CS101 Lecture 17: Networking

Circuit Switching Packet Switching

Aaron Stevens (azs@bu.edu)

4 March 2013

Computer Science

What You’ll Learn Today

• What is a communications network?
• What are the implications of the network topology

and transmission strategy?

• How do computers connect to each other?
• What are the building blocks of the Internet?
• How is data transferred across a network?
• How does my computer connect to the Internet?

3/4/13 2

Computer Science

Communications Networks

• What is a network?
• What are its defining characteristics?

Computer Science

The Telephone Network

POTS (the plain old telephone system), a.k.a PSTN To connect a phone call, the caller’s phone must be physically connected to connect to the receiver’s phone. Connecting these circuits (called switching) takes place at dedicated facilities called central offices.

3/4/13 3

Computer Science

POTS Circuit Switching

Telephone wires leave your house, and connect to the central office. At the central office, connections are made to other telephone lines…

Image from www.exegesis.uklinux. net.

Computer Science

POTS Circuit Switching

Telephone operators used to actually switch wires to connect the calls. In the PSTN, this connection (called switching) is done electronically.

3/4/13 4

Computer Science

Modem

Early computer networking used the phone network: dial up. A modem converts computer signals into sounds.

Computer Science

Circuit Switched Network

Computers can be connected over a circuit switched network (e.g. phone lines), creating a circuit between the source and destination.

A Switched Circuit connects devices A and B.

Image from www.tcpipguide.com.

3/4/13 5

Computer Science

Circuit Switching: Details

• How many circuits do you need to connect

1 pair of computers? 2 pairs? N pairs?

• What happens when a backhoe cuts the

line?

Computer Science

Bursty Data Transmissions

Computers send data in irregular bursts. Example: email. Using a switched network connection is wasteful – the circuits must be connected even if no data is being sent!

3/4/13 6

Computer Science

Packet Switching

Packet A unit of data sent across a network. Packet switching Messages are divided into fixed-sized, numbered packets. Packets are individually routed to their destination. Reassembled into messages. Router A network device that directs a packet between networks toward its final destination.

Computer Science

Nodes send packets of data along routes to a destination, without a dedicated circuit. Packets (even in the same transmission) can take different routes.

Image from http://www.teach-ict.com/technology_explained/packet_switching/packet.switching.gif

Packet Switching Network

Image from www.tcpipguide.com.

3/4/13 7

Computer Science

Packet Switching: Details

• What happens to packets when they arrive?
• Are they ready for consumption?
• What happens if some packet(s) get lost?

Computer Science

Packet Switching

What’s so great about packet switching?

• Efficient use of wires/circuits
• Multiple paths between source and

destination

• Do not need as much infrastructure as

number of users increases

3/4/13 8

Computer Science

What’s Not To Love?

• Time required to reassembly

messages, resend missing packets.

• Why does this matter?
• Speed of delivery: latency is not

guaranteed.

• Inefficient for small packets

Computer Science

Circuit or Packet Switching?

• For which kind of information is circuit switching

preferred?

• For which kinds of information is packet switching

preferred?

• Are all packets treated the same by the network?

Should some be prioritized?

3/4/13 9

Computer Science

Network Interface Controller

Each node has a network interface controller (NIC) connected to its circuit board.

The CPU treats the NIC as an input/output device. It communicates by reading or writing bytes of data to the NIC. Each NIC has a unique Media Access Control (MAC) address, which distinguishes it from all other NICs.

Computer Science

Types of Networks

Local-area Network (LAN) A network that connects a relatively small number of machines in a relatively close geographical area.

Wide-area network (WAN) A network that connects local-area networks over a potentially large geographic distance. Gateway/Router A particular computer on a LAN which directs all communication going between that LAN and other networks.

3/4/13 10

Computer Science

LAN/WAN Example

LANs separated by a great distance are connected by High speed communication links to create a WAN.

Image source: http://www.air-stream.org.au/files/wide_area_network.gif Computer Science

What You Learned Today

• Circuit Switching
• Packet Switching
• Network Topology
• How Your Computer Connects to the

Internet

3/4/13 11

Computer Science

Announcements and To-Do List

• Readings this week:
• Reed ch 3, pp 44-50 (today)
• Watch: history of Internet video
• linked to class schedule page
• Start at time 19:45, to end (about 40 minutes)
• Reed ch 3, pp. 51-53 (Wednesday))
• HW07 due WED 3/6
• QUIZ 3 will be on Friday 3/8
• HTML forms, CSS, frames, images, audio
