Citizens’ Transportation Advisory Committee

December 15, 2010

PROJECT NEEDS & BENEFITS

• Provide direct connection from Port to

Interstate Highways from I‐395 via Watson Island

• Maintain Port as County’s second‐leading

Economic Generator

• Relieve congestion from Downtown Streets
• Keep Port Competitive

PROJECT PARTNERS

90% Equity Partner 10% Equity Partner Contractor VMS Operator Public Sponsors Federal Support

PUBLIC‐PRIVATE PARTNERSHIP‐ P3

• Design‐Build‐Finance‐Operate‐Maintain

Concession Agreement

• 35‐year contract between FDOT & MAT

Concessionaire

• Design and Construction period is 55 months
• Operation and Maintenance period is the

remaining 30+ years

Contract Overview

PUBLIC PRIVATE PARTNERSHIP – P3

• Upon Tunnel opening, FDOT begins making

availability payments adjusted yearly for inflation

• Maximum Availability Payment $32.5M/yr
• Payment is subject to reduction if Tunnel not
• perational during required hours
• Contract includes ‘Handback’ requirements to ensure

Tunnel is returned to FDOT in first‐class condition

Payments during O&M

FUNDING THE POMT

• FDOT contributing $457.5M
• Miami‐Dade County contribution $357.5M
• City of Miami contribution $50M
• R/W donations (County & City) $50M
• FDOT funding Tunnel Operations & Maintenance from

statewide maintenance funds (about $200 million over 30 years)

PUBLIC PRIVATE PARTNERSHIP – P3

Project Funding

SCOPE OF WORK

Shifting of EB MacArthur Cswy MacArthur Cswy Bridge Widening Twin tunnels under Government Cut Modification of Dodge Island Roadway System

PROJECT STATUS:

Watson Island

• Construction of New Parrot Jungle

Trail is 95% Complete

• EB MacArthur Causeway has been

shifted south to new alignment

• Site Installation Permits for

Support Operations under Bridge:

• Water Treatment Plant
• Concrete and Grout Batch Plant
• Cooling and Power Systems
• Mechanic Shop
• Barge to Receive Spoils

PROJECT STATUS:

MacArthur Causeway & Bridge

• Widening of MacArthur Bridge for Tunnel Traffic
• Widening of the Median for Launching Pit – Tunnel

Starting Point

• Tunnel Support Operations located below Bridge

PROJECT STATUS:

Dodge Island

• 60% Roadway Design Plans are

under review process

• Exploratory Geotechnical Borings

performed and analyzed

• Sub‐sea Ground Investigation

performed in Channel

• Construction began early in

December 2010

• Ongoing Stakeholder Meetings

with Cruise, Cargo & Port Reps

TUNNEL BORING MACHINE

• Tunnel Boring Machine

(TBM) is currently being designed and fabricated in Germany.

• 43’ diameter & +600 ft.

long train

• Expected Arrival is

scheduled for May 2011

• EB Bore to begin

September 2011

• Completion of WB

Bore Spring 2013

TUNNEL VERTICAL ALIGNMENT & SECTION

• Tunnels are 3900 ft. long
• +40 ft. under the Bottom
• f Channel
• 5% Grade
• Precast Lining Segments

fabricated Off‐Site

CONSTRUCTION SCHEDULE

*THESE DATES ARE SUBJECT TO CHANGE BASED ON THE CONSTRUCTION SCHEDULE

May 24, 2010 – Construction began on Watson Island December 2010 – Construction begins on Dodge Island Spring 2011 – Arrival of TBM in Miami Fall 2011 – Beginning of eastbound tunnel boring Spring 2012 – Completion of eastbound tunnel Spring 2013 – Completion of westbound tunnel Spring 2014 – Completion of Dodge Island roadway improvements May 15, 2014 – Grand opening of the Port of Miami Tunnel

MAINTENANCE OF TRAFFIC (MOT)

• Weekly MOT releases
• Full‐time Communications Manager
• Full‐time Traffic Manager
• Full‐time Health & Safety Manager
• Emergency Response vehicles
• Live Cameras (Sunguide.org)

TUNNEL RENDERING

QUESTIONS?

Visit www.portofmiamitunnel.com
