Collection of Statistical Data on Single Vehicle Incidents Robust. GRD1-2002-70021 Method of Approach and Work 1 completed Presented by Gavin Williams, TRL, UK APPROACH APPROACH APPROACH APPROACH Scoping study distributed in early

SLIDE 1

Robust. GRD1-2002-70021

1

Collection of Statistical Data on Single Vehicle Incidents Method of Approach and Work completed Presented by Gavin Williams, TRL, UK

SLIDE 2

Robust. GRD1-2002-70021

2

APPROACH APPROACH APPROACH APPROACH

Scoping study distributed in early

April 2004

Replies received from:

– Norwegian Public Roads Administration (NPRA), Norway – Politechnico di Milano, Italy – Autostrade, Italy – Centre for Automotive Research and Development (CIDAUT), Spain – European Union Road Federation (ERF), Belgium – Volkmann & Rossbach Gmbh & Co., Germany

SLIDE 3

Robust. GRD1-2002-70021

3

APPROACH APPROACH APPROACH APPROACH

Two documents were distributed in

early May 2004 for the collection of incident data:

– A Table (for completion) – Guidance for completing the Table (for continuity)

Coding used to aid analysis
Different driving legislation
Incident data for:
Single vehicle incidents
Incidents on ALL roads
Incidents in which a VRS has been hit
Only incidents FROM 1st Jan 1990

SLIDE 4

Robust. GRD1-2002-70021

4

DATA COLLECTION TABLE DATA COLLECTION TABLE DATA COLLECTION TABLE DATA COLLECTION TABLE

General incident information

(date, road type, speed limit)

Details of the vehicle (make,

model, weight)

Movement and damage to the

vehicle

Severity and location of injury to

the occupant(s)

Type of VRS
Impact speed and angle
Data source(s)

SLIDE 5

Robust. GRD1-2002-70021

5

RESULTS RESULTS RESULTS RESULTS

TWO main contributions:

– TRL TRL TRL TRL

(23,313 incidents - basic data, 1990-02)

– Politecnico di Milano Politecnico di Milano Politecnico di Milano Politecnico di Milano

(70 incidents - very detailed data, 2000-03)

The results of the analysis and subsequent conclusions are therefore based only on the two sets of data provided from the UK and Italy

SLIDE 6

Robust. GRD1-2002-70021

6

TRL DATA (1990 TRL DATA (1990 TRL DATA (1990 TRL DATA (1990-

2000)

2000) 2000) 2000)

Total Number of UK Incidents 1990 to 2000 – 2,815,900 Incidents relevant to the ROBUST Project - 23,313 (48%)

(0.8% of total UK incidents) incidents not relevant to the ROBUST Project - 24,933 (52%) incidents involving a VRS - 48,246 (1.7%)

SLIDE 7

Robust. GRD1-2002-70021

7

TRL DATA (1990 TRL DATA (1990 TRL DATA (1990 TRL DATA (1990-

2000)

2000) 2000) 2000)

Incidents Severity:

1. All UK Incidents

‘ROBUST’ Incidents

2. All UK VRS Incidents

SLIDE 8

Robust. GRD1-2002-70021

8

TRL DATA (1990 TRL DATA (1990 TRL DATA (1990 TRL DATA (1990-

2000)

2000) 2000) 2000)

Vehicle Movement:

– Vehicle Left the Carriageway to the right: 47.6% – Vehicle Left the Carriageway to the left: 40.7%

Road Type:

– Dual Carriageway 3+ lanes: 36.3% – Dual Carriageway 2 lanes: 38.16%

SLIDE 9

Robust. GRD1-2002-70021

9

1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000 13000 14000 15000 25kph 30kph 50kph 65kph 80kph 100kph 110kph Number of Accidents Fatal Serious Slight

TRL DATA (1990 TRL DATA (1990 TRL DATA (1990 TRL DATA (1990-

2000)

2000) 2000) 2000)

Location of VRS Incidents (by speed of road)

SLIDE 10

Robust. GRD1-2002-70021

10

Car 80% Motorcycle 6% Other motor vehicle 1% Goods vehicle 12% Agricultural vehicle 0% Minibus 1% Bus or coach 0% MPV or SUV 0%

TRL DATA (1990 TRL DATA (1990 TRL DATA (1990 TRL DATA (1990-

2000)

2000) 2000) 2000)

Type of Vehicle involved in the incident

SLIDE 11

Robust. GRD1-2002-70021

11

TRL DATA (1990 TRL DATA (1990 TRL DATA (1990 TRL DATA (1990-

2000)

2000) 2000) 2000)

Severity of Motorcycle/VRS incidents

Fatal 10% Serious 47% Slight 43%

Fatal 3% Serious 18% Slight 79%

Severity of all VRS incidents

SLIDE 12

Robust. GRD1-2002-70021

12

1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000 13000 14000 15000 16000 17000 18000 1 2 3 4 5 6 7 8 9 10 11 Fatal Serious Slight

Average of 1.37 casualties per incident

TRL DATA (1990 TRL DATA (1990 TRL DATA (1990 TRL DATA (1990-

2000)

2000) 2000) 2000)

Number of Casualties per Incident

SLIDE 13

Robust. GRD1-2002-70021

13

PDM DATA (2000 PDM DATA (2000 PDM DATA (2000 PDM DATA (2000-

2003)

2003) 2003) 2003)

Motorcycle 15% Unknown 4% Car 81%

Total Number of Detailed Data Sets: 70

SLIDE 14

Robust. GRD1-2002-70021

14

PDM DATA (2000 PDM DATA (2000 PDM DATA (2000 PDM DATA (2000-

2003)

2003) 2003) 2003)

59 (100%) TOTAL

14 (24%)

Not recorded 100% 2 (3%) 1576 – 1890 50% 2 (3%) 1425 – 1575

1366 – 1424

67% 6 (10%) 1235 – 1365 65% 17 (29%) 941 – 1234 86% 7 (12%) 860 – 940 45% 11 (19%) 735 – 859 % age less than 5 years old Number of Incidents Car Weight (kgs) EN1317-1 Vehicle Weight Requirement 15 Incidents within current EN1317-1 requirements 30 Incidents outside current EN1317-1 requirements

SLIDE 15

Robust. GRD1-2002-70021

15

1 2 3 4 5 6 7 8 9 10 11 0-1 1-2 2-3 3-4 4-5 5-6 6-7 7-8 8-9 9-10 10+

PDM DATA (2000 PDM DATA (2000 PDM DATA (2000 PDM DATA (2000-

2003)

2003) 2003) 2003)

Age of the Vehicle at the Time of the Incident

SLIDE 16

Robust. GRD1-2002-70021

16

On, 4 Off, 7 Unknown, 4 Serious, 44 Slight, 29 Unknown, 6 Fatal, 15

Seat Belt Use - Total

PDM DATA (2000 PDM DATA (2000 PDM DATA (2000 PDM DATA (2000-

2003)

2003) 2003) 2003)

SLIDE 17

Robust. GRD1-2002-70021

17

PDM DATA (2000 PDM DATA (2000 PDM DATA (2000 PDM DATA (2000-

2003)

2003) 2003) 2003)

SLIDE 18

Robust. GRD1-2002-70021

18

RECOMMENDATIONS RECOMMENDATIONS RECOMMENDATIONS RECOMMENDATIONS

For all impact testing with cars, an impact

speed of 110kph is recommended for all testing;

The impact angle for cars remains at twenty

degrees;

The number of registered motorcycles be

recorded, and the occurrence of such incidents analysed in future years;

It is recommended that the weight specified

for the small car test (currently referred to as TB11) should be changed so as to be 950±50kg;

SLIDE 19

Robust. GRD1-2002-70021

19

RECOMMENDATIONS RECOMMENDATIONS RECOMMENDATIONS RECOMMENDATIONS

It is recommended that the vehicles used for

the testing of VRS are no more than 5 years old;

The data have shown that one dummy (either

instrumented or un-instrumented) should be seated in the vehicle during all testing between cars and VRS;

It is further recommended that the dummy

should be placed on the driver’s side of the vehicle;

It is recommended that, any dummy installed in

a vehicle during VRS testing should be restrained by a seat belt.

SLIDE 20

Robust. GRD1-2002-70021

20

RECOMMENDATIONS RECOMMENDATIONS RECOMMENDATIONS RECOMMENDATIONS

An additional task has examined incidents
ccurring on UK roads;
It has been found that there is little

information currently collected regarding the VRS at incident scenes;

It is recommended that this information is
