Anonymity Applica cation Example: Elect ctronic c Cash (E-Cash) and Bitco coin CS CS 134 134 Wi Winter 2016

2

Motivation For E-Cash

Conventional Cash is:

• Counterfeitable
• Slow
• Costly
• Vulnerable
• Bad for Remote Transactions

3

Credit Cards, Bank Cards, Checks, and Phone/Subway cards: Easy Fraud Little Privacy

4

Off-line Electronic Cash is for 2-Party (PayeràPayee) Payment

Deposit

Payment

Withdrawal

• Low Communication Requirements

5

In Contrast, On-line Payments:

“OK”

E-Cash in 1970s

• Stephen Wiesner‘s (graduate student at Columbia) paper “Conjugate Coding

and Quantum Money” sent in 1970 to IEEE Transactions on Information Theory

• Paper immediately rejected
• Published in 1983 as is in ACM SIGACT
• Proposed design of unforgaeble bank notes based on quantum properties
• Influenced Quantum (Cryptographic) Key Distribution (QKD)

E-Cash in 1980s and 1990s

• Chaum’s “Blind Signatures for Untraceable Payments” paper is the

first to propose (realizable) E-Cash using blind digital signatures

• Based on RSA (Rivest Shamir and Adelman) signatures
• RSA breaks if one can factor large composite numbers (100s of

decimal digits, 1000s of bits)

• DigiCash (anonymous ecash) launched by Chaum in 1990.

DigiCash declared bankruptcy in 1998.

1970s 2000s 1990s

Requirements for Anonymous Payments (afterwards known as E-Cash)

From Chaum’s “Blind Signatures for Untraceable Payments” paper:

• Unlinkability: third parties can not determine payee (amount

and time of payment)

• Provability: individuals can provide (unforgaeble) proof of

payment, or determine identity of payee under exceptional circumstance (e.g., by courts)

• Revocation: revoke stolen coins or payment media

Anonymous Payments

user 1 user 2

Anonymous Payments

user 1 user 2

Anonymous Payments

withdraw coins withdraw coins user 1 user 2

Anonymous Payments

user 1 user 2

transfer coins user 2

Anonymous Payments

Was it user 1 or user 2?

user 2

Anonymous Payments

15

Overspending: Problem with Off-line E-Cash

Step 1: The bad user copies his money

16

Step 2: The bad user gives copied cash to multiple people

17

The Bank is aware of trouble only later

!!!

18

1.

Use tamper-resistant hardware to prevent over- spending (e.g., MONDEX in Europe)

2.

Trace over-spenders

3.

Blacklist over-spenders

4.

Put a bound on dollar-value for off-line transactions

Techniques to Contain Over-Spending

19

Tracing be used to fight big-time international crime

But, tracing could be abused on many levels

20

Minting the Money/Coins

Heart of Each Coin is a Digital Signature

Secret Minting Key to Create Coins (Signatures)

Public Verification Key to Recognize Coins

21

Minting a Conventional Coin

E-Cash Withdrawer

SN= 12345 SN = 12345 BankSig SN= 12345 SN = 12345 BankSig

The Mint

22

Without Anonymity Mint Knows Serial Number

One Dollar

SN 12345

The Mint E-Cash Withdrawer $1 signing key

23

Minting an Untraceable Coin

E-Cash User The Mint

SN= 12345 SN = 12345 BankSig BankSig BankSig

24

Blind Signing is (Like) Signing Through a Veil

One Dollar

The Mint $1 signing key E-Cash Withdrawer

25

Minting a Trustee-Traceable Coin

E-Cash User The Mint

SN= 12345 SN = 12345 BankSig BankSig BankSig

26

Escrowing Trustee-Traceable Coins

SN= 12345

E-Cash User

Trustee 1 Trustee 2 escrow key1 escrow key2

27

Recall: Cryptographic Assumptions

Infeasible Tasks

• 1. Factoring. Given a number N = pq, find p and q

primes of at least 2048 bits

• 1a. RSA assumption.

Given exponent e and me (mod N), find m

28

• 2. Discrete log. Given a prime p, a generator g,

and gx (mod p), find x Infeasible Tasks

(continued)

• f at least 2048 bits

Recall: Cryptographic Assumptions

29

Example of Coin Minting

Public Information:

N H()

• - Large Composite Number
• - Cryptographic hash function

Private Minting Information: Key = p,q prime numbers such that N=pq A coin has the form: (x,H(x)d mod N), 1 < x < N

30

Minting a Conventional Coin with RSA (Traceable)

E-Cash User The Mint

x,H(x)

x,H(x)d

x,H(x)

x,H(x)d

31

x H(x) H(x)d mod N

Anti-counterfeiting Assumption:

Without knowing the key, it is difficult to find pre-images that map to the same point

= p,q

Where: d = e-1 mod phi(N)

Blind (Digital) Signatures

• Message is blinded (disguised or randomized) before it is signed
• Signature can be publicly verified against the original message

(unblinded one) similar to a standard digital signature

• Typically employed in privacy-preserving protocols where signer

and author of message are different entities

• Main goal is to provide unlinkability: prevent signer from linking

the blinded message it signs to a later un-blinded version that it may be called upon to verify

Anonymous Payments via Blind Signatures

(to withdraw coins: obtain Bank’s signature on a coin (m))

(6) I got this coin: sig(m) for coin m Was it M?

(4) transfer coins: sig(m) (1) send blinded coin/message (m’) (2) sign coin: sig(m’) (3) unblind the coin to obtain sig(m)

(6) Not sure!? I saw a random value: m’

(5) receive goods or services

34

Blind Digital Signatures à Payer’s Privacy [Chaum]

E-Cash User The Mint

chooses random

x,r

x,H(x)

x, H(x)d

reH(x) reH(x)

rH(x)d rH(x)d

RSA-based Blind Signatures

• Public key (e, N) and corresponding private key (d, p, q), such that N =p*q

and e*d = 1 mod Φ(N)

• Choose a random r coprime to N, i.e., GCD(r, N) = 1. re mod N is then used

as a blinding factor. (GCD = greatest common divisor)

• m’ = m * re mod N ( m’ is random, does not leak any info about m)
• m’ is sent to the signing authority who signs it as
• s’ = (m’)d mod N = md * red mod N = md * r mod N
• s’ is sent back to the message owner who unblinds it by multiplying by r-1 to
• btain the signature s = md mod N

Anonymous Payments via RSA-based Blind Signatures

(to withdraw coins: obtain Bank’s signature on a coin (m))

(6) I got this coin: s = md * modN Was it M?

(4) transfer coins: send coin s (1) m’ = m * re modN (2) s’ = md * r modN (3) s = s’ * r-1 modN = md * modN

(6) Not sure!? I saw a random value: s’ = md * r modN

(5) receive goods or services

37

• p1, p2: two large prime numbers such that p2 | p1-1
• G: subgroup of Zp1 such that |G| = p2
• g: generator of G
• I: the user’s identity (set up by bank),

expressed as a number

*

= Coin = (ga mod p1, gb mod p1, H(ga,gb)d mod N) where I = ab mod p2

Tracing Double-Spenders

38

Buyer

ga mod p1, gb mod p1, H(ga,gb)1/3

Seller

• verify Bank’s signature
• send random challenge k
• verify gr=(ga)kgb

k

r = ak+b

r

Tracing Double-Spenders

39

Two Payments with the same coin yield Buyer’s Identity r = ak + b r’ = ak’ + b

a,b

I

Tracing Double-Spenders

r = ak + b

a?,b?

?

A lot of E-Cash and anonymous payment schemes followed similar blueprints in the 1990s and early 2000s

2009-2016

• 2009: Bitcoin paper by Satoshi Nakamoto
• Pseudonym for individual or a group
• 2009-2011: slow start …
• 2011-2013: Silk Road and Dread Pirate Roberts
• End 2013: Bitcoin price skyrockets
• a lot of people notice
• 2014-2015: Price drops by 75%
• 2016: Price up again

In 2016

Large Ecosystem Market Capitalization over $4 Billion ($8.2 Billion a year ago) Number of transactions growing steadily

Bitcoin (BTC) Preliminaries

• Cryptographic Hash Function: a hash function that is hard to

invert, i.e., computationally infeasible to recreate data from hash value alone, e.g., the secure hash algorithm (SHA)

• Required properties of a Cryptographic Hash Function:

i. easy to compute hash value h( ) of any message m ii. given h(m) it is (computationally) infeasible to recover m iii. infeasible to modify m without h(m) being also modified iv. infeasible to find two different m with same hash (collision resistance)

• Proof-of-Work Schemes/Protocols: originally invented as an

economic measure to prevent denial-of-service and spam by requiring clients to solve computationally-demanding puzzles, e.g., find a number that has a certain preamble (say 3 zeros) in its hash

Stepping Back

Stepping back: most physical and digital currencies today effectively exist in the form of a ledger.

Electronic Accounts in Banks Blockcain in Bitcoin (BTC)

Questions Answered by Bitcoin (BTC)

How to maintain integrity of a public ledger in a distributed manner (BTC answer: longest chain of verified transactions) How to use such a ledger for transactions (BTC answer: transferring coins via signatures) How to incentivize people to allocate CPU power to ensure integrity of the longest chain (BTC answer: reward with new minted coins when verifying transactions, also called mining)

Bitcoin’s Peer-to-Peer Network

• A peer-to-peer network without any “central” authority

for ensuring integrity of transactions and keeping track of

• wnership of (Bit)coins (and minting them)
• Ledger and history of ALL transactions are public and

available for anyone to inspect

Transactions in Bitcoin

Owner 0 is transferring Coin(s) to Owner 1 A (Bit)coin is defined as a chain of digital signatures.

Timestamps in Bitcoin

• Hash a block of items (transactions) to be time stamped and widely

publish the hash

• The time stamp proves that data must have existed in order to have

gotten into the hash

• Each timestamp includes previous timestamp in the hash, forming

chain (the Btitcoin blockchain)

• Each additional time stamp reinforces the ones before it

Hash Hash Block Item Item … Block Item Item …

Proof-of-Work (PoW) and Incentives in Bitcoin

• PoW in Bitcoin is finding a value that when hashed (SHA-256) the

hash begins with a certain number of zeros (control of difficulty level)

• Incentive for Mining/Ensuring Integrity of Blockchain: The first

transaction in a block is a special transaction that starts a new coin owned by the creator of the block.

Block Tx Tx … Previous Hash Nonce (to be found) Block Tx Tx … Previous Hash Nonce (to be found)

Operation of Bitcoin’s Network

1) New transactions are broadcast to all nodes 2) Each node collects new transactions into a block 3) Each node works on finding a difficult proof-of-work for its block 4) When a node finds a proof-of-work, it broadcasts the block to all nodes 5) Nodes accept block only if all transactions in it are valid and not already spent 6) Nodes express their acceptance of the block by working on creating the next block in the chain, using the hash of the accepted block as the previous hash

51% Attack

Blockchain Size

More Features of Bitcoin

Additional Features:

– Saving disk space by using hash (Merkle) trees to compress history of coins – Allow multiple inputs and

• utputs to be

handled with one transaction

Alternative Coins (Alt-Coins)

Digital Currency Scheme Centralized/ Decentralized Can be Regulated? Security Guarantees Privacy/Anonymity Guarantees Resilience Guarantees Bitcoin, Namecoin Fully (P2P) Decentralized No SHA-256 proof-of- work Unrecoverable (but Linkable) Anonymity P2P Decentralized Ledger Litecoin Fully (P2P) Decentralized No Scrypt-based proof-of-work Unrecoverable (but Linkable) Anonymity P2P Decentralized Ledger Zerocoin Fully (P2P) Decentralized No SHA-256 proof-of- work Unrecoverable, Unlinkable Anonymity P2P Decentralized Ledger PPcoin Fully (P2P) Decentralized No SHA-256 proof-of- work/proof-of- stake Unrecoverable (but Linkable) Anonymity P2P Decentralized Ledger Ripple Fully (P2P) Decentralized No Trust-based consensus Anonymity Level Varies P2P Decentralized Ledger

–Essentially all following the Bitcoin blueprint –Ethereum is the new kid on the block (smart

contracts via a “Turing complete” language)
