CM10134 / CM50147 CM10134 / CM50147 Pr Prog ogramming I mming I - - PDF document

CM10134 / CM50147 CM10134 / CM50147 Pr Prog

• gramming I

mming I

Lecture Handouts

• Dr. Marina De Vos

2005-2006

Programming 1 06/10/2005 Lecture 1a: Introduction 1

CM10134-CM50147 Programming I Basic Programming in Java

Marina De Vos

Course Contents

• Introduction to object-oriented

programming…

• …with a strong software engineering

foundation…

• …aimed at producing and maintaining

large, high-quality software systems.

Buzzwords

interface

javadoc encapsulation coupling cohesion polymorphic method calls inheritance mutator methods collection classes

• verriding

iterators responsibility-driven design aggregation design patterns reuse abstraction

Goals

• Sound knowledge of programming

principles

• Sound knowledge of object-orientation
• Able to critically assess the quality of a

(small) software system

• Able to implement a small software system

in Java

Course Text

David J. Barnes & Michael Kölling Objects First with Java A Practical Introduction using BlueJ Pearson Education, 2003 ISBN 0-13-044929-6.

Additional Book

Bruce Eckel Thinking in Java, 3rd Edition Prentice-Hall, 2002 ISBN 031002872 Free online copy: “http://www.mindview.net/Books/TIJ/”

Programming 1 06/10/2005 Lecture 1a: Introduction 2

Webpage

The course webpage is at

www.cs.bath.ac.uk/~mdv/courses/prog1.html

Please check it regularly. It will be used for announcements and distribution of material for lectures, labs, coursework.

Mailing lists

• programming1@bath.ac.uk

the general mailing list for this unit.

• tutors-programming1@cs.bath.ac.uk

to contact the tutors of this unit and to submit lab sheets in case of illness.

Course overview (1)

• Objects and classes
• Understanding class definitions
• Object interaction
• Grouping objects
• More sophisticated behaviour - libraries
• Well-behaved objects - testing, maintaining,

debugging

• Designing classes

Course overview (2)

• Inheritance
• Polymorphism
• Extendable, flexible class structures
• Handling errors
• Designing applications

Passing this Unit

• Exam

– Answer three questions on theoretical and practical issues of programming.

• Coursework

– Write four medium-sized programs in an object

• riented way using the design methods we discussed.

In order to be allowed to sit the exam and to do the coursework 7 exercise sheets have to be satisfactory completed.

Programming 1 06/10/2005 Lecture 1b: Objects and Classes 1

Objects and Classes

First Programming Concepts

Fundamental Concepts

• object
• class
• method
• parameter
• data type

Objects and Classes

• Objects

– represent ‘things’ from the real world, or from some problem domain (example: “the red car down there in the car park”)

• Classes

– represent all objects of a kind (example: “car”)

Objects represent individual instantiations of the

• class. Object are instantiated.

Objects and Classes in BlueJ

Things we can do with Objects

Things we can do with Objects

Programming 1 06/10/2005 Lecture 1b: Objects and Classes 2

Methods and Parameters

• Objects/classes have operations which can be
• invoked. They are called methods
• void moveHorizontal(int distance) is called the

signature of the methods

• The collection of methods of a class is referred to

as the interface of that class

• methods may have parameters to pass additional

information needed to execute

• Methods are called or invoked

Data Types

• Parameters have types. A type defines what

kinds of values a parameter can take.

• Defining a class defines a type
• In Java, everything has a type.
• Java is strongly typed language
• Examples of types: int, String, Circle, …

Other Observations

• many instances can be created from a single

class

• an object has attributes: values stored in

fields.

• the class defines what fields an object has,

but each object stores its own set of values.

• These set of values is called the state of the
• bject.

State

Two Circle Objects

Object Interaction

Programming 1 06/10/2005 Lecture 1b: Objects and Classes 3

Source Code

• Each class has source code (Java code)

associated with it that defines its details (fields and methods).

• In other words, it determines the structure

and the behavior of each of its instance.

• This source code is compiled and

interpreted by Java.

Return Values

• Methods may return a result via a return

value.

• Example: String getName()

– This method returns a String.

• Example: void changeName()

– Void indicates that this method does not return anything

Developing Java Programs

• To learn to develop Java programs, one

needs to learn how to write class definitions, including fields and methods, and how to put these classes together as well

• During the rest of this unit we will deal with

these issues in more detail

Terms

• Object
• Instance
• State
• Compiler
• Virtual Machine
• Method Calling
• Class
• Method
• Return Value
• Signature
• Parameter
• Type
• Source Code

Programming 1 13/10/2005 Lecture 2: Understanding Class Definitions 1

Understanding class definitions

Looking inside classes

Main concepts to be covered

• fields
• constructors
• methods
• parameters
• assignment statements
• conditional statements

Ticket machines – an external view

• Exploring the behavior of a typical ticket

machine.

– Use the naive-ticket-machine project. – Machines supply tickets of a fixed price.

• How is that price determined?

– How is ‘money’ entered into a machine? – How does a machine keep track of the money that is entered? – How is a ticket provided?

Resulting Fields

Resulting Methods

Ticket machines – an internal view

• Interacting with an object gives us clues

about its behavior.

• Looking inside allows us to determine how

that behavior is provided or implemented.

– Looking at the source code

• All Java classes have a similar-looking

internal view.

Programming 1 13/10/2005 Lecture 2: Understanding Class Definitions 2

The Source Code

Basic class structure

The outer wrapper

• f TicketMachine

The contents of a class

Comments/Documentation

• Comments make source code easier to read

for humans. No effect on the functionality.

• Three sorts:

– // comment: single-line comments – /* comments */: multiple-lines – more detail – /** */: similar to previous, but used when documentation software is used.

Fields

• Fields store values for

an object.

• They are also known as

instance variables.

• Use the Inspect option

to view an object’s fields.

• Fields define the state
• f an object.

visibility modifier type variable name

Constructors

• Constructors initialize

an object.

• Then assign the

necessary memory to the created object

• They have the same

name as their class.

• They store initial values

into the fields.

• They often receive

external parameter values for this.

Passing data via parameters

Programming 1 13/10/2005 Lecture 2: Understanding Class Definitions 3

Parameters

• Parameter names inside a constructor or

method are referred to as Formal Parameters.

• Parameter values provided from the outside

are referred to as Actual Parameters.

• In the example: ticketCost is a formal

parameter and 500 is an actual parameter.

Space

• The ticketCost box in the object

representation is only created when the constructor is executed.

• Extra temporarily storage is provided to

store a value for ticketCost. This is called the constructor space or method space.

• Values can only be used during the

execution.

Scope and Lifetime

• The scope of a variable/parameter defines the

section of the code from where it can be accessed.

• For instance variables this is the entire class.
• For parameters, this is the constructor or method

that declares it.

• Trick: find the enclosing {}, this is the scope
• The lifetime of a variable/parameter describes how

long the variable continues to exist before it is destroyed.

Assignment

• Values are stored into fields (and other

variables) via assignment statements:

– variable = expression; – price = ticketCost;

• Both sides of the assignment should have

the same type, e.g. int, double, String, …

• A variable stores a single value, so any

previous value is lost.

Accessor methods

• Methods implement the behavior of objects.
• Accessors provide information about an
• bject.
• Methods have a structure consisting of a

header and a body.

• The header defines the method’s signature.

public int getPrice()

• The body encloses the method’s statements.

Accessor methods

public int getPrice() { return price; }

return type method name parameter list (empty) start and end of method body (block) return statement visibility modifier

Programming 1 13/10/2005 Lecture 2: Understanding Class Definitions 4

Mutator methods

• Have a similar method structure: header and

body.

• Used to mutate (i.e., change) an object’s

state.

• Achieved through changing the value of one
• r more fields.

– Typically contain assignment statements. – Typically receive parameters.

Mutator methods

public void insertMoney(int amount) { balance += amount; }

return type (void) method name parameter visibility modifier assignment statement field being changed

Printing from methods

public void printTicket() { // Simulate the printing of a ticket. System.out.println("##################"); System.out.println("# The BlueJ Line"); System.out.println("# Ticket"); System.out.println("# " + price + " cents."); System.out.println("##################"); System.out.println(); // Update the total collected with the balance. total += balance; // Clear the balance. balance = 0; }

Output

Reflecting on the ticket machines

• Their behavior is inadequate in several

ways:

– No checks on the amounts entered. – No refunds. – No checks for a sensible initialization.

• How can we do better?

– We need more sophisticated behavior.

Making choices

public void insertMoney(int amount) { if(amount > 0) { balance += amount; } else { System.out.println("Use a positive amount: " + amount); } }

Programming 1 13/10/2005 Lecture 2: Understanding Class Definitions 5

Making choices

if(perform some test) { Do the statements here if the test gave a true result } else { Do the statements here if the test gave a false result }

‘if’ keyword boolean condition to be tested - gives a true or false result actions if condition is true actions if condition is false ‘else’ keyword

Boolean Tests

• == : equality
• > : greater than
• < : less than
• =< : less or equal than
• >= : greater or equal than
• != : not equal

Local variables

• Fields are one sort of variable.

– They store values through the life of an object. – They are accessible throughout the class.

• Methods can include shorter-lived variables.

– They exist only as long as the method is being executed. – They are only accessible from within the method.

Local variables

public int refundBalance() { int amountToRefund; amountToRefund = balance; balance = 0; return amountToRefund; } A local variable

No visibility modifier

Review

• Class bodies contain fields, constructors and

methods.

• Fields store values that determine an
• bject’s state.
• Constructors initialize objects.
• Methods implement the behavior of objects.
• Constructors are methods which do not

return anything.

Review

• Fields, parameters and local variables are all

variables.

• Fields persist for the lifetime of an object.
• Parameters are used to receive values into a

constructor or method.

• Local variables are used for short-lived

temporary storage.

Programming 1 13/10/2005 Lecture 2: Understanding Class Definitions 6

Review

• Objects can make decisions via conditional

(if) statements.

• A true or false test allows one of two

alternative courses of actions to be taken.

Terms

• Instance variables
• Local variables
• Parameters
• Formal Parameters
• Actual Parameters
• Scope
• Lifetime
• Constructors
• Methods
• If-statement
• Assignment
• =
• +=
• <=, >=, <, >, !=, ==

Programming 1 20/10/2005 Lecture 3: Object Interaction 1

Object interaction

Creating cooperating objects

Main concepts to be covered

• Abstraction
• Modularization
• Class and Object Diagrams
• Call-by-reference and Call-by-value
• Overloading
• Internal and External method calls
• this keyword
• Debugging

A digital clock

Abstraction and modularization

• Abstraction is the ability to ignore details
• f parts to focus attention on a higher level
• f a problem.
• Modularization is the process of dividing a

whole into well-defined parts, which can be built and examined separately, and which interact in well-defined ways.

Modularizing the clock display

One four-digit display? Or two two-digit displays?

Implementation: NumberDisplay

public class NumberDisplay { private int limit; private int value; Constructor and methods omitted. }

Programming 1 20/10/2005 Lecture 3: Object Interaction 2

Implementation ClockDisplay

public class ClockDisplay { private NumberDisplay hours; private NumberDisplay minutes; Constructor and methods omitted. }

Object diagram

Class diagram

Diagrams

• Class Diagrams

– Shows the classes of an application and the relationships between them – Gives information about the source code – Static view of the program

• Object Diagrams

– Shows objects and their relationships at one moment in time during the execution of the program – Dynamic view of the program

BlueJ and Diagrams

Primitive types vs. object types

• Java defines two very different kinds of

type: primitive types and object types.

• Primitive types are predefined by Java.
• Object types originate from classes.
• Variables and parameters store references to
• bjects.
• The primitive types are non-object types.

Programming 1 20/10/2005 Lecture 3: Object Interaction 3

Primitive types vs. object types

32

• bject type

primitive type SomeObject obj; int i;

Primitive types vs. object types

32

SomeObject a; int a; SomeObject b;

32

int b; b = a;

Call-by-reference and Call-by-value

• There are two ways of passing arguments to

methods in many programming languages: call-by-value and call-by-reference.

• Call-by-value: A copy of the actual

parameter is passed to the formal parameter

• f the called method. Any change made to

the formal parameter will have no effect on the actual parameter.

Call-by-reference and Call-by-value

• Call-by-reference: the caller gives the called

method the ability to directly access to the caller’s data and to modify that data if the called method so chooses.

• Java uses call-by-value for primitive data

types and call-by-reference for object types.

Source code: NumberDisplay

public class NumberDisplay { private int limit; private int value; public NumberDisplay(int rollOverLimit) { limit = rollOverLimit; value = 0; }

Source code: NumberDisplay

public int getValue() { return value; } public void setValue(int replacementValue) { if((replacementValue >= 0) && (replacementValue < limit)) value = replacementValue; }

Programming 1 20/10/2005 Lecture 3: Object Interaction 4

Logical Operators

• && : and, operands are tested, left to right,

until conclusion can be reached

• || : or, operands are tested, left to right, until

conclusion can be reached

• ! : not
• & : and, both operands are tested
• | : or, both operands are tested

Source code: NumberDisplay

public String getDisplayValue() { if(value < 10) return "0" + value; else return "" + value; } public void increment() { value = (value + 1) % limit; } }

String Concatenation

• Addition:

– 12 + 24

• String Concatenation:

– “Java” + “with BlueJ” -> “Javawith BlueJ” – “answer: ” + 42 -> “answer: 42”

String toString() method

• String toString() method: Java provides a way of

transforming every Object into a String. To tailor this to your own preference write a method toString() returning a String representation of your class/object.

public String toString() { return “value: “ + value + “ with limit ” + limit; }

The Modulo Operator

• % : the modulo operator calculates the

remainder of an integer division

– 27 & 4 -> 3

• Division in Java: if both arguments are

integers, division will result in an integer.

– double res = 5 / 2 -> res = 2 – double res = 5 / (2.0) or 5 / (2 * 1.0)

• > res = 2.5

Objects creating objects

public class ClockDisplay { private NumberDisplay hours; private NumberDisplay minutes; private String displayString; public ClockDisplay() { hours = new NumberDisplay(24); minutes = new NumberDisplay(60); updateDisplay(); } }

Programming 1 20/10/2005 Lecture 3: Object Interaction 5

Objects creating objects

1. new ClassName(parameter-list)

– It creates a new object of the named class

• here NumberDisplay
• this involves creating sufficient memory to store the values
• f primitive instance variables and references to object

instance variables.

2. It executes the constructor of that class public NumberDisplay new NumberDisplay

(int rollOverLimit)

formal parameter

(24)

actual parameter

ClockDisplay object diagram

Method Overloading

• Multiple Constructors of ClockDisplay:

– new Clockdisplay() – new Clockdisplay(hour, minute)

• It is common for class definitions to contain

alternative versions of constuctors or methods that provide various ways of achieving a particular task via their distinctive sets of parameters.

• This is known as overloading.

Method calling

public void timeTick() { minutes.increment(); if(minutes.getValue() == 0) { // it just rolled over! hours.increment(); } updateDisplay(); }

Internal method

/** * Update the internal string that * represents the display. */ private void updateDisplay() { displayString = hours.getDisplayValue() + ":" + minutes.getDisplayValue(); }

Method calls

• internal method calls

updateDisplay(); private void updateDisplay()

• methodName(parameter-list)
• external method calls

minutes.increment();

• object.methodName(parameter-list)

Programming 1 20/10/2005 Lecture 3: Object Interaction 6

Public and Private Methods

• Public methods:
• public void increment()
• can be called externally
• Private methods
• private void updateDisplay()
• can only be called internally
• used for auxiliary methods

The Mail System

The this Keyword

public class MailItem { private String from; private String to; private String message; public MailItem(String from, String to, String message) { this.from = from; this.to = to; this.message = message; }

The this Keyword

• this.from = from

– name overloading: the same name is used for two different entities: instance variable and formal parameter. – this is used to go out of the scope of the constructor to class level – this always refers to the current object. – can also used for methods – for internal methods calls and access to instance fields Java automatically inserts this – updateDisplay -> this.updateDisplay

Debugging

• Software is hardly ever written without

making mistakes or bugs.

• There are two type of bugs:

– syntax: can be traced using the compiler – logical:

• tracing the program manually
• using a debugging tool
• BlueJ provides a debugger

Debugging

Programming 1 20/10/2005 Lecture 3: Object Interaction 7

Concepts

• abstraction
• modularisation
• call-by-value
• call-by-reference
• logical operators/modulo
• this
• class/object diagram
• primitive types
• object types
• object creation
• overloading
• internal/external method

calls

• private methods
• debugging

Programming 1 27/10/2005 Lecture 4: Grouping Objects 1

Grouping objects

Collections and iterators

Main concepts to be covered

• Collections
• Loops
• Iterators
• Arrays

The requirement to group objects

• Many applications involve collections of
• bjects:

– Personal organizers. – Library catalogs. – Student-record system.

• The number of items to be stored varies.

– Items added. – Items deleted.

A personal notebook

• Notes may be stored.
• Individual notes can be viewed.
• There is no limit to the number of notes.
• It will tell you how many notes are stored.

A personal notebook

Class Libraries

• Learning to program is to learn how to

reuse code written by other. There is no point in reinventing the wheel.

• Java comes with a library of useful classes,

which are referred to as the Java API

• They are organized in packages that follow

a directory structure

Programming 1 27/10/2005 Lecture 4: Grouping Objects 2

Class Libraries

Class libraries

• You can access the classes from your code,

using the import statement

– import java.util.Vector; – import java.util.*;

• Grouping objects is a recurring requirement.

– The java.util package contains classes for doing this. – We will use ArrayList as a first example

Class Libraries

import java.util.ArrayList; /** * ... */ public class Notebook { // Storage for an arbitrary number of notes. private ArrayList notes; /** * Perform any initialization required for the * notebook. */ public Notebook() { notes = new ArrayList(); } ... }

Object structures with collections

Adding a third note

Programming 1 27/10/2005 Lecture 4: Grouping Objects 3

Features of the collection

• It increases its capacity as necessary.
• It keeps a private count (size() accessor).
• It keeps the objects in order.
• Details of how all this is done are hidden.

– Does that matter? Does not knowing how prevent us from using it?

Using the collection

public class Notebook { private ArrayList notes; ... public void storeNote(String note) { notes.add(note); } public int numberOfNotes() { return notes.size(); } ... } Adding a new note Returning the number of notes (delegation).

Index numbering

Retrieving an object

Index validity checks Retrieve and print the note public void showNote(int noteNumber) { if(noteNumber < 0) { // This is not a valid note number. } else if(noteNumber < numberOfNotes()) { System.out.println(notes.get(noteNumber)); } else { // This is not a valid note number. } }

Removing an item

public void removeNote(int noteNumber) { if(noteNumber < 0) { // This is not a valid note number, so do nothing. } else if(noteNumber < numberOfNotes()) { // This is a valid note number. notes.remove(noteNumber); } else { // This is not a valid note number, so do nothing. } }

Removal may affect numbering

Programming 1 27/10/2005 Lecture 4: Grouping Objects 4

Review

• Collections allow an arbitrary number of
• bjects to be stored.
• Class libraries usually contain tried-and-

tested collection classes.

• Java’s class libraries are called packages.
• We have used the ArrayList class from

the java.util package.

Review

• Items may be added and removed.
• Each item has an index.
• Index values may change if items are

removed (or further items added).

• The main ArrayList methods are add,

get, remove and size.

Iteration

• We often want to perform some actions an

arbitrary number of times.

– E.g., print all the notes in the notebook. How many are there?

• Most programming languages include loop

statements to make this possible.

• Java has three sorts of loop statements.

– We will focus on its while loop to begin with.

While loop pseudo code

Boolean test while keyword Statements to be repeated Pseudo-code example to print every note General form of a while loop

A Java example

/** * List all notes in the notebook. */ public void listNotes() { int index = 0; while(index < notes.size()) { System.out.println(notes.get(index)); index++; } } Increment by one

Increments

• i++ : the value of i is used first before it is

being incremented with one

– a = 5; b = a++; – a == 6; b == 5;

• ++i: increments i with one, the new value of

i is then used.

– a = 5; b = ++a; – a == 6; b == 6;

Programming 1 27/10/2005 Lecture 4: Grouping Objects 5

Iterating over a collection

Iterator it = myCollection.iterator(); while(it.hasNext()) { call it.next() to get the next object do something with that object } java.util.Iterator Returns an Iterator

• bject

public void listNotes() { Iterator it = notes.iterator(); while(it.hasNext()) { System.out.println(it.next()); } }

Iterators

• An iterator is an object that provides functionality

to iterate over all elements of a collection or container class

• java.util.Iterator
• two main methods: hasNext() to check if the

Iterator has more elements and next() to take the next object from the Iterator.

• You can access an iterator for all java collections.
• Not all collections can be accessed using indexes.

The auction project

• The auction project provides further

illustration of collections and iteration.

• Two further points to follow up:

– The null value. – Casting. Used to store the result of get into a variable:

• String message = (String) notes.get(0);

The auction project

The Lot Class

public void bidFor(Person bidder, long value) { if((highestBid == null) || (highestBid.getValue() < value)) { // This bid is the best so far. setHighestBid(new Bid(bidder, value)); } else { System.out.println("Lot number: " + getNumber() + " (" + getDescription() + ")" + " already has a bid of: " + highestBid.getValue()); } }

The null Keyword

• highestBid == null;

– The Java keyword null is used to mean ‘no

• bject’ when a variable is not currently holding

a reference to a particular object.

• setHighestBid(new Bid(bidder, value));

– two things are done here:

• we create a new object Bid
• we pass this new object immediately to the method

Programming 1 27/10/2005 Lecture 4: Grouping Objects 6

The Auction Class

Type Casting

• Lot lot = (Lot) it.next();

– the return value of the Iterator method next() is an object of type Object. To store this in an

• bject of type Lot we need to explicitly convert

it that type. This is called Casting – This can only been done if the objects we have added to the container were originally of type Lot.

Type Casting

• Collections in Java allow for the storage of

any type of objects. In order to do so it transforms everything you add into an

• bject of type Object.
• When retrieving objects from a collection

we normally cast them back into their

• riginal types.

Wrapper Classes

• Container classes in Java can only contain
• bjects.
• Primitive types can therefore not be added.
• To solve this, Java provides wrapper

classes: Integer, Float, Double

– Integer a = new Integer(10); – int b = a.intValue();

Fixed-size collections

• Sometimes the maximum collection size

can be pre-determined.

• Programming languages usually offer a

special fixed-size collection type: an array.

• Java arrays can store objects or primitive-

type values.

• Arrays use a special syntax.

The weblog-analyzer project

• Web server records details of each access.
• Supports webmaster’s tasks.

– Most popular pages. – Busiest periods. – How much data is being delivered. – Broken references.

• Analyze accesses by hour.

Programming 1 27/10/2005 Lecture 4: Grouping Objects 7

The weblog-analyzer project

Creating an array object

public class LogAnalyzer { private int[] hourCounts; private LogfileReader reader; public LogAnalyzer() { hourCounts = new int[24]; reader = new LogfileReader(); } ... } Array object creation Array variable declaration

The hourCounts array

Using an array

• Square-bracket notation is used to access an array

element: hourCounts[...]

• The number of elements of an array can be
• btained via: hourCounts.length
• Elements are used like ordinary variables.

– On the left of an assignment:

• hourCounts[hour] = ...;

– In an expression:

• adjusted = hourCounts[hour] – 3;
• hourCounts[hour]++;
• Arrays are passed by reference while their

elements are passed by value.

The for loop

• Similar to a while loop.
• Often used to iterate a fixed number of

times.

• Often used to iterate over an array.

For loop pseudo-code

for(initialization; condition; post-body action) { statements to be repeated } General form of a for loop Equivalent in while-loop form initialization; while(condition) { statements to be repeated post-body action }

Programming 1 27/10/2005 Lecture 4: Grouping Objects 8

A Java example

for(int hour = 0; hour < hourCounts.length; hour++) { System.out.println(hour + ": " + hourCounts[hour]); } int hour = 0; while(hour < hourCounts.length) { System.out.println(hour + ": " + hourCounts[hour]); hour++; } for loop version while loop version

Review

• Arrays are appropriate where a fixed-size

collection is required.

• Arrays use special syntax.
• For loops offer an alternative to while loops

when the number of repetitions is known.

• For loops are often used to iterate over

arrays.

Concepts

• Java API
• packages
• import
• ArrayList
• Iterator
• type cast
• for
• while
• array
• a++
• ++a
• null

Programming 1 03/11/2005 Lecture 5: More Sophisticated Behavior 1

More sophisticated behavior

Using library classes to implement some more advanced functionality

Main concepts to be covered

• Using library classes
• Reading documentation
• Writing documentation

The Java class library

• Thousands of classes
• Tens of thousands of methods
• Many useful classes that make life much

easier

• A competent Java programmer must be able

to work with the libraries.

Working with the library

You should:

• know some important classes by name;
• know how to find out about other classes.

Remember:

• We only need to know the interface, not the

implementation.

A Technical Support System

• A textual dialog system
• Idea based on ‘Eliza’ by Joseph

Weizenbaum (MIT, 1960s)

• This is a system that when entering

questions will try to answer them in an “intelligent” way.

A Technical Support System

Programming 1 03/11/2005 Lecture 5: More Sophisticated Behavior 2

A Technical Support System

Main loop structure

// from the start method in SupportSystem boolean finished = false; while(!finished) {// sentinel controlled loop do something if(exit condition) { finished = true; } else { do something more } }

Main loop body

String input = reader.getInput(); ... String response = responder.generateResponse(); System.out.println(response);

The exit condition

String input = reader.getInput(); if(input.startsWith("bye")) { finished = true; }

• Where does ‘startsWith’ come from?
• What is it? What does it do?
• How can we find out?

String Info

Reading class documentation

• Documentation of the Java libraries in

HTML format;

• Readable in a web browser
• Class API: Application Programmers’

Interface

• Interface description for all library classes
• http://java.sun.com/j2se/1.3/docs/api/

Programming 1 03/11/2005 Lecture 5: More Sophisticated Behavior 3

Interface vs implementation

The documentation includes

• the name of the class;
• a general description of the class;
• a list of constructors and methods
• return values and parameters for constructors

and methods

• a description of the purpose of each constructor

and method the interface of the class

Interface vs implementation

The documentation does not include

• private fields (most fields are private)
• private methods
• the bodies (source code) for each method

the implementation of the class

Interface vs implementation

• The interface of a method consists of

– signature

• access modifier
• return type
• method name
• a list of parameters

– comment

• discussion of all signature items
• purpose of method

Using library classes

• Classes from the library must be imported

using an import statement (except classes from java.lang).

• They can then be used like classes from the

current project.

Packages and import

• Classes are organised in packages.
• Single classes may be imported:

import java.util.ArrayList;

• Whole packages can be imported:

import java.util.*;

Side Note 1: Strings

• Strings are immutable objects

– immutable objects cannot change content or state once they have been created

String input = reader.getInput(); input = input.trim; if(input.startsWith(“bye”)){ finished = true; } else { … Code omitted }

Programming 1 03/11/2005 Lecture 5: More Sophisticated Behavior 4

Side Note 1: StringBuffer

• A string buffer implements a mutable

sequence of characters. A string buffer is like a String, but can be modified. At any point in time it contains some particular sequence of characters, but the length and content of the sequence can be changed through certain method calls.

Side note 2: String equality

if(input == "bye") { tests identity ... } if(input.equals("bye")) { tests equality ... }

• Strings should (almost) always be compared with .equals

Identity vs equality 1

Other (non-String) objects: person1 == person2 ?

“Fred”

:Person

person1 person2 “Jill”

:Person

Identity vs equality 2

Other (non-String) objects: person1 == person2 ?

“Fred”

:Person

person1 person2 “Fred”

:Person

Identity vs equality 3

Other (non-String) objects: person1 == person2 ?

“Fred”

:Person

person1 person2 “Fred”

:Person

Identity vs equality (Strings)

"bye"

:String

input "bye"

:String String input = reader.getInput(); if(input == "bye") { ... }

== tests identity

== ?

➠ (may be) false!

Programming 1 03/11/2005 Lecture 5: More Sophisticated Behavior 5

Identity vs equality (Strings)

"bye"

:String

input "bye"

:String String input = reader.getInput(); if(input.equals("bye")) { ... }

equals tests equality

equals

?

➠ true!

Using Random

• The library class Random can be used to

generate random numbers

import java.util.Random; ... Random randomGenerator = new Random(); ... int index1 = randomGenerator.nextInt(); int index2 = randomGenerator.nextInt(100);

Generating random responses

Maps

• Maps are collections that contain pairs of

values.

• Pairs consist of a key and a value.
• Lookup works by supplying a key, and

retrieving a value.

• An example: a telephone book.

Using maps

• A map with Strings as keys and values

"Charles Nguyen"

:HashMap

"(531) 9392 4587" "Lisa Jones" "(402) 4536 4674" "William H. Smith" "(998) 5488 0123"

Using maps

HashMap phoneBook = new HashMap(); phoneBook.put("Charles Nguyen", "(531) 9392 4587"); phoneBook.put("Lisa Jones", "(402) 4536 4674"); phoneBook.put("William H. Smith", "(998) 5488 0123"); String number = (String)phoneBook.get("Lisa Jones"); System.out.println(number);

Programming 1 03/11/2005 Lecture 5: More Sophisticated Behavior 6

Maps in TechSupport

Using sets

import java.util.HashSet; import java.util.Iterator; ... HashSet mySet = new HashSet(); mySet.add("one"); mySet.add("two"); mySet.add("three"); Iterator it = mySet.iterator(); while(it.hasNext()) { call it.next() to get the next object do something with that object }

Compare this to ArrayList code!

Sets and List

• A Set is a collection that stores each

individual element at most once. It does not maintain any specific order.

• A List is a collection that stores all

elements it is been giving regardless of

• duplication. It maintains a order at all times.

Tokenizing Strings

public HashSet getInput() { System.out.print("> "); String inputLine = readInputLine().trim().toLowerCase(); StringTokenizer tokenizer = new StringTokenizer(inputLine); HashSet words = new HashSet(); while(tokenizer.hasMoreTokens()) { words.add(tokenizer.nextToken()); } return words; }

Writing class documentation

• Your own classes should be documented the

same way library classes are.

• Other people should be able to use your

class without reading the implementation.

• Make your class a 'library class'!

Elements of documentation

Documentation for a class should include:

• the class name
• a comment describing the overall purpose

and characteristics of the class

• a version number
• the authors’ names
• documentation for each constructor and

each method

Programming 1 03/11/2005 Lecture 5: More Sophisticated Behavior 7

javadoc

Class comment:

/** * The Responder class represents a response * generator object. It is used to generate an * automatic response. * * @author Michael Kölling and David J. Barnes * @version 1.0 (1.Feb.2002) */

Elements of documentation

The documentation for each constructor and method should include:

• the name of the method
• the return type
• the parameter names and types
• a description of the purpose and function of the

method

• a description of each parameter
• a description of the value returned

javadoc

Method comment:

/** * Read a line of text from standard input (the text * terminal), and return it as a set of words. * * @param prompt A prompt to print to screen. * @return A set of Strings, where each String is * one of the words typed by the user */ public HashSet getInput(String prompt) { ... }

Public vs private

• Public attributes (fields, constructors,

methods) are accessible to other classes.

• Fields should not be public.

– Data encapsulation

• Private attributes are accessible only within

the same class.

• Only methods that are intended for other

classes should be public.

Information hiding

• Data belonging to one object is hidden

from other objects.

• Know what an object can do, not how it

does it.

• Information hiding increases the level of

independence.

• Independence of modules is important for

large systems and maintenance.

The Balls Project

Programming 1 03/11/2005 Lecture 5: More Sophisticated Behavior 8

Class and Object Level

• So far we have created classes for the sake
• f objects which should have each a state of

their own.

• Sometimes, objects should be able to share

common properties

• For People this could be the gravitational pull
• For Employees of the same company this could be

the company’s details

Class and Object Level

• Instead of having these details stored in each
• bject it would be better to store this at one central

point:

– THE CLASS

• Classes themselves can also have state

– class variables or static variables – Exactly one copy exists of a class variable at all times, independent of the number of created instances – The key word static is Java’s syntax to define class variables – methods at object level can access static variables

Class and Object Level

Class variables

Constants

• Variables can change their value by means of

assignment.

• Sometimes, when programming you need a

mechanism that can guarantee you that the value does not change at all

• Constants provide you a way in doing so

– similar to maths or physics

• pi, i, …

– The key word final is Java’s syntax to express constants – Once given a value, initialized, they can change value – Trying to do so will result in a syntax error.

Constants

private static final int gravity = 3;

• private: access modifier, as usual
• static: class variable
• final: constant

Programming 1 03/11/2005 Lecture 5: More Sophisticated Behavior 9

Review

• Java has an extensive class library.
• A good programmer must be familiar with the

library.

• The documentation tells us what we need to know

to use a class (interface).

• The implementation is hidden (information

hiding).

• We document our classes so that the interface can

be read on its own (class comment, method comments).

Concepts

• Interface
• class level
• static variables
• class variables
• object level
• constants
• Signature
• javadoc
• documentation
• final
• static

Programming 1 10/11/2005 Lecture 6: Well-behaved Objects and Designing Classes 1

Well-behaved objects

Improving your coding skills

Main concepts to be covered

• Testing
• Debugging
• Test automation
• Writing for maintainability

We have to deal with errors

• Early errors are usually syntax errors.

– The compiler will spot these.

• Later errors are usually logic errors.

– The compiler cannot help with these. – Also known as bugs.

• Some logical errors have no immediately
• bvious manifestation.

– Commercial software is rarely error free.

Prevention vs Detection

(Developer vs Maintainer)

• We can lessen the likelihood of errors.

– Use software engineering techniques, like encapsulation.

• We can improve the chances of detection.

– Use software engineering practices, like modularization and documentation.

• We can develop detection skills.

Testing and debugging

• These are crucial skills.
• Testing searches for the presence of errors.
• Debugging searches for the source of errors.

– The manifestation of an error may well occur some ‘distance’ from its source.

Testing and debugging techniques

• Unit testing (within BlueJ)
• Test automation
• Manual walkthroughs
• Print statements
• Debuggers

Programming 1 10/11/2005 Lecture 6: Well-behaved Objects and Designing Classes 2

Unit testing

• Each unit of an application may be tested.

– Method, class, module (package in Java).

• Can (should) be done during development.

– Finding and fixing early lowers development costs (e.g. programmer time). – A test suite is built up.

Testing fundamentals

• Understand what the unit should do – its

contract.

– You will be looking for violations. – Use positive tests and negative tests.

• Test boundaries.

– Zero, One, Full.

• Search an empty collection.
• Add to a full collection.

Unit testing within BlueJ

• Objects of individual classes can be created.
• Individual methods can be invoked.
• Inspectors provide an up-to-date view of an
• bject’s state.
• Explore through the diary-prototype project.

Test automation

• Good testing is a creative process, but ...
• ... thorough testing is time consuming and

repetitive.

• Regression testing involves re-running tests.
• Use of a test rig or test harness can relieve

some of the burden.

– Classes are written to perform the testing. – Creativity focused in creating these.

Test automation

• Explore through the diary-testing project.

– Human analysis of the results still required.

• Explore fuller automation through the

diary-test-automation project.

– Intervention only required if a failure is reported.

Modularization and interfaces

• Applications often consist of different

modules.

– E.g. so that different teams can work on them.

• The interface between modules must be

clearly specified.

– Supports independent concurrent development. – Increases the likelihood of successful integration.

Programming 1 10/11/2005 Lecture 6: Well-behaved Objects and Designing Classes 3

Modularization in a calculator

• Each module does not need to know

implementation details of the other.

– User controls could be a GUI or a hardware device. – Logic could be hardware or software.

Method signatures as an interface

// Return the value to be displayed. public int getDisplayValue(); // Call when a digit button is pressed. public void numberPressed(int number); // Call when a plus operator is pressed. public void plus(); // Call when a minus operator is pressed. public void minus(); // Call to complete a calculation. public void equals(); // Call to reset the calculator. public void clear();

Debugging

• It is important to develop code-reading

skills.

– Debugging will often be performed on others’ code.

• Techniques and tools exist to support the

debugging process.

• Explore through the calculator-engine

project.

Manual walkthroughs

• Relatively underused.

– A low-tech approach. – More powerful than appreciated.

• Get away from the computer!
• ‘Run’ a program by hand.
• High-level (Step) or low-level (Step into)

views.

Tabulating object state

• An object’s behavior is usually determined

by its state.

• Incorrect behavior is often the result of

incorrect state.

• Tabulate the values of all fields.
• Document state changes after each method

call.

Verbal walkthroughs

• Explain to someone else what the code is

doing.

– They might spot the error. – The process of explaining might help you to spot it for yourself.

• Group-based processes exist for conducting

formal walkthroughs or inspections.

Programming 1 10/11/2005 Lecture 6: Well-behaved Objects and Designing Classes 4

Print statements

• The most popular technique.
• No special tools required.
• All programming languages support them.
• Only effective if the right methods are

documented.

• Output may be voluminous!
• Turning off and on requires forethought.

Debuggers

• Debuggers are both language- and

environment-specific.

– BlueJ has an integrated debugger.

• Support breakpoints.
• Step and Step-into controlled execution.
• Call sequence (stack).
• Object state.

Review

• Errors are a fact of life in programs.
• Good software engineering techniques can

reduce their occurrence.

• Testing and debugging skills are essential.
• Make testing a habit.
• Automate testing where possible.
• Practise a range of debugging skills.

Designing classes

How to write classes in a way that they are easily understandable, maintainable and reusable

Main concepts to be covered

• Responsibility-driven design
• Coupling
• Cohesion
• Refactoring
• Static methods

Software changes

• Software is not like a novel that is written
• nce and then remains unchanged.
• Software is extended, corrected, maintained,

ported, adapted…

• The work is done by different people over

time (often decades).

Programming 1 10/11/2005 Lecture 6: Well-behaved Objects and Designing Classes 5

Change or die

• There are only two options for software:

– Either it is continuously maintained – or it dies.

• Software that cannot be maintained will be

thrown away.

World of Zuul

Code quality

Two important concepts for quality of code:

• Coupling
• Cohesion

Coupling

• Coupling refers to links between separate

units of a program.

• If two classes depend closely on many

details of each other, we say they are tightly coupled.

• We aim for loose coupling.

Loose coupling

Loose coupling makes it possible to:

• understand one class without reading others;
• change one class without affecting others.
• Thus: improves maintainability.

Cohesion

• Cohesion refers to the the number and

diversity of tasks that a single unit is responsible for.

• If each unit is responsible for one single

logical task, we say it has high cohesion.

• Cohesion applies to classes and methods.
• We aim for high cohesion.

Programming 1 10/11/2005 Lecture 6: Well-behaved Objects and Designing Classes 6

High cohesion

High cohesion makes it easier to:

• understand what a class or method does;
• use descriptive names;
• reuse classes or methods.

Cohesion of methods

• A method should be responsible for one and
• nly one well defined task.

Cohesion of classes

• Classes should represent one single, well

defined entity.

Code duplication

Code duplication

• is an indicator of bad design,
• makes maintenance harder,
• can lead to introduction of errors during

maintenance.

Responsibility-driven design

• Question: where should we add a new

method (which class)?

• Each class should be responsible for

manipulating its own data.

• The class that owns the data should be

responsible for processing it.

• RDD leads to low coupling.

Localizing change

• One aim of reducing coupling and

responsibility-driven design is to localize change.

• When a change is needed, as few classes as

possible should be affected.

Programming 1 10/11/2005 Lecture 6: Well-behaved Objects and Designing Classes 7

Thinking ahead

• When designing a class, we try to think

what changes are likely to be made in the future.

• We aim to make those changes easy.

Refactoring

• When classes are maintained, often code is

added.

• Classes and methods tend to become longer.
• Every now and then, classes and methods

should be refactored to maintain cohesion and low coupling.

Refactoring and testing

• When refactoring code, separate the

refactoring from making other changes.

• First do the refactoring only, without

changing the functionality.

• Test before and after refactoring to ensure

that nothing was broken.

Design questions

Common questions:

• How long should a class be?
• How long should a method be?
• Can now be answered in terms of cohesion

and coupling.

Design guidelines

• A method is too long if it does more then
• ne logical task.
• A class is too complex if it represents more

than one logical entity.

• Note: these are guidelines - they still leave

much open to the designer.

Review

• Programs are continuously changed.
• It is important to make this change possible.
• Quality of code requires much more than

just performing correct at one time.

• Code must be understandable and

maintainable.

Programming 1 10/11/2005 Lecture 6: Well-behaved Objects and Designing Classes 8

Review

• Good quality code avoids duplication,

displays high cohesion, low coupling.

• Coding style (commenting, naming, layout,

etc.) is also important.

• There is a big difference in the amount of

work required to change poorly structured and well structured code.

Static Methods

• Previous we discussed class and object

level.

• We introduced class variables
• static keyword
• A similar thing can be done for methods

providing services for the class instead an

• bject

Static Methods (2)

public class StaticTest { static count = 0; public StaticTest { count++; } public static int giveCount() { return count; } … }

Executing without BlueJ

• If we want to start a Java application

without BlueJ, we need to use a class method.

• Java uses a class method with a specific

signature:

– public static void main(String args[]) – args contains the command line options for your application

Executing without BlueJ (2)

• Compiling

– javac className.java

• Running

– java className – java className command line options – but className should contain a main method

• BlueJ write its own main whenever you ask

it to execute something.

Concepts

• testing
• positive and negative

testing

• debugging
• unit testing
• regression testing
• walkthroughs
• responsibility-driven

design

• coupling
• cohesion
• refactoring
• static
• class methods
• main method

Programming 1 17/11/2005 Lecture 7: Inheritance 1

Improving structure with inheritance

Main concepts to be covered

• Inheritance
• Subtyping
• Substitution
• Polymorphic variables

The DoME example

"Database of Multimedia Entertainment"

• stores details about CDs and videos

– CD: title, artist, # tracks, playing time, got- it, comment – Video: title, director, playing time, got-it, comment

• allows (later) to search for information or

print lists

DoME objects

DoME classes

DoME object model

Programming 1 17/11/2005 Lecture 7: Inheritance 2

Class diagram

CD source code

public class CD { private String title; private String artist; private String comment; public CD(String theTitle, String theArtist) { title = theTitle; artist = theArtist; comment = " "; } void setComment(String newComment) { ... } String getComment() { ... } void print() { ... } ... }

incomplete (comments!)

[ ]

Video source code

public class Video { private String title; private String director; private String comment; public Video(String theTitle, String theDirect) { title = theTitle; director = theDirect; comment = " "; } void setComment(String newComment) { ... } String getComment() { ... } void print() { ... } ... }

incomplete (comments!)

[ ]

Database source code

Critique of DoME

• code duplication

– CD and Video classes very similar (large part are identical) – makes maintenance difficult/more work – introduces danger of bugs through incorrect maintenance

• code duplication also in Database class

Using inheritance

Programming 1 17/11/2005 Lecture 7: Inheritance 3

Using inheritance

• define one superclass : Item
• define subclasses for Video and CD
• the superclass defines common attributes
• the subclasses inherit the superclass

attributes

• the subclasses add own attributes

Inheritance hierarchies

Inheritance in Java

public class CD extends Item { ... } public class Video extends Item { ... }

no change here change here

Superclass

public class Item { private String title; private int playingTime; private boolean gotIt; private String comment; // constructors and methods omitted. }

Subclasses

public class CD extends Item { private String artist; private int numberOfTracks; // constructors and methods omitted. } public class Video extends Item { private String director; // constructors and methods omitted. }

public class Item { private String title; private int playingTime; private boolean gotIt; private String comment; /** * Initialise the fields of the item. */ public Item(String theTitle, int time) { title = theTitle; playingTime = time; gotIt = false; comment = ""; } // methods omitted }

Inheritance and constructors

Programming 1 17/11/2005 Lecture 7: Inheritance 4

Inheritance and constructors

public class CD extends Item { private String artist; private int numberOfTracks; /** * Constructor for objects of class CD */ public CD(String theTitle, String theArtist, int tracks, int time) { super(theTitle, time); artist = theArtist; numberOfTracks = tracks; } // methods omitted }

Superclass constructor call

• Subclass constructors must always contain

a 'super' call.

• If none is written, the compiler inserts one

(without parameters)

– works only, if the superclass has a constructor without parameters

• Must be the first statement in the subclass

constructor.

Adding more item types

Deeper hierarchies

Review (so far)

Inheritance (so far) helps with:

• Avoiding code duplication
• Code reuse
• Easier maintenance
• Extendibility

public class Database { private ArrayList items; /** * Construct an empty Database. */ public Database() { items = new ArrayList(); } /** * Add an item to the database. */ public void addItem(Item theItem) { items.add(theItem); } ... }

New Database source code

avoids code duplication in client!

Programming 1 17/11/2005 Lecture 7: Inheritance 5

/** * Print a list of all currently stored CDs and * videos to the text terminal. */ public void list() { for(Iterator iter = items.iterator(); iter.hasNext(); ) { Item item = (Item)iter.next(); item.print(); System.out.println(); // empty line between items } }

New Database source code

Subtyping

First, we had:

public void addCD(CD theCD) public void addVideo(Video theVideo)

Now, we have:

public void addItem(Item theItem)

We call this method with:

Video myVideo = new Video(...); database.addItem(myVideo);

Subclasses and subtyping

• Classes define types.
• Subclasses define subtypes.
• Objects of subclasses can be used where
• bjects of supertypes are required.

(This is called substitution .)

Subtyping and assignment

Vehicle v1 = new Vehicle(); Vehicle v2 = new Car(); Vehicle v3 = new Bicycle();

subclass objects may be assigned to superclass variables

Subtyping and parameter passing

public class Database { public void addItem(Item theItem) { ... } } Video video = new Video(...); CD cd = new CD(...); database.addItem(video); database.addItem(cd);

subclass objects may be passed to superclass parameters

Object diagram

Programming 1 17/11/2005 Lecture 7: Inheritance 6

Class diagram

Polymorphic variables

• Object variables in Java are polymorphic.

(They can hold objects of more than one type.)

• They can hold objects of the declared type,
• r of subtypes of the declared type.

The Object class

All classes inherit from Object.

Polymorphic collections

• All collections are polymorphic.
• The elements are of type Object.

public void add(Object element) public Object get(int index)

Casting revisited

• Can assign subtype to supertype.
• Cannot assign supertype to subtype!

String s1 = myList.get(1); error!

• Casting fixes this:

String s1 = (String) myList.get(1);

(only if the element really is a String!)

Wrapper classes

• All objects can be entered into collections...
• ...because collections accept elements of

type Object...

• ...and all classes are subtypes of Object.
• Great! But what about simple types?

Programming 1 17/11/2005 Lecture 7: Inheritance 7

Wrapper classes

• Simple types (int, char, etc) are not objects. They

must be wrapped into an object!

• Wrapper classes exist for all simple types:

simple type wrapper class int Integer float Float char Character ... ...

Wrapper classes

int i = 18; Integer iwrap = new Integer(i); myCollecton.add(iwrap); ... Integer element = (Integer) myCollection.get(0); int value = element.intValue()

wrap the int value add the wrapper retrieve the wrapper unwrap

Review

• Inheritance allows the definition of classes as

extensions of other classes.

• Inheritance

– avoids code duplication – allows code reuse – simplifies the code – simplifies maintenance and extending

• Variables can hold subtype objects.
• Subtypes can be used wherever supertype objects

are expected (substitution).

Concepts

• Inheritance
• Superclass
• Subclass
• Base Class
• Object
• Subtyping
• Type casting
• Polymorphic variables
• Inheritance

Hierarchies

Programming 1 24/12/2005 Lecture 8: More About Inheritance 1

More about inheritance

Exploring polymorphism

Main concepts to be covered

• method polymorphism
• static and dynamic type
• overriding
• dynamic method lookup
• protected access

The inheritance hierarchy

Conflicting output

What we want What we now have

The problem

• The print method in Item only prints the

common fields.

• Inheritance is a one-way street:

– A subclass inherits the superclass fields. – The superclass knows nothing about its subclass’s fields.

Attempting to solve the problem

• Place print where it has

access to the information it needs.

• Each subclass has its own

version.

• But Item’s fields are

private.

• Database cannot find a

print method in Item.

Programming 1 24/12/2005 Lecture 8: More About Inheritance 2

Static type and dynamic type

• A more complex type hierarchy requires

further concepts to describe it.

• Some new terminology:

– static type – dynamic type – method dispatch/lookup

Static and dynamic type

Car c1 = new Car();

What is the type of c1?

Vehicle v1 = new Car();

What is the type of v1?

Static and dynamic type

• The declared type of a variable is its static

type.

• The type of the object a variable refers to is

its dynamic type.

• The compiler’s job is to check for static-

type violations.

Item item = (Item) iter.next(); item.print(); // Compile-time error.

Overriding: the solution

print method in both super- and subclasses. Satisfies both static and dynamic type checking.

Overriding

• Superclass and subclass define methods

with the same signature.

• Each has access to the fields of its class.
• Superclass satisfies static type check.
• Subclass method is called at runtime – it
• verrides the superclass version.
• What becomes of the superclass version?

Method lookup

No inheritance or polymorphism. The obvious method is selected.

Programming 1 24/12/2005 Lecture 8: More About Inheritance 3

Method lookup

Inheritance but no overriding. The inheritance hierarchy is ascended, searching for a match.

Method lookup

Polymorphism and overriding. The ‘first’ version found is used.

Method lookup summary

• The variable is accessed.
• The object stored in the variable is found.
• The class of the object is found.
• The class is searched for a method match.
• If no match is found, the superclass is searched.
• This is repeated until a match is found, or the class

hierarchy is exhausted.

• Overriding methods take precedence.

Super call in methods

• Overridden methods are hidden ...
• ... but we often still want to be able to call

them.

• An overridden method can be called from

the method that overrides it.

– super.method(...) – Compare with the use of super in constructors.

Calling an overridden method

public class CD { ... public void print() { super.print(); System.out.println(" " + artist); System.out.println(" tracks: " + numberOfTracks); } ... }

Method polymorphism

• We have been discussing polymorphic

method dispatch.

• A polymorphic variable can store objects of

varying types.

• Method calls are polymorphic.

– The actual method called depends on the dynamic object type.

Programming 1 24/12/2005 Lecture 8: More About Inheritance 4

The Object class’s methods

• Methods in Object are inherited by all

classes.

• Any of these may be overridden.
• The toString method is commonly
• verridden:

– public String toString() – Returns a string representation of the object.

Overriding toString

public class Item { ... public String toString() { String line1 = title + " (" + playingTime + " mins)"); if(gotIt) { return line1 + "*\n" + " " + comment + "\n"); } else { return line1 + "\n" + " " + comment + "\n"); } } ... }

Overriding toString

• Explicit print methods can often be
• mitted from a class:

– System.out.println(item.toString());

• Calls to println with just an object

automatically result in toString being called:

– System.out.println(item);

Protected access

• Private access in the superclass may be too

restrictive for a subclass.

• The closer inheritance relationship is

supported by protected access.

• Protected access is more restricted than

public access.

• We still recommend keeping fields private.

– Define protected accessors and mutators.

Access levels

Review

• The declared type of a variable is its static type.

– Compilers check static types.

• The type of an object is its dynamic type.

– Dynamic types are used at runtime.

• Methods may be overridden in a subclass.
• Method lookup starts with the dynamic type.
• Protected access supports inheritance.

Programming 1 24/12/2005 Lecture 8: More About Inheritance 5

Concepts

• method polymorphism
• overriding
• dynamic method

lookup

• static types
• dynamic types
• super
• protected

Class Exercise

• Design a Local Area Network application. This

application consists of the following classes:

• Node, Workstation, Fileserver and Printserver, and

Packet.

• A Packet is an object transporting textual

information to a given LAN-element.

• A Workstation is a special Node in the sense that

it is the only one which can put Packets on the LAN.

Class Exercise (II)

• A Fileserver saves the contents of the Packets to a

file (which is created with the same name as the Fileserver with a .txt extension). The contents of the Packets should be put in file separated by '@'.

• A Printserver prints the contents of the Packet to

standard output.

• The LAN we are simulating is circular such that

Packets cannot drop off the LAN. This means that each LAN-element should keep a link to the next LAN-element.

Class Exercise (III)

• Any LAN-element should be able to stop a Packet.

Of course this can only be done if the Packet is addressed to it. Make sure that a Packet does not circle indefinitely.

• Design each of the classes: specify static and

instance fields and methods. Describe the purpose

• f all of those. If required, specify the inheritance

relationship between them. Were do you use polymorphism (if ever)?

Programming 1 01/12/2005 Lecture 9: Abstraction Techniques 1

Further abstraction techniques

Abstract classes and interfaces

Main concepts to be covered

• Abstract classes
• Interfaces
• Multiple inheritance

Simulations

• Programs regularly used to simulate real-world

activities.

– city traffic – the weather – nuclear processes – stock market fluctuations – environmental changes – LAN networks – animal behavior

Simulations

• They are often only partial simulations.
• They often involve simplifications.

– Greater detail has the potential to provide greater accuracy. – Greater detail typically requires more resources.

• Processing power.
• Simulation time.

Benefits of simulations

• Support useful prediction.

– The weather.

• Allow experimentation.

– Safer, cheaper, quicker.

• Example:

– ‘How will the wildlife be affected if we cut a highway through the middle of this national park?’

Predator-prey simulations

• There is often a delicate balance between

species.

– A lot of prey means a lot of food. – A lot of food encourages higher predator numbers. – More predators eat more prey. – Less prey means less food. – Less food means ...

Programming 1 01/12/2005 Lecture 9: Abstraction Techniques 2

The foxes-and-rabbits project

Main classes of interest

• Fox

– Simple model of a type of predator.

• Rabbit

– Simple model of a type of prey.

• Simulator

– Manages the overall simulation task. – Holds a collection of foxes and rabbits.

The remaining classes

• Field

– Represents a 2D field.

• Location

– Represents a 2D position.

• SimulatorView, FieldStats,

Counter

– Maintain statistics and present a view

• f the field.

Example of the visualization

A Rabbit’s state

A Rabbit’s state

// Individual characteristics (instance fields). // The rabbit's age. private int age; // Whether the rabbit is alive or not. private boolean alive; // The rabbit's position private Location location;

Programming 1 01/12/2005 Lecture 9: Abstraction Techniques 3

A Rabbit’s behavior

• Managed from the run method.
• Age incremented at each simulation ‘step’.

– A rabbit could die at this point.

• Rabbits that are old enough might breed at

each step.

– New rabbits could be born at this point.

A Rabbit’s behavior

public Rabbit(boolean randomAge){…} public void run(Field updatedField, List newRabbits) { incrementAge(); if(alive) { int births = breed(); for(int b = 0; b < births; b++) { Rabbit newRabbit = new Rabbit(false); newRabbits.add(newRabbit); Location loc = updatedField.randomAdjacentLocation(location); newRabbit.setLocation(loc); updatedField.place(newRabbit, loc); }

A Rabbit’s behavior

Location newLocation = updatedField.freeAdjacentLocation(location); // Only transfer to the updated field if //there was a free location if(newLocation != null) { setLocation(newLocation); updatedField.place(this, newLocation); } else { // can neither move nor stay – //overcrowding - all locations taken alive = false; }}}

A Rabbit’s behavior

Rabbit simplifications

• Rabbits do not have different genders.

– In effect, all are female.

• The same rabbit could breed at every step.
• All rabbits die at the same age.

A Fox’s state

public class Fox { Static fields omitted // The fox's age. private int age; // Whether the fox is alive or not. private boolean alive; // The fox's position private Location location; // The fox's food level, which is increased // by eating rabbits. private int foodLevel; Methods omitted. }

Programming 1 01/12/2005 Lecture 9: Abstraction Techniques 4

A Fox’s behavior

• Managed from the hunt method.
• Foxes also age and breed.
• They become hungry.
• They hunt for food in adjacent locations.

A Fox’s behavior

public void hunt(Field currentField, Field updatedField, List newFoxes) { incrementAge(); incrementHunger(); if(isAlive()) { // New foxes are born into adjacent locations. int births = breed(); for(int b = 0; b < births; b++) { Fox newFox = new Fox(false); newFoxes.add(newFox); Location loc = updatedField.randomAdjacentLocation(location); newFox.setLocation(loc); updatedField.place(newFox, loc); }

A Fox’s behavior

A Fox’s behavior

private Location findFood(Field field, Location location) { Iterator adjacentLocations = field.adjacentLocations(location); while(adjacentLocations.hasNext()) { Location where = (Location) adjacentLocations.next(); Object animal = field.getObjectAt(where); if(animal instanceof Rabbit) { Rabbit rabbit = (Rabbit) animal; if(rabbit.isAlive()) { rabbit.setEaten(); foodLevel = RABBIT_FOOD_VALUE; return where; }}} return null; }

Configuration of foxes

• Similar simplifications to rabbits.
• Hunting and eating could be modeled in

many different ways.

– Should food level be additive? – Is a hungry fox more or less likely to hunt?

• Are simplifications ever acceptable?

The Simulator class

• Three key components:

– Setup in the constructor. – The populate method.

• Each animal is given a random starting age.

– The simulateOneStep method.

• Iterates over the population.
• Two Field objects are used: field and

updatedField.

Programming 1 01/12/2005 Lecture 9: Abstraction Techniques 5

The update step

public class Simulator { … public void simulateOneStep() { step++; newAnimals.clear(); // let all animals act for(Iterator iter = animals.iterator(); iter.hasNext(); ) { Object animal = iter.next();

The update step

if(animal instanceof Rabbit) { Rabbit rabbit = (Rabbit)animal; if(rabbit.isAlive()) { rabbit.run(updatedField, newAnimals); } else { iter.remove(); } } else if(animal instanceof Fox) { Fox fox = (Fox)animal; if(fox.isAlive()) { fox.hunt(field, updatedField, newAnimals); } else { iter.remove(); } }

Instanceof

• Checking an object’s dynamic type

– obj instanceof Myclass

• General not considered good practice
• Make code to depend on the exact type of
• bjects.
• The usage of instanceof is an indicator of

refactoring

Room for improvement

• Fox and Rabbit have strong similarities

but do not have a common superclass.

• The Simulator is tightly coupled to the

specific classes.

– It ‘knows’ a lot about the behavior of foxes and rabbits.

The Animal superclass

• Place common fields in Animal:

– age, alive, location

• Method renaming to support

information hiding:

– run and hunt become act.

• Simulator can now be significantly

decoupled.

Revised (decoupled) iteration

for(Iterator iter = animals.iterator(); iter.hasNext(); ) { Animal animal = (Animal)iter.next(); if(animal.isAlive()) { animal.act(field, updatedField, newAnimals); } else { iter.remove(); } }

Programming 1 01/12/2005 Lecture 9: Abstraction Techniques 6

The act method of Animal

• Static type checking requires an act

method in Animal.

• There is no obvious shared implementation.
• Define act as abstract:

abstract public void act(Field currentField, Field updatedField, List newAnimals);

Abstract classes and methods

• Abstract methods have abstract in the

signature.

• Abstract methods have no body.
• Abstract methods make the class abstract.
• Abstract classes cannot be instantiated.
• Concrete subclasses complete the

implementation.

The Animal class

public abstract class Animal { fields omitted /** * Make this animal act - that is: make it do * whatever it wants/needs to do. */ abstract public void act(Field currentField, Field updatedField, List newAnimals);

• ther methods omitted

}

More abstract methods

public boolean canBreed() { return age >= getbreedingAge() } abstract public int getBreedingAge();

• Note: fields are handled differently from methods in Java:

they cannot be overridden by subclass version

– both Rabbit and Fox have their own static field BREEDING_AGE and Animal has none.

Further abstraction

Selective drawing (multiple inheritance)

// let all animals act for(Iterator iter = actors.iterator(); iter.hasNext();) { Actor actor = (Actor) iter.next(); actor.act(…); } for(Iterator iter = drawables.iterator(); iter.hasNext();) { Drawable item = (Drawable) iter.hasNext(); item.draw(…); }

Programming 1 01/12/2005 Lecture 9: Abstraction Techniques 7

Selective drawing (multiple inheritance)

Multiple inheritance

• Having a class inherit directly from multiple

ancestors.

• Each language has its own rules.

– How to resolve competing definitions?

• Java forbids it for classes.
• Java permits it for interfaces.

– No competing implementation.

An Actor interface

public interface Actor { /** * Perform the actor's daily behavior. * Transfer the actor to updatedField if it is * to participate in further steps of the simulation. * @param currentField The current state of the field. * @param location The actor's location in the field. * @param updatedField The updated state of the field. */ void act(Field currentField, Location location, Field updatedField); }

Interfaces

• A Java interface is a specification of a type (in the

form of a type name and methods) that does not define any implementation of methods

• uses interface instead of class
• all methods are public (no need to mention)
• all methods are abstract (no need to mention)
• no constructors
• all constant fields are allowed (public static final)

Classes implement an interface

public class Fox extends Animal implements Drawable { ... } public class Hunter implements Actor, Drawable { ... }

Interfaces as types

• Implementing classes do not inherit code,

but ...

• ... implementing classes are subtypes of the

interface type.

• So, polymorphism is available with

interfaces as well as classes.

Programming 1 01/12/2005 Lecture 9: Abstraction Techniques 8

Interfaces as specifications

• Strong separation of functionality from

implementation.

– Though parameter and return types are mandated.

• Clients interact independently of the

implementation.

– But clients can choose from alternative implementations.

Alternative implementations

Review

• Inheritance can provide shared

implementation.

– Concrete and abstract classes.

• Inheritance provides shared type

information.

– Classes and interfaces.

Review

• Abstract methods allow static type checking

without requiring implementation.

• Abstract classes function as incomplete

superclasses.

– No instances.

• Abstract classes support polymorphism.

Interfaces

• Interfaces provide specification without

implementation.

– Interfaces are fully abstract.

• Interfaces support polymorphism.
• Java interfaces support multiple inheritance.

Concepts

• abstract class
• interfaces
• instanceof

Programming 1 08/12/2005 Lecture 10: Handling Errors 1

Handling errors

Writing robust code

Main concepts to be covered

• Defensive programming.

– Anticipating that things could go wrong.

• Exception handling and throwing.
• Error reporting.
• Simple file processing.

Some causes of error situations

• Incorrect implementation.

– Does not meet the specification.

• Inappropriate object request.

– E.g., invalid index.

• Inconsistent or inappropriate object state.

– E.g. arising through class extension.

Not always programmer error

• Errors often arise from the environment:

– Incorrect URL entered. – Network interruption.

• File processing is particular error-prone:

– Missing files. – Lack of appropriate permissions.

Exploring errors

• Explore error situations through the

address-book projects.

• Two aspects:

– Error reporting. – Error handling.

Defensive programming

• Client-server interaction.

– Should a server assume that clients are well- behaved? – Or should it assume that clients are potentially hostile?

• Significant differences in implementation

required.

Programming 1 08/12/2005 Lecture 10: Handling Errors 2

Issues to be addressed

• How much checking by a server on method

calls?

• How to report errors?
• How can a client anticipate failure?
• How should a client deal with failure?

An example

• Create an AddressBook object.
• Try to remove an entry.
• A runtime error results.

– Whose ‘fault’ is this?

• Anticipation and prevention are preferable

to apportioning blame.

Argument values

• Arguments represent a major ‘vulnerability’

for a server object.

– Constructor arguments initialize state. – Method arguments often contribute to behavior.

• Argument checking is one defensive

measure.

Checking the key

public void removeDetails(String key) { if(keyInUse(key)) { ContactDetails details = (ContactDetails) book.get(key); book.remove(details.getName()); book.remove(details.getPhone()); numberOfEntries--; } }

Server error reporting

• How to report illegal arguments?

– To the user?

• Is there a human user?
• Can they solve the problem?

– To the client object?

• Return a diagnostic value.
• Throw an exception.

Returning a diagnostic

public boolean removeDetails(String key) { if(keyInUse(key)) { ContactDetails details = (ContactDetails) book.get(key); book.remove(details.getName()); book.remove(details.getPhone()); numberOfEntries--; return true; } else { return false; } }

Programming 1 08/12/2005 Lecture 10: Handling Errors 3

Client responses

• Test the return value.

– Attempt recovery on error. – Avoid program failure.

• Ignore the return value.

– Cannot be prevented. – Likely to lead to program failure.

• Exceptions are preferable.

Exception-throwing principles

• A special language feature.
• No ‘special’ return value needed.
• Errors cannot be ignored in the client.

– The normal flow-of-control is interrupted.

• Specific recovery actions are encouraged.

Throwing an exception

/** * Look up a name or phone number and return the * corresponding contact details. * @param key The name or number to be looked up. * @return The details corresponding to the key, * or null if there are none matching. * @throws NullPointerException if the key is null. */ public ContactDetails getDetails(String key) { if(key == null){ throw new NullPointerException( "null key in getDetails"); } return (ContactDetails) book.get(key); }

Throwing an exception

• An exception object is constructed:

– new ExceptionType("...");

• The exception object is thrown:

– throw ...

• Javadoc documentation:

– @throws ExceptionType reason

The exception class hierarchy

Exception categories

• Checked exceptions

– Subclass of Exception – Use for anticipated failures. – Where recovery may be possible.

• Unchecked exceptions

– Subclass of RuntimeException – Use for unanticipated failures. – Where recovery is unlikely.

Programming 1 08/12/2005 Lecture 10: Handling Errors 4

The effect of an exception

• The throwing method finishes prematurely.
• No return value is returned.
• Control does not return to the client’s point
• f call.

– So the client cannot carry on regardless.

• A client may ‘catch’ an exception.

Unchecked exceptions

• Use of these is ‘unchecked’ by the

compiler.

• Cause program termination if not caught.

– This is the normal practice.

• IllegalArgumentException is a

typical example.

Argument checking

public ContactDetails getDetails(String key) { if(key == null) { throw new NullPointerException( "null key in getDetails"); } if(key.trim().length() == 0) { throw new IllegalArgumentException( "Empty key passed to getDetails"); } return (ContactDetails) book.get(key); }

Preventing object creation

Exception handling

• Checked exceptions are meant to be caught.
• The compiler ensures that their use is tightly

controlled.

– In both server and client.

• Used properly, failures may be recoverable.

The throws clause

• Methods throwing a checked exception

must include a throws clause:

public void saveToFile(String destinationFile) throws IOException

Programming 1 08/12/2005 Lecture 10: Handling Errors 5

The try block

• Clients catching an exception must protect

the call with a try block:

try { Protect one or more statements here. } catch(Exception e) { Report and recover from the exception here. }

The try block

try{ addressbook.saveToFile(filename); tryAgain = false; } catch(IOException e) { System.out.println("Unable to save to " + filename); tryAgain = true; }

• 1. Exception thrown from here
• 2. Control transfers to here

Catching multiple exceptions

try { ... ref.process(); ... } catch(EOFException e) { // Take action on an end-of-file exception. ... } catch(FileNotFoundException e) { // Take action on a file-not-found exception. ... }

The finally clause

try { Protect one or more statements here. } catch(Exception e) { Report and recover from the exception here. } finally { Perform any actions here common to whether or not an exception is thrown. }

The finally clause

• A finally clause is executed even if a return

statement is executed in the try or catch clauses.

• A uncaught or propagated exception still

exits via the finally clause.

Defining new exceptions

• Extend Exception or Runtime-

Exception.

• Define new types to give better diagnostic

information.

– Include reporting and/or recovery information.

Programming 1 08/12/2005 Lecture 10: Handling Errors 6

public class NoMatchingDetailsException extends Exception { private String key; public NoMatchingDetailsException(String key) { this.key = key; } public String getKey() { return key; } public String toString() { return "No details matching '" + key + "' were found."; } }

Error recovery

• Clients should take note of error

notifications.

– Check return values. – Don’t ‘ignore’ exceptions.

• Include code to attempt recovery.

– Will often require a loop.

Attempting recovery

Error avoidance

• Clients can often use server query methods

to avoid errors.

– More robust clients mean servers can be more trusting. – Unchecked exceptions can be used. – Simplifies client logic.

• May increase client-server coupling.

Text input-output

• Input-output is particularly error-prone.

– It involves interaction with the external environment.

• The java.io package supports input-
• utput.
• java.io.IOException is a checked

exception.

Readers, writers, streams

• Readers and writers deal with textual input.

– Based around the char type.

• Streams deal with binary data.

– Based around the byte type.

• The address-book-io project illustrates

textual IO.

Programming 1 08/12/2005 Lecture 10: Handling Errors 7

Text output

• Use the FileWriter class.

– Open a file. – Write to the file. – Close the file.

• Failure at any point results in an

IOException.

Text output

try { FileWriter writer = new FileWriter("name of file"); while(there is more text to write) { ... writer.write(next piece of text); ... } writer.close(); } catch(IOException e) { something went wrong with accessing the file }

Text input

• Use the FileReader class.
• Augment with BufferedReader for

line-based input.

– Open a file. – Read from the file. – Close the file.

• Failure at any point results in an

IOException.

Text input

Review

• Runtime errors arise for many reasons.

– An inappropriate client call to a server object. – A server unable to fulfill a request. – Programming error in client and/or server.

Review

• Runtime errors often lead to program

failure.

• Defensive programming anticipates errors –

in both client and server.

• Exceptions provide a reporting and recovery

mechanism.

Programming 1 08/12/2005 Lecture 10: Handling Errors 8

Concepts

• try
• catch
• throw
• finally
• Defensive

programming

• Exception
• Error
• Reader
• Writer
• Streams

Programming 1 15/12/2005 Lecture 11: Designing Applications 1

Designing applications

Software Engineering from a Code Perspective

Main concepts to be covered

• Discovering classes
• CRC cards
• Designing interfaces
• Patterns

Analysis and design

• A large and complex area.
• The verb/noun method is suitable for

relatively small problems.

• CRC cards support the design process.

The verb/noun method

• The nouns in a description refer to ‘things’.

– A source of classes and objects.

• The verbs refer to actions.

– A source of interactions between objects. – Actions are behavior, and hence methods.

A problem description

The cinema booking system should store seat bookings for multiple theatres. Each theatre has seats arranged in rows. Customers can reserve seats and are given a row number and seat number. They may request bookings of several adjoining seats. Each booking is for a particular show (i.e., the screening of a given movie at a certain time). Shows are at an assigned date and time, and scheduled in a theatre where they are screened. The system stores the customers’ telephone number.

Nouns and verbs

Cinema booking system Stores (seat bookings) Stores (telephone number) Seat booking Theatre Has (seats) Seat Row Customer Reserves (seats) Is given (row number, seat number) Requests (seat booking) Row number Seat number Show Is scheduled (in theatre) Movie Date Time Telephone number

Programming 1 15/12/2005 Lecture 11: Designing Applications 2

Using CRC cards

• First described by Kent Beck and Ward

Cunningham.

• Each index cards records:

– A class name. – The class’s responsibilities. – The class’s collaborators.

A CRC card

Class name Collaborators Responsibilities

A partial example

CinemaBookingSystem Collaborators Can find shows by Show title and day. Stores collection of Collection shows. Retrieves and displays show details. ...

Scenarios

• An activity that the system has to carry out
• r support.

– Sometimes known as use cases.

• Used to discover and record object

interactions (collaborations).

• Can be performed as a group activity.

Scenarios as analysis

• Scenarios serve to check the problem

description is clear and complete.

• Sufficient time should be taken over the

analysis.

• The analysis will lead into design.

– Spotting errors or omissions here will save considerable wasted effort later.

Class design

• Scenario analysis helps to clarify

application structure.

– Each card maps to a class. – Collaborations reveal class cooperation/object interaction.

• Responsibilities reveal public methods.

– And sometimes fields; e.g. “Stores collection ...”

Programming 1 15/12/2005 Lecture 11: Designing Applications 3

Designing class interfaces

• Replay the scenarios in terms of method

calls, parameters and return values.

• Note down the resulting signatures.
• Create outline classes with public-method

stubs.

• Careful design is a key to successful

implementation.

Documentation

• Write class comments.
• Write method comments.
• Describe the overall purpose of each.
• Documenting now ensures that:

– The focus is on what rather than how. – That it doesn’t get forgotten!

Cooperation

• Team-working is likely to be the norm not

the exception.

• Documentation is essential for team

working.

• Clean O-O design, with loosely-coupled

components, also supports cooperation.

Prototyping

• Supports early investigation of a system.

– Early problem identification.

• Incomplete components can be simulated.

– E.g. always returning a fixed result. – Avoid random behavior which is difficult to reproduce.

Software growth

• Waterfall model.

– Analysis – Design – Implementation – Unit testing – Integration testing – Delivery

• No provision for iteration.

Iterative development

• Use early prototyping.
• Frequent client interaction.
• Iteration over:

– Analysis – Design – Prototype – Client feedback

• A growth model is the most realistic.

Programming 1 15/12/2005 Lecture 11: Designing Applications 4

Using design patterns

• Inter-class relationships are important, and

can be complex.

• Some relationship recur in different

applications.

• Design patterns help clarify relationships,

and promote reuse.

Pattern structure

• A pattern name.
• The problem addressed by it.
• How it provides a solution:

– Structures, participants, collaborations.

• Its consequences.

– Results, trade-offs.

Decorator

• Augments the functionality of an object.
• Decorator object wraps another object.

– The Decorator has a similar interface. – Calls are relayed to the wrapped object ... – ... but the Decorator can interpolate additional actions.

• Example: java.io.BufferedReader

– Wraps and augments an unbuffered Reader object.

Singleton

• Ensures only a single instance of a class

exists.

– All clients use the same object.

• Constructor is private to prevent external

instantiation.

• Single instance obtained via a static

getInstance method.

• Example: Canvas in shapes project.

Factory method

• A creational pattern.
• Clients require an object of a particular

interface type or superclass type.

• A factory method is free to return an

implementing-class object or subclass

• bject.
• Exact type returned depends on context.
• Example: iterator methods of the

Collection classes.

Observer

• Supports separation of internal model from

a view of that model.

• Observer defines a one-to-many

relationship between objects.

• The object-observed notifies all Observers
• f any state change.
• Example SimulatorView in the foxes-

and-rabbits project.

Programming 1 15/12/2005 Lecture 11: Designing Applications 5

Observers

Review

• Class collaborations and object interactions

must be identified.

– CRC analysis supports this.

• An iterative approach to design, analysis

and implementation can be beneficial.

– Regard software systems as entities that will grow and evolve over time.

Review

• Work in a way that facilitates collaboration

with others.

• Design flexible, extendible class structures.

– Being aware of existing design patterns will help you to do this.

• Continue to learn from your own and
• thers’ experiences.

A case study

Whole-application development

The case study

• A taxi company is considering expansion.

– It operates taxis and shuttles.

• Will expansion be profitable?
• How many vehicles will they need?

The problem description

The company operates both individual taxis and shuttles. The taxis are used to transport an individual (or small group) from one location to another. The shuttles are used to pick up individuals from different locations and transport them to their several destinations. When the company receives a call from an individual, hotel, entertainment venue, or tourist organization, it tries to schedule a vehicle to pick up the fare. If it has no free vehicles, it does not operate any form of queuing system. When a vehicle arrives at a pick-up location, the driver notifies the company. Similarly, when a passenger is dropped off at their destination, the driver notifies the company.

Programming 1 15/12/2005 Lecture 11: Designing Applications 6

Amendments

• Purpose of the modeling suggests additions:

– Record details of lost fares. – Record details of how each vehicle passes its time.

• These issues will help assess potential

profitability.

Discovering classes

• Singular nouns: company, taxi, shuttle,

individual, location, destination, hotel, entertainment venue, tourist organization, vehicle, fare, pickup location, driver, passenger.

• Identify synonyms.
• Eliminate superfluous detail.

Simplified nouns and verbs

Company Operates taxis. Receives calls. Schedules a vehicle. Taxi Transports a passenger. Shuttle Transports one or more passengers. Passenger Location Vehicle Pick up individual. Arrives at pickup location. Notifies company of arrival. Notifies company of drop-off. Passenger source Calls the company.

Scenarios

• Follow a pickup through from request to

drop off with CRC cards.

PassengerSource Collaborators Create a passenger. Passenger Request a taxi. TaxiCompany Generate pickup and Location destination.

Designing class interfaces

public class PassengerSource { /** * Have the source generate a new passenger and * request a pickup from the company. * @return true If the request succeeds, * false otherwise. */ public boolean requestPickup(); /** * Create a new passenger. * @return The created passenger. */ private Passenger createPassenger(); }

Collaborators

• Received through a constructor:

new PassengerSource(taxiCompany)

• Received through a method:

taxiCompany.requestPickup(passenger)

• Constructed within the object.

– Taxi company’s vehicle collection. – Some such objects may be passed as collaborators to other objects, as above.

Programming 1 15/12/2005 Lecture 11: Designing Applications 7

Outline implementation

• Once the interfaces are complete, the
• utline implementation can start.
• The outline implementation tests the

adequacy of the interfaces.

– Expect to have to correct the design.

• Lay down some basic tests that will be

repeated as development continues.

Iterative development

• Take relatively small steps towards the

completion of the overall application.

• Mark the end of each step with a period of

testing.

– Regression test. – Fix errors early. – Revisit earlier design decisions, if necessary. – Treat errors-found as successes.

Review

• Robust software requires thoughtful

processes to be followed with integrity.

– Analyze carefully. – Specify clearly. – Design thoroughly. – Implement and test incrementally. – Review, revise and learn. Nobody’s perfect!

• ⑧

• ❡❍⑤⑦♦✜❡❍✐➂✈✠❾❭✈✠❤❥⑥✞✈✝♥

• ✚

• ⑧

• ❷➆❤✠s✔♦❢❡❥❺❂❁❃☞✞④❦⑤✞②❋♠①③✞✈➅✈✝♥①♥①❡❥♥✠⑧

• ❤❥⑤

• ✜

• ❤❥⑤

• ✜

• ✜

• ❡❍⑤⑦♦♣④❦⑥✞✈✝♥❻♠①③✞✈✍❺

• ❋❅

• ■❅❑❏✲▲✝✮✟☛❘❏

• ■❅

• ■❅❑❏▼▲

• ■❅❑❏▼▲
