CONTAINER AND MICROSERVICE SECURITY

ADRIAN MOUAT

Chief Scientist @ Container Solutions Wrote "Using Docker" for O'Reilly 40% Discount with AUTHD code Free Docker Security minibook @adrianmouat http://www.oreilly.com/webops-perf/free/docker- security.csp

OVERVIEW

The Benefits of Security Container Attack Vectors Security Philosophy Demo Tips & Techniques

THE BENEFITS OF SECURITY

CONTAINER ATTACK VECTORS

KERNEL ATTACKS

DENIAL OF SERVICE

CONTAINER BREAKOUTS

POISONED IMAGES

SNIFFING SECRETS

SECURITY PARADIGMS

DEFENCE-IN-DEPTH

Multiple layers of security

LEAST PRIVILEGE

Only access data and resources essential to function "Least Privilege Microservices" by Nathan McCauley and Diogo Mónica

DEMO

SO WHAT NOW?

Ideally have guidelines for procedure Need to isolate container (and probably host) docker network disconnect Don't delete, preferably don't stop if safe docker diff

HOW TO MITIGATE

Run container with less privileges

• -read-only

Use non-privileged user ...

NOT A SOLUTION!

Still allows remote execution of arbitrary JS Real solution is to replace vulnerable library Image should be scanned for known vulns

IMAGE SCANNING

Docker Security Scanning Other solutions Clair from CoreOS Peekr from Aqua Security Twistlock Atomic Scan from Red Hat

DEPENDENCY CHECKERS

OWASP Dependency Checker Node Security Project (NSP)

TIPS & TECHNIQUES

USE CONTAINERS AND VMS

Use VMs to segregate groups of containers For multitenancy Each user's containers in separate VM For different security levels Containers processing CC details in own VM

ASIDE: DIRTY COW (CVE-2016-5195)

Recent vulnerability found in the kernel Allows “privilege escalation” Can be used to break out of containers Also breaks read-only filesystems https://dirtycow.ninja/ https://blog.paranoidsoftware.com/dirty-cow-cve-2016- 5195-docker-container-escape/

docker run --rm amouat/dirty-cow-test

SEGREGATE BY NETWORK

Use multiple "logical" networks e.g. backend, frontend frontend should not be able to backend network "link" container will be in both

docker network create frontend

DOCKER PRIVILEGES == ROOT PRIVILEGES

Can mount any directory Can create and copy out "backdoors"

docker run -v $PWD:/data debian /bin/sh -c \ 'cp /bin/sh /data/ && chown root.root /data/sh && chmod a+s /data/sh'

USER NAMESPACING

By default, there is no user namespacing Root in container is root on host Don't run apps in a VM as root Same goes for containers

USER NAMESPACING

Can be turned on since 1.10 Maps users in containers to high-numbered users on host Set on daemon, not per container Due to complications with ownership of image layers

GOTCHAS

Problems with volumes and plugins Can't use --pid=host or --net=host Can't use read-only Restrictions on some operations (e.g. mknod)

SET A USER

Create a user in your Dockerfile Change to the user via USER or su/sudo/gosu

RUN groupadd -r user && useradd -r -g user user USER user

BE CAREFUL WHEN DELETING DATA IN DOCKERFILES

THIS DOESN'T WORK

FROM debian RUN apt-get update && apt-get install -y curl RUN curl http://sourcecode.com/file.tgz -o /file.tgz RUN tar xzf /file.tgz && make RUN rm /file.tgz

THIS DOES

FROM debian RUN apt-get update && apt-get install -y curl RUN curl http://sourcecode.com/file.tgz -o /file.tgz && tar xzf /file.tgz && make && rm /file.tgz

AND THIS IS REALLY BAD

# Copy github ssh key COPY github_rsa /root/.ssh/id_rsa ... # Remove ssh key RUN rm /root/.ssh/id_rsa

SET CONTAINER FS TO READ-ONLY

$ docker run --read-only debian touch x touch: cannot touch 'x': Read-only file system

SET VOLUMES TO READ-ONLY

$ docker run -v $(pwd)/secrets:/secrets:ro \ debian touch /secrets/x touch: cannot touch '/secrets/x': Read-only file system

DROP CAPABILITIES

$ docker run --cap-drop SETUID --cap-drop SETGID myimage $ docker run --cap-drop ALL --cap-add ...

SET CPUSHARES

$ docker run -d myimage $ docker run -d -c 512 myimage $ docker run -d -c 512 myimage

SET MEMORY LIMITS

$ docker run -m 512m myimage

DEFANG SETUID/SETGID BINARIES

Applications probably don't need them So don't run them in production

TO FIND THEM

$ docker run debian \ find / -perm +6000 -type f -exec ls -ld {} \; 2> /dev/null

• rwsr-xr-x 1 root root 10248 Apr 15 00:02 /usr/lib/pt_chown
• rwxr-sr-x 1 root shadow 62272 Nov 20 2014 /usr/bin/chage
• rwsr-xr-x 1 root root 75376 Nov 20 2014 /usr/bin/gpasswd
• rwsr-xr-x 1 root root 53616 Nov 20 2014 /usr/bin/chfn

...

TO DEFANG THEM

FROM debian:wheezy RUN find / -perm +6000 -type f -exec chmod a-s {} \; \ || true

RESULT

$ docker build -t defanged-debian . ... Successfully built 526744cf1bc1 $ docker run --rm defanged-debian \ find / -perm +6000 -type f -exec ls -ld {} \; \ 2> /dev/null | wc -l $

USE MINIMAL IMAGES

Less software Less attack surface

Alpine Linux Static binaries Go makes this easy https://hub.docker.com/_/alpine/ https://medium.com/iron-io-blog/an-easier-way-to- create-tiny-golang-docker-images-7ba2893b160

USE LINUX SECURITY MODULES

SELINUX

By NSA! Policy based MAC not DAC File access, sockets, interfaces

PITA

Hard to define own policies Have to use devicemapper Extra work to use volumes

$ sestatus | grep mode Current mode: enforcing $ mkdir data $ echo "hello" > data/file $ docker run -v $(pwd)/data:/data debian cat /data/file cat: /data/file: Permission denied

$ ls --scontext data unconfined_u:object_r:user_home_t:s0 file $ chcon -Rt svirt_sandbox_file_t data $ docker run -v $(pwd)/data:/data debian cat /data/file hello

APPARMOR

Used by Debian & Ubuntu On by default Limits container access to host files and kernel capabilities Can pass in own policy for a container Process based; not as fine-grained as SELinux

ALSO A PITA, BUT...

BANE

Project by Jessie Frazelle Simplifies creating AppArmor profiles

SECURITY HARDENED KERNEL

Patched kernel with security enhancements grsecurity PaX Lag behind latest kernel version

VERIFY IMAGES

Know what you're running And where it came from Only use automated builds, check Dockerfile Docker Content Trust Pull by digest

AUDITING

Immutable infrastructure Audit images, not containers Docker diff Scanning tools scalock, twistlock, clair

SHARING SECRETS

BAKE IT INTO THE IMAGE

ENVIRONMENT VARIABLES

Suggested by 12 factor apps Can be seen too many places linked containers, inspect Can't be deleted Get included in reports

$ docker run -e API_TOKEN=MY_SECRET myimage

MOUNTED VOLUMES OR DATA VOLUME CONTAINERS

Works, but icky Files can get checked in by accident

$ docker run -v /secretdir/keyfile:/keyfile:ro myimage $ docker run --volumes-from my-secret-container myimage

SECURE KEY-VALUE STORE

Docker 1.13 in Swarm Mode Kubernetes Secrets Vault Can control leases, store encrypted https://github.com/docker/docker/pull/27794 https://hashicorp.com/blog/vault.html

CONCLUSION

Containers Add isolation Provide tools for restricting attackers Use with VMs if concerned Think Defence-In-Depth & Least Privilege

THANK YOU!

Chief Scientist @ Container Solutions Wrote "Using Docker" for O'Reilly Free Docker Security minibook @adrianmouat https://www.openshift.com/promotions/docker- security.html
