City of Kansas City AI RPORT COMMI TTEE BRI EFI NG New Terminal Evaluation for Kansas City I nternational Airport March 15, 2016 1 Agenda Process Overview Establishing Requirements & Identifying Issues Forecast

slide-1
SLIDE 1

City of Kansas City AI RPORT COMMI TTEE BRI EFI NG New Terminal Evaluation for Kansas City I nternational Airport

March 15, 2016

1

slide-2
SLIDE 2
  • Process Overview
  • Establishing Requirements & Identifying Issues
  • Forecast
  • Airside
  • Terminal
  • Landside
  • New Terminal Concepts
  • Evaluation Process
  • Questions & Discussion

Agenda

2

slide-3
SLIDE 3
  • Developed a non-political and methodical process to evaluate both

Major Renovation and New Terminal options which was defined in Exhibit K of the Lease Agreement

  • Established Leadership Committee made up of KCAD and Airline

representatives

  • Revisited future Aviation Demand for the Kansas City market
  • Established facility requirements based on that future demand
  • Workshops included Airlines, KCAD staff, airline and airport subject

matter experts, and planning team consultants

Process Overview

3

slide-4
SLIDE 4

Establishing Requirements & Identifying Issues 3Q2014 to 4Q2014

4

slide-5
SLIDE 5

Improving KCI

Customer Convenience Affordability Efficiency

Technology

Right- Sized Flexibility Construct- ability

Program Objectives

5

slide-6
SLIDE 6

Workshops

  • Aviation Demand Forecasting
  • Airside Programming
  • Terminal Requirements
  • Landside Requirements

Establishing Requirements

6

slide-7
SLIDE 7

Forecast Results

7

slide-8
SLIDE 8

Forecast Results

8

slide-9
SLIDE 9

Forecast Results

9

Courtesy: Leigh Fisher

slide-10
SLIDE 10

Airside Program Requirements

  • 35 Gates (Design Aircraft B737-900/A321)
  • 31 Airline Gates
  • 4 City Gates (internationally capable allowing for two dependent widebodies)
  • 7 Gates and core processors for future expansion (Total of 42 gates)
  • Requirement for 19 remain overnight aircraft parking positions
  • Eliminate aircraft movement conflicts
  • Upgrade deicing facilities and operation

Airside Program Highlights

10

slide-11
SLIDE 11

Eliminate Aircraft Movement Conflicts

Terminal B Terminal C

Terminal A

Closed

Airside Program Highlights

11 Building Restriction Line Pushback Conflict Area

slide-12
SLIDE 12

Eliminate Aircraft Movement Conflicts

Airside Program Highlights

12 Building Restriction Line Taxiway Conflict Area

Terminal B Terminal C

slide-13
SLIDE 13

Flexibility to Accommodate Aircraft Mix

Airside Program Highlights

13

Courtesy: KCAD

slide-14
SLIDE 14

Terminal Program Requirements & Existing I ssues

Curbside Ticket Lobby Baggage Handling System Security Screening Checkpoint (SSCP) Holdrooms Concessions Baggage Claim International Arrivals Facility

Terminal Program Highlights

14

slide-15
SLIDE 15

Curbside

Terminal Program Highlights

15

Courtesy: KCAD

slide-16
SLIDE 16

Curbside

Terminal Program Highlights

16

Courtesy: KCAD

slide-17
SLIDE 17

Curbside

Terminal Program Highlights

17

Courtesy: KCAD

slide-18
SLIDE 18

Curbside

Terminal Program Highlights

18

Courtesy: KCAD

slide-19
SLIDE 19

Curbside

Terminal Program Highlights

19

Courtesy: KCAD

slide-20
SLIDE 20

Ticket Lobby

Terminal Program Highlights

20

Courtesy: KCAD

slide-21
SLIDE 21

Ticket Lobby

Terminal Program Highlights

21

Photo: Jill Toyoshiba, The Kansas City Star

slide-22
SLIDE 22

Outbound Baggage System

Terminal Program Highlights

22

Courtesy: KCAD

slide-23
SLIDE 23

Outbound Baggage Systems

Terminal Program Highlights

23

Photo: Allison Long, The Kansas City Star

slide-24
SLIDE 24

Outbound Baggage Systems

Terminal Program Highlights

24

Courtesy: KCAD

slide-25
SLIDE 25

Outbound Baggage System

Terminal Program Highlights

25

Courtesy: American Airlines (3/ 5/ 16)

slide-26
SLIDE 26

Outbound Baggage System

Terminal Program Highlights

26

Courtesy: American Airlines (3/ 5/ 16)

slide-27
SLIDE 27

Airside Program Highlights

27

Security Screening Checkpoint

slide-28
SLIDE 28

Security Screening Checkpoint

Terminal Program Highlights

28

Courtesy: KCAD

slide-29
SLIDE 29

Security Screening Checkpoint

Terminal Program Highlights

29

Courtesy: KCAD

slide-30
SLIDE 30

Security Screening Checkpoint

Terminal Program Highlights

30

Courtesy: KCAD

slide-31
SLIDE 31

Holdrooms

Terminal Program Highlights

31

Courtesy: KCAD

slide-32
SLIDE 32

Holdrooms

Terminal Program Highlights

32

Courtesy: American Airlines (3/ 5/ 16)

slide-33
SLIDE 33

Holdrooms

Terminal Program Highlights

33

Courtesy: American Airlines

slide-34
SLIDE 34

Holdrooms

Terminal Program Highlights

34

Courtesy: KCAD

slide-35
SLIDE 35

Holdrooms

Terminal Program Highlights

35

Courtesy: KCAD

slide-36
SLIDE 36

Holdrooms

Terminal Program Highlights

36

Courtesy: KCAD

slide-37
SLIDE 37

Holdrooms

Terminal Program Highlights

37

Courtesy: KCAD

slide-38
SLIDE 38

Holdroom Restrooms

Terminal Program Highlights

38

Courtesy: KCAD

slide-39
SLIDE 39

Concessions

Terminal Program Highlights

39

Courtesy: KCAD

slide-40
SLIDE 40

Concessions

Terminal Program Highlights

40

Courtesy: KCAD

slide-41
SLIDE 41

Concessions

Terminal Program Highlights

41

Courtesy: KCAD

slide-42
SLIDE 42

Concessions

Terminal Program Highlights

42

Courtesy: KCAD

slide-43
SLIDE 43

Baggage Claim

Terminal Program Highlights

43

Courtesy: KCAD

slide-44
SLIDE 44

Baggage Claim

Terminal Program Highlights

44

Courtesy: KCAD

slide-45
SLIDE 45

Airside Program Highlights

45

I nternational Arrivals

slide-46
SLIDE 46

I nternational Arrivals

Terminal Program Highlights

46

Courtesy: KCAD

slide-47
SLIDE 47

Post-Security Space Undersized by Nearly One-Half Pre-Security Space Nearly 3x Amount Needed

Existing* Requirements Gates 29 35

Ticketing/Check-in 20,879 32,000 Security Checkpoint 29,951 18,640 Departure Lounges 100,281 81,600 Post-Security Departure Corridor 95,540 Post-Security Restrooms 4,949 11,200 Airline Club 2,500 International Arrivals 21,001 31,460 Concessions 60,097 70,660 Pre-Security Circulation, Restrooms, and Seating 156,283 58,200 Bag Claim 17,745 45,710 Baggage Makeup 72,761 82,080 Airline Operations/ATO/BSO 96,591 56,720 Non Public Spaces 91,955 49,450 Terminal Functions (HVAC, MEP) 101,357 117,200

Total Area 773,850 752,960

*Existing Terminals B&C

FUNCTION

Bag Claim Space Undersized by Nearly 2/3rds Non Public Space Oversized by Nearly 2x Amount Needed

Existing & Proposed Terminal Program

SQUARE FEET

47

slide-48
SLIDE 48

Landside Program Requirements

  • Improve Terminal Roadways
  • Improve Safety and Congestion of Terminal Roadways by

Separating Curbs for Arrivals and Departures and minimizing conflicts

  • Parking Structure for 6,500 spaces (4,264 today)
  • Close-in Surface Parking for 1,940 spaces (1,722 today)

Landside Program Highlights

48

slide-49
SLIDE 49

Ground Transportation

Landside Program Highlights

49

Courtesy: KCAD

slide-50
SLIDE 50

Ground Transportation

Landside Program Highlights

50

Courtesy: KCAD

slide-51
SLIDE 51

Ground Transportation

Landside Program Highlights

51

Courtesy: KCAD

slide-52
SLIDE 52

Ground Transportation

Landside Program Highlights

52

Courtesy: KCAD

slide-53
SLIDE 53

Ground Transportation

Landside Program Highlights

53

Courtesy: KCAD

slide-54
SLIDE 54

Ground Transportation

Landside Program Highlights

54

Courtesy: KCAD

slide-55
SLIDE 55

Ground Transportation

Landside Program Highlights

55

Courtesy: KCAD

slide-56
SLIDE 56

Ground Transportation

Landside Program Highlights

56

Courtesy: KCAD

slide-57
SLIDE 57

Concessions Deliveries

Landside Program Highlights

57

Courtesy: KCAD

slide-58
SLIDE 58

New Terminal Alternatives 4Q2014 to 2Q2015

58

slide-59
SLIDE 59

Site Alternatives

59

slide-60
SLIDE 60

KCAD and the airlines reviewed options identified in earlier studies, ideas from the Mayor’s Terminal Advisory Group, and public comments; then generated numerous new terminal alternatives to optimize the configurations

New Terminal | NT Major Renovation | MR

MR | OPTION A NT | OPTION A MR | OPTION B NT | OPTION B

Overview of Terminal Planning Process

60

slide-61
SLIDE 61

Planning Team focused on Existing Terminal Area

  • Terminal A Site
  • Terminal A & B Site
  • Terminal B & C Site
  • Terminal C & D Site

Site Alternatives

61

slide-62
SLIDE 62

Concept Development

Preliminary Concepts New Terminal Site A

62

slide-63
SLIDE 63

Concept Development

Preliminary Concepts New Terminal Site A and B

63

slide-64
SLIDE 64

Concept Development

Preliminary Concepts New Terminal Site B and C Site C and D

64

slide-65
SLIDE 65

New Terminal The First Cut

65

slide-66
SLIDE 66
  • High level evaluation by KCAD/Airlines
  • Roadway Access
  • Parking
  • Terminal Access
  • Terminal/Concourse Configuration
  • Airside Access & Aircraft Parking
  • Reduced 22 alternatives to 9 alternatives, which were

adjusted to conform with program requirements

New Terminal – First Cut

66

slide-67
SLIDE 67

Concept Analysis – NT 1

67

slide-68
SLIDE 68

Concept Analysis – NT 1

68

slide-69
SLIDE 69

Concept Analysis – NT 2

69

slide-70
SLIDE 70

Concept Analysis – NT 2

70

slide-71
SLIDE 71

Concept Analysis – NT 3

71

slide-72
SLIDE 72

Concept Analysis – NT 3

72

slide-73
SLIDE 73

Concept Analysis – NT 4

73

slide-74
SLIDE 74

Concept Analysis – NT 4

74

slide-75
SLIDE 75

Concept Analysis – NT 5

75

slide-76
SLIDE 76

Concept Analysis – NT 5

76

slide-77
SLIDE 77

Concept Analysis – NT 6

77

slide-78
SLIDE 78

Concept Analysis – NT 7

78

slide-79
SLIDE 79

Concept Analysis – NT 8

79

slide-80
SLIDE 80

Concept Analysis – NT 9

80

slide-81
SLIDE 81

Concept Analysis – NT 9

81

slide-82
SLIDE 82

New Terminal The Finalists

82

slide-83
SLIDE 83

Proposed NT-A Conceptual Site Plan

83

New Terminal | “NT A”

  • Builds a new

centralized terminal at the Terminal A site

  • Provides separate

arrivals and departures roadways and curbs

  • Builds a new central

parking garage

  • Reuses B garage

LEGEND New Terminal Garage

slide-84
SLIDE 84

Proposed NT-B Conceptual Site Plan

84

New Terminal | “NT B”

  • Builds a new

centralized terminal at the Terminal A site

  • Provides separate

arrivals and departures curbs

  • Builds a new central

parking garage

  • Reuses B garage

LEGEND New Terminal Garage

slide-85
SLIDE 85

New Terminal Evaluation Process

85

slide-86
SLIDE 86
  • Passenger Convenience
  • Safety & Security
  • Sustainability – Environmental
  • Landside Functionality
  • Terminal Functionality
  • Baggage Handling Systems
  • Airside Functionality
  • Future Expansion
  • Construction Logistics & Phasing
  • Program Costs

Evaluation Criteria – Major Categories

86

slide-87
SLIDE 87

Evaluation Matrices

87

slide-88
SLIDE 88

Evaluation Matrices

88

slide-89
SLIDE 89

Evaluation Matrices Evaluation Matrices

89

slide-90
SLIDE 90

Cost Estimate at I nitial Reductions

(2Q2015)

90

slide-91
SLIDE 91

Summary & Next Steps

91

slide-92
SLIDE 92
  • Airlines actively engaged with the City to evaluate both Major

Renovations and New Terminal alternatives through a formal and objective process over the last 2 years

  • The New Terminal alternatives are able to meet the future

needs of the Kansas City community related to Customer convenience, future growth opportunity, and serve as a gateway to the region

  • From an Airline perspective, New Terminal alternatives

achieve objectives related to Customer convenience,

  • perational efficiency, future flexibility, constructability,

completion schedule, and financial affordability

  • The Major Renovation alternatives do not achieve the agreed

upon program objectives

Summary

92

slide-93
SLIDE 93
  • Airlines are prepared to make a significant investment in

the future of Kansas City and its airport terminal facilities

  • The goal is to establish an affordable Terminal

Modernization Program that meets the future needs of the Kansas City community, achieving customer convenience and operational efficiency objectives

  • The Program will be financially backed by the Airlines

serving Kansas City and not City tax revenues

  • A joint recommendation regarding a future Terminal

Modernization Program as outlined in Exhibit K is anticipated in April 2016

Next Steps

93

slide-94
SLIDE 94

Questions & Discussion

94
