Community Task Force October 5, 2017 Welcome and Introductions Project Partners Regional Transportation District (RTD) Colorado Department of Transportation (CDOT) Denver Regional Council of Governments (DRCOG) City of Aurora

slide-1
SLIDE 1

Community Task Force

October 5, 2017

slide-2
SLIDE 2

Welcome and Introductions

slide-3
SLIDE 3

Project Partners

  • Regional Transportation District (RTD)
  • Colorado Department of Transportation (CDOT)
  • Denver Regional Council of Governments (DRCOG)
  • City of Aurora
slide-4
SLIDE 4

Meeting Purpose and Agenda

slide-5
SLIDE 5

Meeting Purpose

  • Review findings of initial center-running BRT

evaluation

  • Review key differentiators/opportunities/challenges of

center-running concept

  • Identify common themes and outstanding questions on

center-running BRT evaluation

slide-6
SLIDE 6

Agenda

  • Peer City Review
  • Review findings of center-

running BRT evaluation

  • Evaluation criteria: key

differentiators/benefits/ challenges

  • Key themes and group

discussion

  • Next steps and path forward
slide-7
SLIDE 7

Center-Running BRT on Colfax

slide-8
SLIDE 8

Aurana

Ca mp~s

I

"'

  • g:

: ~':r' n -

;-

  • -·;;·------
  • -1

8ih------

  • ------·

g ~

~ -- -

  • ;:;-
  • - - - ~
  • --

d

\!'~

~

7 v~ ty J;-° ,)_

  • -------1

· · 7 ·

.:_···

  • ••••••••••• ·.;; •••• M ed ~c8~

~p

u s ~ 17th

Q Q

s;

~

U I (1)
  • ~

ID

CJ

:J

(5- ro

Q

  • ......
  • .

iil

colfax Ill

ro

3

&'

~ 14th N ational

  • §-

8

n

ip'

1143

~

: ••••••••••••••••••••

~

  • ~ ;:~

.

Je•\lish Heallh •••••••••• ••••••••• •••••••••••••••••••••••••••••••••

~ ••••••••••••••••

~

~ •••••••••••••••••••••••••••••••••

:

A-U\. tipj:Ua i- MIM »::MM 01).-

" 1c

fB o

1o111e
  • .5
  • m

e

~I~

____________

£ _

·1~
  • coif

ax corridor connections

Study Area

slide-9
SLIDE 9
  • Corridor Development Timeline

Alternatives Analysis

Conceptual Design & Environmental Analysis

Engineering & Design Construction Revenue Service

Locally Preferred Alternative

  • Definition of

mode & alignment

  • Conceptual

station locations

  • Operating plan
  • Local decision

Concept Design & Environmental Clearances

  • Design detail

determined

  • Environmental

impacts identified

Fully Designed and Funded Project

  • Design

complete

  • Finance

package

Federal Transit Administration Project Development 12 18 months 18 months 18 24 months Ongoing Opportunity for Stakeholders and Public To Influence Project Design

Design Detail Broad Definition

  • f Project

We Are Here

slide-10
SLIDE 10

Center-Running BRT in Sister Cities

slide-11
SLIDE 11

Denver’s Peers are Building Quality BRT

  • Cleveland: HealthLine BRT
  • Chicago: Ashland BRT
  • Seattle: Madison RapidRide BRT
  • NYC: Fordham Road Select Bus Service
  • Eugene: EmX BRT
  • Boston: Silver Line BRT
slide-12
SLIDE 12

coif ax corridor connections

Healthline BRT, Cleveland

https://youtu.be/kF6EF3kOGQE

slide-13
SLIDE 13

Ashland BRT, Chicago

  • Similar corridor and ridership to Colfax
  • Population living within 0.5 miles of Ashland corridor expected to

grow by 55,000 (about 24%) by 2040.

Ashland Corridor, Chicago

slide-14
SLIDE 14

coif ax corridor connections

Ashland BRT, Chicago

https://youtu.be/_csc2ZDuQLo

slide-15
SLIDE 15

Seattle Madison BRT

  • Serves several neighborhood retail districts
  • Purpose is to deliver high-quality mobility to accommodate

current and expected growth

slide-16
SLIDE 16

coif ax corridor connections

Madison BRT, Seattle

https://youtu.be/nmpCkw9dPkw

slide-17
SLIDE 17

Center-Running BRT Evaluation and New Criteria

slide-18
SLIDE 18 I~

h

GOOD GOOD/FAIR FAIR

FAIR/POOR POOR coif

ax corridor connections

Where We’ve Been: Screen 3 Plus Results Summary

slide-19
SLIDE 19
  • SCREEN4

111.

RESULTS SUMMARY

KIY Bus Rapid Transit Bus Rapid Transit

GOOD

Side-Running in Center-Running in Exclusive Lanes- All Day Exclusive Lanes - All Day

Ridership

GOOD/FAIR

Transit Travel Time Auto Travel Time Person capacitY

FAIR

Transit ReliabilitY cost-EHectiveness

FAIR/POOR

Vehicle Miles Traveled Multimodal Access Pedesttian satetv +IXJJerience ••••••

  • POOR

Multimodal satetv Expansion capacitv curb Access Vehicle Access Economic oevelopmem Urban oesign/Placemaking

CODSU'UCtiOD Impact

Agency+ communitv suppon

lstrong agency SUPPOrll

  • verall Results
  • TBD
  • TBO

_Jll\

  • coif•• corridor connections
slide-20
SLIDE 20

Potential Evaluation Criteria for Additional Screening

OPERATIONS

  • Transit Operating

Cost

  • Expansion Capacity
  • Traffic Operations
  • Cost-Effectiveness
  • Ridership
  • Person Capacity

EXPERIENCE

  • Travel Time

Reliability

  • Placemaking
  • Passenger

Experience

  • Multimodal Access

(Station Spacing) COMMUNITY

  • Multimodal Safety –

Vision Zero

  • Vehicle Miles

Traveled

  • Economic

Development

  • Construction

Impacts

  • Business Access
  • Community &

Agency Support

  • Construction

Impacts

slide-21
SLIDE 21

Screen 4 Criteria: Key Differentiators, Benefits and Tradeoffs

slide-22
SLIDE 22

Criteria Topics for Today’s Discussion

Transit Travel Time Reliability Operating Cost Future Proofing

Placemaking

Passenger Experience Multimodal Safety Pedestrian Comfort & Experience Traffic Operations Pedestrian, Bicycle, ADA Access Station Spacing Business Access Parking & Loading

slide-23
SLIDE 23

Transit Reliability

Transit Travel Time Reliability Operating Cost Future Proofing

The Bottom Line:

  • Center Running BRT (CRBRT) has less friction with
  • ther road users including curbside conflicts, providing

more reliable travel

  • Changes to traffic and corridor development don’t affect

future transit operations

  • CRBRT operators can accurately predict future operating

costs/avoid year-over-year increases

Tradeoffs/Other Considerations:

  • More left turn restrictions
  • Less auto travel lanes

Future proofing from delay as land-use, traffic, and curb uses change

CENTER

slide-24
SLIDE 24

Reduced Conflicts

No conflicts with turning vehicles, parallel parking,

  • r truck loading
slide-25
SLIDE 25

EmX, Eugene-Springfield, OR

100% Near-Level Boarding

Off Board Fare Payment & Level Boarding are major contributors to improved travel speed and reliability

slide-26
SLIDE 26

Transit Reliability

Transit Travel Time Reliability Operating Cost Future Proofing

The Bottom Line:

  • Center Running BRT (CRBRT) has less friction with
  • ther road users including curbside conflicts, providing

more reliable travel

  • Changes to traffic and corridor development don’t affect

future transit operations

  • CRBRT operators can accurately predict future operating

costs/avoid year-over-year increases

Tradeoffs/Other Considerations:

  • More left turn restrictions
  • Less auto travel lanes

Future proofing from delay as land-use, traffic, and curb uses change

CENTER

slide-27
SLIDE 27

Local Business Access

Business Access Parking & Loading The Bottom Line:

  • CRBRT will restrict auto left turns at most non-signalized

left turns

  • CRBRT has similar curb use (parking and loading)

impacts to SRBRT (no conflicts with buses)

  • CRBRT will improve pedestrian safety and crossing
  • pportunities, making it more attractive to park and cross

the street to access businesses

  • CRBRT will also improve bicycle and motor vehicle

safety

Tradeoffs/Other Considerations:

  • On-street parking movements don’t negatively impact

transit operations

SIDE

Given current vehicle oriented uses

  • n corridor, side running has lesser
  • impacts. This may change over time.
slide-28
SLIDE 28

Vehicle Access

Before Center-Running After Center-Running

Colfax

slide-29
SLIDE 29

Local Business Access

Business Access Parking & Loading The Bottom Line:

  • CRBRT will restrict auto left turns at most non-signalized

left turns

  • CRBRT has similar curb use (parking and loading)

impacts to SRBRT (no conflicts with buses)

  • CRBRT will improve pedestrian safety and crossing
  • pportunities, making it more attractive to park and cross

the street to access businesses

  • CRBRT will also improve bicycle and motor vehicle

safety

Tradeoffs/Other Considerations:

  • On-street parking movements don’t negatively impact

transit operations

SIDE

Given current vehicle oriented uses

  • n corridor, side running has lesser
  • impacts. This may change over time.
slide-30
SLIDE 30

Stop Consolidation/Local Service

Pedestrian, Bicycle, ADA Access Station Spacing The Bottom Line:

  • CRBRT will maintain or improve overall transit travel

times when considering walk, wait, and ride

  • All CRBRT stations will offer more rail-like boarding

experience, making it easier for seniors and people with disabilities to ride

  • CRBRT and SRBRT provide opportunities for improved

sidewalks and bike and pedestrian access to corridor

Tradeoffs/Other Considerations:

  • Some passengers will need to walk further to access

service

  • Some local stops are consolidated

CENTER

slide-31
SLIDE 31

Project Map

To Tower Rd.

0 Conceptual BRT Stations

Sludy Boundoly

Q Conceptual Standard Bus Stop

To ALA"ora Metro Center I R ti-le

coif ax corridor connections

Conceptual Stops

slide-32
SLIDE 32

Stop Spacing In Denver

  • Local and Limited use one set of high-quality stations in Denver
  • 3-5-minute headways

Colfax has a well connected urban sidewalk network providing good access to the corridor

slide-33
SLIDE 33

BlocksTraveled by Service Provided

1/8 mi. Service BRT 114 mi. Household A

2 blocks

3 blocks

I I

Household B 3 blocks 3 blocks

I

Household C 3 blocks 3 blocks

······•

BRT 1/2 mi.

3 blocks 5 blocks

4 blocks

e

  • Walking Travel Path to Transit Stop
  • 9-

BRT Stop (112 mile stop spacing) and Path

.••.•••• BRT Stop (114 mile stop spacing) and Path

  • -

118 mi. Service Stop and Path

coif ax corridor connections

How stop spacing affects walking distances

slide-34
SLIDE 34

Anatomy of a Trip

Side Running BRT

Walk to End Walk to Transit

Wait @ Station

Ride

Center Running BRT

Walk to Transit

Wait @ Station

Ride Walk to End

Wait time perceived as most punitive

slide-35
SLIDE 35

Traffic Operations

The Bottom Line: Traffic Operations

  • CRBRT will shift some vehicle trips to parallel corridors,

but impacts are limited to a few intersections (will be focus for mitigations)

  • CRBRT will reduce total vehicle volume on corridor but

increase person throughput and access

  • CRBRT or SRBRT will provide opportunity for operational

improvements (signal optimization, extended/new turn lanes, re-striping, minor curb/gutter relocation) that will aid vehicle and transit operations

Tradeoffs/Other Considerations:

  • Some vehicles will shift to parallel corridors
  • Auto trips are more susceptible to minor delays due to

parallel parking and truck loading

  • Auto trips will experience a few additional minutes of

travel time from end-to-end

TIE

Grid street network can absorb diversion with minimal vehicle travel time increases

slide-36
SLIDE 36

Safety

Multimodal Safety Pedestrian Comfort & Experience The Bottom Line:

  • CRBRT will eliminate many of the most significant

conflict points that lead to serious injury and fatal collisions

  • CRBRT will reduce crossing exposure
  • CRBRT design could provide center pedestrian refuges

at non-signalized crossings (under discussion)

  • CRBRT provides vertical features in the roadway that

serve as traffic calming

Tradeoffs/Other Considerations:

  • Left turns only allowed at signalized intersections. May

require U-turns or multiple lefts to get to destinations.

  • Will require careful design decisions about pedestrian

crossings at non-signalized intersections

CENTER

slide-37
SLIDE 37

Healthline, Cleveland, OH

Improves Crossing Safety and Comfort

  • Island stations calm traffic
  • Pedestrian refuges reduce crossing distance
  • Shorter crossing distances = less exposure to vehicle traffic
  • Eliminating unprotected lefts improves pedestrian safety
  • Station lighting enhances security

Madison BRT, Seattle

slide-38
SLIDE 38

Safety

Multimodal Safety Pedestrian Comfort & Experience The Bottom Line:

  • CRBRT will eliminate many of the most significant

conflict points that lead to serious injury and fatal collisions

  • CRBRT will reduce crossing exposure
  • CRBRT design could provide center pedestrian refuges

at non-signalized crossings (under discussion)

  • CRBRT provides vertical features in the roadway that

serve as traffic calming

Tradeoffs/Other Considerations:

  • Left turns only allowed at signalized intersections. May

require U-turns or multiple lefts to get to destinations.

  • Will require careful design decisions about pedestrian

crossings at non-signalized intersections

CENTER

slide-39
SLIDE 39

Placemaking/Streetscaping

Placemaking Passenger Experience The Bottom Line:

  • CRBRT will open sidewalk space for pedestrian, retail

activation by removing bulky shelters and waiting passengers

  • CRBRT alternative eliminates all curbside transit stops

and boarding

  • CRBRT improves transit customer security by separating

transit customers from other sidewalk users (and providing transparent design and lighting)

  • CRBRT can increase space for landscaping and public

art

  • CRBRT station design is less constrained, allowing for

signature design

Tradeoffs/Other Considerations:

  • Passenger may feel more isolated in the center of the

street during off-peak times (lighting and station design

CENTER

can mitigate)

slide-40
SLIDE 40

Placemaking/Streetscaping

  • Frees sidewalk space for retail and community activation
  • Increases opportunity for public art and streetscape

improvements

  • Landscaping increases property values

Colfax: Curb Bus Stations Limit Public Realm Ops Euclid Avenue, Cleveland

slide-41
SLIDE 41

Street Design

HealthLine BRT, Cleveland

slide-42
SLIDE 42

Street Design

HealthLine BRT, Cleveland

slide-43
SLIDE 43
  • Landscaping

HealthLine BRT, Cleveland

slide-44
SLIDE 44

Public Art

Steve Manka, “Chorus Line” HealthLine BRT, Cleveland

slide-45
SLIDE 45

Placemaking/Streetscaping

Placemaking Passenger Experience The Bottom Line:

  • CRBRT will open sidewalk space for pedestrian, retail

activation by removing bulky shelters and waiting passengers

  • CRBRT alternative eliminates all curbside transit stops

and boarding

  • CRBRT improves transit customer security by separating

transit customers from other sidewalk users (and providing transparent design and lighting)

  • CRBRT can increase space for landscaping and public

art

  • CRBRT station design is less constrained, allowing for

signature design

Tradeoffs/Other Considerations:

  • Passenger may feel more isolated in the center of the

street during off-peak times (lighting and station design

CENTER

can mitigate)

slide-46
SLIDE 46

Key Themes and Group Discussion

slide-47
SLIDE 47

Next Steps and Path Forward

slide-48
SLIDE 48

Where Do We Go From Here?

  • Identify Local/Regional Funding Sources
  • Compete for Federal Funding*
  • BID/RNO presentations and updates
  • Gather community feedback and complete more detailed

design and implementation schedule

  • Next Task Force Meeting: Wednesday, November 15

*requires environmental clearance by Federal Transit Administration and funding availability

slide-49
SLIDE 49

www.ColfaxCorridorConnections.com Info@ColfaxCorridorConnections.com
