CLASYS

WORK HOLDING SOLUTIONS FOR ANY APPLICATION CLAMPING SOLUTIONS

OBJECTIVE

TO Highlight : Our variety of Products Range in each Product group Advantages of our Products

Customer Requirements

Quality Product Performance Good Service Value for Money

Customer Satisfaction Quality Value Service

Meeting the Needs

Swing cyl Block Cyl Work supp Link Clamp Th body cy l Compact c Collet Vice Valves & Ac

Block Cylinders

Pusher Type Cylinders Sizes ranging from Ø20,25,32,42,50,63 with different strokes. Male & Female threaded endings for piston available. Pressure range- 1-15 Mpa. Special bore and stroke sizes taken upon Customer request

Swing Cylinders

HORIZONTAL swing clamp cylinders Sizes ranging from Ø25,32,42,50,63&72 Single & Dual clamp options available Self Locking Taper for clamp arm Pressure Range: 1.5 to 12 Mpa. Option for Internal Piping available Special bore and stroke sizes taken

Swing Cylinders

HORIZONTAL swing clamp cylinders Sizes ranging from Ø25,32,42,50,63&72 Different type of Piston E ndings allow for Single and Dual Clamp Loading Self Locking Taper for clamp arm Pressure Range: 1.5 to 12 Mpa. Option for Internal Piping available Special bore and stroke sizes taken

Link Clamp Cylinders

Vertical Swing Type Cylinders Size range varying from Ø20,25,32,42,50 63,72,80 &100 Varied stroke range is available Pressure Range : 1 to 15 Mpa Option for Internal Piping available Special bore and stroke sizes taken

• n customer request.

Work Support

Flange Mounting Type & Threaded body Size range varying from Ø40,48,55,65,75,90 & M26,M30,M36,M45 Varied stroke range Pressure Range : 1.5 to 7 Mpa Special Models developed for Fixture applications.

Threaded Body Cylinder

Manifold Mounted cylinders Standard Range : M20,M24,M30,M36,M45,M55, M65 & M80 Male & Female piston endings available Stroke Range : 6,10,16,20,25,32 & 40mm Pressure Range : 1 - 15 Mpa

Valves & Accessories

Flow Control Valve: In Cylinder mounting Flow capacity of 10-12 lpm Compact Design & Mounting Sequence valve Pressure Range : 1 - 15Mpa Manifolds for different applications are available DPCV Pressure Range : 1 -15 Mpa Compact Mounting

Collet Vice

Pull down type clamping Collet Range from dia 01 to 26 Pressure Range : 1 - 10 Mpa Threaded locking of collet to body Spring return for collet Tenon Mounting to Fixture Plate

Compact Cylinder

Compact Design E asy Mounting Double Acting Std Range : 45, 55, 65, 75, 95 Pressure Range : 1 - 15 Mpa Stroke Range : 5-20 mm

Power pack

M/s Subros, Noida M/s Continental Engines, Bhiwadi M/s Amtek , Daruheda M/s OCAP, Bhiwadi M/s Amtek, Gurgaon M/s SPM Autocomp, Manesar M/s RIMACO Auto, Ghaziabad M/s Agrasen Engg, Jaipur M/s M&M, Mumbai M/s Ashok Iron Works, Belagaum M/s Prakash Home Inds,Belagaum M/s BOSCH Ltd., Bangalore M/s TVS Motor Co, Hosur M/s Metrix Precision,Bidadi M/s AMS, Bangalore M/s CNC India, Bangalore M/s Batliboi, Bangalore M/s Distinct Products,Bangalore M/s Abhiyant Systems,Bangalore M/s Craftsmann, Coimbatore M/s CRI Pumps, Coimbatore M/s ISML, Coimbatore M/s SACL, Erode M/s MahleMigma M/s Avtec Ltd M/s Amtek Auto Ltd., Pune M/s Jayahind, Pune M/s Johndeere, Pune M/s RSB Transmissions, Pune M/s Endurance, Pune M/s Makino, Pune M/s Kalyani Forge,Pune M/s Royal Enfield, Chennai M/s TAFE, Sembium M/s Wabco TVS, M/s UCAL Machine Tools M/s Supreme Automech, Pondicherry M/s UCAL Fuel, Chennai M/s Brakes India,Chennai M/s Classic Engineering, Chennai M/s TATA Motors M/s RSB Transmissions M/s RamKrishna forgings M/s TATA Cummins

Our Esteemed Customers Customers

FUTURE PLANS

Bore clamping cylinder Low block cylinder Oil-Oil booster Pneumatic Range Pressure Reducing valve

Key Benefits

Quality Product Good Performance International Standards Value For Money 1-1 Replacement Easy to Use Excellent Service back up
