COLORADO CHAPTER ICC DENVER FIRE DEPARTMENT GASES AND THE FIRE CODE Carbon Dioxide (CO 2 ) and Inert Gas Awareness E61 Response Phoenix Fire McDonalds Phoenix, Arizona May 31st, 2011 2106 Hours Fall Injury Courtesy

slide-1
SLIDE 1

COLORADO CHAPTER ICC DENVER FIRE DEPARTMENT GASES AND THE FIRE CODE

slide-2
SLIDE 2

Carbon Dioxide (CO2) and Inert Gas Awareness

slide-3
SLIDE 3

E61 Response –Phoenix Fire

  • McDonalds
  • Phoenix, Arizona
  • May 31st, 2011
  • 2106 Hours
  • Fall Injury
  • 24 year old female
  • Pregnant Approximately 4

Months

  • Complaining Of Pain All

Over

Courtesy Phoenix Fire Courtesy Phoenix Fire

slide-4
SLIDE 4

E61 Response –Phoenix Fire

  • Patient is

– Confused – Unable to Effectively Communicate – Distraught – Dizzy – Pregnant Approximately 4 Months – Complaining Of Pain All Over

Courtesy Phoenix Fire

slide-5
SLIDE 5

E61 Response –Phoenix Fire

  • Video:

– https://www.youtube.com/watch?v=eY__H-CMvw0

slide-6
SLIDE 6

Who has these CO2tanks???

Courtesy Phoenix Fire

slide-7
SLIDE 7

What is Carbon Dioxide (CO2)?

  • Molecular Formula: CO2 (Not to be confused

with Carbon Monoxide (CO)

  • Specific Gravity (SG)/Vapor Density: 1.53

times heavier than air (SG = 1)

  • Appearance: Colorless
  • Odor: Odorless but with a slightly pungent
  • dor and biting or acidic taste may be noticed

at high concentrations

  • Always present around 400 ppm in our

atmosphere

  • The second most widely delivered and used

compressed gas after Oxygen – Very Common

slide-8
SLIDE 8

Effects of Carbon Dioxide (CO2)?

  • A toxic gas often referred to mistakenly as only a simple

asphyxiant

  • CO2 can kill in two ways: Either by displacing Oxygen

(O2) or as a toxin in its own right

  • Target Organs: Respiratory system; central nervous

system; heart

  • Acceptable levels less than 600 ppm
  • General drowsiness at 1,000 – 2,500 ppm
  • Adverse health effects expected at 2,500 – 5,000 ppm
  • Slightly intoxicating, breathing and pulse rate increase,

nausea at 30,000 ppm

  • Headaches and sight impairment at 50,000 ppm
  • Unconscious at 100,000 ppm
slide-9
SLIDE 9

Carbon Dioxide (CO2) Awareness

slide-10
SLIDE 10

How did we get here today?

  • Historically gas cylinders
  • f CO2 were filled at the

gas distributors’ facility

  • Approximately 20 years

ago the beverage industry developed a system to fill larger storage vessels on-site

slide-11
SLIDE 11

Where does the CO2leak?

  • Improperly vented to the outside of

the building

  • Leaking fittings, connections,

piping/tubing/hoses, or storage container plumbing

  • Leaking carbonators, syrup pumps, bag

in box (BIB) racks, etc.

  • Leaking beer keg connections and

equipment

slide-12
SLIDE 12

Reported incidents of CO2 leaks

  • November 2012 – Evacuation of a restaurant in

Brentwood Borough Pennsylvania. Patient complained of dizziness

  • September 2011 – Ten people hospitalized,

including two firefighters, and one fatality at a fast food restaurant in Pooler, Georgia

  • June 2011 – Evacuation of a fast food restaurant

in Dorchester, United Kingdom

  • May 2011 – Three hospitalized, including two

firefighters, at a fast food restaurant in Phoenix, Arizona

slide-13
SLIDE 13

Morereported incidents of CO2 leaks

  • May 2010 – Evacuation of a movie theater in Des

Moines, Iowa

  • July 2008 – Two hospitalized from an incident in

a bar in Benson, Nebraska

  • April 2008 – One fatality in a hotel in Victoria,

Australia

  • August 2007 – Fatality of a waiter at a restaurant

in Coronado, California

slide-14
SLIDE 14

Morereported incidents of CO2 leaks

  • January 2005 – Two fatalities, employee and

delivery driver, outside a fast food restaurant in Sanford, Florida

  • March 1998 – Two hospitalized and two

treated at the scene at a fast food restaurant in the U.S. (location unknown)

  • 1996 – Fatality of a delivery driver outside a

restaurant in Cincinnati, Ohio

slide-15
SLIDE 15

Carbon Dioxide (CO2) Awareness

slide-16
SLIDE 16

Carbon Dioxide (CO2) Awareness

NEW!!! 2015 IFC Section 5307 Carbon Dioxide (CO2) Systems Used In Beverage Dispensing Applications SO WHA T’S THE BIG DEAL? IT IS A BIG DEAL –PEOPLE DIE!!

slide-17
SLIDE 17

Carbon Dioxide (CO2) Awareness

  • Denver Amended Section 5307

– Too General – Not Specific Enough – Input from gas industry – Input from Beverage and Restaurant Associations – Public meetings

slide-18
SLIDE 18

WHA T IS REGULA TED?

  • Systems with more than 100 pounds of CO2
  • Equipment including tanks, cylinders,

piping, tubing, fittings, valves

  • Automatic system shut-off valve(s)
  • Venting
  • Mechanical ventilation
  • Emergency alarm CO2 gas detection system
  • Warning Signage

Carbon Dioxide (CO2) Awareness

slide-19
SLIDE 19

WHA T IS REGULA TED?

Carbon Dioxide (CO2) Awareness

  • Filling CO2 gases
  • Permits
  • Inspections and testing
  • Daily, monthly, semi-annually, and

annually testing

  • Records
  • Training of all employees
slide-20
SLIDE 20

Carbon Dioxide (CO2) Awareness

Typical Restaurant

slide-21
SLIDE 21

Carbon Dioxide (CO2) Awareness

Typical Restaurant (McDonalds)

slide-22
SLIDE 22

Carbon Dioxide (CO2) Awareness

Typical Restaurant (Below grade)

slide-23
SLIDE 23

Who else has these CO2tanks???

  • Swimming pools
  • Agriculture grow rooms
  • Breweries / wine rooms
  • Sporting events
  • Concerts
  • Night clubs
  • Movie theatres
  • Others
slide-24
SLIDE 24

Carbon Dioxide (CO2) Awareness

Swimming Pools for PhBalancing

slide-25
SLIDE 25

Carbon Dioxide (CO2) Awareness

  • Section 5310 Carbon dioxide (CO2) gas

enrichment systems using on-site supply tanks

Agriculture Grow Rooms

slide-26
SLIDE 26

Carbon Dioxide (CO2) Awareness

Agriculture Grow Rooms

slide-27
SLIDE 27

Carbon Dioxide (CO2) Awareness

Breweries / Wine Rooms

  • Carbon Dioxide (CO2) and Nitrogen (N2) gases are

used in beer dispensing

  • Nitrogen is:

 inert gas (typically non-reactive)  simple asphyxiant  Displaces oxygen  It is not a toxic gas at high concentrations like Carbon Dioxide

slide-28
SLIDE 28

Carbon Dioxide (CO2) Awareness

Breweries / Wine Rooms (Pepsi Center)

slide-29
SLIDE 29

Carbon Dioxide (CO2) Awareness

Breweries / Wine Rooms (Pepsi Center)

slide-30
SLIDE 30

Carbon Dioxide (CO2) Awareness

Breweries / Wine Rooms

slide-31
SLIDE 31

Carbon Dioxide (CO2) Awareness

Breweries / Wine Rooms

slide-32
SLIDE 32

Carbon Dioxide (CO2) Awareness

Breweries / Wine Rooms

slide-33
SLIDE 33

Carbon Dioxide (CO2) Awareness

Breweries / Wine Rooms

slide-34
SLIDE 34

Carbon Dioxide (CO2) Awareness

Concerts and Sporting Events

slide-35
SLIDE 35

Inert Gas Awareness

  • Section 5309 Inert Gas Systems Used In

Commercial, Manufacturing or Industrial Applicatons

– pH Balancing – Food Processing – Laboratories – Medical Equipment (MRI) – Medical Treatment – Others

slide-36
SLIDE 36

Inert Gas Awareness

  • Section 5309 Inert Gas Systems versus

Section 5307 Carbon Dioxide (CO2) Systems

– Section 5307 is for Carbon Dioxide (CO2) only – Section 5309 is for all other inert gases – If CO2 is used for a non-beverage dispensing use, section 5309 refers back to 5307 – CO2 detection versus Oxygen detection

slide-37
SLIDE 37

Inert Gas Awareness

Cryogenic Gas Therapy

slide-38
SLIDE 38

Inert Gas Awareness

New CryoSpa at Pepsi Center

slide-39
SLIDE 39

Inert Gas Awareness

New CryoSpa at Pepsi Center

slide-40
SLIDE 40

Inert Gas Awareness

CryoSpa Therapy

slide-41
SLIDE 41

Inert Gas Awareness

  • Section 1107 Requirements For Existing

Compressed Gas Systems

– Section 1107.1 Compressed gas systems. Effective January 1, 2018, existing compressed gas systems located within existing buildings shall be retrofitted and modified in accordance with Sections 1107.1.1 through 1107.1.4.

slide-42
SLIDE 42

Inert Gas Awareness

  • Section 1107.1.1 Carbon dioxide (CO2) systems

used in beverage dispensing applications. Existing carbon dioxide (CO2) systems used in beverage dispensing applications shall comply with Section 5307.

  • Section 1107.1.2 Inert gas systems used in

commercial, manufacturing or industrial

  • applications. Existing inert gas systems used in

commercial, manufacturing or industrial applications shall comply with Section 5309.

slide-43
SLIDE 43

Inert Gas Awareness

  • Section 1107.1.3 Carbon dioxide (CO2) gas

enrichment systems using on-site supply tanks and/or cylinders in plant growing (husbandry) applications. Existing carbon dioxide (CO2) gas enrichment systems using on-site supply tanks and/or cylinders in plant growing (husbandry) applications shall comply with Section 5310.

  • Section 1107.1.4 Carbon dioxide (CO2) gas

enrichment systems using a natural gas burner in plant growing (husbandry) applications. Existing carbon dioxide (CO2) gas enrichment systems using a natural gas burner in plant growing (husbandry) applications shall comply with Section 5311.

slide-44
SLIDE 44

Inert Gas Awareness

  • Challenges

– Implementation – Drawing submittals for new and existing – What type of permit to issue? – Inspections? By Whom? Building, Fire or both? – Enforcement?

slide-45
SLIDE 45

Questions??

Contact Information www.denvergov.org J.D. Lanz Office: 720-865-2952 James.Lanz@denvergov.org Brad Emerick Office: 720-865-2964 Brad.Emerick@denvergov.org

Thank you!
