CO444H Administrivia Overview of the Material Ben Livshits Two - - PowerPoint PPT Presentation

Course Staff Administrivia Overview of the Material

CO444H

Ben Livshits

Two Primary Goals We Pursue

Optimisations

• Make programs run faster
• We will see some

traditional “old-school”

• ptimisations
• We will see some that are

based on parallelism

• We will see some runtime
• ptimisations

Reliability

• Find bugs before they

make it into production

• Find security flaws

before they are exploited by hackers

• Help developers

produce better code

2

Aren’t Compilers a Solved Problem?

“Optimization for scalar machines is a problem that was solved ten years ago.”

• -David Kuck, 1990, Professor at UIUC
• Architectures keep changing (ARM and Qualcomm

Snapdragon are popular processors/architectures)

• Languages keep changing (think about compiling

JavaScript)

• Applications keep changing, (i.e. Android apps)
• When to compile keeps changing, i.e. JIT (just-in-time

compilation)

3

What You Will Learn

• Methodology of

compiler development

• Theoretical framework
• Key algorithms
• Hands-on experience
• Practical trade-offs
• Compiler optimisations
• Reliability tools
• Extracting parallelism
• Inner working of

runtimes

4

Nongoal: build a complete optimizing compiler

Why Is This Useful and Important

• Software developers

interact with compilers

• daily. Understanding

how the process of transforming a (static) program into (runtime) execution simply makes you a better developer

• Knowing how to build such

tools gives you an extra edge in development

• Knowing how optimisations

work gives you the ability to harness the compiler to its full extent

• Unlocking parallelism leads

to significant performance improvements on today’s architectures

5

Studying Compilers Changes Your Mindset

• Excellent software-

engineering example – theory meets practice: need to understand the math and also create real systems

• You start thinking about

software/hardware interactions a lot more

• Compilers are

everywhere: An essential way of thinking about software

• development. For

example, consider DSLs for boosting developer productivity for databases, graphics, networking, bio- computation, IoT, etc.

6

Finding Bugs with FB Infer

7

Requires Pretty Deep Code Analysis

• Can be shallow, i.e.

syntactic matching such as grep

• Can be intraprocedural

– perform analysis within a single procedure

• Can be a little deeper,

interprocedural

• What are some of the

concerns in building such an analysis?

8

Surprising Applications

• f Compilers: PrePose
• Programming games is painful
• Part of this is because games require gestures to

be defined

• Today, gesture definition is a pain process, like the

punch gesture shown on the right in C++

// Punch Gesture if ( vHandPos.z – vShoulderPos.z > fThreshold1 && fVelocityOfHand > fThreshold2 || fVelocityOfElbow > fThreshold3 && DotProduct( vUpperArm, vLowerArm) > fThreshold4 ) { bDetect = TRUE; }

9

PrePose – a Language for gesture-based Programming

10

Ballet Gestures in PrePose

11

Encoding Tai Chi Gestures

12

IKEA Furniture Assembly Programming

• Provide instructions

for the furniture assembler in a specialized, domain- specific language

• Generate manuals

containing pictures and text in multiple languages

• Generate an

assembly plan for a specialized robot

13

Compilers are everywhere: An essential way of thinking about software development

14

Administrative Matters

15

Course Staff

• Professor:
• Dr. Ben Livshits (Reader in Computing)
• TA’s:
• Anastasios Andronidis
• Course page – everything will be here:

https://www.doc.ic.ac.uk/~livshits/classes/CO444H

16

Course Requirements

Requirements

• It is generally assumed that

you have taken beginner Compilers CO221

• Come talk to me if you have

questions

• You should be quite

comfortable programming in Java and ideally Python

• r C++

Workload

• Two (programming)

assignments

• Some tutorials
• Exam

17

Course Resources: Slides + …

18

COMPILERS: PRINCIPLES TECHNIQUES AND TOOLS, second edition, 2013

Dragon Book (Ch. 1 — 5) (previous class)

• Chapter 1 contains

motivational materials

• Chapter 2 develops a

miniature compiler

• Chapter 3 covers lexical

analysis, regular expressions, finite-state machines, and scanner- generator tools

• Chapter 4 covers the major

parsing methods, top-down (recursive-descent, LL) and bottom-up (LR and its variants).

• Chapter 5 introduces the

principal ideas in syntax- directed definitions and syntax-directed translations.

19

Dragon Book (Ch. 6 — 9)

• Chapter 6 takes the theory
• f Chapter 5 and shows

how to use it to generate intermediate code for a typical programming language.

• Chapter 7 covers run-time

environments, especially management of the run- time stack and garbage collection.

• Chapter 8 is on object-code
• generation. It covers

construction of basic blocks, generation of code from expressions and basic blocks, and register- allocation techniques.

• Chapter 9 covers flow

graphs, data-flow frameworks, and iterative algorithms

20

Dragon Book (Ch. 10 — 12)

• Chapter 10 covers

instruction-level

• ptimization. The emphasis

is on the extraction of parallelism from small sequences of instructions and scheduling them on single processors that can do more than one thing at

• nce.
• Chapter 11 talks about

larger-scale parallelism detection and exploitation.

• Chapter 12 is on

interprocedural analysis. It covers pointer analysis, aliasing, and call graph construction, etc.

21

Compiler Organisation

22

Language 1 source Language 2 source

Lexical analyzer (scanner) Syntax/semantic analyzer (parser) Intermediate code generator Lexical analyzer (scanner) Syntax/semantic analyzer (parser) Intermediate code generator Intermediate code

• ptimizer and analyzer

Target 1 code generator Target 2 code generator

Program Machine code

Structural inlining loop unrolling loop perm Scalar CSE constants expressions Memory scalar repl ptrs Register allocation Scheduling peephole

Analysis Flavours

Scope of program analysis

• within a basic block (local) – start here
• within a method (global)
• across methods (interprocedural)

Analysis types we will consider…

23

control flow graph dominators, loops, etc. dataflow analysis flow of values static-single-assignment transform programs such that each variable has a unique definition alias analysis pointer memory usage dependence analysis parallelism

Break…

24

Some of the Basics

Flow Graphs Constant Folding Global Common Subexpressions Induction Variables/Reduction in Strength

25

Intermediate Code

for (i=0; i<n; i++) { A[i] = 1; }

• Intermediate code

exposes optimizable constructs we cannot see at the source-code level

• General idea
• Lowering passes
• Start with a high-level

program

• Translate it into levels of

intermediate representation (IR)

• Often, the next level of

IR will be lower level and will enable new analysis opportunities

26

Basic Blocks in a Control Flow Graph (CFG)

• Make program control

flow explicit by breaking into basic blocks

• What are basic blocks?
• Sequences of

instructions with entry at beginning, exit at end.

27

i = 0 if i>=n goto … t1 = 8*i A[t1] = 1 i = i+1

28

Induction Variables

• x is an induction variable in a loop if it takes on a linear

sequence of values each time through the loop.

• Common case: loop index like i and computed array

index like t1

• Eliminate “superfluous” induction variables
• Replace multiplication by addition (reduction in

strength)

29

Example of Induction Variables

i = 0 if i>=n goto … t1 = 8*i A[t1] = 1 i = i+1 t1 = 0 n1 = 8*n if t1>=n1 goto … A[t1] = 1 t1 = t1+8

30

Loop-Invariant Code Motion

• Sometimes, a computation is done each time

around a loop

• Move it before the loop to save n-1 computations.
• Be careful: could n=0?
• i.e., the loop is typically executed 0 times

31

Example of Loop-Invariant Code Motion

i = 0 if i>=n goto … t1 = y+z x = x+t1 i = i+1 i = 0 t1 = y+z if i>=n goto … x = x+t1 i = i+1

32

Constant Folding

• Sometimes a variable has a known

constant value at a point

• If so, replacing the variable by the

constant simplifies and speeds-up the code.

• Easy within a basic block; harder across

blocks

33

Example of Constant Folding

i = 0 n = 100 if i>=n goto … t1 = 8*i A[t1] = 1 i = i+1 t1 = 0 if t1>=800 goto … A[t1] = 1 t1 = t1+8

Global Common Subexpressions

• Suppose basic block B has a computation of x+y
• Suppose we are sure that when we reach this

computation, we are sure to have:

1. Computed x+y, and 2. Not subsequently reassigned x or y

• Then we can hold the value of x+y and use it in B

34

35

Example of Global Common Subexpression Elimination

a = x+y b = x+y c = x+y t = x+y a = t t = x+y b = t c = t

36

Example of CSE – Even Better

t = x+y a = t t = x+y b = t c = t t = x+y a = t b = t c = t t = x+y b = t

Q&A on the Optimisations Above

• Can we sometimes lose optimisation opportunities as a

result of lowering IR?

• Is it trivial to decide which basic blocks to connect to each
• ther?
• Can the optimisations we described above reduce the

performance?

• Can optimisations take more time to perform than they

save?

37
