Colt’s Carrier SDN & NFV Experience, Learnings and Future Plans

ONS 2017, Santa Clara

Javier Benitez

1

Contents

2

Colt Introduction SDN and NFV transformation (Novitas) Roadmap Learnings Future developments 1 2 3 4 5

25k+

Business customers

SME Enterprise Carrier Voice Services

205

Cities

3

Continents

50+

Industry Awards

24/7 5k+

Employees

5 6 7 3 2 1

Colt in focus

4

Data Centre Services Network Services

28

Countries 3

Underpinned by our world-class network

• 187,586 km of LDN, metro fibre and subsea & terrestrial leased

capacity connecting 28 countries across 4 continents.

• 200 connected cities; metropolitan area networks

in 49 cities

• 24,000+ buildings directly connected
• 700+ 3rd-party DCs and 29 Colt-owned DCs
• 919 COs (635 EFM) and 390 E-NNIs (180 cities,146 countries)
• Single end to end SLA
• Consistent and predictable user experience across

geographies

• Single view of service activity and performance
• Ability to rapidly change your services as business

needs change allowing you to flex and grow

• 24/7 operational management

4

Underpinned by our world-class network

• 187,586 km of LDN, metro fibre and subsea & terrestrial leased

capacity connecting 28 countries across 4 continents.

• 200 connected cities; metropolitan area networks

in 49 cities

• 24,000+ buildings directly connected
• 700+ 3rd-party DCs and 29 Colt-owned DCs
• 919 COs (635 EFM) and 390 E-NNIs (180 cities,146 countries)
• Single end to end SLA
• Consistent and predictable user experience across

geographies

• Single view of service activity and performance
• Ability to rapidly change your services as business

needs change allowing you to flex and grow

• 24/7 operational management

5

The world around us is changing at a rapid pace

Four mega technology trends transforming IT:

2.5 Trillion Gigabytes

Data created globally each day

6.4 billion

Connected things in use worldwide in 2016

85%

Of enterprises use at least one cloud service today

75%

Of world’s mobile traffic will be video by 2020

BIG DATA INTERNET OF THINGS SHIFT TO THE CLOUD MOBILITY

Gartner forecasts that 6.4 billion connected things will be in use worldwide in 2016, up 30 percent from 2015, and will reach 20.8 billion by 2020 Worldwide revenues from public cloud services will reach more than $195 billion in

• 2020. This will be more than double 2016

revenues and represents a CAGR of 20.4%

6

• ur customers are facing a new set of challenges

7

Need for higher bandwidth Customer demand has a strong growth: WAN bandwidth requirements are increasing above 30% per annum every year Customers can set up new cloud services in minutes, yet delivery times for new VPN sites and Ethernet connections are still measured in weeks and months. Radically faster network delivery Need for more in-life agility Cost efficient scaling Cloud services can be scaled up and down on demand, while bandwidth upgrades and feature changes for the network are traditionally manually requested and take days/weeks to deliver Since 65% of WAN budgets are flat or declining, cost efficient scaling of bandwidth is crucial.

“With a progressive uptake of video, IP audio and cloud, the compound annual growth rate (CAGR) of IP traffic is above 30% per year”

In response to this we are…

8

Investing in a new ultra-high bandwidth network Introducing a high bandwidth

• ptimised portfolio

Launching On Demand and Software Defined WAN Services Further increasing focus on Enterprise market

Investment in ultra-high bandwidth “IQ” network: 4 focus areas

Build an Integrated Core and Metro Packet Network

• Single integrated IP and

Ethernet core network, covering 200+ data centres across Europe and Asia

• Delivers 100Mbps to 100Gbps

services via plug and play model

4 key investments will transform the backbone networks that support our customer services

• New metro optical network

across 90+ data centres in 13 key cities in Europe and Asia

• Off the shelf delivery of

100Gbps & 200Gbps waves

• Rapid leadtimes – 5 days for

10Gbps waves High bandwidth optical network between major data centres Evolve our voice network New optical backbone: “Express” Long Distance Network

• Next generation SIP Trunking

session board controller

• SIP Trunking coverage expansion

to 21 countries

1

• Build “Express” long haul

network between 30 major European cities

• Based on architecture optimised

for high bandwidth connectivity

2 3 4

9

Novitas what is the customer need?

Today’s digital economy means our customers can:

Place an order, and it is delivered the next day Book a taxi via an app, it turns up in minutes

However, most telecom services are still ordered and delivered in the same way they were 20 years ago!

Order cloud IT services and it is delivered in seconds

10

Novitas what does it mean?

11

NOVITAS transforms the way that network services are ordered and consumed, and brings a cloud like customer experience

Delivery in weeks Manual configuration Steep bandwidth vs cost curve Traditional telco experience Today’s cloud experience Real time delivery

Colt NOVITAS

Portal consumed network services, delivered in real time!

Colt SDN/NFV transformation programme (Novitas)

Self- provision Near real-time Interworking with other providers Available through portal and APIs Provides performance analytics

And delivering important benefits:

Supports value added services

Elastic Topology Elastic Service Deliver programmable flexible topologies based on overlay and underlay networks. Deliver virtualised off-net and on-net L2 and L3 edge services on top of basic connectivity.

SDN NFV

Elastic Bandwidth Deliver programmable elastic links with variable bandwidth. The Vision: to transform the way network services are ordered and consumed, delivering a cloud like customer experience (self-provision, in real-time)

2015

12

NOVITAS Engine (Choreographer / Service Orchestration)

Colt portal APIs Customer portal

Packet/Optical Multi-layer SDN Controller SDN Network virtualisation controller NFV MANO

Node Infrastructure Cloud (x86 & Merchant silicon) SDN Fabric 3rd-Party Network Infrastructure Optical / OTN Core Address Book Inventory Billing Order Mgmt Customer Care Monitoring Analytics

OSS/BSS Systems Software Defined Networking Network Function Virtualisation Telco Node Virtualisation APIs Network domain

• rchestrator

(Model-driven YANG/TOSCA) SD WAN Controller

IQ Network (integrated Ethernet+IP) SP Cloud x86 CPE

SDN NFV

Compute Virtualisation

NOVITAS target architecture

13

14

NOVITAS roadmap (Original)

vCPE for Internet

Pre-NFV PE-based

QoS alignment in the metro

DSCP-PCP mapping, queue sharing

Edge integration Core integration

Technical capability

2014 2013 2015 2016

DCNet On Demand

Ethernet P2P service on-demand

2017

Multi-vendor WAN SDN

Modular Multi-service Network (M-MSP)

SDN in the DC

IP fabric overlay

vCPE for IP-VPN

Pre-NFV PE-based

NFV PoC

CG-NAT & MANO

Novitas v1 Novitas v2 Ethernet On Demand

SDN & NFV devs

SD WAN On Demand

(first customer-facing NFV function)

Novitas v3+ Dedicated Cloud Access On Demand

NOVITAS roadmap (progress and update)

2017 2016 2018 2019 2020

SD WAN

Basic service for hybrid site (MPLS & Internet), Oct’16

In Planning Target NFV Platform

Distributed Unified NFV Cloud

DCNet On Demand

Inter-DC Ethernet on Demand Apr’16 (27 sites)

Ethernet On Demand

Extension to Enterprise buildings (~ 300 buildings, Nov’16)

DCA on Demand

Public Cloud Access on demand Microsoft Azure (Feb’17) and AWS (Mar’17)

DCNet & Ethernet On Demand

400 DCs eligible, 42 Managed capacity ~ 5000 enterprise buildings, Mar’17)

On Demand evolution

Colt Asia, BW Calendaring, additional sites Public Cloud extensions

In Development SD WAN evolution

Internet-only, MPLS-only, FW, DPI, self-install CPE, etc

IQNet Packet Network

MPLS SR, external SDN Control (PCE), vBGP RR

In Research Standard SDN/NFV NNI

Industry collaboration to develop standard SDN/NFV East-West APIs (MEF LSO Sonata/Interlude)

IPA On Demand

Internet Access On demand

Optical SDN

fully disaggregated, SW- controllable optical transport network (Layer 0-Photonic/WDM & Layer 1-OTN)

15

Ethernet on demand (solutions)

Market demand Colt on-demand solution Value proposition On-Demand connectivity between data centres On-Demand connectivity to enterprise buildings On Demand connectivity into the cloud

1 2 3

+24% yoy Traffic Data Centre to user +32% yoy Traffic Data Centre to data centre +100% yoy Private Cloud connectivity Ethernet

• n Demand

Data centres Enterprise Buildings DCA on Demand Data centre Public Clouds Enterprise Building DCNet on Demand Data centres Data centres 16

Ethernet on demand (definition)

Customer

DC Enterprise Public Cloud

SDN Enabled Network Layer

• Select locations
• Select ports
• Create, change (BW/Vlan),

cease Ethernet connection

• Real-time Provisioning

A-End B-End

1Gbps

On Demand Self-Service Portal (or API)

M-MSP

Colt OSS/BSS

(Premise, XNG, …)

DC Enterprise Public Cloud

17

Ethernet on demand (definition)

Customer

DC Enterprise Public Cloud

SDN Enabled Network Layer

• Select locations
• Select ports
• Create, change (BW/Vlan),

cease Ethernet connection

• Real-time Provisioning

A-End B-End

1Gbps

On Demand Self-Service Portal (or API)

M-MSP

Colt OSS/BSS

(Premise, XNG, …)

DC Enterprise Public Cloud

18

Ethernet on demand (learnings)

 Product/sales innovation required (new commercial model)  Full leadership support a must  Equal priority to API and Portal/GUI  Agile development requires internal alignment & agreements  Commercial APIs (NB & SB) not 100% mature  IT development trade offs (java vs cloud)  Effective automation requires a clean inventory  OPS transformation is paramount

19

SD WAN on demand (enterprise challenges)

More Bandwidth Flexible Traffic Patterns Need to increase Agility

Bandwidth requirements increase by

20 – 30% per y ear

while

65% of WAN budgets

are Flat to Declining Implementing changes (portal driv en, not off-line process) A dding a new branch site (in hours, not weeks) Upgrading bandwidth (instantaneous, not days) Public Cloud impacts WA N traffic patterns

• WAN “break-out” to public Internet no more

centrally , but close touser, e.g. SalesForce traf fic at customer site

• Need f or Firewall

f unctionality and network-wide policy management

High WAN Costs

Which Portion of Your Network is the Most Expensiv e?

Cloud IaaS, PaaS, SaaS

20

SD WAN on demand (definition & benefits)

MPLS

QoS enabled

Branch site 1 Novitas CPE E.g. Salesforce Ethernet OLO (premium) MPLS VPN IPsec Tunnels Internet On-net site Data centre

Management SD WAN Controller

Premium Traffic

Internet Best Effort Traffic

Branch site 2 Novitas CPE Cloud

SD-MPLS GW

Customer portal Cost Delivered using competitively priced public Internet services, meaning only high priority traffic is routed across premium MPLS paths. Resilience Either network path (MPLS or Internet) can be used as backup in the event of a failure. Speed of delivery Using customer’s existing Internet Access enables a much quicker service deployment than OLO tails. Multi function CPE X86 architecture means that one CPE can act as a router, firewall, or application performance monitor via a single device.

MPLS WAN Public Internet MPLS WAN Enterprise / branch

• ffice site

Enterprise / branch

• ffice site

Public Internet

SD WAN

Colt SD WAN – Benefits at a glance

21

SD WAN on demand (learnings)

 Initial technical complexity (IPSEC/MPLS/BGP)  Not 100% technology maturity  Compute performance limitations  Self-Install / ZTP a must  Big change in the operating & development model  Strong customer demand (renewal requirement)

22

Packet SDN IQ Network (under deployment)

 Integrated Packet Network (Internet, IPVPN, EVPN)  MPLS to the edge with last mile CE  MPLS Segment Routing:

 Same LDP / RSVP-TE functionality, plus ..  higher scaling  improved FRR  SDN centralized control

 SDN controller for SR:

 path computation (PCE) for traffic steering (disjoint E2E, low latency, BWoD using live traffic analytics, custom paths) Core Metro Metro

L2 PE CPE PE P PE P PE PE PE P PE P L2 PE Customer CPE Customer

MPLS SR CE CE MPLS SR

MPLS SR

Service & Network Orchestration

SDN Controller

PCE / Topology / Resource Manager / Analytics CLI, NETCONF CLI, NETCONF SNMP, BGP-LS, PCEP SNMP, BGP-LS, PCEP SDN Controller NB API

23

NFV platform architecture (under planning)

 Tiered-Deployment Model  Tier 1 sites - OpenStack cloud  Tier 2 sites - virtualisation pods & BM  Customer sites – Colt x86 CPE  VIM – OpenStack & Virtualisation pods  Compute Hypervisor – KVM  Colt Standard Compute & Network  Evaluation  NFV Orchestrator  Generic VNF Manager  Network Virtulisation

Customer Sites Tier 2 sites Tier 1 sites Central Mgt.

OpenStack Cloud KVM VNFs OpenStack Cloud KVM VNFs OpenStack Cloud KVM VNFs OpenStack Cloud KVM VNFs KVM VNFs KVM VNFs

NFV - O Portal VNF MGR.

Bare Metal VNFs L2 CPE Bare Metal VNFs L2 CPE L2 CPE L2 CPE L2 CPE Colt x86 CPE L2 CPE L2 CPE Control Path CPE Data & Control Path

OSS BSS

Public Cloud VNFs Public Cloud VNFs VNFs VNFs VNFs VNFs Colt x86 CPE Colt x86 CPE Colt x86 CPE Colt x86 CPE Colt x86 CPE Colt x86 CPE VNFs VNFs VNFs

24

25

NFV platform use cases (under planning)

L2/L3 Packet Colt Integrated MPLS Core INTERNET (IPv4/IPv6)

MPLS VPN Customer

L2/L3 Packet

Tier 1Site Tier 1 / 2 Site Peering Transit

L2 CPE NFVI PE/P PE/P

SD WAN Hybrid Customer

Colt x86 CPE PR L2 PE L2 PE L2 PE L2 PE L3 CPE

ENNI OLO

L2/L3 Packet

Tier 1 / 2 Site

PE/P PE/P L2 PE L2 PE

SD WAN Customer

FlexVNF - SD WAN GW SD WAN Controller Local Management (Analytics & Syslog Collector) FlexVNF – vCPE, vFW, vLB, Filtering vBGP RR

NFVI

vFW vLB NAT vIDS vCPE vCPE

IPAoD Customer

NFVI

vPE/P vPR vFW NAT vLB vIDS vSBC

L2 CPE Colt x86 CPE

FlexVNF – vCPE, vFW, vLB, Filtering

Colt x86 CPE SFP L2 CPE x86 slot L2 CPE

Standard SDN/NFV NNI (under research)

 SDN NNI PoC (July 2016)

AT&T Network AT&T (New Jersey)

Colt London Beaufort House Colt Barcelona Colt Frankfurt

AT&T portal Novitas portal Novitas engine  Service Enquiry  Service Activation  Service modification (Bandwidth Flexing)  Service Cease Novitas SDN API calls SDN E-NNI

26

Standard SDN/NFV NNI (under research)

 SDN NNI PoC (July 2016)  SDN/NFV API standardization  MEF is the right Forum  MEF provides right framework (LSO)  TMForum provides the API background  Open industry collaboration: AT&T, Orange, Colt, Comcast, Level 3, Sparkle, PCCW, Verizon  8 API definitions in scope: Address validation, Service availability, Ordering, Quoting, Billing, Assurance, Testing and Change management

Backend

Access Ring

3rd-party Network

Colt Network

Node

NNI

3rd-party portal Novitas portal

OSS/BSS OSS/BSS

SDN/NFV Service Abstraction Layer

API Backend Colt SDN & NFV Controller 3rd-party SDN & NFV Controller API

VNF A VNF B

27

Optical SDN (under research)

 Objective: Fully disaggregated, software- controllable optical transport network (Photonic/WDM and -OTN)  Operator internal use cases  Service and network automation  Multi-vendor optical network (open line system, open ROADM)  Optical & packet multi-layer resource

• ptimization

 Customer use cases  Optical connectivity on-demand (Grey, colored and WDM/spectrum)  Optical VPN (p2p and mp2mp)  Route selection on-demand (centralized PCE engine)

Application Layer

Novitas Portal Novitas Engine

Control Layer

Customer Customer Colt OSS/BSS Novitas API Novitas API Novitas API

Optical Infrastructure Layer

Topology Path Computation Service Abstraction Resource Manager API API Open ROADM Control REST, RESTconf, NETCONF PCEP, BGP-LS, NETCONF, OVSDB, OTS, REST, OpenFlow, SNMP UI Colt delivery UI Programmable ROADM, flexible grid and GMPLS Super-channel, sliceable and SD modulation Flexible Ethernet Alien wave, open line system and open ROADM 28

Thankyou

For your time

29
