Construction and Materials Specifications 107.10 Protection and Restoration of Property

Brett Shearer R/W Plan Specialist, Office of Real Estate Brett.shearer@dot.ohio.gov

John R n R. Kasich, Governor Jer erry W Wray, Director

ORC 5519.05 R/W to be Monumented and Preserved

• ORC 5519.05: ODOT must promptly monument the right of way
• Definitely and accurately ascertain and monument the roads

and highways

• All monuments shall be preserved or reset in their EXACT

location.

• Non performing the setting or resetting of monuments is

ILLEGAL

John R n R. Kasich, Governor Jer erry W Wray, Director

Memorandum of Understanding of newly acquired highway R/W

Established between the Board of Registration for P.E.’s and P.S.’s and ODOT Monuments are to be set or reset based on the right of way plan information. May be reset by any Professional Surveyor licensed in the State of Ohio.

John R n R. Kasich, Governor Jer erry W Wray, Director

623.04 Verification

Requires coordination and communication between district survey operation manager, project engineer and construction contractors surveyor. Construction contractor surveyor makes reasonable effort to verify the position of all survey monuments shown in R/W plans before construction activities.

John R n R. Kasich, Governor Jer erry W Wray, Director

623.04 Verification

Registered Surveyor prepare a verification report with coordinates, station, offset, and a description. The Report is necessary to protect the contractor. NO Report the Contractor is responsible for protecting and resetting ALL monuments as per the R/W plan at their expense.

John R n R. Kasich, Governor Jer erry W Wray, Director

Protection and Restoration of Property

• Any permanent Right-of-Way Monuments or property monuments on or
• utside the Right-of-Way limits and not enclosed within a temporary

easement for the project will be the Contractor’s responsibility to protect.

• Upon

completion

• f

the final grading replace any Right-of-Way Monuments destroyed during or by construction activities.

• A quantity for replacement of Right-of-Way Monuments expected to be

destroyed that are within a temporary easement will be paid under Item 623.

John R n R. Kasich, Governor Jer erry W Wray, Director

623.05 Placement, Protection and Restoration of Monuments

Position primary project control monuments according to the departments Survey and Mapping Spec. During construction the Contractor will construct all Monuments per item 623.03. Reference the latest revision of the Standard Construction Drawing RM-1.1

John R n R. Kasich, Governor Jer erry W Wray, Director

All R/W Monuments, Monument Assemblies and Reference Monuments are to be set under the direct supervision of a Professional Surveyor licensed in the State of Ohio. Contractor’s surveyor is required to submit a signed and sealed report identifying any monuments set or reset.

623.05 Placement, Protection and Restoration of Monuments

9

Monument Assembly, Reference and Right of Way

10

Questions?

Conaway Conference 2017

Brett Shearer R/W Plan Specialist, Office of Real Estate 4th Floor, 1980 W. Broad St. Mail Stop 4120 Columbus Ohio 43223 Phone (614) 728-6142 Brett.shearer@dot.ohio.gov
