CR 455 Extension Project Development and Environment (PD&E) Study

RSQ 17-0014 October 24, 2019

2

Preferred Alternative Public Meeting October 24, 2019

WELCOME

Open House Format Presentation Runs Every 10 Minutes

Clermont Arts & Recreation Center 3700 S. Highway 27, Clermont, Florida 34711 5:30 p.m. to 7:30 p.m.

CR 455 Extension Project Development & Environment (PD&E) Study

Project Background

The need for improvements was identified by:

• Lake-Sumter Metropolitan Planning Organization (MPO)
• The 2035 Long Range Transportation Plan identified the need for an additional

north-south corridor

• Wellness Way Area Plan (WWAP)
• Identified as an area with significant economic development opportunities
• Mix of residential, commercial, office, education, medical and recreational

uses to provide employment in Lake County

• Identified a north-south corridor extension of County Road 455

3

CR 455 Extension Project Development & Environment (PD&E) Study

What is a PD&E Study?

A Project Development and Environment (PD&E) Study is an environmental and engineering process used to document social, economic, and environmental impacts associated with a proposed transportation improvement project.

4

CR 455 Extension Project Development & Environment (PD&E) Study

5

Study Area

Complete Design FY 2020

Proposed Roadway Proposed Roadway

CR 455 Extension Project Development & Environment (PD&E) Study

6

Level of Service (LOS)

LOS A

LOS C

LOS D LOS F

CR 455 Extension Project Development & Environment (PD&E) Study

Existing Traffic Conditions (2018)

7

U.S. 27 Hartwood Marsh Road Schofield Road 25,500 C Hancock Road S.R. 50 Johns Lake Road 20,087 C Johns Lake Road Hartwood Marsh Road 11,175 C Hartwood Marsh Road U.S. 27 Hancock Road 16,077 F Hancock Road Lake/Orange County Line 12,123 C Schofield Road U.S. 27 Lake/Orange County Line 198 C Level of Service Roadway From To Average Daily Traffic (vpd)

CR 455 Extension Project Development & Environment (PD&E) Study

Future Traffic Conditions (2045) No-Build Scenario

8

CR 455 Extension Project Development & Environment (PD&E) Study

Future Traffic Volumes (2045) No-Build Scenario

% Change U.S. 27 Hartwood Marsh Road CFX Connector 62,063 143% D Hancock Road S.R. 50 Johns Lake Road 28,577 42% F Johns Lake Road Hartwood Marsh Road 23,484 110% F Hartwood Marsh Road Wellness Way 22,458

• C

Hartwood Marsh Road U.S. 27 Hancock Road 16,721 4% F Hancock Road CR 455 Extension 20,669 70% F CR 455 Extension Lake/Orange County Line 13,012 7% C Wellness Way U.S. 27 Lake/Orange County Line 31,655

• C

Schofield Road Hancock Road Lake/Orange County Line 11,449 5682% C CFX Connector U.S. 27 S.R. 429 24,353

• B

Roadway From To Average Daily Traffic (vpd) Level of Service

9

CR 455 Extension Project Development & Environment (PD&E) Study

Public & Neighborhood Meetings

Public Concerns

▪ Impacts to rural character ▪ Environmental impacts ▪ Divided Community ▪ Property value ▪ Project need ▪ Planned developments in Wellness Way Area Plan

10

CR 455 Extension Project Development & Environment (PD&E) Study

Additional Stakeholder Input

▪ Coordination Meetings

• Property Owners
• Water Conserv II
• Central Florida Expressway (CFX) Authority

▪ Emails ▪ Website Comments ▪ Letters

11

CR 455 Extension Project Development & Environment (PD&E) Study

Typical Section – 4 Lanes

12

CR 455 Extension Project Development & Environment (PD&E) Study

Future Traffic Conditions (2045)

CR 455 Extension

13

CR 455 Extension Project Development & Environment (PD&E) Study

Alternatives Overview

14

Blue

14

Green Yellow Purple Pink

CR 455 Extension Project Development & Environment (PD&E) Study

CR 455 Alternatives Evaluation Matrix

15

Evaluation Factors Purple Green Yellow Blue Pink No-Build RIGHT-OF-WAY IMPACTS # of Residential Parcels Impacted 5 5 10 15 10 # of Business Parcels Impacted 6 4 2 2 2 # of Utility and Governmental Parcels Impacted 7 7 7 3 7 # of Vacant Parcels Impacted 6 6 8 6 8 # of Parcels Impacted (Total) 24 22 27 26 27 Right-of-Way Required for Roadway (acres) 72.18 78.61 78.09 67.88 78.64 0.00 Right-of-Way Required for Ponds (acres) 21.29 20.66 19.29 21.69 19.29 Total Right-of-Way Required (acres) 93.46 99.27 97.37 89.57 97.93 0.00 Splits a Community? No No Yes Yes Yes No Conserv II Impacts (acres) 17.03 17.03 17.03 21.26 17.03 RELOCATION IMPACTS # of Potential Residential Relocations 1* 3 # of Potential Business Relocations ENVIRONMENTAL IMPACTS Natural Environment Wetland Impacts (acres) 2.47 2.47 3.48 2.29 3.49 Floodplain Impacts (acres) 5.85 5.85 10.54 10.85 10.13 Wildlife/Habitat Impacts Med Med High Low High None Cultural Environment Cultural Impacts Low Low Low Low Low None Physical Environment Potential Contamination Sites Impacted TOTAL CONSTRUCTION COST ONLY (in millions) $55.1 $58 $67.1 $47.2 $66.4 $0

*Can be zero if typical section footprint is reduced during design.

CR 455 Extension Project Development & Environment (PD&E) Study

CR 455 Ranking of Alternatives

(1 = Highest Ranked & 5 = Lowest Rank)

16

Alternative

Purple Green Yellow Blue Pink

Engineering & Environmental

1 2 4 2 4

Relocations

4 5 1 1 1

Right of Way

1 5 3 2 4

Public Input

1 2 3 5 3

Total Construction Cost

2 3 5 1 4

Weighted Ranking

1.7 2.9 3.5 2.5 3.3

Ranking (Overall)

1 3 5 2 4

Weighted ranking is based on the following weighting: Engineering & Environmental 25% Relocations 15% Right of Way 5% Public Input 30% Total Construction Cost 25%

CR 455 Extension Project Development & Environment (PD&E) Study

CR 455 Ranking of Alternatives

(1 = Highest Ranked & 5 = Lowest Rank)

17

Alternative

Purple Green Yellow Blue Pink

Engineering & Environmental

1 2 4 2 4

Relocations

4 5 1 1 1

Right of Way

1 5 3 2 4

Public Input

1 2 3 5 3

Total Construction Cost

2 3 5 1 4

Weighted Ranking

1.7 2.9 3.5 2.5 3.3

Ranking (Overall)

1 3 5 2 4

Weighted ranking is based on the following weighting: Engineering & Environmental 25% Relocations 15% Right of Way 5% Public Input 30% Total Construction Cost 25%

CR 455 Extension Project Development & Environment (PD&E) Study

CR 455 Preferred Alternative

18

A B C

2/3 mile

South Detail Overall North Detail

CR 455 Extension Project Development & Environment (PD&E) Study

CR 455 Preferred Alternative Roundabout Locations

19

Northern Roundabout Southern Roundabout

CR 455 Extension Project Development & Environment (PD&E) Study

CR 455 Northern Roundabout

20

CR 455 Extension Project Development & Environment (PD&E) Study

21

CR 455 Southern Roundabout

CR 455 Extension Project Development & Environment (PD&E) Study

Stormwater Pond Locations

22

Proposed Pond Locations Optional Pond Locations

CR 455 Extension Project Development & Environment (PD&E) Study

23

CR 455 North – Landscaping

CR 455 Extension Project Development & Environment (PD&E) Study

Project Benefits

Opportunities ▪ Coordinate with other FDOT/County/City projects ▪ Joint use ponds ▪ Improved traffic safety ▪ Continuous north/south corridor ▪ Alternate emergency evacuation route ▪ Pedestrian/bicycle amenities Objectives ▪ Provide short-term improvements that will improve safety ▪ Support the Wellness Way Area Plan ▪ Develop an improvement that is consistent with projected growth ▪ Balanced project approach ▪ Context sensitive design

24

On-going stakeholder engagement

CR 455 Extension Project Development & Environment (PD&E) Study

Project Schedule

25

Notice to Proceed | March 2018 Alternatives Workshop | June 2019 Preferred Alternative Meeting | October 2019 Public Hearing | January 2020 Document Closeout | February 2020

CR 455 Extension Project Development & Environment (PD&E) Study

26

Stay Informed! Stay Involved

For additional information, please contact:

George Gadiel, PE Lake County Project Manager Lake County Public Works 350 N. Sinclair Ave Tavares, FL 32778 Phone: (352) 253-9092 Email: ggadiel@lakecountyfl.gov Dwayne Darbonne, PE Consultant Project Manager METRO Consulting Group, LLC 604 Courtland St. Ste. 140 Orlando, FL 32804 Phone: (407) 960-3973 Email: dwayne.darbonne@metrocgllc.com Visit the study website, www.cr455extensionstudy.com, to stay informed about the study’s progress.

www.cr455extensionstudy.com

CR 455 Extension Project Development and Environment (PD&E) Study

THANK YOU!

Lake County Preferred Alternative Public Meeting October 24, 2019

RSQ 17-0014

www.cr455extensionstudy.com
