Mechanical Equipment (ENGI-7903) Spring 2013 Course Review 2 Quantitative Overview Chapter 1 (Introduction) 0.5 session, 14 slides Chapter 2 (Thermofluids fundamentals) 2.5 sessions, 20 slides, 4 examples Chapter 3 (Flow


slide-1
SLIDE 1

Mechanical Equipment (ENGI-7903) Spring 2013 Course Review

slide-2
SLIDE 2

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

2

Quantitative Overview

  • Chapter 1 (Introduction)

– 0.5 session, 14 slides

  • Chapter 2 (Thermofluids fundamentals)

– 2.5 sessions, 20 slides, 4 examples

  • Chapter 3 (Flow Analysis)

– 9 sessions, 51 slides, 12 examples

  • Chapter 4 (Turbomachinery)

– 5 sessions, 30 slides, 6 examples

  • Chapter 5 (Heat Exchangers)

– 6 sessions, 45 slides, 9 examples

slide-3
SLIDE 3

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

3

Chapters 1 and 2

  • Chapter 1 (Mechanical Equipment and Systems

Design)

– Mechanical equipment codes – System Identification

  • Chapter 2 (Thermodynamics, Fluid Dynamics, and

Heat Transfer)

– Thermodynamics – Fluid dynamics (choose CV wisely, …) – Heat Transfer (Forced convection correlations for Nu) – Dimensionless groups

slide-4
SLIDE 4

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

4

Chapter 3 (Flow Analysis)

  • Mechanical Energy Balance

– Applications:

  • Pump (compressor, fan, blower) pressure rise when flow rate is given
  • Elevation (head) required for a given flow rate
  • Power generation by turbine
  • Pressure (head) loss of a system (when flow velocity is known)
  • Velocity (volumetric or mass flow rate) as a result of a given pressure

drop, this requires iteration

  • Special cases, for example a fountain height
  • etc.
slide-5
SLIDE 5

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

5

Chapter 3 (Flow Analysis)

  • Head loss calculations:

– Single phase or two phase? – Laminar or turbulent?

  • fRe=C (for laminar flows and “C” depends on the geometry)
  • Add entrance effects if the channel is not long enough
  • Different models (graphs) for “f” in turbulent flow

– How many minor losses and/or equipments? – Other required information:

  • Velocity (or volumetric or mass flow rate). If this is to be calculated for a

given pressure drop, we need to iterate!

  • Pipe diameter (or hydraulic diameter in case of turbulent flow in non-

circular channels)

  • Wall roughness (pipe material)
slide-6
SLIDE 6

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

6

Chapter 3 (Flow Analysis)

  • How to iterate for flow rate (or velocity) if the flow is

laminar

– Step 1: Guess a value for velocity – Step 2: Calculate Re, L*, and fapp – Step 3: Solve for velocity (flow rate) using the new equation – Step 4: Check for convergence

  • Or:

– Substitute all variables as functions of flow rate and then solve the new equation in which there is only one unknown.

slide-7
SLIDE 7

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

7

Chapter 3 (Flow Analysis)

  • How to iterate for flow rate (or velocity) if the flow is

turbulent

– Step 1: Guess a value for “f”. If we do not have an idea of the possible values, we can use f=0 as initial guess. – Step 2: Solve the equation for the flow rate. – Step 3: Update “Re” using the flow rate calculated in step 2. – Step 4: Update “f” using the calculated “Re” in step 3 and an appropriate model (Blasius, Swammee-Jain, Churchil, etc.) – Step 5: Solve the equation for the flow rate using the “f” from step 4. – Step 6: Compare the flow rates of steps 5 and 2 and iterate again if difference is high.

slide-8
SLIDE 8

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

8

Chapter 3 (Flow Analysis)

  • Pipes in series

– Same flow rate through all pipes in series – Total pressure drop is sum of pressure drops in all pipes in series

  • Pipes in parallel

– Same pressure drop in all pipes in parallel – Total flow rate is sum of flow rates in all pipes in parallel

  • Piping networks

– Zero pressure drop in each loop – Mass balance at each junction (node)

slide-9
SLIDE 9

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

9

Chapter 4 (Turbomachinery)

  • Positive displacement and kinetic pumps
  • Performance curve for centrifugal pumps includes

head, efficiency, power, and NPSHR versus flow rate.

  • Calculating the system working point:

– Graphically or mathematically – If we know the pump performance function we can solve for working flow rate mathematically e.g. iterative methods. – The iterative procedure is much like what we did in chapter 3 i.e. initial guess for friction factor and solve for flow rate and then update friction factor …

slide-10
SLIDE 10

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

10

Chapter 4 (Turbomachinery)

  • Pumps in series

– We add heads at the same flow rate for pump curve – Now we can iterate using the new curve

  • Pumps in parallel

– We add flow rates at the same head for pump curve – Now we can iterate using the new curve – Special care for different pumps in parallel

slide-11
SLIDE 11

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

11

Chapter 4 (Turbomachinery)

  • NPSH calculations

– Note that hf,i for NPSHA calculation includes the head losses of the inlet piping i.e. from inlet of the piping system to the inlet of the pump.

slide-12
SLIDE 12

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

12

Chapter 5 (Heat Exchangers)

  • Different heat exchanger problems:

– Type 1: mc, mh are known. Th,i, Th,o, Tc,i, Tc,o are known. A = ? Appropriate method is LMTD method. ε-NTU may be used as well. – Type 2: U and A are known. Th,i, Tc,i are known. Th,o and Tc,o = ? Appropriate method is ε-NTU method.

slide-13
SLIDE 13

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

13

Chapter 5 (Heat Exchangers)

  • LMTD method

– Step 1: Energy balance – Step 2: Calculating U if necessary – Step 3: Calculating ΔTLMTD – Step 4: Calculating F (correction factor) if necessary – Step 5: Calculating A, and other dimensions

slide-14
SLIDE 14

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

14

Chapter 5 (Heat Exchangers)

  • ε-NTU method (for type 1 problems)

– Step 1: Calculating Cc and Ch and determine Cmin and Cmax – Step 2: Calculating Cr – Step 3: Calculating Qmax, Qact – Step 4: Calculating ε – Step 5: Calculating NTU using ε and Cr – Step 6: Calculating A and other dimensions

slide-15
SLIDE 15

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

15

Chapter 5 (Heat Exchangers)

  • ε-NTU method (for type 2 problems)

– Step 1: Calculating Cc and Ch and determine Cmin and Cmax – Step 2: Calculating Cr – Step 3: Calculating Qmax – Step 4: Calculating NTU – Step 5: Calculating ε using NTU and Cr – Step 6: Calculating Qact – Step 7: Calculating outlet temperatures using energy balance

slide-16
SLIDE 16

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

16

Chapter 5 (Heat Exchangers)

  • Notes:

– Different methods and formula for pressure drop in different heat exchangers – Fouling leads to higher hydraulic resistance and lower thermal performance – Special attention to index and nomenclature. For example index “f” means finned somewhere and fouled somewhere else.

slide-17
SLIDE 17

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

17

Frequent Mistakes

  • Midterm exam (2011):
slide-18
SLIDE 18

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

18

Frequent Mistakes (cont.)

  • Midterm exam (2012):
slide-19
SLIDE 19

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

19

Frequent Mistakes (cont.)

  • Final exam (2012):
slide-20
SLIDE 20

Faculty of Engineering and Applied Science

Memorial University of Newfoundland

  • St. John’s, Newfoundland, Canada

20

Frequent Mistakes (cont.)

  • Midterm exam (2013):
