Call Graphs

• Class analysis:
• Given a reference variable x, what are the classes of the
• bjects that x refers to at runtime?
• We saw CHA and RTA
• Deal with polymorphic/virtual calls: x.m()
• Compilers: can we devirtualize a virtual call x.m()?
• Software engineering:
• Construct the call graph of the program
• Why is that important in everyday development?

Features of RTA

• RTA may evaluate a method several times
• If new callers are discovered the method has

to be re-evaluated

• RTA runs until the worklist is empty, at which

point it has reached a fixed point and cannot resolve any new call edges to add to the call graph

3

RTA Revisited

RAPID TYPE ANALYSIS RTA = call graph of only methods (no edges) CHA = class hierarchy analysis call graph W = worklist containing the main method while W is not empty M = next method in W T = set of allocated types in M T = T U {allocated types in RTA callers of M} for each callsite (C) in M if C is a static dispatch or constructor: add an edge to statically resolved method

• therwise:

M' = methods called from M in CHA M' = M' intersection {methods declared in T or supertypes of T} add an edge from the method M to each method in M' add each method in M' to worklist W

4

Using RTA in Eclipse

5

RTA May Be Unsound

public static void main(String[] args){ Object o = foo(); bar(o); } public static Object foo(){ return new A(); } public static void bar(Object o){

• .toString()

}

• main calls foo, which

returns an allocation

• f type A that is then

passed as a parameter in the call to bar

• The call edge to A.

toString would be missing because neither bar or its parents (main) allocated a type of A

6

Call Graph Construction: Reachability Computation

Queue worklist CallGraph graph; worklist.addAtTail(main()) Graph.addNode(main()) while (worklist.notEmpty()) { m = worklist.getFromHead(); process_method_body(m); }

Next Steps…

• Ingredients
• Adding pointers
• Adding call graphs
• Combining those two
• How to we mix the ingredients?
• Can first build a call graph; then add pointers
• Can do it all at once: we can use Datalog to represent

everything, with some Datalog relations encoding intraprocedural aspects and some interprocedural

8

Pointer Analysis: Basics and Algorithms

9

Variants of Pointer Analysis

• For C:
• Andersen analysis
• Steensgard analysis
• Pointer analysis for Java
• How to encode these in Datalog
• Other variants

10

What is the Goal of Pointer Analysis?

• What memory locations can a pointer expression

refer to?

• Alias analysis: When do two pointer expressions

refer to the same storage location?

int x; p = &x; q = p;

11

• *p and *q alias
• as do x and *p
• and x and *q

Sources of Aliasing

• Aliasing can arise due to several reasons,

depending on the language…

• Pointers
• e.g., int *p, i; p = &i;
• Call-by-reference

void m(Object a, Object b) { … } m(x,x); // a and b alias in m

• Array indexing
• int i, j, a[100];
• i = j; // a[i] and a[j] alias

12

Why do we Want to Know?

• Pointer analysis tells us

what memory locations code uses or modifies

• Useful in many analyses
• E.g., available

expressions

*p = a + b; y = a + b;

• If *p aliases a or b, then

second computation of a+b is not redundant

• E.g., consider constant

propagation x = 3; *p = 4; y = x;

• Is y constant?
• If *p and x do not alias each
• ther, then yes.
• If *p and x always alias each
• ther, then yes.
• If *p and x sometimes alias each
• ther, then no

13

Pointer Analysis Dimensions

• Intraprocedural /

interprocedural

• Flow-sensitive /

flow-insensitive

• Context-sensitive /

context-insensitive

• Definiteness: May

versus must

• Heap modelling
• Data representation

14

Flow-sensitive vs. Flow- insensitive Points-To

• Flow-sensitive pointer

analysis computes for each program point what memory locations pointer expressions may refer to

• Flow-insensitive pointer

analysis computes what memory locations pointer expressions may refer to, at any time in program execution

• Flow-sensitive pointer

analysis is (traditionally) too expensive to perform for whole program

• Flow-insensitive pointer

analyses typically used for whole program analyses

15

Context Sensitivity

• Also difficult,

but success in scaling up to hundreds of thousands LOC

• BDDs see Whaley and

Lam PLDI 2004

• Doop, Bravenboer and

Smaragdakis OOPSLA 2009

16

May vs. Must

• May analysis: aliasing

that may occur during execution

• (cf. must-not alias,

although often has different representation)

• Must analysis: aliasing

that must occur during execution

• Sometimes both are

useful

• E.g., consider liveness

analysis for *p = *q + 4;

• If *p must alias x, then

x in kill set for statement

• If *q may alias y, then y

in gen set for statement

17

Representation Options

• Points-to pairs: first

element points to the second

• e.g., (p → b), (q → b)
• p and b alias, as do *q

and b, as do *p and *q

• Pairs that refer to the

same memory

• e.g., (*p,b), (*q,b),

(*p,*q), (**r, b)

• General, may be less

concise than points-to pairs

• Equivalence sets: sets

that are aliases

• e.g., {*p,*q,b}

18

Modeling Memory Locations

• We want to describe

what memory locations a pointer expression may refer to

• How do we model

memory locations?

• For global variables, no

trouble, use a single “node”

• For local variables, use

a single “node” per context

• i.e., just one node if

context insensitive

• For dynamically

allocated memory

• Problem: Potentially

unbounded locations created at runtime

• Need to model

locations with some finite abstraction

19

Modeling Dynamic Memory Locations

• For each allocation

statement, use one node per context

• Note: could choose

context-sensitivity for modelling heap locations to be less precise than context- sensitivity for modelling procedure invocation

• Other solutions:
• One node for

entire heap

• One node for

each type

• Nodes based on

analysis of “shape” of heap

20

Problem Statement

• Let’s consider flow-

insensitive may pointer analysis

• Assume program

consists of statements

• f form

p = &a (address of, includes allocation statements) p = q *p = q p = *q

• Assume pointers p,q∈P and

address-taken variables a,b∈A are disjoint

• Can transform program to

make this true

• For any variable v for which

this isn’t true, add statement pv = &av, and replace v with *pv

• Want to compute relation

pts : P∪A → 2A

• Essentially points to pairs

21

Andersen-style Pointer Analysis

• View pointer assignments as subset constraints
• Use constraints to propagate points-to information
• Called inclusion-based pointer analysis

22

Andersen-style Pointer Analysis

• Can solve these constraints directly on sets pts(p)
• p = &a; p ⊇ {a}
• q = p;

q ⊇ p

• p = &b; p ⊇ {b}
• r = p;

r ⊇ p

23

Example of Subset Constraints

24

How Precise Is This Analysis?

25

Andersen-style as Graph Closure

• Can be cast as a graph closure problem
• One node for each pts(p), pts(a)
• Each node has an associated points-to set
• Compute transitive closure of graph, and add edges

according to complex constraints

26

Work List Algorithm

• Initialize graph and points to sets using base and

simple constraints

• Let W = { v | pts(v) ≠∅ } (all nodes with non-empty

points to sets)

• While W not empty
• v ← select from W
• for each a ∈ pts(v) do
• add edge a→ p, and add a to W if edge is new
• for each constraint *v ⊇ q
• add edge q→a, and add q to W if edge is new
• for each edge v→q do
• pts(q) = pts(q) ∪ pts(v), and add q to W if pts(q) changed

27

Same Example, as A Graph (Initial)

28

W: p q r s a

Same Example, as A Graph (Final)

29

W: {}

Cycle Elimination

• Andersen-style pointer analysis is O(n3), for number
• f nodes in graph
• Actually, quadratic in practice [Sridharan and Fink,

SAS 09];

• Improve scalability by reducing the value of n
• Cycle elimination: important optimization for Andersen-

style analysis

• Detect strongly connected components in points-to

graph, collapse to single node

• Why? All nodes in an SCC will have same points-to

relation at end of analysis

30

Steensgaard-style Analysis

• Also a constraint-based analysis
• Uses equality constraints instead of subset constraints
• Originally phrased as a type-inference problem
• Less precise than Andersen-style, thus more scalable

31

Steensgaard-style Example

32

a b c p q a,b c p,q a,b c p,q r a,b c p,q,s,t r a,b,c p,q,s,t,r All pointers end up in the same equivalence class pointing to all the locations

Implementing Steensgaard

• Can be efficiently implemented

using UnionFind algorithm

• Nearly linear time: O(nα(n))
• Each statement needs to be

processed just once

• Unlike Andersen’s, which is a lot

more difficult to scale

33

Datalog-based Formulation of Pointer Analysis

34

35

Pointer or Points-to Analysis

• We shall consider Andersen’s formulation of Java
• bject references.
• Flow/context insensitive analysis.
• Cast of characters:

1. Local (or stack) variables, which point to… 2. Heap objects, which may have fields that are references to other heap objects.

Matches a Language Like Java

• Pointers (or

references) go from the stack(s) to the heap elements

• Also from one

heap element to another

36

Stack 1 Stack 2 Heap

37

Representing Heap Objects

• A heap object is named by the statement in which

it is created.

• Note many run-time objects may have the same

name.

• Example: h: T v = new T; says variable v can

point to (one of) the heap object(s) created by statement h.

v h

38

Field Store

• v.f = w makes the f field of the heap object h

pointed to by v point to what variable w points to.

v h g w i f f

39

Field Load

• v = w.f makes v point to what the f field of the

heap object h pointed to by w points to.

v h g w i f

40

Variable Assignment

• v = w makes v point to whatever w points to
• Interprocedural Analysis : Also models copying

an actual parameter to the corresponding formal or return value to a variable

v h w

41

EDB (Initial) Relations

• The facts about the statements in the program and

what they do to pointers are accumulated and placed in several EDB relations.

• Example: there would be an EDB relation

Copy(To,From) whose tuples are the pairs (v,w) such that there is a copy statement v=w.

42

Convention for Initial EDB

• Instead of using EDB relations for the various

statement forms, we shall simply use the quoted statement itself to stand for an atom derived from the statement.

• Example: “v=w” stands for Copy(v,w).

43

What Do We Compute?

• Pts(V,H) will get the set of pairs (v, h) such

that variable v can point to heap object h.

• Hpts(H1,F,H2) will get the set of triples (h, f,

g) such that the field f of heap object h can point to heap object g.

44

Datalog Rules for Points-to

1. Pts(V,H) :- “H: V = new T” 2. Pts(V,H) :- “V=W”, Pts(W,H). 3. Pts(V,H) :- “V=W.F”, Pts(W,G), Hpts(G,F,H). 4. Hpts(H,F,G) :- “V.F=W”, Pts(V,H), Pts(W,G).

45

Program Example

T p(T x) { h: T a = new T; a.f = x; return a; } void main() { g: T b = new T; b = p(b); b = b.f; }

46

Apply Rules Recursively --- Round 1

T p(T x) {h: T a = new T; a.f = x; return a;} void main() {g: T b = new T; b = p(b); b = b.f;}

Pts(a,h) Pts(b,g)

47

Apply Rules Recursively --- Round 2

T p(T x) {h: T a = new T; a.f = x; return a;} void main() {g: T b = new T; b = p(b); b = b.f;}

Pts(a,h) Pts(b,g) Pts(b,h) Pts(x,g)

48

Apply Rules Recursively --- Round 3

T p(T x) {h: T a = new T; a.f = x; return a;} void main() {g: T b = new T; b = p(b); b = b.f;}

Pts(a,h) Pts(b,g) Pts(x,g) Pts(b,h) Hpts(h,f,g) Pts(x,h)

49

Apply Rules Recursively --- Round 4

T p(T x) {h: T a = new T; a.f = x; return a;} void main() {g: T b = new T; b = p(b); b = b.f;}

Pts(a,h) Pts(b,g) Pts(x,g) Pts(b,h) Pts(x,h) Hpts(h,f,g) Hpts(h,f,h)

50

Extension to Support Flow Sensitivity

• IDB predicates need additional arguments B, I.
• B = block number.
• I = position within block, 0, 1,…, n for n -statement

block.

• Position 0 is before first statement, position 1 is between 1st

and 2nd statement, etc.

• Is there another way to introduce flow sensitivity?

51

Adding Context Sensitivity

• Include a component C = context.
• C doesn’t change within a function.
• Call and return can extend the context if the called

function is not mutually recursive with the caller.

52

Context Sensitive Analysis: Maintaining the Context

Pts(X,H,B0,0,D) :- Pts(V,H,B,I,C), “B,I: call P(…,V,…)”, “X is the corresponding actual to V in P”, “B0 is the entry of P”, “context D is C extended by P”.

Path Numbering To Make Calling Contexts Finite

53

Cloning-Based Context-Sensitive Pointer Alias Analysis Using Binary Decision Diagrams, Whaley and Lam, 2004

Expressing the Entire Analysis in Datalog

54
