x86 Segmentation

• Segment descriptors are stored in tables in the kernel's memory

region

• Local descriptor table (LDT) [Mem]: Up to 8192 segment

descriptors for each process

• Global descriptor table (GDT) [Mem]: Kernel, LDT, and a few
• ther types of descriptors

– Pointed to by GDTR / Interrupt descriptor table pointed to by IDTR

• MMU (in CPU) stores a cache of descriptors from the process'

LDT for each segment register (CS, DS, SS, ES, FS, GS)

CPU

esp

VA: 0x102000

ebx eip eax Translation Unit / MMU

> + PA: 0x16000

Exception

Physical Addr Virtual Addr

unused Stack Seg.

Base: 0x14000 Base + Bound: 0x19000 0x16000 0x2a000 0x03200 R/W Base Bound R/W 0x14000 0x05000 R/W 0x08000 0x0400 R 1 02000 seg.

• ffset

DS SS CS Descriptor Cache 1:1:3

ss Data Seg.

Base: 0x2a000

Code Seg.

Base + Bound: 0x2d200 Base: 0x08000 Base + Bound: 0x80400

http://ece-research.unm.edu/jimp/310/slides/micro_arch2.html LDT1 GDT

0xc4000 GDTR 0xc0000 0xc4000 IDTR LDT/ TR 0xc0000 8191 0:1:3

cs

2:1:3

ds

14

Multiple Processes + Sharing

• A physical segment can be shared by 2

processes by setting up the descriptor

CPU

esp

VA: 0x102000

ebx eip eax Translation Unit / MMU

> + PA: 0x16000

Exception

Physical Addr Virtual Addr

unused P1 Stack

Base: 0x14000 0x16000 0x7a000 0x03200 R/W Base Bound R/W 0x14000 0x05000 R/W 0x08000 0x0400 R 1 02000 seg.

• ffset

DS SS CS Descriptor Cache 1:1:3

ss P2 Data

Base: 0x7a000

P1/P2 Code

Base: 0x08000

http://ece-research.unm.edu/jimp/310/slides/micro_arch2.html LDT1 GDT

0xc4000 GDTR 0xc0000 0xc4000 IDTR LDT/ TR 0xc0000

8191

0:1:3

cs

2:1:3

ds LDT2

8191

P1 Data P2 Stack

0x7e000 0x01000 R/W Base Bound R/W 0x6e000 0x05000 R/W 0x08000 0x0400 R DS SS CS Base: 0x6e000 Base: 0x7e000

Process 2 Process 1

15

Forking a Process & Copy-On-Write

• Recall forking a process makes a "copy" of the address space

– Generally going to "exec" soon afterward

• In reality we can just make a copy of the page directory but

mark all entries read/only

• On any write, we will gen. an exception and we can make a

copy of the segment for the child (aka Copy-On-Write)

• If no write, the two processes can share and thus we save time

avoiding the copy

• This is an example of a general concept called Lazy Evaluation

– Start by doing minimal required work; do more work when required CPU

esp

VA: 0x102000

ebx eip eax Translation Unit / MMU unused Stack Seg.

Base: 0x14000 Base + Bound: 0x19000 0x16000 0x2a000 0x03200 R/W Base Bound R/W 0x14000 0x05000 R/W 0x08000 0x0400 R 1 2 1:1:3

ss Data Seg.

Base: 0x2a000

Code Seg.

Base + Bound: 0x2d200 Base: 0x08000 Base + Bound: 0x80400 0x2a000 0x03200 R 0x14000 0x05000 R 0x08000 0x0400 R 1 2 Forked Proc Seg. Table (Read only) Parent Proc Seg. Table (Read only)

16

Shared Library Tangent

• All programs don't need to link in the same

library functions (think printf, strcpy, memset, etc.)

• Place the library functions in a shared library

– Problem: Compiled progs. won't know where the library code will be when compiled – Solution: Compiler generates code to lookup any call to a shared function's in a table that it generates but loader fills in with actual library – Map a segment to describe that shared code area

unused P1 Stack

Base: 0x14000 0x16000

P2 Data

Base: 0x7a000

Shared Lib.

Base: 0x08000

LDT1 GDT

0xc0000 0xc4000 8191

LDT2

8191

P1 Code P2 Code

Base: 0x6e000 Base: 0x7e000

CPU

esp

VA: 0x102000

ebx eip eax Translation Unit / MMU

0x2a000 0x03200 R/W Base Bound R/W 0x14000 0x05000 R/W 0x08000 0x0400 R 1 2 1:1:3

ss

• Proc. 2
• Proc. 1

0x7e000 0x01000 R/W Base Bound R/W 0x6e000 0x05000 R/W 0x08000 0x0400 R 2 3 4 printf 0x400 strcpy 0x640 … … printf 0x400 strcpy 0x640 … …

17

PAGING

18

Paging

• Helps to avoid external fragmentation

– No unused "gaps" in memory

• Virtual memory (process' viewpoint) is

divided into equal size "pages" (4KB)

• Physical memory is broken into page

frames (which can hold any page of virtual memory and then be swapped for another page)

• Virtual address spaces are contiguous

while physical layout is not

Physical Frame of memory can hold data from any virtual page. Since all pages are the same size any page can go in any frame (and be swapped at our desire).

0x00000000 0x3fffffff

frame

• Pg. 1
• Pg. 0
• Pg. 3
• Pg. 2
• Pg. 0

frame I/O and un- used area

0xffffffff

• Pg. 0
• Pg. 1
• Pg. 2
• Pg. 3

unused …

• Pg. 0
• Pg. 1
• Pg. 2

unused unused …

• Phys. Addr.

Space

• Proc. 1 VAS Proc. 2 VAS

19

Page Size and Address Translation

• Since pages are usually retrieved from disk, we size them to be fairly large

(several KB) to amortize the large access time

• Virtual page number to physical page frame translation performed by HW

unit = MMU (Mem. Management Unit)

• Page table is an in-memory data structure that the HW MMU will use to look

up translations from VPN to PPFN

Offset within page

Virtual Address

Virtual Page Number

31 12 11

Offset within page

Physical Address

• Phys. Page Frame

Number

31 30 12 11

00

Copied

12

Translation Process (MMU + Page Table)

29 20 18

20

Analogy for Page Tables

• Suppose we want to build a caller-ID mechanism for your

contacts on your cell phone

– Let us assume 1000 contacts represented by a 3-digit integer (0-999) by the cell phone (this ID can be used to look up their names) – We want to use a simple Look-Up Table (LUT) to translate phone numbers to contact ID’s, how shall we organize/index our LUT

213-745-9823

LUT indexed w/ contact ID

000

LUT indexed w/ all possible phone #’s

626-454-9985 … 323-823-7104 818-329-1980 001 002 999 null 000-000-0000 .. … null 000 213-745-9823 999-999-9999

Sorted LUT indexed w/ used phone #’s

436 213-745-9823 000 … 002 999 323-823-7104 213-730-2198 818-329-1980

O(n) - Doesn’t Work We are given phone # and need to translate to ID (1000 accesses) O(log n) - Could Work Since its in sorted order we could use a binary search (log21000 accesses) O(1) - Could Work Easy to index & find but LARGE (1 access) 1 2 3

21

Page Tables

• VA is broken into:

– VPN (upper bits) – Page offset: Based on page size (i.e. 0 to 4K-1 for 4KB page)

• VPN is index to the "Page Table"
• MMU uses VPN & PTBR to access the page table in memory and lookup physical

frame

• Physical frame is combined with offset to form physical address
• For 20-bit VPN, how big is the page table?

VA

Offset w/in page Virtual Page Number

31 12 11

Page Table Size = 220 entries * 19 bits = approx. 220*4bytes = 4MB

PTBR = Page Table Base Reg. Offset w/in page

PA

• Phys. Frame #

31 12 11

00

Page Frame Number … Valid / Present

20

CPU Memory

18

22

Paging

• Each process has its own virtual

address space and thus needs its own page table

• On context switch to new process,

reload the PTBR

CPU

esp

VA: 0x001040

ebx

VA: 0x002eac

eip eax Translation Unit / MMU

+ PA: 0x6e040 Physical Addr Virtual Addr

unused

VPN

• ffset

ss

Code 2.1

PT1 GDT

0xc4000 PTBR/CR3 0xc4000 0xd0000

cs ds PT2

0x7e000 R/W

• Phys. Frame #

R/W 0x6e000 R/W 0x08000 R 1 2 0x6e000

Process 2 Page Table Process 1

VPN 0x7e000 R/W

• Phys. Frame #

R/W 0x6e000 R/W 0x08000 R Stack 2.1 Data 1.1 Stack 1.1 Code 1.2 Data 2.1 Code1.1 1 2 VPN

• ffs: 0x040

PPFN: 0x6e000 0x08000 0x002 0xeac 0x001 0x040

• ffs: 0xeac

PA: 0x08eac PPFN: 0x08000 0xc4000 Physical Addr

Process 1 Page Table

23

Reducing the Size of Page Tables

• Can we use the table indexed using all possible phone numbers (because it only

requires 1 access) but somehow reduce the size especially since much of it is unused?

• Do you have friends from every area code? Likely contacts are clustered in only a few

area codes.

• Use a 2-level organization

– 1st level LUT is indexed on area code and contains pointers to 2nd level tables – 2nd level LUT’s indexed on local phone numbers and contains contact ID entries LUT indexed w/ all possible phone #’s

null … … 000 213 323

1st Level Index = Area Code

Area Code null 000-000-0000 .. … null 000 213-745-9823 999-999-9999 … 213 Table

2nd Level Index = Local Phone #

000-0000 999-9999 323 Table 000-0000 999-9999

If only 2 used area codes then only 1000 + 2(107) entries rather than 1010 entries

24

Analogy for Multi-level Page Tables

• Could extend to 3 levels if desired

– 1st Level = Area code and pointers to 2nd level tables – 2nd Level = First 3-digits of local phone and pointers to 3rd level tables – 3rd Level = Contact ID’s

null … … 000 213 323

1st Level Index = Area Code

Area Code …

2nd Level Index = Local Phone #

000 999 000 999 323 Table 213 Table null null 745 823 null null

3rd Level Index = Local Phone #

000 999 213-745 Table null 000 null 9823 000 999 323-823 Table null 999 null 7104

25

Analogy for Multi-level Page Tables

• If we add a friend from area code 408 we would have to add a second and

third level table for just this entry

null … … 000 213 323

1st Level Index = Area Code

Area Code …

2nd Level Index = Local Phone #

000 999 000 999 323 Table 213 Table null null 745 823 null null

3rd Level Index = Local Phone #

000 999 213-745 Table null 000 null 9823 000 999 323-823 Table null 999 null 7104

26

Multi-level Page Tables

CPU

esp

VA: 0x001040

ebx

VA: 0x002eac

eip eax Translation Unit / MMU

+ PA: 0x6e040 Physical Addr Virtual Addr

unused

VPN

• ffset

ss

Code 2.1

PTy PD

0xd0000 PDBR/CR3 0xc4000 0xd0000

cs ds PTx

0x0007e R/W

• Phys. Frame #

Acess 0x0006e R/W 0x00008 R 1023 0x6e000 PTIdx Phys PT Pointer Access Stack 2.1 Data 1.1 Stack 1.1 Code 1.2 Data 2.1 Code1.1 1023 PDIdx

• ffs: 0x040

PPFN: 0x6e000 0x08000 0x000 0x040 0xd0000 Physical Addr

Proc 1 Page Table y

0x001 PDIdx PTIdx

Page Directory

0x0007a R

• Phys. Frame #

R/W … … 0x00041 R/W 1023 PTIdx 0xe8000 0xe8000 1 0xc4000 0x4a000 0x7e000 0x7a000 0x000e8

• …

… 0x000c4

• Proc 1 Page Table x

27

Another View

1 2 1023 1 2 1023 1 2 1023 1 2 1023

Offset w/in page Level Index 1

31 12 11 22 21

Level Index 2

10 10

Pointer to start of 2nd Level Table PPFN’s

frame I/O and un- used area frame

0x0

Unused entries can store a NULL pointer (dark shaded entries) "Swapping" can be performed if no physical frames available when a new page need be allocated. We simply swap the page of data to disk to free up the physical frame. We can retrieve it when necessary. A secondary data structure (not shown) can be maintained for pages and store where that page’s data resides on disk

28

Page Table Entries (PTEs)

• Valid bit (1 = desired page in memory / 0 = page not present / page fault)
• Referenced = To implement replacement algorithms (e.g. pseudo-LRU)
• Protection: Read/Write/eXecute

Page Frame Number Valid / Present Modified / Dirty Referenced Protection Cacheable

29

Page Fault Steps

• What happens when you reference a page that is not present?
• HW will…

– Record the offending address and generate a page fault exception

• SW will…

– Pick an empty frame or select a page to evict – Writeback the evicted page if it has been modified

• May block process while waiting and yield processor

– Bring in the desired page and update the page table

• May block process while waiting and yield processor

– Restart the offending instruction

• Key Idea: Handler can bring in the page or do anything

appropriate to handle the page fault

– Allocate a new page, zero it out, perform copy-on-write, etc.

30

Multi-level Page Tables

• Think of multi-level page tables as a tree

– Internal nodes contain pointers to other page tables – Leaves hold actual translations

0x40 0x040 0x35 Virtual Addr VPN

• ffset

Idx1 Idx2 7 bits 7 bits 12 bits 0xd0000 PDBR/CR3 … … 0x3f 6 bits Idx3 [0x45] PT2[] = start addr PD start addr [0x3f] [0x35] PT3[] = start addr Level 1 Level 2 Level 3 CPU

• Phys. Frame Addr

…

Translations live in this level

31

Sparse Address Spaces

0x40 0x040 0x35 Virtual Addr VPN

• ffset

Idx1 Idx2 7 bits 7 bits 12 bits 0xd0000 PDBR/CR3 … … 0x3f 6 bits Idx3 [0x45] PT2[] = start addr PD start addr [0x3f] [0x35] PT3[] = start addr CPU

• Phys. Frame Addr

…

unused unused used unused used unused used used unused used used

Physical Address Space Pages can be anywhere.

used used used unused unused used unused used unused unused used

Virtual Address Space may be "sparse". In that case any PT entry can be null indicating no translations (and page tables are needed for those address ranges)

1 2 3 3 Notes:

• 1. No 2nd level table means…
• 2. …no 3rd level tables for that range
• 3. No 3rd level tables for NULL 2nd level

entries

32

x86 Segments + Paging

• x86 allows use of segments + paging
• Most modern OS's do NOT use x86

segmentation for newer (protected-mode) apps

• All segments use Base = 0, Bounds = 0xffffffff

and thus little use of LDTs

Segment Translation (Bounds checks)

Proc. Core

Virtual Addr

Memory

Physical Addr Data

Paging

33

32-bit x86 (Pintos) Translation

0x040 Virtual Addr VPN

• ffset

12 bits 0xd0000 PDBR/CR3 0x001 0x001 VPN PDIdx PTIdx 10 bits10 bits [0x3f] CPU … Level 1 (Page Dir) Level 2 (Page Table)

unused

Code 2.1

PTy

0xc4000 0xd0000

PTx

0x6e000 Stack 2.1 Data 1.1 Stack 1.1 Code 1.2 Data 2.1 Code1.1 0x08000 0xe8000 0x4a000 0x7e000 0x7a000

PD

0x040 + PA: 0x6e040 Physical Addr PPFN: 0x6e000

• 2 Level Page table

34

SPARC VM Implementation

Offset w/in page

Index 1

8 11 6

Index 2 Process ID Index 3

6

4095 MMU hold 4096 entry table (one entry per context/process) [Essentially, PTBR for each process] Context Table First Level Second Level Third Level 4K Page Desired word PPFN 28 * 4 bytes 26 * 4 bytes 26 * 4 bytes

Virtual Address:

35

Shared Memory

• In current system, all memory is

private to each process

• To share memory between two

processes, the OS can allocate an entry in each process’ page table to point to the same physical page

• Can use different protection

bits for each page table entry (e.g. P1 can be R/W while P2 can be read only)

1 2 3 1 2

… …

1 2

…

Physical Memory Page Tables P1 P2

36

Paged Segmentation (Not covered)

• Paging & segmentation can

be combined

• Segment could point to a

page table

– PT for Code, Data, Stack, etc.

• VA is broken into segment,

VPN, and offset

• Used when VA < PA

CPU

esp

VA: 0x102040

ebx

VA: 0x202eac

eip eax Translation Unit / MMU

+ PA: 0x6e040 Physical Addr Virtual Addr

unused ss

Code 2.1

PT1.1

0xc4000 0xcc000

cs ds PT1.0

0x7e000 R

• Phys. Frame #

R/W 0x6e000 R 0x08000 R 1 2 0x6e000

• Proc. 1 CS Page Table

VPN 0x75000 R/W

• Phys. Frame #

R/W 0x48000 R/W 0x6e000 R/W Stack 2.1 Stack 1.0 Stack 1.2 Code 1.0 Stack 1.1 Code1.1 1 2 VPN PPFN: 0x6e000 0x08000 0x02 0x040 0xc4000 Physical Addr

• Proc. 1 SS Page Table

0x1 0xcc000 0x18 R/W PTBase Bound (# pages) R/W 0xc4000 0x03 R/W 0xc8000 0x08 R/W 1 2 > 0x75000 0x48000 VPN offset seg. 0xcc000 Exception

• ffs: 0x040

Descriptor Table

37

Inverted Page Tables

• Page tables may seem expensive in terms of memory
• verhead

– Though they really aren't that big

• One option to consider is an "inverted" page table

– One entry per physical frame – Hash the virtual address and whatever results is where that page must reside

• What about collisions?

– Becomes hard to maintain in hardware, but can be used by secondary software structures

213-745-9823

LUT indexed w/ contact ID

000 626-454-9985 … 323-823-7104 818-329-1980 001 002 999 626-454-9985

Hash func.

38

A Note on Portability

• You can see that VM implementations

leverage specific HW registers and capabilities

• OSs may provide some VM abstraction for

easier portability

• Also may maintain secondary data structures

about virtual and physical pages to help this process

39

EFFICIENCY

40

VM Design Implications

• SLOW secondary storage access on page faults (10 ms)

– Implies page size should be fairly large (i.e. once we’ve taken the time to find data on disk, make it worthwhile by accessing a reasonably large amount of data) – Implies a “page fault” is going to take so much time to even access the data that we can handle them in software (via an exception) rather than using HW like typical cache misses [Other implications you might not yet understand yet w/o caching knowledge] – Implies eviction algorithms like LRU can be used since reducing page miss rates will pay off greatly – Implies the placement of pages in main memory should be fully associative to reduce conflicts and maximize page hit rates – Implies write-back (write-through would be too expensive)

41

Page Table Performance

• How many accesses to memory does it take to get the desired word that

corresponds to the given virtual address?

• So for each needed memory access, we need 3 additional?

– That sounds BAD!

• Would that change for a 1- or 2- level table?
• Walking the page table can take a long time

Offset w/in page

Index 1

8 11 6

Index 2 Process ID Index 3

6

4095 MMU hold 4096 entry table (one entry per context/process) [Essentially, PTBR for each process] Context Table First Level Second Level Third Level 4K Page Desired word PPFN 28 * 4 bytes 26 * 4 bytes 26 * 4 bytes

Virtual Address

42

Processor Chip Translation Unit / MMU

Translation Lookaside Buffer (TLB)

• Solution: Let’s create a cache for translations = Translation

Lookaside Buffer (TLB)

• Needs to be small (64-128 entries) so it can be fast, with high degree of

associativity (at least 4-way and many times fully associative) to avoid conflicts – On hit, the PPFN is produced and concatenated with the offset – On miss, a page table walk is needed

TLB Cache

CPU

VA VPN Page Offset PPFN PA data 10 ns 10 ns

Memory Memory (Page Table)

Hit Miss Miss Hit

Cost of Translation: Cost of TLB lookup + (1-P(TLB-hit) * Cost(Page Table Walk))

43

Translation Lookaside Buffer (TLB)

Offset w/in page

Virtual Address

Virtual Page Number

31 12 11

Page Frame # 0x308ac

Offset w/in page

Physical Address

• Phys. Frame #

31 12 11

V D 0x7ffe4 Tag = VPN

= = = =

Fully Associative TLB

(Entry can be anywhere and thus we must check all locations in TLB for a hit)

20 12

TLB

0x7ffe4

44

A 4-Way Set Associative TLB

• 64 entry 4-way SA TLB (wet field indexes each “way”)

– On hit, page frame # supplied quickly w/o page table access

Offset w/in page

Virtual Address

Virtual Page Number

31 12 11

Offset w/in page

Physical Address

• Phys. Frame #

31 12 11

Set Tag

Tag PF# Tag PF# Tag PF# Tag PF#

= = = =

Way 1 Way 0 Way 2 Way 3

4 16

45

TLB Miss Process

• On a TLB miss, there is some division of work between the hardware (MMU) and OS
• Option 1

– MMU can perform page table walk if needed – If page fault occurs, OS takes over to bring in the page

• Option 2

– If TLB miss, OS can perform both the page table walk and bring in page if necessary

• When we want to remove a page from memory

– First flush out blocks belong to that page from data cache (writing back if necessary) – Invalidate tags of those blocks – Invalidate TLB entry (if any) corresponding to that page

• If D=1, set dirty bit in page table

– If page is dirty, copy page back to the disk – Simple way to remember this…

• If parents (page) leave a party then the children (cache blocks & TLB entries) must leave too

46

Multiple Processes

• On a process context switch can TLB maintain mappings

– Can TLB share mappings from multiple processes?

• Recall each process has its own virtual address space, page table, and

translations

– Virtual addresses are not unique between processes

• How does TLB handle context switch

– Can choose to only hold translations for current process and thus invalidate all entries on context switch – Can hold translations for multiple processes concurrently by concatenating a process or address space ID (PID or ASID) to the VPN tag

Offset

VA

VPN

31 12 11

ASID

Unique ID for each process

Page Frame # V M Tag

= = = =

ASID

47

Page Sizes & Superpages

• For large contiguous chunks of virtual address space we can attempt to allocate a

large contiguous physical chunk

– All the lower (2nd) level entries of the page table would point at a contiguous range – Instead of the level 1 entry pointing at a level 2 page table, it has the physical address translation – A bit in the level 1 entry indicates if it contains this phys. translation or a pointer to the 2nd level table

0x00000000 0x3a000000

Super Page

• Pg. 3
• Pg. 2
• Pg. 0
• Pg. 0

frame I/O and un- used area

0xffffffff

• Phys. Addr. Space
• Pg. 0
• Pg. 1
• Pg. 2

unused unused

Super Page

• Virt. Addr.

Space

0x040 Virtual Addr VPN

• ffset

12 bits 0xd0000 PDBR/CR3 0x010 0x001 VPN PDIdx PTIdx 10 bits10 bits CPU … Level 1 (Page Dir) Level 2 (Page Table)

x86 allows for 2MB or 1GB super pages by skipping 1 or 2 last levels of its 4-level page table scheme.

0x001040

• ffset 22-bits

0x3a001040 0x01001040

48

Processor Chip Translation Unit / MMU

Modern Processor Organizations

• Often times, separate TLB’s for instruction and data address

translation (and data/instruction caches as well)

TLB IL1 $ / DL1 $

CPU

VA VPN Page Offset PPFN PA data 10 ns 10 ns

Memory Memory (Page Table)

Hit Miss Miss Hit

ITLB / DTLB IL1 $ / DL1 $

49

Multiprocessor TLB Issues & Shootdown

• Assume 2 threads from 2 processes executing on 4 cores
• TLB's store copies of PTEs but no HW support for "coherency"
• What if one thread needs to reduce access privileges of a page?

– Conservatively need to invalidate TLB entry in the other processor

• What if access in P2 cause eviction of pages whose translations are cached

in the TLBs from P1?

– SHOOTDOWN: 1 proc. interrupts another and indicates a TLB entry should be invalidated

Processor Chip Translation Unit / MMU Core1 (P1)

TLB Cache

Translation Unit / MMU Core3 (P2)

TLB Cache

Translation Unit / MMU Core2 (P1)

TLB Cache

Translation Unit / MMU Core4 (P2)

TLB Cache

… Level 1 (Page Dir) Level 2 (Page Table) … Level 1 (Page Dir) Level 2 (Page Table)

50

IMPLICATIONS FOR DATA CACHES

51

Cache Addressing with VM

• Review of cache

– Store copies of data indexed based on the address they came from in MM – Simplified view: 2 steps to determine hit

• Index: Hash portion of address to find "set" to look in
• Tag match: Compare remaining address to all

entries in set to determine hit

– Sequential connection between indexing these two steps (index + tag match)

• Rather than waiting for address translation and

then performing this two step hit process, can we

• verlap the translation and portions of the hit

sequence?

– Yes if we choose page size, block size, and set/direct mapping carefully

1 2 3 4 …

addr, data addr, data

Index/Hash Tag Offset

Address

52

Virtual vs. Physical Addressed Cache

• Physically indexed, physically tagged (PIPT)

– Wait for full address translation – Then use physical address for both indexing and tag comparison

• Virtually indexed, physically tagged (VIPT)

– Use portion of the virtual address for indexing then wait for address translation and use physical address for tag comparisons – Easiest when index portion of virtual address w/in offset (page size) address bits, otherwise aliasing may occur

• Virtually indexed, virtually tagged (VIVT)

– Use virtual address for both indexing and tagging…No TLB access unless cache miss – Requires invalidation of cache lines on context switch or use of process ID as part of tags

Offset

VA

VPN

31 12 11

Offset

PA

PFN

31 12 11

Set/Blk Tag

PIPT

Offset

VA

VPN

31 12 11

Offset

PA

PFN

31 12 11

Tag Set/Blk Offset

VA

VPN

31 12 11

Offset

PA

PFN

31 12 11

Set/Blk Tag

VIPT VIVT

53

Virtual vs. Physical Addressed Cache

• Another view:

Virtually addressed Cache Physically addressed Cache In a modern system the L1 caches may be virtually addressed while L2 may be physically addressed.

54

SOFTWARE PROTECTION

55

Protection Without (With Less) HW

• Interpreted languages can perform checking before

dereferencing

– Most languages don't provide raw pointer features

• Intermediate code

– MS.NET - Many languages (C#, VB, etc.) compiled to intermediate byte-code and then run by an interpreter – Java

• Program Analysis

– Insert code to perform checks that prove the program cannot violate certain properties – If proven we can remove checks
