Computational Methods for Systems and Synthetic Biology Franois Fages The French National Institute for Research in Computer Science and Control INRIA Paris-Rocquencourt Constraint Programming Group http://contraintes.inria.fr/ Franois

slide-1
SLIDE 1

24/06/2013 François Fages – Ecole Jeunes Chercheurs - Porquerolles 1

Computational Methods for Systems and Synthetic Biology

François Fages

The French National Institute for Research in Computer Science and Control INRIA Paris-Rocquencourt

Constraint Programming Group

http://contraintes.inria.fr/

slide-2
SLIDE 2

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 2

Overview of the Lectures

1. Introduction

  • Transposing concepts from programming to the analysis of living processes

2. Rule-based Modeling in Biocham

  • Macromolecules, compartments and elementary processes in the cell
  • Boolean, Differential and Stochastic interpretations of reaction rules
  • Cell signaling, Gene expression, Retrovirus, Cell cycle

3. Temporal Logic constraints in Biocham

  • Qualitative properties in propositional Computation Tree Logic CTL
  • Quantitative properties in quantifier-free Linear Time Logic LTL(R)
  • Parameter optimization and robustness w.r.t. temporal logic properties

4. Conclusion 5. Killer lecture: abstract interpretation in Biocham

slide-3
SLIDE 3

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 3

References

A wonderful textbook: Molecular Cell Biology. 5th Edition, 1100 pages+CD, Freeman Publ. Lodish, Berk, Zipursky, Matsudaira, Baltimore, Darnell. Nov. 2003. Formal Cell Biology in BIOCHAM (tutorial). François Fages and Sylvain Soliman. 8th International School on Computational Systems Biology. ISpringer-Verlag, LNCS 5016. Mar. 2008.(pdf) The Biochemical Abstract Machine BIOCHAM. http://contraintes.inria.fr/BIOCHAM Modeling dynamic phenomena in molecular and cellular biology.

  • Segel. Cambridge Univ. Press. 1987.
slide-4
SLIDE 4

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 4

Systems Biology ?

“Systems Biology aims at systems-level understanding [which] requires a set of principles and methodologies that links the behaviors of molecules to systems characteristics and functions.”

  • H. Kitano, ICSB 2000
  • Analyze (post-)genomic data produced with high-throughput technologies

(stored in databases like GO, KEGG, BioCyc, etc.);

  • Integrate heterogeneous data about a specific problem;
  • Understand and predict the behaviors of large networks of genes and

proteins.  Systems Biology Markup Language (SBML): model exchange format  SBML model repositories: e.g. biomodels.net 261 curated models

slide-5
SLIDE 5

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 5

Issue of Abstraction in Systems Biology

Models are built in Systems Biology with two contradictory perspectives :

slide-6
SLIDE 6

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 6

Issue of Abstraction in Systems Biology

Models are built in Systems Biology with two contradictory perspectives : 1) Models for representing knowledge : the more concrete the better

slide-7
SLIDE 7

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 7

Issue of Abstraction in Systems Biology

Models are built in Systems Biology with two contradictory perspectives : 1) Models for representing knowledge : the more concrete the better 2) Models for making predictions : the more abstract the better !

slide-8
SLIDE 8

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 8

Issue of Abstraction in Systems Biology

Models are built in Systems Biology with two contradictory perspectives : 1) Models for representing knowledge : the more concrete the better 2) Models for making predictions : the more abstract the better !

La simplicité est la sophistication suprême. Léonard de Vinci.

slide-9
SLIDE 9

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 9

Issue of Abstraction in Systems Biology

Models are built in Systems Biology with two contradictory perspectives : 1) Models for representing knowledge : the more concrete the better 2) Models for making predictions : the more abstract the better !

La simplicité est la sophistication suprême. Léonard de Vinci.

These perspectives can be reconciled by organizing formalisms and models into hierarchies of abstractions. To understand a system is not to know everything about it but to know abstraction levels that are sufficient for answering questions about it

slide-10
SLIDE 10

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 10

Issue of Abstraction in Systems Biology

Models are built in Systems Biology with two contradictory perspectives : 1) Models for representing knowledge : the more concrete the better 2) Models for making predictions : the more abstract the better !

La simplicité est la sophistication suprême. Léonard de Vinci.

These perspectives can be reconciled by organizing formalisms and models into hierarchies of abstractions. To understand a system is not to know everything about it but to know abstraction levels that are sufficient for answering questions about it

Karl Popper empirical falsification versus positivist confirmation

slide-11
SLIDE 11

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 11

Formal Semantics of Living Processes ?

Formally, “the” behavior of a system depends on our choice of observables. ? ?

Mitosis movie [Lodish et al. 03]

slide-12
SLIDE 12

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 12

Boolean Semantics

  • Formally, “the” behavior of a system depends on our choice of observables.
  • Presence/absence of molecules
  • Boolean transitions models

1

Mitosis movie [Lodish et al. 03]

slide-13
SLIDE 13

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 13

Continuous Semantics

  • Formally, “the” behavior of a system depends on our choice of observables.
  • Concentrations of molecules
  • Ordinary Differential Equation models

x ý

Mitosis movie [Lodish et al. 03]

slide-14
SLIDE 14

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 14

Stochastic Semantics

  • Formally, “the” behavior of a system depends on our choice of observables.
  • Numbers of molecules
  • Continuous Time Markov Chain models

n 

Mitosis movie [Lodish et al. 03]

slide-15
SLIDE 15

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 15

Temporal Logic LTL

  • Formally, “the” behavior of a system depends on our choice of observables.
  • Presence/absence of molecules
  • Temporal logic formulas

F x F x F (x ^ F ( x ^ y)) FG (x v y) …

Mitosis movie [Lodish et al. 03]

slide-16
SLIDE 16

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 16

Temporal Logic LTL(R)

  • Formally, “the” behavior of a system depends on our choice of observables.
  • Concentrations of molecules
  • Temporal Logic with Constraints over R

F x>1 F (x >0.2) F (x >0.2 ^ F (x<0.1 ^ y>0.2)) FG (x>0.2 v y>0.2) …

Mitosis movie [Lodish et al. 03]

slide-17
SLIDE 17

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 17

Hierarchy of Semantics

Stochastic model Differential model Discrete model

abstraction concretization

Boolean model

Theory of abstract Interpretation Abstractions as Galois connections [Cousot Cousot POPL’77] [Fages Soliman CMSB’06,TCS’07]

Syntactical model

slide-18
SLIDE 18

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 18

Regulation Graph as Abstraction

Stochastic model Differential model Discrete model

abstraction concretization

Boolean model Syntactical model

[Fages Soliman FMSB’06]

Structural regulation graph (pos/neg influences w.r.t. the stoichiometric coefficient in reactions)

  • Thm. Same graphs for

monotonic kinetics Differential regulation graph (pos/neg influences w.r.t. the signs of the Jacobian)

slide-19
SLIDE 19

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 19

Regulation Graphs Circuit Analyses

Stochastic model Differential model Discrete model

abstraction concretization

Boolean model Syntactical model Jacobian circuit analysis Discrete circuit analysis Boolean circuit analysis

abstraction abstraction abstraction

  • Thm. Positive circuits are

a necessary condition for multistationarity

[Thomas 81] [Soulé 03] [Remy Ruet Thieffry 05] [Richard 07] [Soliman 13]

slide-20
SLIDE 20

24/06/2013 François Fages - Ecoles Jeunes Chercheurs - Porquerolles 20

Mammalian Cell Cycle Control Map [Kohn 99]

slide-21
SLIDE 21

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 21

Hierachy of Models / Model Reductions

Models of circadian clock in http://www.biomodels.net Reductions as Subgraph Epimorphisms [Gay Fages Soliman ECCB’10 DAM 13]

slide-22
SLIDE 22

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 22

Overview of the Lectures

1. Introduction

  • Transposing concepts from programming to the analysis of living processes

2. Rule-based Modeling in Biocham

  • Macromolecules, compartments and elementary processes in the cell
  • Boolean, Differential and Stochastic interpretations of reaction rules
  • Cell signaling, cell cycle models

3. Temporal Logic constraints in Biocham

  • Qualitative properties in propositional Computation Tree Logic CTL
  • Quantitative properties in quantifier-free Linear Time Logic LTL(R)
  • Model inference from temporal logic properties

4. Conclusion 5. Killer lecture: abstract interpretation in Biocham

slide-23
SLIDE 23

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 23

Cell Molecules

  • Small molecules: covalent bonds 50-200 kcal/mol

– 70% water – 1% ions – 6% amino acids (20), nucleotides (5), – fats, sugars, ATP, ADP, …

slide-24
SLIDE 24

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 24

Cell Molecules

  • Small molecules: covalent bonds 50-200 kcal/mol

– 70% water – 1% ions – 6% amino acids (20), nucleotides (5), – fats, sugars, ATP, ADP, …

  • Macromolecules: hydrogen bonds, ionic, hydrophobic, Waals 1-5 kcal/mol

Stability and bindings determined by the number of weak bonds: 3D shape – 20% proteins (50-104 amino acids) – DNA (102-106 nucleotides AGCT) – RNA (102-104 nucleotides AGCU)

slide-25
SLIDE 25

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 25

DNA Deoxyribonucleic Acid

1) Primary structure: word over 4 nucleotides Adenine, Guanine, Cytosine, Thymine

slide-26
SLIDE 26

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 26

DNA Deoxyribonucleic Acid

1) Primary structure: word over 4 nucleotides Adenine, Guanine, Cytosine, Thymine 2) Secondary structure: double helix of pairs A--T and C---G stabilized by hydrogen bonds Size of DNA = number of pairs A gene is a subword of DNA Nobel Prizes Watson and Crick (1956)

slide-27
SLIDE 27

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 27

DNA: Genome Size

Species Genome size Chromosomes Coding DNA

  • E. Coli (bacteria)

5 Mb 1 circular 100 % 12 Mb … 3 Gb … 15 Gb … 140 Gb Artificial life by Craig Venter: fully synthetic bacteria genome (0,39 $/b) implemented in a bacteria without DNA still living and proliferating!

slide-28
SLIDE 28

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 28

DNA: Genome Size

Species Genome size Chromosomes Coding DNA

  • E. Coli (bacteria)

5 Mb 1 circular 100 %

  • S. Cerevisae (yeast)

12 Mb 16 70 % … 3 Gb … 15 Gb … 140 Gb

slide-29
SLIDE 29

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 29

DNA: Genome Size

Species Genome size Chromosomes Coding DNA

  • E. Coli (bacteria)

5 Mb 1 circular 100 %

  • S. Cerevisae (yeast)

12 Mb 16 70 % Mouse, Human 3 Gb 20, 23 15 % … 15 Gb … 140 Gb

3,200,000,000 pairs of nucleotides Fully sequenced in year 2000 Single nucleotide polymorphism =1/2kb

slide-30
SLIDE 30

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 30

Genome Size

Species Genome size Chromosomes Coding DNA

  • E. Coli (bacteria)

4 Mb 1 100 %

  • S. Cerevisae (yeast)

12 Mb 16 70 % Mouse, Human 3 Gb 20, 23 15 % Onion 15 Gb 8 1 % … 140 Gb

slide-31
SLIDE 31

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 31

Genome Size

Species Genome size Chromosomes Coding DNA

  • E. Coli (bacteria)

4 Mb 1 100 %

  • S. Cerevisae (yeast)

12 Mb 16 70 % Mouse, Human 3 Gb 20, 23 15 % Onion 15 Gb 8 1 % Lungfish 140 Gb 0.7 %

slide-32
SLIDE 32

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 32

DNA Replication

  • 1. Separation of the two helices
  • 2. Production of one complementary strand for each copy

(from one or several starting points of replication)

  • 3. Segregation
  • 4. Mitosis (cell division)
slide-33
SLIDE 33

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 33

Gene Transcription and Translation

  • 1. Activation (Inhibition): Nobel prize Jakob and Monod (1965)

transcription factors bind to the regulatory region of the gene

  • 2. Transcription:

RNA polymerase copies the DNA from start to stop positions into a single stranded pre-mature messenger pRNA

  • 3. (Alternative) splicing:

non coding regions of pRNA are removed giving mature messenger mRNA

  • 4. Translation:

mRNA moves to cytoplasm and binds to ribosome to assemble a protein

slide-34
SLIDE 34

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 34

Formal Genes: Syntax

  • Part of DNA, unique E2
  • Activation

binding of promotion factor E2-(E2f13-DP12)

  • Repression (inhibition)

binding of another molecule E2-Rep

slide-35
SLIDE 35

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 35

Transcription and Translation Rules

Activation E2 + E2f13-DP12 => E2-E2f13-DP12 Repression E2 + Rep => E2-Rep

slide-36
SLIDE 36

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 36

Transcription and Translation Rules

Activation E2 + E2f13-DP12 => E2-E2f13-DP12 Repression E2 + Rep => E2-Rep Transcription _ =[E2-E2F13-DP12]=> pRNAcycA

slide-37
SLIDE 37

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 37

Transcription and Translation Rules

Activation E2 + E2f13-DP12 => E2-E2f13-DP12 Repression E2 + Rep => E2-Rep Transcription _ =[E2-E2F13-DP12]=> pRNAcycA (Alternative) Splicing pRNAcycA => mRNAcycA (pRNAcycA => mRNAcycA2)

slide-38
SLIDE 38

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 38

Transcription and Translation Rules

Activation E2 + E2f13-DP12 => E2-E2f13-DP12 Repression E2 + Rep => E2-Rep Transcription _ =[E2-E2F13-DP12]=> pRNAcycA (Alternative) Splicing pRNAcycA => mRNAcycA (pRNAcycA => mRNAcycA2) Translation mRNAcycA => mRNAcycA::cyt mRNAcycA::cyt + ribosome::cyt => cycA::cyt + ribosome::cyt

(mRNAcycA2::cyt + ribosome::cyt => cycA2::cyt + ribosome::cyt)

slide-39
SLIDE 39

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 39

Peptides and Proteins

1) Primary structure: word of n amino acids residues (20n possibilities) linked with C-N bonds

slide-40
SLIDE 40

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 40

Peptides and Proteins

1) Primary structure: word of n amino acids residues (20n possibilities) linked with C-N bonds Example: MPRI Methionine-Proline-Arginine-Isoleucine

slide-41
SLIDE 41

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 41

Peptides and Proteins

1) Primary structure: word of n amino acids residues (20n possibilities) linked with C-N bonds Example: MPRI Methionine-Proline-Arginine-Isoleucine Question: How many nucleotides on the gene are necessary to code for one amino acid on the protein?

slide-42
SLIDE 42

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 42

Peptides and Proteins

1) Primary structure: word of n amino acids residues (20n possibilities) linked with C-N bonds Example: MPRI Methionine-Proline-Arginine-Isoleucine Question: How many nucleotides on the gene are necessary to code for one amino acid on the protein? 3 ! 2 are not sufficient: 4*4=16 3 is sufficient but with a lot of non coding sequences: 4*4*4=64

slide-43
SLIDE 43

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 43

Peptides and Proteins

1) Primary structure: word of n amino acids residues (20n possibilities) linked with C-N bonds Example: MPRI Methionine-Proline-Arginine-Isoleucine 2) Secondary: word of m a-helix, b-strands, random coils,… (3m-10m) stabilized by hydrogen bonds H---O

slide-44
SLIDE 44

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 44

Peptides and Proteins

1) Primary structure: word of n amino acids residues (20n possibilities) linked with C-N bonds Example: MPRI Methionine-Proline-Arginine-Isoleucine 2) Secondary: word of m a-helix, b-strands, random coils,… (3m-10m) stabilized by hydrogen bonds H---O 3) Tertiary 3D structure: spatial folding stabilized by hydrophobic interactions explains the protein interaction capabilities

slide-45
SLIDE 45

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 45

Formal Proteins: Syntax

  • Cyclin dependent kinase 1 Cdk1

(free, inactive)

slide-46
SLIDE 46

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 46

Formal Proteins: Syntax

  • Cyclin dependent kinase 1 Cdk1

(free, inactive)

  • Complex Cdk1-Cyclin B Cdk1–CycB

(low activity)

slide-47
SLIDE 47

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 47

Formal Proteins: Syntax

  • Cyclin dependent kinase 1 Cdk1

(free, inactive)

  • Complex Cdk1-Cyclin B Cdk1–CycB

(low activity)

  • Phosphorylated form Cdk1~{thr161}-CycB

at site threonine 161 (high activity)

slide-48
SLIDE 48

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 48

Formal Proteins

  • Cyclin dependent kinase 1 Cdk1

(free, inactive)

  • Complex Cdk1-Cyclin B Cdk1–CycB

(low activity)

  • Phosphorylated form Cdk1~{thr161}-CycB

at site threonine 161 (high activity) “Mitosis-Promoting Factor” phosphorylates actin in microtubules  nuclear division

slide-49
SLIDE 49

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 49

Seven Main Reaction Schemas

  • Complexation: A + B => A-B. Decomplexation A-B => A + B.

cdk1+cycB => cdk1–cycB

  • Phosphorylation: A =[C]=> A~{p}. Dephosphorylation A~{p} =[C]=> A.

Cdk1-CycB =[Myt1]=> Cdk1~{thr161}-CycB Cdk1~{thr14,tyr15}-CycB =[Cdc25~{Nterm}]=> Cdk1-CycB

  • Synthesis: _ =[C]=> A. Degradation: A =[C]=> _.

_=[E2-E2f13-Dp12]=>cycA cycE =[@UbiPro]=> _ (not for cycE-cdk2 which is stable)

  • Transport: A::L1 => A::L2.

Cdk1~{p}-CycB::cytoplasm=>Cdk1~{p}-CycB::nucleus

slide-50
SLIDE 50

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 50

Syntax of Objects

E == entity | E-E | E~{p1,…,pn}

  • Entity: molecule name, gene binding site,…
  • - : binding operator for protein complexes, gene binding sites, …

associative and commutative.

  • ~{…}: set of modified sites (phosphorylation, acetylation, methylation,…)

O == E | E::location

  • Object: entity localized in a symbolic compartment (nucleus, cytoplasm,

membrane, …)

slide-51
SLIDE 51

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 51

Syntax of Reactions

S ::= _ | k*O + S A solution is a of objects 0N, written as a linear expression R ::= S => S | f for R A reaction is a multiset rewriting rule, possibly given with a kinetic expression f A =[C]=> B stands for A+C => B+C A <=> B stands for A=>B and B=>A, Syntax compatible with the XML syntax of Systems Biology Markup Language SBML, widely used exchange format for reaction models.

slide-52
SLIDE 52

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 52

From Syntax to Semantics

  • 1. Boolean Semantics: presence-absence of molecules

– Boolean Transition System (asynchronous, synchronous)

  • 2. Discrete semantics: numbers of molecules

– Petri net

  • 3. Continuous Semantics: concentrations

– Ordinary Differential Equations – Hybrid automata

  • 4. Stochastic Semantics: numbers of molecules

– Continuous time Markov chain

slide-53
SLIDE 53

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 53

Cell Signaling

  • Signals:

– hormones: insulin, adrenaline, steroids, EGF, …, – neighboring cell membrane proteins: Delta – nutriments, light, pressure, …

slide-54
SLIDE 54

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 54

Cell Signaling

  • Signals:

– hormones: insulin, adrenaline, steroids, EGF, …, – neighboring cell membrane proteins: Delta – nutriments, light, pressure, …

  • Receptors transmembrane proteins:

– Tyrosine kinases, – G protein-coupled, – TGFβ, – Notch, – Ionic channels – …

slide-55
SLIDE 55

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 55

Receptor Tyrosine Kinase RTK

L + R <=> L-R L-R + L-R => L-R-L-R RAS-GDP =[L-R-L-R]=> RAS-GTP

slide-56
SLIDE 56

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 56

MAPK Signaling Pathways

  • Input:

RAS activated by the receptor activates RAF RAS-GTP + RAF-P14-3-3 => RAS-GDP + RAF + P14-3-3

  • Output:

active MAPK moves to the nucleus phosphorylates a transcription factor which stimulates gene expression RAF + … => … … => MAPK~{T183,Y185}

slide-57
SLIDE 57

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 57

Five MAP Kinase Pathways in Budding Yeast (Saccharomyces Cerevisiae)

slide-58
SLIDE 58

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 58

Three Levels MAPK Cascade

slide-59
SLIDE 59

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 59

Reaction Model of the MAPK Cascade

[Levchenko et al. PNAS 2000]

(MA(1), MA(0.4)) for RAF + RAFK <=> RAF-RAFK. (MA(0.5),MA(0.5)) for RAF~{p1} + RAFPH <=> RAF~{p1}-RAFPH. (MA(3.3),MA(0.42)) for MEK~$P + RAF~{p1} <=> MEK~$P-RAF~{p1} where p2 not in $P. (MA(10),MA(0.8)) for MEKPH + MEK~{p1}~$P <=> MEK~{p1}~$P-MEKPH. (MA(20),MA(0.7)) for MAPK~$P + MEK~{p1,p2} <=> MAPK~$P-MEK~{p1,p2} where p2 not in $P. (MA(5),MA(0.4)) for MAPKPH + MAPK~{p1}~$P <=> MAPK~{p1}~$P-MAPKPH. MA(0.1) for RAF-RAFK => RAFK + RAF~{p1}. MA(0.1) for RAF~{p1}-RAFPH => RAF + RAFPH. MA(0.1) for MEK~{p1}-RAF~{p1} => MEK~{p1,p2} + RAF~{p1}. MA(0.1) for MEK-RAF~{p1} => MEK~{p1} + RAF~{p1}. MA(0.1) for MEK~{p1}-MEKPH => MEK + MEKPH. MA(0.1) for MEK~{p1,p2}-MEKPH => MEK~{p1} + MEKPH. MA(0.1) for MAPK-MEK~{p1,p2} => MAPK~{p1} + MEK~{p1,p2}. MA(0.1) for MAPK~{p1}-MEK~{p1,p2} => MAPK~{p1,p2} + MEK~{p1,p2}. MA(0.1) for MAPK~{p1}-MAPKPH => MAPK + MAPKPH. MA(0.1) for MAPK~{p1,p2}-MAPKPH => MAPK~{p1} + MAPKPH.

slide-60
SLIDE 60

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 60

Reaction Hypergraph

Bipartite Proteins-Reactions Graph

GraphViz

http://www.research.att.co/sw/tools/graphviz

slide-61
SLIDE 61

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 61

Influence Graph inferred from the reaction graph of the MAPK “cascade” Negative circuit [Fages Soliman CMSB 06] Possibility of oscillations [Qiao et al. PLOS 07]

Influence Graph

slide-62
SLIDE 62

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 62

Differential Simulation

slide-63
SLIDE 63

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 63

Stochastic Simulation

slide-64
SLIDE 64

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 64

Boolean Simulation

slide-65
SLIDE 65

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 65

Semantics of Reaction Models

Reaction rule: k*[A]*[B] for A+B => C Three interpretations in Biocham:

  • 1. Stochastic Semantics: number of molecules

– Continuous time Markov chain

  • 2. Differential Semantics: concentration

– Ordinary Differential Equations – Hybrid automata

  • 3. Boolean Semantics: presence-absence of molecules

– Asynchronous Transition System A & B  C & A/A & B/B

slide-66
SLIDE 66

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 66

Automatic Generation of CTL Properties

reachable(MAPK~{p1})) reachable(!(MAPK~{p1})))

  • scil(MAPK~{p1}))

… reachable(MAPKPH-MAPK~{p1})) reachable(!(MAPKPH-MAPK~{p1})))

  • scil(MAPKPH-MAPK~{p1}))

AG(!(MAPKPH-MAPK~{p1})->checkpoint(MAPKPH,MAPKPH-MAPK~{p1}))) AG(!(MAPKPH-MAPK~{p1})->checkpoint(MAPK~{p1},MAPKPH-MAPK~{p1}))) … reachable(MAPK~{p1,p2})) reachable(!(MAPK~{p1,p2})))

  • scil(MAPK~{p1,p2}))

…

slide-67
SLIDE 67

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 67

Model Reductions Preserving CTL Properties

After reduction, 20 rules remain. Deletions: RAF-RAFK=>RAF+RAFK RAFPH-RAF~{p1}=>RAFPH+RAF~{p1} MEK-RAF~{p1}=>MEK+RAF~{p1} MEKPH-MEK~{p1}=>MEKPH+MEK~{p1} MAPK-MEK~{p1,p2}=>MAPK+MEK~{p1,p2} MAPKPH-MAPK~{p1}=>MAPKPH+MAPK~{p1} MEK~{p1}-RAF~{p1}=>MEK~{p1}+RAF~{p1} MEKPH-MEK~{p1,p2}=>MEKPH+MEK~{p1,p2} MAPK~{p1}-MEK~{p1,p2}=>MAPK~{p1}+MEK~{p1,p2} MAPKPH-MAPK~{p1,p2}=>MAPKPH+MAPK~{p1,p2}

slide-68
SLIDE 68

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 68

Model Reduction as Subgraph Epimorphism

011_levc

MAPK models from the SBML model repository http://www.biomodels.net Reaction (hyper)graph reduction G1G2 through 4 operations: molecule/reaction merge/deletion iff SEPI from G1 to G2

[Gay Fages Soliman 2010 ECCB, Bioinformatics, DAM 2013]

slide-69
SLIDE 69

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 69

Biological process model = Concurrent Transition System Biological property = Temporal Logic Formula Biological validation = Model-checking Model inference = Temporal Constraint Solving

  • [Lincoln et al. PSB’02] [Chabrier Fages CMSB’03] [Bernot et al. TCS’04] …

Model: BIOCHAM Biological Properties:

  • Boolean - simulation - Temporal logic CTL
  • Differential - query evaluation - LTL(R), QFLTL(R) constraints
  • Stochastic - rule learning - CSL

(SBML) - parameter search

  • Influences

A Logical Paradigm for Systems Biology

slide-70
SLIDE 70

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 70

A Programmer View at Cell Computations

Size of genome

  • 5 Mb for bacteria: normal size program (Biocham binary: 15Mb as yeast)
slide-71
SLIDE 71

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 71

A Programmer View at Cell Computations

Size of genome

  • 5 Mb for bacteria: normal size program (Biocham binary: 15Mb as yeast)
  • 3 Gb for human: normal size of a video not for a program
slide-72
SLIDE 72

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 72

A Programmer View at Cell Computations

Size of genome

  • 5 Mb for bacteria: normal size program (Biocham binary: 15Mb as yeast)
  • 3 Gb for human: normal size of a video not for a program
  • 140 Gb for lung fish: nature error !
slide-73
SLIDE 73

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 73

A Programmer View at Cell Computations

Size of genome

  • 5 Mb for bacteria: normal size program (Biocham binary: 15Mb as yeast)
  • 3 Gb for human: normal size of a video not for a program
  • 140 Gb for lung fish: nature error !

Speed of interactions

  • Protein interactions: enzyme-substrate collisions at 0,5 Mhz, quite slow
  • Gene expression: hours ! as long as reinstalling an operating system
slide-74
SLIDE 74

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 74

A Programmer View at Cell Computations

Size of genome

  • 5 Mb for bacteria: normal size program (Biocham binary: 15Mb as yeast)
  • 3 Gb for human: normal size of a video not for a program
  • 140 Gb for lung fish: nature error !

Speed of interactions

  • Protein interactions: enzyme-substrate collisions at 0,5 Mhz, quite slow
  • Gene expression: hours ! as long as reinstalling an operating system

Concurrent computation paradigm

  • Chemical metaphor for concurrent programming [Banatre, Le Metayer 78]
  • CHAM [Berry 85] to express the operational semantics of the Pi-Calculus
  • Membranes for modules: just like cell compartments
slide-75
SLIDE 75

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 75

A Programmer View at Cell Computations

Size of genome

  • 5 Mb for bacteria: normal size program (Biocham binary: 15Mb as yeast)
  • 3 Gb for human: normal size of a video not for a program
  • 140 Gb for lung fish: nature error !

Speed of interactions

  • Protein interactions: enzyme-substrate collisions at 0,5 Mhz, quite slow
  • Gene expression: hours ! as long reinstalling an operating system

Concurrent computation paradigm

  • Chemical metaphor for concurrent programming [Banatre, Le Metayer 78]
  • CHAM [Berry 85] to express the operational semantics of the Pi-Calculus
  • Membranes for modules: just like cell compartments

Hybrid continuous+discrete computations (energy + information)

  • Trend for future: more physics in informatics, more informatics in physics
slide-76
SLIDE 76

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 76

Two-stroke Engine with ATP fuel Myosin + ATP => Myosin-ATP

Myosin-ATP => Myosin + ADP

slide-77
SLIDE 77

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 77

Two-stroke Engine with ATP fuel Myosin + ATP => Myosin-ATP

Myosin-ATP => Myosin + ADP

http://www.sci.sdsu.edu/movies

slide-78
SLIDE 78

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 78

Two-stroke Engine with ATP fuel Myosin + ATP => Myosin-ATP

Myosin-ATP => Myosin + ADP

http://www.sci.sdsu.edu/movies http://www-rocq.inria.fr/sosso/icema2

slide-79
SLIDE 79

24/06/2013 François Fages - Ecole Jeunes Chercheurs - Porquerolles 79

Two-stroke Engine with ATP fuel Myosin + ATP => Myosin-ATP

Myosin-ATP => Myosin + ADP Actin-Myosin microtubule contraction controlled by MPF that phosphorylates myosin
