Recent Advances and What’s Next?

Coflow

Mosharaf Chowdhury University of Michigan

Datacenter-Scale Computing Geo-Distributed Computing

Fast Analytics Over the WAN

Rack-Scale Computing

Proactive Analytics Before You Think! Coflow Networking

Open Source

Apache Spark

Open Source

Cluster File System

Facebook

Resource Allocation

Microsoft

DAG Scheduling

Apache YARN

Cluster Caching

Alluxio

Datacenter-Scale Computing Geo-Distributed Computing Rack-Scale Computing

< 0.01 ms ~ 1 ms > 100 ms

Big Data

The volume of data businesses want to make sense of is increasing Increasing variety of sources

• Web, mobile, wearables, vehicles, scientific, …

Cheaper disks, SSDs, and memory Stalling processor speeds

Big Datacenters for Massive Parallelism

2005 2010 2015 MapReduce Hadoop Spark Hive Dryad DryadLINQ Spark-Streaming GraphX GraphLab Pregel Storm Dremel BlinkDB

• 1. Resilient Distributed Datasets: A Fault-Tolerant Abstraction for In-Memory Cluster Computing, NSDI’2012.

Distributed Data-Parallel Applications

Multi-stage dataflow

• Computation interleaved with communication

Computation Stage (e.g., Map, Reduce)

• Distributed across many machines
• Tasks run in parallel

Communication Stage (e.g., Shuffle)

• Between successive computation stages

Map Stage Reduce Stage

A communication stage cannot complete until all the data have been transferred

Communication is Crucial Performance

As SSD-based and in-memory systems proliferate, the network is likely to become the primary bottleneck

• 1. Based on a month-long trace with 320,000 jobs and 150 Million tasks, collected from a 3000-machine Facebook production MapReduce cluster.

Facebook jobs spend ~25% of runtime on average in intermediate comm.1

Faster Communication Stages: Traditional Networking Approach

Flow

Transfers data from a source to a destination Independent unit of allocation, sharing, load balancing, and/or prioritization

Existing Solutions

GPS RED WFQ CSFQ ECN XCP D2TCP DCTCP PDQ D3 FCP DeTail pFabric 2005 2010 2015 1980s 1990s 2000s RCP

Per-Flow Fairness Flow Completion Time

Independent flows cannot capture the collective communication behavior common in data-parallel applications

Datacenter Fabric

1 2 3 1 2 3

Why Do They Fall Short?

r1 r2 s1 s2 s3 r1 r2 s1 s2 s3

Input Links Output Links

Why Do They Fall Short?

r1 r2 s1 s2 s3 r1 r2 s1 s2 s3

Datacenter Fabric

1 2 3 1 2 3

r1 r2 s1 s2 s3

Why Do They Fall Short?

Datacenter Fabric

time

2 4 6

Link to r2 Link to r1 Per-Flow Fair Sharing Shuffle Completion Time = 5

• Avg. Flow

Completion Time = 3.66

3 3 5 3 3 5

s1 s2 s3 r1 r2

1 2 3 1 2 3

Solutions focusing on flow completion time cannot further decrease the shuffle completion time

Improve Application-Level Performance1

Datacenter Fabric

time

2 4 6

Link to r2 Link to r1 Per-Flow Fair Sharing Shuffle Completion Time = 5

• Avg. Flow

Completion Time = 3.66

3 3 5 3 3 5

s1 s2 s3 r1 r2

1 2 3 1 2 3

• 1. Managing Data

Transfers in Computer Clusters with Orchestra, SIGCOMM’2011.

Slow down faster flows to accelerate slower flows

time

2 4 6

Link to r2 Link to r1 Per-Flow Fair Sharing Shuffle Completion Time = 4

• Avg. Flow

Completion Time = 4

4 4 4 4 4 4

Data-Proportional Allocation

Communication abstraction for data-parallel applications to express their performance goals

Coflow

• 1. Size of each flow;
• 2. Total number of flows;
• 3. Endpoints of individual flows;
• 4. Dependencies between coflows;

Aggregation Broadcast Shuffle Parallel Flows All-to-All Single Flow

How to schedule coflows

• nline …

… for faster #1 completion

• f coflows?

… to meet #2 more deadlines? … for fair #3 allocation of the network?

1 2 N 1 2 N

. . . . . .

Datacenter

Varys, Aalo & HUG

• 1. Coflow Scheduler

Faster, application-aware data transfers throughout the network

• 2. Global Coordination

Consistent calculation and enforcement of scheduler decisions

• 3. The Coflow API

Decouples network optimizations from applications, relieving developers and end users

• 1. Efficient Coflow Scheduling with

Varys, SIGCOMM’2014.

• 2. Efficient Coflow Scheduling

Without Prior Knowledge, SIGCOMM’2015.

• 3. HUG: Multi-Resource Fairness for Correlated and Elastic Demands, NSDI’2016.

1 2 3

Benefits of

time

time

time

Coflow1 comp. time = 5 Coflow2 comp. time = 6 Coflow1 comp. time = 5 Coflow2 comp. time = 6 Fair Sharing Smallest-Flow First1,2 The Optimal Coflow1 comp. time = 3 Coflow2 comp. time = 6 L1 L2 L1 L2 L1 L2

• 1. Finishing Flows Quickly with Preemptive Scheduling, SIGCOMM’2012.
• 2. pFabric: Minimal Near-Optimal Datacenter Transport, SIGCOMM’2013.

Link 1 Link 2 3 Units Coflow 1 6 Units Coflow 2 2 Units

Inter-Coflow Scheduling

Inter-Coflow Scheduling

1 2 3 1 2 3 Input Links Output Links Datacenter

Concurrent Open Shop Scheduling with Coupled Resources

• Examples include job scheduling and

caching blocks

• Solutions use a ordering heuristic
• Consider matching constraints

Link 1 Link 2 3 Units Coflow 1 6 Units Coflow 2 2 Units

3 6 2

is NP-Hard

Many Problems to Solve

Aalo Varys

Clairvoyant Objective

HUG

Min CCT Min CCT Fair CCT Yes No No Optimal Yes No No

Coflow-Based Architecture

Centralized master-slave architecture

• Applications use a client library to

communicate with the master

Actual timing and rates are determined by the coflow scheduler

Master/Coordinator

Network Interface f Computation tasks

Local Daemon Local Daemon Local Daemon

Coordination

Coflow Scheduler

• 1. CODA:

Toward Automatically Identifying and Scheduling Coflows in the Dark, SIGCOMM’2016.

Coflow API

Change the applications

• At the very least, we need to know

what a coflow is

• For clairvoyant versions, we need

more information

Changing the framework can enabled ALL jobs to take advantage

• f coflows

DO NOT change the applications1

• Infer coflows from traffic network

traffic patterns

• Design robust coflow scheduler that

can tolerate misestimations

Our current solution only works for coflows without dependencies; we need DAG support!

Performance Benefits of Using Coflows

• 1. Managing Data

Transfers in Computer Clusters with Orchestra, SIGCOMM’2011

• 2. Finishing Flows Quickly with Preemptive Scheduling, SIGCOMM’2012
• 3. pFabric: Minimal Near-Optimal Datacenter

Transport, SIGCOMM’2013

• 4. Decentralized

Task-Aware Scheduling for Data Center Networks, SIGCOMM’2014 1.00 3.21 5.65 5.53 22.07 1.10 5 10 15 20 25 Varys Fair FIFO Priority FIFO-LM NC

Overhead Over Varys

Varys Aalo

Per-Flow Fairness Per-Flow Prioritization

Lower is Better

The Need for Coordination

8 17 115 495 992 1 10 100 1000 100 1000 10000 50000 100000

Average Coordination Time (ms) # (Emulated) Aalo Slaves

Coordination is necessary to determine realtime

• Coflow size (sum);
• Coflow rates (max);
• Partial order of coflows (ordering);

Can be a large source of overhead

• Does not impact too much for large

coflows in slow networks, but …

How to perform decentralized coflow scheduling?

Coflow-Aware Load Balancing

Especially useful in asymmetric topologies

• For example, in the presence of switch or link failures

Provides an additional degree of freedom

• During path selection
• For dynamically determining load balancing granularity

Increased need for coordination, but at an even higher cost

Coflow-Aware Routing

Relevant in topologies w/o full bisection bandwidth

• When topologies have temporary in-network oversubscriptions
• In geo-distributed analytics

Scheduling-only solutions do not work well

• Calls for routing-scheduling joint solutions
• Must take network utilization into account
• Must avoid frequent path changes

Increased need for coordination

Coflows in Circuit-Switched Networks

Circuit switching is relevant again due to the rise of optical networks

• Provides very high bandwidth
• Expensive to setup new circuits

Co-scheduling applications and coflows

• Schedule tasks so that we can reuse already-setup circuits
• Perform in-network aggregation using existing circuits instead of waiting for new

circuits to be created

Extension to Multiple Resources1

A DAG of coflows is very similar to a job DAG of stages

• Same principle applies, but with new

challenges

Consider both fungible (b/w) and non-fungible resources (cores)

• Across the entire DAG
• 1. Altruistic Scheduling in Multi-Resource Clusters, OSDI2016.

Communication abstraction for data-parallel applications to express their performance goals

Coflow

Key open challenges

1. Better theoretical understanding 2. Efficient solutions to deal with decentralization, topologies, multi-resource settings, estimations over DAG, circuit-switching, etc.

More information

1. Papers: http://www.mosharaf.com/publications/ 2. Software/simulator/workloads: https://github.com/coflow
