SLIDE 1
CSC 369: Distributed Computing Alex Dekhtyar May 6 Day 14: Java - - PowerPoint PPT Presentation
CSC 369: Distributed Computing Alex Dekhtyar May 6 Day 14: Java - - PowerPoint PPT Presentation
CSC 369: Distributed Computing Alex Dekhtyar May 6 Day 14: Java Hadoop API CSC 369: Distributed Computing Alex Dekhtyar May 6 Day 14: Java Hadoop API HAPPY EQUATOR DAY! Housekeeping Lab 4 (mini-project): due Sunday night Lab 5: due
SLIDE 2
SLIDE 3
SLIDE 4
SLIDE 5
SLIDE 6
Housekeeping
Lab 4 (mini-project): due Sunday night Lab 5: due tonight (grace period tomorrow) Lab 6: full lab coming out Friday Grading: slowly happening…
SLIDE 7
Hadoop Java API
SLIDE 8
Hadoop API
Current Version is 3.2.1.
hadoop hdfs yarn
Command-line tools We limit ourselves to hadoop jar
SLIDE 9
Hadoop Java API
- rg.apache.hadoop
Let’s concentrate on things we absolutely need
SLIDE 10
Hadoop Java API
- rg.apache.hadoop
- rg.apache.hadoop.mapreduce
- rg.apache.hadoop.mapreduce.lib.input
- rg.apache.hadoop.mapreduce.lib.output
- rg.apache.hadoop.io
- rg.apache.hadoop.conf
- rg.apache.hadoop.fs
Core MapReduce classes Inuput/Output parsing atomic type wrappers Job configuration File system classes
SLIDE 11
- rg.apache.hadoop.mapreduce
- rg.apache.hadoop.mapreduce.Job
MapReduce Job
- rg.apache.hadoop.mapreduce.Mapper
- rg.apache.hadoop.mapreduce.Reducer
Extensible Mapper Extensible Reducer
- rg.apache.hadoop.mapreduce.Partitioner
Parent class for Partitioning tasks
- rg.apache.hadoop.mapreduce.InputFormat
Parent classes for Input/Output Formats
- rg.apache.hadoop.mapreduce.OutputFormat
- rg.apache.hadoop.mapreduce.InputSplit
Parent class for Input Split
SLIDE 12
How it works
Input File
SLIDE 13
How it works
Input File
InputSplit InputSplit InputSplit
SLIDE 14
How it works
Input File
InputSplit InputSplit InputSplit Job
Mapper Reducer Combiner (Reducer)
SLIDE 15
How it works
Input File
InputSplit InputSplit InputSplit Job
Mapper Reducer Combiner (Reducer) Compute Node1 Compute Node2 Compute Node3
SLIDE 16
How it works
Input File
InputSplit InputSplit InputSplit Job
Mapper Reducer Combiner (Reducer) Compute Node1 Compute Node2 Compute Node3
SLIDE 17
How it works
Input File
InputSplit InputSplit InputSplit
Mapper Compute Node1 Compute Node2 Compute Node3 Mapper Mapper Combiner (Reducer) Combiner (Reducer) Combiner (Reducer) Mapper
SLIDE 18
Compute Node1 Mapper Combiner (Reducer)
InputSplit
SLIDE 19
Compute Node1 Mapper Combiner (Reducer)
InputSplit
SLIDE 20
Compute Node1 Compute Node2 Compute Node3 Compute Node1 Compute Node2 Compute Node3
MAP STAGE Reduce STAGE
Mapper Mapper Combiner Combiner Mapper Combiner Reducer Reducer Reducer
time
SLIDE 21
Compute Node1 Compute Node2 Compute Node3 Compute Node1 Compute Node2 Compute Node3
MAP STAGE Reduce STAGE
Mapper Mapper Combiner Combiner Mapper Combiner Partitioner
time
Partitioner Partitioner Reducer Reducer Reducer
SLIDE 22
Compute Node1 Compute Node2 Compute Node3 Compute Node1 Compute Node2 Compute Node3
MAP STAGE Reduce STAGE
Mapper Mapper Combiner Combiner Mapper Combiner Partitioner
time
Partitioner Partitioner
Shuffle STAGE
Reducer Reducer Reducer
SLIDE 23
Compute Node1 Compute Node2 Compute Node3 Compute Node1 Compute Node2 Compute Node3
MAP STAGE Reduce STAGE
Mapper Mapper Combiner Combiner Mapper Combiner Partitioner
time
Partitioner Partitioner
Shuffle STAGE
Reducer Reducer Reducer
SLIDE 24
Mapper in a nutshell
protected void cleanup(org.apache.hadoop.mapreduce.Mapper.Context context)
protected void map(KEYIN key, VALUEIN value,
- rg.apache.hadoop.mapreduce.Mapper.Context context)
protected void setup(org.apache.hadoop.mapreduce.Mapper.Context context)
void run(org.apache.hadoop.mapreduce.Mapper.Cont ext context)
SLIDE 25
run(InputSplit s, Context c): setup(s,c); for each record in s do: map(record, c); end for; cleanup(s,c)
Run setup() once Run map() for each record Run cleaunp() once
SLIDE 26
Reducer in a nutshell
protected void cleanup(org.apache.hadoop.mapreduce.Mapper.Context context)
protected void reduce(KEYIN key, Iterable<VALUEIN> value,
- rg.apache.hadoop.mapreduce.Mapper.Context context)
protected void setup(org.apache.hadoop.mapreduce.Mapper.Context context)
void run(org.apache.hadoop.mapreduce.Mapper.Cont ext context)
SLIDE 27
run(InputSplit s, Context c): setup(s,c); for each record in s do: map(record, c); end for; cleanup(s,c)
Run setup() once Run map() for each record Run cleaunp() once Shuffle Sort SecondarySort
SLIDE 28
Hadoop Java API
- rg.apache.hadoop
- rg.apache.hadoop.mapreduce
- rg.apache.hadoop.mapreduce.lib.input
- rg.apache.hadoop.mapreduce.lib.output
- rg.apache.hadoop.io
- rg.apache.hadoop.conf
- rg.apache.hadoop.fs
Core MapReduce classes Inuput/Output parsing atomic type wrappers Job configuration File system classes
SLIDE 29
Hadoop Java API
- rg.apache.hadoop
- rg.apache.hadoop.mapreduce
- rg.apache.hadoop.mapreduce.lib.input
- rg.apache.hadoop.mapreduce.lib.output
- rg.apache.hadoop.io
- rg.apache.hadoop.conf
- rg.apache.hadoop.fs
Core MapReduce classes Inuput/Output parsing atomic type wrappers Job configuration File system classes
SLIDE 30
- rg.apache.hadoop.mapreduce.lib.input
Single File Input Format
FileInputFormat TextInputFormat KeyValueInputFormat FixedLengthInputFormat NLineInputFormat Generic Input File format (others extend it) Text Input User-defined Key-Value Pairs Fixed Length Records in input Controls the size of split (in terms of #lines)
SLIDE 31
- rg.apache.hadoop.mapreduce.lib.input
Single File Input Format
FileInputFormat TextInputFormat KeyValueInputFormat FixedLengthInputFormat NLineInputFormat Generic Input File format (others extend it) Text Input User-defined Key-Value Pairs Fixed Length Records in input Controls the size of split (in terms of #lines)
Other Important Classes
