Contents

• 1. Generator
• 2. Tube
• 3. Collimator
• 4. X-ray Tube Support Unit
• A. Stand Type
• B. Ceiling Type
• 5. Patient Table: 4-way
• 6. Bucky Stand
• 7. Connection With CR
• 8. Installation Site & Picture
• 9. Certificate

• 1. Generator

Microprocessor Operating Control system with Digital display for all Generators.

• Max. Power

40 kW

• Max. Output

500 mA at 80 KVP 320 mA at 125 KVP mA Range 10-500 mA KVP Range 40-125 KVP Time Range 0.001-10 sec Line power 220V±10%, 50/60 Hz Single Phase Dimensions (DxWxH) OP Consol (400x200x36~42mm) HV Trans (571x476,5x428,5mm) Weight OP Consol: 2 kg HV Trans: 62.5 kg

• 2. Tube
• Max. Voltage

125 kVP E7239X Filtration 0.9 mmAL Type Rotating Anode

• Max. Heating Unit

140 KHU (98KJ) Maximum Focal Size 2.0mm Minimum Focal Size 1.0mm Maximum Input power Focal spot size 75kW EnvironmentalLimits Operating Limits Temperature:10 to 40 ºС Humidity: 30 to 85 % AtmosphericPressure: 70 to 106 kPa Shipping and Storage Limits Temperature:-20 to 70 ºC Humidity: 20 to 90 % AtmosphericPressure: 50 to 106 kPa

• 3. Collimator

Type Manual Filtration 1.2 mmAL

• Max. Field (SID 65 cm)

35 Х 35 cm

• Min. Field (SID 100 cm)

5 Х 5 cm Illumination (100 cm) 160 Lux more Lamp Operating Time 30 sec ± 5% Weight 5 kg

• 4. X-ray Tube Support Unit
• A. Stand Type (Model Name : RTS-02A)

Tube Stand Type-Electromagnetic Lock Vertical Movement 1300 mm Longitudinal Movement 2100 mm Lateral Movement 1400 mm Tube Rotation ± 90 Column Rotation ±180°

Medonica Craftsmen make Stand type TUBE SUPPORT by HANDs.

Due to the Tube Wires Rotation allowances are slight lower. Length of Movement can be Changed depending on Room Size and what Customer needs.

• 4. X-ray Tube Support Unit
• B. Ceiling Type (option)

Medonica Craftsmen make Ceiling type TUBE SUPPORT by HANDs.

Ceiling Type-Electromagnetic Lock Vertical Movement 1370 mm Longitudinal Movement 2790 mm Lateral Movement 1480 mm Column Rotation ±180° X-ray Tube Rotation ± 90° Movement Lengths can be changed depending on the Room Dimension and What Customer need. Due to the Tube Wires Rotation allowances are slight lower.

• 5. Patient Table

4-Way Table (Model Name : RBT-02A)

Medonica Craftsmen make 4-Way Table by HANDs.

Bucky Table with 4-way Floating table top (Standard) Top Panel Material Melamine or Acrylic (option) Size 2000mm (Length) х 750mm (Width) x 665mm(Height) LongitudinalMovement ±270 mm Lateral Movement ±120 mm

• Max. Load

150 kg Cassette Size 14X17 Inch

Acrylic (option) Melamine

• 6. Bucky Stand

Medonica Craftsmen make Bucky Stand by HANDs.

Bucky Stand (Model Name : RBS-02A) Vertical Movement 1000 mm Front panel to film 32 mm Lowest position from the bottom 200 mm Oscillation Bucky grid system YES Size 1935mm (Length) х 770mm (Width) x 500mm(Height)

CT imaging MR imaging Ultrasound Dry printer HIS / RIS X-ray Reusable Phosphorplate CR Digitizer Impax DR-Thorax DR-Mammo Conventional X-ray Film Developer,Fixer Hardcopy

• 7. Conection To Image Processing

• 8. Installation Site & Pictures

Medonica Craftsmen make X-ray by HANDs.

• 8. Installation Site & Pictures

• 9. Certificate
