2 nd International Conference on Sustainable Energy and Resource Use in Food Chains Construction of an sCO 2 Joule- Brayton Cycle For High Exergy Heat Source Conversion To Electricity Romain Loeb, Giuseppe Bianchi, Gal Levque, Arthur

slide-1
SLIDE 1

2nd International Conference on Sustainable Energy and Resource Use in Food Chains

RCUK Centre for Sustainable Energy Use in Food Chains

Construction of an sCO2 Joule- Brayton Cycle For High Exergy Heat Source Conversion To Electricity

Romain Loeb, Giuseppe Bianchi, Gaël Levêque, Arthur Leroux, Savvas A. Tassou

Brunel University London Enogia, Marseille Paphos, 18/10/2018

slide-2
SLIDE 2

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

Summary

2

  • The I-ThERM project
  • sCO2 scope & market
  • Cycle description
  • Compressor-Generator-Turbine (CGT) unit

Frame components - CAD & assembly CGT - CAD & assembly First test

  • Conclusion and next steps
slide-3
SLIDE 3

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

I-ThERM Project aims to

3

Investigate, design, build and demonstrate innovative plug and play waste heat recovery solutions to facilitate optimum utilisation of energy in selected applications with high replicability and energy recovery potential in the temperature range 70℃ – 1000℃

slide-4
SLIDE 4

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

sCO 2 targeted market

4

Mecheri, M. & Le Moullec, Y. Supercritical CO2 Brayton cycles for coal-fired power plants. Energy 103, 758–771 (2016).

Improve actual power generation cycles

Industrial waste heat recovery

  • Iron & steel
  • Chemical processes
  • Cement
  • Glass

…

Potential high grade energy sources at the selected range

slide-5
SLIDE 5

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

Why sCO2 to power generation?

5

Great compactness

Wright, S. a, Radel, R. F. Operation and Analysis of a Supercritical CO2 Brayton Cycle. SANDIA Report SAND2010-0171 (2010).

High energetic density High compressibility Clean, harmless & cheap fluid Reachable working conditions Up to 60 % efficiency Depending on the configuration

slide-6
SLIDE 6

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

Thermodynamic cycle

6

Isentropic CFD efficiency Turbine 70 % Compressor 76 % Cycle efficiency About 25 % 1 2 3 4

slide-7
SLIDE 7

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

General overview

7

Max 780 °C Heat source 20 °C Cold source

50 kWe 2.08 kg/s

Flexible Up to 830 kWth 500 kWth

Small scale installation

630 kWth

slide-8
SLIDE 8

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

Brunel test rig

8

slide-9
SLIDE 9

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

CGT Unit P&ID

9

Highly integrated unit Electricity Automation Mechanic Cooling Lubrication

slide-10
SLIDE 10

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

CGT Unit CAD

10

slide-11
SLIDE 11

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

CGT CAD

11

Fully instrumented Pressure resistant pipings & parts Compact

slide-12
SLIDE 12

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

Mechanical CGT Design

12 Cooling Generator Rotational guidance Labyrinth seals Drain

Casing maintained via tie rods

Compressor Turbine Volute Permanent magnets Cooler Coils

  • Drain from the generator air gap to remain at a subcritical (gaseous) state
slide-13
SLIDE 13

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

Skid assembly process

13 Components installation Custom welding… Strong attachement … & passivation

slide-14
SLIDE 14

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

CGT assembly process

14

Balancing zone 1 Balancing zone 2

Magnet hooped on the shaft Several balancing works Resistant volutes Wheels Cooler and coils…. mounted in the casing

slide-15
SLIDE 15

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

First check up rotational tests

15

Showed good mechanical and electrical sizing

slide-16
SLIDE 16

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

Conclusion

16

  • Promising efficiency and compactness compared to power generated

thanks to high rotational speed wheels & CO2 properties

  • Plug&Play philosophy ready for high grade heat sources
  • Manufacturing difficulties due to the harsh thermodynamic working

conditions, but can be lifted with off-the-shelve components

Future work

  • Finish the system assembly and automatization
  • Installation in the container at the final test bench
  • One year test campaign

March 2019 February 2020

slide-17
SLIDE 17

RCUK Centre for Sustainable Energy Use in Food Chains

2nd International Conference on Sustainable Energy and Resource Use in Food Chains Brunel University London Enogia, Marseille

Acknowledgments

17

BUL team

  • Prof. Savvas A. Tassou
  • Dr. Giuseppe Bianchi
  • Dr. Samira Sayad Saravi
  • Dr. Konstantinos M. Tsamos
  • Dr. Lei Chai
  • Mr. Matteo Marchionni

Enogia team

  • Mr. Arthur Leroux
  • Mr. Romain Loeb
  • Mr. Norman Holaind
  • Mr. Nicolas Goubet
  • Mr. Gabriel Henry
  • Dr. Gael Leveque
  • Mr. Maxime Leconte

This project has received funding from the European Union’s Horizon 2020 research and innovation programme under grant agreement No. 680599
