CS 598: Advanced Internet

Brighten Godfrey pbg@illinois.edu Fall 2009

1 Tuesday, August 25, 2009

Today

Internet History Course Overview What’s Next

2 Tuesday, August 25, 2009

This course

• is instructed by Brighten Godfrey (pbg@illinois.edu, 3128

Siebel)

• takes place Tue & Thu, 3:30 - 4:45 pm, in 1302 Siebel
• comes with FREE office hours: currently, Fri 10:30-11:30am

(we’ll reselect in a week or two) and by appointment

• has a web site: http://www.cs.illinois.edu/homes/pbg/

courses/cs598fa09/

3 Tuesday, August 25, 2009

Your Instructor

• Ph.D. from UC Berkeley, Spring 2009, advised by Ion Stoica
• Dissertation on improving resilience and performance of

distributed systems by taking advantage of heterogeneity

• Research interests: Design of highly reliable, flexible, and

efficient networked systems, algorithms for and analysis of distributed systems. Currently Internet and routing architectures.

4 Tuesday, August 25, 2009

Course Goals

• Learn how the Internet works; how the

Internet fails to work; new research re- envisioning the architecture and attacking new problems

• Experience in networking research, and how

to read, criticize and present papers

5 Tuesday, August 25, 2009

Major topics

• Classic Architecture
• Congestion Control
• Routing
• Security
• Measurement
• New Internet Architectures
• Recent Topics (Overlay/P2P,

DTN, data center)

Big Challenges Scale Reliability Independence Selfishness Maliciousness

Classic & recent, Design & analysis

6 Tuesday, August 25, 2009

Requirements & Grading

• Project (50%)
• Paper reviews (15%)
• Paper presentations (20%)
• Class participation (15%)

7 Tuesday, August 25, 2009

• 1. Class project
• Goal: research project that could be

developed into a conference submission

• Work alone or in groups of two
• Next lecture: Project ideas. Pick one or use

your own.

• Steps: (1) topic approval, (2) midterm

presentation, (3) final poster presentation, (4) final paper

8 Tuesday, August 25, 2009

• 2. Paper reviews
• Generally two papers per lecture
• Before class, you read them and email me

comments (Subject: “CS598 Paper Review”)

• For each paper, one-paragraph review,

including at least 2 criticisms

9 Tuesday, August 25, 2009

• 2. Paper reviews

Examples of acceptable comments

• This piece of the system could have been designed better

by doing __, because __.

• The system won’t work as claimed because...
• A drawback/benefit not described in the paper is ___.

Examples of unacceptable comments

• Repeating statements in paper abstract
• Spelling mistakes
• Personal remarks

10 Tuesday, August 25, 2009

• 3. Paper presentation
• 20-25 minute presentation including key

concepts / techniques / results and your criticism

• 10-15 minutes of discussion during/after
• At least 2 days before it happens, meet with

me to show me your presentation

11 Tuesday, August 25, 2009

• 4. Class participation
• Comment, question, interact!

12 Tuesday, August 25, 2009

Today

Internet History Course Overview What’s Next

13 Tuesday, August 25, 2009

Visions

• Vannevar Bush, “As we may

think” (1945): memex

• J. C. R. Licklider (1962): “Galactic

Network”

• Concept of a global network of

computers connecting people with data and programs

• First head of DARPA computer

research, October 1962 Bush Licklider

14 Tuesday, August 25, 2009

Circuit switching

1920s 1967

15 Tuesday, August 25, 2009

1961-64: Packet switching

Circuit Switching Datagram packet switching

Physical channel carrying stream of data from source to destination Message broken into short packets, each handled separately Three phase: setup, data transfer, tear-down One operation: send packet Data transfer involves no routing Packets stored (queued) in each router, forwarded to appropriate neighbor

16 Tuesday, August 25, 2009

• Leonard Kleinrock: queueing-theoretic analysis of

packet switching in MIT Ph.D. thesis (1961-63) demonstrated value of statistical multiplexing

• Concurrent work from Paul Baran (RAND),

Donald Davies (National Physical Labratories, UK) Kleinrock Baran

1961-64: Packet switching

Circuit switching Time Packet switching Time

17 Tuesday, August 25, 2009

1965: First computer network

• Lawrence Roberts and Thomas Merrill

connect a TX-2 at MIT to a Q-32 in Santa Monica, CA

• ARPA-funded project
• Connected with telephone line – it

works, but it’s inefficient and expensive – confirming motivation for packet switching

Roberts

18 Tuesday, August 25, 2009

The ARPANET begins

• Roberts joins DARPA (1966),

publishes plan for the ARPANET computer network (1967)

• December 1968: Bolt, Beranek, and

Newman (BBN) wins bid to build packet switch, the Interface Message Processor

• September 1969: BBN delivers first

IMP to Kleinrock’s lab at UCLA An older Kleinrock with the first IMP

19 Tuesday, August 25, 2009

ARPANET comes alive

Stanford Research Institute (SRI)

“LO”

Oct 29, 1969 UCLA

20 Tuesday, August 25, 2009

ARPANET grows

• Dec 1970:

ARPANET Network Control Protocol (NCP)

• 1971: Telnet, FTP
• 1972: Email (Ray

Tomlinson, BBN)

• 1979: USENET

ARPANET, April 1971

21 Tuesday, August 25, 2009

22 Tuesday, August 25, 2009

ARPANET to Internet

• Meanwhile, other networks such as

PRnet, SATNET deveoped

• May 1973: Vinton G. Cerf and Robert
• E. Kahn present first paper on

interconnecting networks

• Concept of connecting diverse

networks, unreliable datagrams, global addressing, ...

• Became TCP/IP

Kahn Cerf

23 Tuesday, August 25, 2009

TCP/IP deployment

• TCP/IP implemented on mainframes by

groups at Stanford, BBN, UCL

• David Clark implements it on Xerox

Alto and IBM PC

• 1982: International Organization for

Standards (ISO) releases Open Systems Interconnection (OSI) reference model

• January 1, 1983: “Flag Day” NCP to

TCP/IP transition on ARPANET

Application Presentation Session Transport Network Data Link Physical

OSI Reference Model’s layers

24 Tuesday, August 25, 2009

Growth brings change

• Early 1980s: Many new

networks: CSNET, BITNET, MFENet, SPAN (NASA), ...

• Nov 1983: DNS developed by

Jon Postel, Paul Mockapetris (USC/ISI), Craig Partridge (BBN)

• 1984: Hierarchical routing: EGP

and IGP (later to become eBGP and iBGP) Postel Partridge Mockapetris

25 Tuesday, August 25, 2009

Growth from Ethernet

• Ethernet: R. Metcalfe and
• D. Boggs, July 1976
• Spanning Tree protocol:

Radia Perlman, 1985

• Made local area networking

easy Metcalfe Perlman

26 Tuesday, August 25, 2009

NSFNET

• 1984: NSFNET for US higher education
• Serve many users, not just one field
• Encourage development of private

infrastructure (e.g., initially, backbone required to be used for Research and Education)

• Stimulated investment in

commercial long-haul networks

• 1990: ARPANET ends
• 1995: NSFNET decommissioned

NSFNET backbone, 1992

27 Tuesday, August 25, 2009

The “hourglass” model

IP

TCP UDP HTTP VoIP FTP

P2P Email ... Web

Ethernet NTP ... ...

Copper Fiber Radio ...

Innovation! Simple, flexible standard “language of the internet” Innovation!

28 Tuesday, August 25, 2009

Explosive growth!

In hosts

29 Tuesday, August 25, 2009

Explosive growth!

In networks

Internet forwarding table size [Huston ’09] Year (Colors correspond to measurements from different vantage points)

30 Tuesday, August 25, 2009

Explosive growth!

In complexity

ethernet segment hub switch LAN LAN IP router Autonomous System

...

BGP router

spanning tree + learning broadcast MPLS, CSPF, OSPF, RIP, ... eBGP, iBGP Routing protocols

31 Tuesday, August 25, 2009

Explosive growth!

In applications

Morris Internet Worm (1988) World wide web (1989) MOSAIC browser (1992) Search engines Voice Radio Botnets Streaming video Social networking Peer-to-peer The results of your class projects!

In devices & technologies

NATs and firewalls Wireless everywhere Mobile everywhere Tiny devices (smart phones) ... Giant devices (data centers) Link speeds 200,000x faster

32 Tuesday, August 25, 2009

Huge societal relevance

Friday June 12 Saturday June 13 Sunday June 14

[Source: Renesys]

Routing instabilities and outages in Iranian prefixes following 2009 presidential election Affected prefixes

33 Tuesday, August 25, 2009

Today

Internet History Course Overview What’s Next

34 Tuesday, August 25, 2009

Upcoming lectures

• Thursday Aug. 27: Discussion of challenges for the Internet,

project, project topic suggestions

• Tuesday Sept. 1:
• Vinton Cerf and Robert Kahn, “A protocol for packet

network intercommunication”, IEEE Transactions on Communications, Vol. 22 No. 5, May 1974.

• David Clark, “The Design Philosophy of the DARPA

Internet Protocols”, Proc. SIGCOMM 1988.

• Thu Sept. 3: You begin presenting!
• Full reading list available next week

35 Tuesday, August 25, 2009

And finally...

• Name
• Email address
• Educational situation (Masters / PhD,

research area, one or two sentences about your background in networking) If you are taking this course, please email me your

36 Tuesday, August 25, 2009
